MODEL NO. 134 HYDRAULIC PRESS
OPERATION, PARTS & MAINTENANCE MANUAL
Model: Purchased From:
Serial #: Date Received:

FOREWORD
This manual has been prepared for the owner and operators of Roper Whitney No. 134 Hydraulic Press.
Its purpose, aside from operations instructions, is to promote safety through the use of accepted operat-
ing procedures. Read all instructions thoroughly before operating the press.
Also contained in this manual is the parts list for your press. It is recommended that only Roper Whitney
or factory authorized parts be used as replacements.
Roper Whitney 2833 Huffman Blvd. Rockford, IL 61103
815-962-3011 / Fax [phone]
www.roperwhitney.com
- 2 -
Warranty Statement:
3 YEAR LIMITED WARRANTY
Roper Whitney (“Manufacturer”) warrants, commencing with the date of shipment to first end-user
(“Customer”) and for a period of thirty-six (36) months thereafter, all machinery and parts manufactured
by Manufacturer to be free of defects in workmanship and material. This warranty remains in force for
the above time period only if all of Manufacturer’s operational procedures are followed and
recommended maintenance is performed. If, within such warranty period, any machinery or parts
manufactured by Manufacturer shall be proved to Manufacturer’s satisfaction to be defective, such
machinery or parts shall be repaired or replaced, at Manufacturer’s option. All warranty claims are made
F.O.B Manufacturer’s plant, providing such machinery or parts are returned freight prepaid to
Manufacturer’s plant or designated service center for Manufacturer’s inspection. All failed parts or
components must be returned to Manufacturer prepaid for inspection before credit will be issued for new
parts or components. Manufacturer’s obligation hereunder shall be confined to such repair or replacement
and does not include any charges, direct or indirect, for removing or replacing defective machinery or
parts. No warranty shall apply to machinery, or parts or accessories, which have been furnished, repaired,
or altered by others so as, in Manufacturer’s judgment, to affect the same adversely or which shall have
been subject to negligence, accident or improper care, installation, maintenance, storage, or other than
normal use or service, during or after shipment. No warranty shall apply to the cost of repairs made or
attempted outside of Manufacturer’s plant or designated service center without Manufacturer’s
authorization. No warranty shall apply with respect to machinery or part not manufactured by
Manufacturer, including but not limited to motors, accessories, electrical and hydraulic components, if such
machinery or part is subject to warranty by the manufacturer of such machinery or part. No warranty
claims by Customer will be honored with respect to any machinery or part from which the name and date
plate has been removed or is otherwise no longer located or exhibited on such machinery or part. THE
FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY AND IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. MANUFACTURER SHALL NOT BE SUBJECT TO
ANY OTHER OBLIGATIONS OR LIABILITIES WHATSOEVER WITH RESPECT TO MACHINERY, PARTS,
ACCESSORIES, OR SERVICES MANUFACTURED OR FURNISHED BY IT OR ANY UNDERTAKINGS, ACTS,
OR OMISSIONS RELATING THERETO. UNDER NO CIRCUMSTANCES SHALL MANUFACTURER BE
LIABLE FOR ANY CONSEQUENTIAL OR OTHER DAMAGES, EXPENSES, LOSSES, OR DELAYS HOW SO
EVER CAUSED.
THERE ARE NO WARRANTIES THAT EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF.
Note: Consumable tooling is not covered under the 3 year manufacturer’s warranty.
RETURN OF THE PRODUCT REGISTRATION CARD FURNISHED WITH THE PRODUCT IS NECESSARY TO OBTAIN
WARRANTY COVERAGE THEREON. CARD MUST BE FULLY COMPLETED, SIGNED BY THE PURCHASER, AND IF
APPLICABLE, SIGNED BY THE DISTRIBUTOR. RETURN REGISTRATION CARD TO:

SAFETY LABELS
Do not operate the hydraulic press without the proper safety labels in place. If your machine is
missing the following labels please contact Roper Whitney Co. or your authorized Roper Whitney
distributor to order.
- 3 -
(This label is located on the footswitch)

