ROOMS TO GO HNCL 3778E-SF User manual

1
Manufactured for Rooms To Go
HNCL
3778E-SF SOFA SKU#14137815,14137827
3778E-LS LOVESEAT SKU#14237817,14237829
3778E-CH CHAIR SKU#14337819,14337821
3778E-OT OTTOMAN SKU#14437811,14437823
A
B
C
4
1
1
SOFA
SOFA LOVESEAT
CHAIR OTTOMAN
TOOLS REQUIRED:NO NEED
Item
QTY
Description
NO
Central
Support Leg
Wood Leg
Sofa Assembly
A
Legs are located inside of the zip porket
LIST OF PARTS

2
LOVESEAT
CHAIR
NO Item QTY
A
B
TOOLS REQUIRED:NO NEED
1
4
LOVESEAT
NO
Description
Item QTY
A
B
TOOLS REQUIRED:NO NEED
1
4
NO Item QTY
A
B
TOOLS REQUIRED:NO NEED
1
4
Wood Leg
Wood Leg
Loveseat
Assembly
Description
Wood Leg
Chair
Assembly
Ottoman
Assembly
Description
A
Legs are located inside of the zip porket
Legs are located inside of the zip porket
Legs are located inside of the zip porket
LIST OF PARTS

3
ASSEMBLY INSTRUCTION
3778E-LS LOVESEAT SKU#14237817,14237829
p
l
3778E-SF SOFA SKU#14137815,14137827
Turn the sofa on its back and place on a soft surface to prevent scratching the leather.Take off the legs B,C
from the zip pocket at the bottom of sofa.
Align wood leg
B bolt to the pre-drilled hole at the corner and turn the leg clockwise until it is tightened.
Intall 4 legs in same way.
Align support leg C bolt to the pre-drilled holes at the central of the bottom and turn leg clockwise until itis
tightened.
Assembly of the sofa is now complete.
C
Turn the loveseat on its back and place on a soft surface to prevent scratching the leather.Take off the legs
B from the zip pocket at the bottom of loveseat
Align wood leg B bolt to the pre-drilled hole at the corner and turn the leg clockwise until it is tightened.
Intall 4 legs in same way.
Assembly of the loveseat is now complete.

4
4
3778E-CH CHAIR SKU#14337819,14337821
3778E-OT OTTOMAN SKU#14437811,14437823
ASSEMBLY INSTRUCTION
Turn the chair on its back and place on a soft surface to prevent scratching the leather.Take off the legs
B
from the zip pocket at the bottom of chair.
Align wood leg B bolt to the pre-drilled hole at the corner and turn the leg clockwise until it is tightened.
Intall 4 legs in same way.
Assembly of the chair is now complete.
Turn the ottoman on its side and place on a soft surface to prevent scratching the leather.Take off the legs
B from the zip pocket at the bottom of ottoman.
Align wood leg B bolt to the pre-drilled hole at the corner and turn the leg clockwise until it is tightened.
Intall 4 legs in same way.
Assembly of the sofa is now complete.
