  9. ROOMS TO GO HMIS B9500-01 QN HDBD User manual

ROOMS TO GO HMIS B9500-01 QN HDBD User manual

MADE IN VIETNAM 1 OF 2
Assembly Instructions
***Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two
people are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly.
Parts List
Headboard 1Pc
Code
1
21Pc
Hardware List
Step Code
4
Footboard
Allen Key - 4mm 1Pc
Left Headboard Leg
51Set
A
Rails
64Pcs
Slats
74Pcs
Support Legs
1Pc
3Right Headboard Leg
1-2-3-4
1Pc
1
8
Stretcher Rail 1Pc
3
4
2
HMIS B9500-01 QN HDBD SKU # 32395039
HMIS B9500-02 QN FTBD SKU # 32795037
HMIS B9500-03/06 QNKG RAILS
SKU # 32995031
A
1Pc
STEP 2
STEP 1
A
STEP 3
A
3
1
1
2
This product is manufactured by HMIS
for
NOTE: The Headboard and Footboard bolts are already pre-installed.
STEP 1 : Assembly Stretcher rail (4) with HB legs using allen key (A).
Do not tighten all bolts until HB is fully assembly.
STEP 2 : Assembly the left legs(2) with the left HB(1) using allen key
(A). Do not tighten all bolts until HB is fully assembly.
STEP 3 : Assembly the right legs(3) with the right HB(1) using allen
key (A).
Do not tighten all bolts until HB is fully assembly.
Hardware Pack Location(S):
HMIS B9500-01&03/06 QN HDBD & QNKG RAILS
SKU # 32395039
/
32995031
6 B Screw - #8x32mm 8Pcs
4
TOOLS REQUIRED (NOT PROVIDED)
Phillips screwdriver
Description Sketch
MADE IN VIETNAM 2 OF 2
***Caution: Please read all instructions carefully before starting the assembly process. These parts are cumbersome and heavy. Therefore, two people
are recommended in order to prevent personal injury and ensure the parts are not damaged during the assembly.
STEP 4
STEP 5
STEP 6
A
6
7
5
6
1
5
5
8
3
2
4
Assembly Instructions
HMIS B9500-01 QN HDBD SKU # 32395039
HMIS B9500-02 QN FTBD SKU # 32795037
HMIS B9500-03/06 QNKG RAILS
SKU # 32995031
This product is manufactured by HMIS
for
STEP 4: Assemble the side rails to the HB(1) and FB(8) using allen key (A) .
STEP 5: Assemble the support leg(7) to slats(6).
STEP 6: Assemble the slats (6) to the side rail (5).
Adjustable Leveler
44
4
B

This manual suits for next models

5