SAFETY INSTRUCTIONS
CAUTION:
Before operating the 134 Hydraulic Press, read and understand this operator’s manual. Become famil-
iar with the controls of the machine.
FOR MAXIMUM SAFETY:
* Always wear eye protection when operating this machine.
* Install and use all necessary point-of-operation guards.
* Maintain adequate ground at all times. A ground indicator has been provided.
* Keep the machine and the area around the machine free of clutter.
* Always double check punch to die alignment to prevent tool breakage and possible injury.
* Be sure to punch within the eight ton capacity of this press. Type and thickness of material vs. final hole
size will determine the tonnage.
* Do not nibble. Always punch a full hole.
* Use only punches and dies designed for this tool. They are marked either W or R-W.
* Keep all tooling sharp.
SPECIFICATIONS
Characteristic IN. MM
Throat height at ram 10 254.0
Throat depth 24 609.6
Length of stroke 1 25.4
Ram adjustment 3/4 19.05
Bed plate holes (C to C) 6 3/4 171.45
Dia. of punch shank hole in ram 1 25.4
Depth of punch shank hole in ram 1 1/4 31.75
Slug clearance 3 x 5 76.2 x 127.0
DIMENSIONS
Reference IN. MM.
A 44 1117.6
B 51 1295.4
C 24 609.6
D 6 152.4
E 4 101.6
F 18 457.2
- 4 -

PANEL CONTROLS:
ON/OFF ----- These two buttons, located on the main control panel on the right side of the machine, turn the
hydraulic power unit on and off.
JOG/RUN --- This switch selects either of two running modes. The RUN position is for automatic, single
stroke operation. In this position, the foot switch must be released to repeat the cycle. The JOG
position permits the operator to inch the ram down for alignment and center spotting. In the JOG
position, the ram will continue downward until the foot switch is released. At the bottom-of-
stroke of the machine (set at the factory), the ram automatically returns to the top-of-stroke
position.
JOG UP ----- This button, located on the right side of the machine in the top shroud, will raise the ram from any
intermediate position. The ram will continue to rise until the button is released or the machine
reaches its absolute top-of-stroke position. The JOG UP button overrides both the JOG/RUN
switch and the adjustable top-of-stroke mechanism.
PUNCH TO DIE ALIGNMENT:
Select the desired punch and die. Insert die into die adaptor (if needed) and tighten screw. Place die
adaptor (or die) in die shoe and tighten square head set screw. Leave die shoe bolts loose. Insert punch
into punch holder and tighten set screw (it may be necessary to move the die shoe for adequate
clearance). Set the selector switch on the main control panel to JOG, turn the machine on, and inch the
punch toward the die. Adjust the loose die shoe so the punch can enter without striking the die. There
should be equal clearance around the punch for proper punching action. If the ram reaches the bottom-
of-stroke position before the punch can enter the die, remove wear plates from the top of the ram lever
and replace them below. This will lower the ram so the punch can enter the die. When the punch and die
are properly aligned, tighten the die shoe bolts. Recheck alignment after tightening. Adjust wearplates
so at the bottom-of-stroke the punch enters the die between 1/16 and 1/32 of an inch.
TOP-OF-STROKE ADJUSTMENT:
After punch to die alignment is verified, the ram top-of-stroke position must be set. The stroke of the 134
press is infinitely variable between zero and one inch. To set desired stroke length, lower the punch
(using the JOG setting) to the desired top-of-stroke height. Loosen the two knurled nuts of the trip
mechanism on top of the ram. Run the upper nut up the threaded spindle until it contacts the limit switch
roller. Continue to run the nut up until a distinct click is heard. Turn the nut another quarter turn in the
same direction and lock it in place by turning the lower knurled nut against it. The ram will continue to
stop at this position until the knurled nuts are moved or the wear plates are adjusted.
The ram can be run up to the full one inch stroke position by pressing the JOG UP button. This will
facilitate tool change and part removal. To return to limited stroke operation, depress the foot switch until
the punch enters the die. On returning, the ram will once again stop at the preset height.
- 5 -

134 HYDRAULIC PRESS
PARTS IDENTIFICATION CHART
MECHANICAL - HYDRAULIC - ELECTRICAL
- 6 -
*See page 10 for item 42,
Power Unit component
identification

134 HYDRAULIC PRESS
POWER UNIT COMPONENTS IDENTIFICATION
ITEM #42
See pg 10, for item 42,
power unit component
identification
REAR VIEW
FRONT VIEW
42C, 42D
42K, 42N
42M
42I
42G
42Q
42P
42H
42A, 42F
42O
42B
42J
42L
42E
- 7 -

CUSTOMER CONNECTIONS:
Manifold Ports P, A & B - #4 SAE
SETTINGS:
Pump Flow - 2.85 GPM
Relief Valve - 1500 PSI
See pg 10 for item 42, power unit component identification
134 HYDRAULIC PRESS
HYDRAULIC DIAGRAM
ITEM #42
- 8 -

134 HYDRAULIC PRESS
PARTS IDENTIFICATION LIST
MECHANICAL - HYDRAULIC - ELECTRICAL
ITEM PART NO. PART NAME QTY.
1 731140279 Frame 1
2 731200254 Cylinder Bracket 1
3 731240255 Cylinder Link 1
4 730560055 Connect. Link Nut 4
5 731240070 Connect. Link 2
6 731160075 Connect. Link Stud 2
7 678033119 Washer, Die Shoe Sup. 2
8 731320145 Die Shoe Support 1
9 731030146 Ram Lever 1
11 600164304 Retaining Ring 2
12 600164307 Retaining Ring 2
13 731160143 Ram Lever Pin 1
14 731160144 Conn. Link Stud 1
15 731220257 Frame Cover 1
16 731440269 Top Shroud 1
17 731440259 Front Shroud 1
18 731440258 Side Shroud 2
19 600000167 Snap Bushing 3
20 731060266 Stand 1
23 Enclosure w/Panel
660193223 (208 Volts) 1
660193222 (230 Volts) 1
660193224 (460 Volts) 1
24 660082016 Stop Push Button (Red) 1
25 660082015 Start Push Button (Green) 1
26 660082017 Selector Switch 1
27 660082023 Ground Indicator 1
28 660021210 Magnetic Starter 1
30 Transformer
660132411 (208 Volts) 1
660132412 (230 & 460 Volts) 1
31 660051720 Fuse (F-1) 1
32 660051722 Fuse Block 1
33 660142502 Relay CR-1, CR-2 1 ea.
34 660142503 Relay CR-3 2
35 660000005 Terminal Block 18
36 660092104 Footswitch 1
37 660152613 Limit Switch 2
38 660152614 Operating Lever w/Roller 2
39 660082028 “Jog Up” Button 1
40 731060270 Switch Mtg. Plate 1
- 9 -

134 HYDRAULIC PRESS
PARTS IDENTIFICATION LIST
MECHANICAL - HYDRAULIC - ELECTRICAL
ITEM PART NO. PART NAME QTY.
41* Hydraulic Oil - Mobil DTE 25 or Compatible Hyd Fluid 5 gal.
42 669092558 Power Unit, 2 H.P. 1
42A 669133107 Reservoir 1
42B 669082399 Electric Motor 1
42C 669021280 Pump/Motor Adapter 1
42D 691386630 Pump/Motor Coupling 1
42E 669082400 Pump 1
42F 669031637 Suction Screen 1
42G 669051917 Custom Manifold 1
42H 669102730 Gauge 1
42I 669123008 Relief Valve 1
42J 669123009 PO Check Valve 1
42K 669123007 Directional Valve 1
42L 669123010 Check Valve 1
42M 669031635 Filter Element 1
42N 611012064 Mounting Bolts 10-24 x 2” SHC 4
42O 669031638 Filler/Breather 1
42P 669102726 Sight/Temp Gauge 1
42Q 669000070 Door Assembly 1
54 669011001 Cylinder 1
55 Fittings:
669021119 Cyl. End-Straight Fitting 1
669021120 45 degree Fitting 1
669021136 Power Unit End-90 degree Fitting 1
56 601012173 Screw, HHC 3/8-16 x 3/4 4
57 679033105 Washer, Lock 3/8 Split Ring 4
58 601012273 Screw, HHC 1/2-13 x 1 1/4 4
59 643023007 Nut, Full Hex 1/2-13 4
60 679033107 Washer, Lock 1/2 Split Ring 4
61 601012374 Screw, HHC 5/8-11 x 2 3/4 2
62 600174431 Screw, Self Tapping Type F Panhead #10-32 x 3/8 34
63 683033102 Washer, Lock #10 Shakeproof External 7
64 610012062 Screw, RHM #10-32 x 1 3/4 4
65 679033102 Washer, Lock #10 Split Ring 1
66 645023002 Nut, Full Hex #10-32 1
67 600194617 King Pin Bushing 2
68 633002966 Spacer 3
*Not Shown
- 10 -

NO. 134 HYDRAULIC PRESS
PARTS IDENTIFICATION CHART
- 11 -

134 HYDRAULIC PRESS
PARTS IDENTIFICATION LIST
RAM - GAGES - ACCESSORIES
ITEM PART NO. PART NAME QTY.
1 600356318 Knurled Nut 2
2 731030267 Threaded Rod 1
3 731180268 Rod Brace 1
5 731610133 Ram 1
6 431600019 Punch Retainer 1
7 731650275 Punch Retainer Screw 2
8 Wear Plate:
731060074 1/6 1
731060081 3/32 2
731060073 1/8 2
731060151 1/4 1
9 731060072 Cover Plate 1
10 611012090 Cover Plate Screw 2
10A 678033103 Flat Washer 2
11 600043266 Taper Pin 4
12 731400085 Gib 2
13 731720086 Gib Shim 4
14 731030108 Depth Gage Bar 1
15 731420078 Depth Gage 1
16 731730080 Side Gage 1
17 731420079 Gage Arm 1
18 774010096 F-8 Punch Holder 1
19 774010091 #20 Die Adaptor 1
20 774010097 F-28 Punch Holder 1
21 774010092 #40 Die Adaptor 1
22 Die Shoe:
139404030 2 3/4 1
139415050 3 3/4 Optional
139426060 4 3/4 Optional
23 678033119 Die Shoe Washer 4
24 731130155 Die Shoe Block Optional
25 731570156 #10 Die Shoe Optional
26 139541010 #10 Die Shoe Complete Optional
27 731570157 #20 Die Shoe Optional
28 139552020 #20 Die Shoe Complete Optional
29 731030265 Stripper Arm 2
- 12 -

134 HYDRAULIC PRESS
PARTS IDENTIFICATION LIST
RAM - GAGES - ACCESSORIES
ITEM PART NO. PART NAME QTY.
30 Stripper Plate:
332200500 A-7 (1/2”) 1
332201000 B-7 (1”) Optional
332202000 C-7 (2”) Optional
332203000 D-7 (3”) Optional
332204000 E-7 (4”) Optional
31 731090260 Worktable 1
32 774420101 Gage 3
33 731200124 Bracket 2
34 731520261 Insert 1
35 233940002 Complete Worktable 1
36 649023003 Nut, Hex Jam 1/4-20 1
37 633012131 Screw, SHS 5/16-18 x 3/4 2
38 643023004 Nut, Full Hex 5/16-18 2
39 611012181 Screw, SHC 3/8-16 x 1 3/4 6
40 633012172 Screw, SHS 3/8-16 x 5/8 3
41 641012088 Screw, Thumb 1/4-20 x 5/8 1
42 678033105 Washer, Flat 3/8 6
43 601012173 Screw, HHC 3/8-16 x 3/4 6
44 621012125 Screw, SS 5/16-18 x 5/16 1
45 621012124 Screw, SS 5/16-18 x 1/4 1
46 601012377 Screw, HHC 5/8-11 x 3 1/2 2
47 678033108 Washer, Flat 1/2 2
48 Die Shoe Set Screw:
Die Shoe Screw
633012181 F-2 3/4 3/8-16 x 1 3/4 Sq. Hd. 1
633012177 F-3 3/4 3/8-16 x 1 1/4 Sq. Hd. 1
633012173 F-4 3/4 3/8-16 x 3/4 Sq. Hd. 1
49 643023009 Nut, Full Hex 5/8-11 2
50 621012083 Screw, SS 1/4-20 x 5/16 1
51 621012082 Screw, SS 1/4-20 x 1/4 1
52 611012179 Screw, SHC 3/8-16 x 1 1/2 2
53 601012281 Screw, HHC 1/2-13 x 2 1/2 2
54 601012131 Screw, HHC 5/16-18 x 3/4 2
55 678033104 Washer, Flat 5/16 6
56 649023004 Nut, Hex Jam 5/16-18 4
57 605012131 Screw, FHM 5/16-18 4
58 615012049 Screw, SHB #10-24 x 3/8 3
59 611012084 Screw, 1/4-20 x 3/8 SHC 3
60 678033103 Washer, Flat 1/4 3
- 13 -

TYPE O ROUND PUNCHES AND DIES
Standard Sizes
Fractional,
Drill or Decimal Punch Part Die Part Set Part Dealer
Millimeter Equiv. Number Number Number Code
1/16 .063 300270063 310210063 200270063 T-7
5/64 .078 300270078 310210078 200270078 T-7
3/32-42 DS .094 300270094 310210094 200270094 T-7
40 DS-2.5MM .098 300270098 310210098 200270098 T-7
7/64 .109 300270109 310210109 200270109 T-7
1/8 .125 300270125 310210125 200270125 T-7
30 DS .129 300170129 310210129 200270129 T-7
29 DS .136 300270136 310210136 200270136 T-7
9/64-28 DS .141 300270141 310210141 200270141 T-7
5/32 .156 300270156 310210156 200270156 T-7
11/64 .172 300270172 310210172 200270172 T-7
3/16 .188 300270188 310210188 200270188 T-7
10 DS .194 300270194 310210194 200270194 T-7
13/64 .203 300270203 310210203 200270203 T-7
7/32 .219 300270219 310210219 200270219 T-7
15/64-A DS .234 300270234 310210234 200270234 T-7
1/4-E DS .250 300270250 310210250 200270250 T-7
17/64-H DS .266 300270266 310210266 200270266 T-7
9/32-K DS .281 300270281 310210281 200270281 T-7
19/64 .297 300270297 310210297 200270297 T-7
5/16 .313 300270313 310210313 200270313 T-7
21/64 .328 300270328 310210328 200270328 T-7
11/32 .344 300270344 310210344 200270344 T-7
23/64 .359 300270359 310210359 200270359 T-7
3/8 .375 300270375 310210375 200270375 T-7
25/64 .391 300270391 310210391 200270391 T-7
13/32 .406 300270406 310210406 200270406 T-7
27/64 .422 300270422 310210422 200270422 T-7
7/16 .438 300270438 310210438 200270438 T-7
29/64-11.5MM .453 300270453 310210453 200270453 T-7
15/32 .469 300270469 310210469 200270469 T-7
31/64 .484 300270484 310210484 200270484 T-7
1/2 .500 300270500 310210500 200270500 T-7
33/64 .516 300280516 310210516 200280516 T-7
17/32-13.5MM .531 300280531 310210531 200280531 T-7
LARGE PRESS TOOLING
Punches and Dies for 127, 129, 130, 150, 230, 231 and 331.
& 134 Power Presses
Kick & Lever Presses No. 15, 811, 118, 218, 32, 34, 29, 58, 68
AVAILABLE TOOLING
- 14 -

TYPE O ROUND PUNCHES AND DIES
Standard Sizes
Fractional,
Drill or Decimal Punch Part Die Part Set Part Dealer
Millimeter Equiv. Number Number Number Code
35/64 .547 300280547 310210547 200280547 T-7
9/16 .563 300280563 310210563 200280563 T-7
37/64 .578 300280578 310210578 200280578 T-7
19/32 .594 300280594 310210594 200280594 T-7
39/64 .609 300280609 310210609 200280609 T-7
5/8 .625 300280625 310210625 200280625 T-7
41/64 .641 300280641 310210641 200280641 T-7
21/32 .656 300280656 310210656 200280656 T-7
43/64 .672 300280672 310210672 200280672 T-7
11/16 .688 300200688 310210688 200280688 T-7
45/64 .703 300280703 310210703 200280703 T-7
23/32 .719 300280719 310210719 200280719 T-7
47/64 .734 300280734 310210734 200280734 T-7
3/4 .750 300280750 310210750 200280750 T-7
49/64 .766 300280766 310210766 200280766 T-7
25/32 .781 300280781 310210781 200280781 T-7
51/64 .797 300280797 310210797 200280797 T-7
13/16 .813 300280813 310210813 200280813 T-7
53/64 .828 300280828 310410828 200280828 T-7
27/32 .844 300280844 310410844 200280844 T-7
55/64 .859 300280859 310410859 200280859 T-7
7/8 .875 300280875 310410875 200280875 T-7
57/64 .891 300280891 310410891 200280891 T-7
29/32-23MM .906 300280906 310410906 200280906 T-7
59/64 .922 300280922 310410922 200280922 T-7
15/16 .938 300280938 310410938 200280938 T-7
61/64 .953 300280953 310410953 200280953 T-7
31/32 .969 300280969 310410969 200280969 T-7
63/64-25MM .984 300280984 310410984 200280984 T-7
1-25.5MM 1.000 300281000 310411000 200281000 T-7
1-1/32 1.031 300281031 310411031 200281031 T-7
1-1/16 1.063 300281063 310411063 200281063 T-7
1-3/32 1.094 300281094 310411094 200281094 T-7
1-1/8 1.125 300281125 310411125 200281125 T-7
1-5/32 1.156 300281156 310411156 200281156 T-7
LARGE PRESS TOOLING
Punches and Dies for 127, 129, 130, 150, 230, 231 and 331.
& 134 Power Presses
Kick & Lever Presses No. 15, 811, 118, 218, 32, 34, 29, 58, 68
AVAILABLE TOOLING
- 15 -

TYPE O ROUND PUNCHES AND DIES
Standard Sizes
Fractional,
Drill or Decimal Punch Part Die Part Set Part Dealer
Millimeter Equiv. Number Number Number Code
1-3/16 1.188 300281188 310411188 200281188 T-7
1-7/32 1.219 300281219 310411219 200281219 T-7
1-1/4 1.250 300281250 310411250 200281250 T-7
1-9/32 1.281 300281281 310411281 200281281 T-7
1-5/16 1.313 300281313 310411313 200281313 T-7
1-11/32 1.344 300281344 310411344 200281344 T-7
1-3/8 1.375 300281375 310411375 200281375 T-7
1-13/32 1.406 300281406 310411406 200281406 T-7
1-7/16 1.438 300281438 310411438 200281438 T-7
1-15/32 1.469 300281469 310311469 200281469 T-7
1-1/2 1.500 300281500 310311500 200281500 T-7
1-17/32 1.531 300281531 310311531 200281531 T-7
1-9/16 1.563 300281563 310311563 200281563 T-7
1-19/32 1.594 300281594 310311594 200281594 T-7
1-5/8 1.625 300281625 310311625 200281625 T-7
1-21/32 1.656 300281656 310311656 200281656 T-7
1-11/16 1.688 300281688 310311688 200281688 T-7
1-23/32 1.719 300281719 310311719 200281719 T-7
1-3/4 1.750 300281750 310311750 200281750 T-7
1-25/32 1.781 300281781 310311781 200281781 T-7
1-13/16 1.813 300281813 310311813 200281813 T-7
1-27/32 1.844 300281844 310311844 200281844 T-7
1-7/8 1.875 300281875 310311875 200281875 T-7
1-29/32 1.906 300281906 310311906 200281906 T-7
1-15/16 1.938 300281938 310311938 200281938 T-7
1-31/32 1.969 300281969 310311969 200281969 T-7
2 2.000 300282000 310312000 200282000 T-7
2-1/16 2.063 300282063 310512063 200282063 T-7
2-1/8 2.125 300282125 310512125 200282125 T-7
2-3/16 2.188 300282188 310512188 200282188 T-7
2-1/4 2.250 300282250 310512250 200282250 T-7
2-5/16 2.313 300282313 310512313 200282313 T-7
2-3/8 2.375 300282375 310512375 200282375 T-7
2-7/16 2.438 300282438 310512438 200282438 T-7
2-1/2 2.500 300282500 310512500 200282500 T-7
LARGE PRESS TOOLING
Punches and Dies for 127, 129, 130, 150, 230, 231 and 331.
& 134 Power Presses
Kick & Lever Presses No. 15, 811, 118, 218, 32, 34, 29, 58, 68
AVAILABLE TOOLING
- 16 -

TYPE O ROUND PUNCHES AND DIES
Standard Sizes
F
ractional,
Drill or Decimal Punch Part Die Part Set Part Dealer
Millimeter Equiv. Number Number Number Code
2-9/16 2.563 300282563 310512563 200282563 T-7
2-5/8 2.625 300282625 310512625 200282625 T-7
2-11/16 2.688 300282688 310512688 200282688 T-7
2-3/4 2.750 300282750 310512750 200282750 T-7
2-13/16 2.813 300282813 310512813 200282813 T-7
2-7/8 2.875 300282875 310512875 200282875 T-7
2-15/16 2.938 300282938 310512938 200282938 T-7
3 3.000 300283000 310513000 200283000 T-7
3-1/16 3.063 300283063 310613063 200283063 T-7
3-1/8 3.125 300283125 310613125 200283125 T-7
3-3/16 3.188 300283188 310613188 200283188 T-7
3-1/4 3.250 300283250 310613250 200283250 T-7
3-5/16 3.313 300283313 310613313 200283313 T-7
3-3/8 3.375 300283375 310613375 200283375 T-7
3-7/16 3.438 300283438 310613438 200283438 T-7
3-1/2 3.500 300283500 310613500 200283500 T-7
3-9/16 3.563 300283563 310613563 200283563 T-7
3-5/8 3.625 300283625 310613625 200283625 T-7
3-11/16 3.688 300283688 310613688 200283688 T-7
3-3/4 3.750 300283750 310613750 200283750 T-7
3-13/16 3.813 300283813 310613813 200283813 T-7
3-7/8 3.875 300283875 310613875 200283875 T-7
3-15/16 3.938 300283938 310613938 200283938 T-7
4 4.000 300284000 310614000 200284000 T-7
4-1/4 4.250 300284250 310714250 200284250 T-7
4-1/2 4.500 300284500 310714500 200284500 T-7
4-3/4 4.750 300284750 310714750 200284750 T-7
Standard Clearances are .006 for sizes listed above
.
LARGE PRESS TOOLING
Punches and Dies for 127, 129, 130, 150, 230, 231 and 331.
& 134 Power Presses
Kick & Lever Presses No. 15, 811, 118, 218, 32, 34, 29, 58, 68
AVAILABLE TOOLING
For additional shapes and sizes, consult factory.
- 17 -

- 18 -
