Rosch Computer CA331-NR User manual

CA331-NR
CA331-P
System Board
User’s Manual
935-CA3311-000G
A11400934

Copyright
This publication contains information that is protected by copyright. No part of it
may be reproduced in any form or by any means or used to make any transfor-
mation/adaptation without the prior written permission from the copyright hold-
ers.
This publication is provided for informational purposes only. The manufacturer
makes no representations or warranties with respect to the contents or use
of this manual and specifically disclaims any express or implied warranties of
merchantability or fitness for any particular purpose. The user will assume the
entire risk of the use or the results of the use of this document. Further, the
manufacturer reserves the right to revise this publication and make changes to
its contents at any time, without obligation to notify any person or entity of such
revisions or changes.
© 2009. All Rights Reserved.
Trademarks
Windows®2000 and Windows®XP are registered trademarks of Microsoft Corpo-
ration. Award is a registered trademark of Award Software, Inc. Other trademarks
and registered trademarks of products appearing in this manual are the proper-
ties of their respective holders.

FCC and DOC Statement on Class B
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandthereceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhich
the receiver is connected.
• ConsultthedealeroranexperiencedradioTVtechnicianforhelp.
Notice:
1. The changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
2. Shielded interface cables must be used in order to comply with the emission
limits.

1
4
Introduction
Table of Contents
Copyright........................................................................................... 2
Trademarks........................................................................................ 2
FCC and DOC Statement on Class B.............................................. 3
About this Manual ............................................................................. 7
Warranty .......................................................................................... 7
Static Electricity Precautions ............................................................. 8
Safety Measures ................................................................................. 8
About the Package ............................................................................ 9
Before Using the System Board ........................................................ 9
Chapter 1 - Introduction ................................................................ 10
Specifications................................................................................ 10
Features ...................................................................................... 12
Chapter 2 - Hardware Installation.................................................. 15
System Board Layout .................................................................... 15
System Memory ........................................................................... 16
Installing the DIM Module ......................................................... 17
CPU ............................................................................................ 19
Installing the CPU .................................................................... 19
Installing the Fan and Heat Sink ................................................ 21
Jumper Settings............................................................................. 23
Clear CMOS Data ..................................................................... 23
PS/2 Power Select.................................................................... 24
USB Power Select..................................................................... 25
COM 2 RS232/RS485 Select ...................................................... 26
Power-on Select....................................................................... 27
Panel Power Select ................................................................... 28
Rear Panel I/O Ports..................................................................... 29
PS/2 Mouse and PS/2 Keyboard Ports......................................... 30
COM (Serial) Ports ................................................................... 31
VGA Port................................................................................. 32
DVI-I Port ............................................................................... 33
RJ45 LAN Port ......................................................................... 34
USB Ports................................................................................ 35
Audio ..................................................................................... 37
IGNORE

1
5
Introduction
I/O Connectors............................................................................ 38
CD-in Internal Audio Connector ................................................. 38
S/PDIF-out Connector............................................................... 39
LVDS LCD Panel and LCD/Inverter Power Connector..................... 40
Digital I/O Connector................................................................ 42
SATA (Serial ATA) Connectors .................................................... 43
IDE Connector ......................................................................... 44
Cooling Fan Connectors............................................................. 46
Chassis Instrusion Connector .................................................... 47
Power Connectors .................................................................... 48
Standby Power LED .................................................................. 49
Front Panel Connectors ............................................................. 50
Expansion Slots ....................................................................... 51
Battery ................................................................................... 52
Chapter 3 - BIOS Setup.................................................................. 53
Award BIOS Setup Utility.............................................................. 53
Standard CMOS Features .......................................................... 54
Advanced BIOS Features........................................................... 58
Advanced Chipset Features........................................................ 62
Integrated Peripherals .............................................................. 65
Power Management Setup ......................................................... 70
PnP/PCI Configurations ............................................................. 72
PC Health Status...................................................................... 74
Frequency/Voltage Control ........................................................ 75
Load Fail-Safe Defaults ............................................................. 76
Load Optimized Defaults ........................................................... 77
Set Supervisor Password........................................................... 78
Set User Password ................................................................... 79
Save & Exit Setup .................................................................... 80
Exit Without Saving.................................................................. 81
Updating the BIOS........................................................................ 82
Chapter 4 - Supported Software ................................................... 84
Drivers, Utilities and Software Applications.................................................84
Intel Chipset Software Installation Utility .................................... 85
Microsoft DirectX 9.0C Driver .................................................... 87
Intel Graphics Drivers............................................................... 88
Audio Drivers........................................................................... 90
LAN Drivers ............................................................................. 92
Hardware Monitor for Windows .................................................. 94
Intel Matrix Storage Manager Utility ........................................... 96
AHCI for F6 During Windows Setup Floppy Driver ........................ 98
Adobe Acrobat Reader 7.0......................................................... 99
Installation Notes .............................................................................................101
IGNORE

1
6
Introduction
Appendix A - Watchdog Sample Code ......................................... 102
Appendix B - System Error Message ............................................ 104
Appendix C - Troubleshooting...................................................... 106
IGNORE

1
7
Introduction
About this Manual
An electronic file of this manual is included in the CD. To view the user’s manual
in the CD, insert the CD into a CD-ROM drive. The autorun screen (Main Board
Utility CD) will appear. Click “User’s Manual” on the main menu.
Warranty
1. Warranty does not cover damages or failures that arised from misuse of the
product, inability to use the product, unauthorized replacement or alteration
of components and product specifications.
2. The warranty is void if the product has been subjected to physical abuse,
improper installation, modification, accidents or unauthorized repair of the
product.
3. Unless otherwise instructed in this user’s manual, the user may not, under
any circumstances, attempt to perform service, adjustments or repairs on the
product, whether in or out of warranty. It must be returned to the purchase
point, factory or authorized service agency for all such work.
4. We will not be liable for any indirect, special, incidental or consequencial
damages to the product that has been modified or altered.

1
8
Introduction
Static Electricity Precautions
It is quite easy to inadvertently damage your PC, system board, components
or devices even before installing them in your system unit. Static electrical dis-
charge can damage computer components without causing any signs of physical
damage. You must take extra care in handling them to ensure against electro-
static build-up.
1. To prevent electrostatic build-up, leave the system board in its anti-static bag
until you are ready to install it.
2. Wear an antistatic wrist strap.
3. Do all preparation work on a static-free surface.
4. Hold the device only by its edges. Be careful not to touch any of the compo-
nents, contacts or connections.
5. Avoid touching the pins or contacts on all modules and connectors. Hold
modules or connectors by their ends.
Important:
Electrostatic discharge (ESD) can damage your processor, disk drive and
other components. Perform the upgrade instruction procedures described
at an ESD workstation only. If such a station is not available, you can
provide some ESD protection by wearing an antistatic wrist strap and
attaching it to a metal part of the system chassis. If a wrist strap is
unavailable, establish and maintain contact with the system chassis
throughout any procedures requiring ESD protection.
Safety Measures
To avoid damage to the system:
• UsethecorrectACinputvoltagerange.
To reduce the risk of electric shock:
• Unplug the power cord before removing the system chassis cover for instal-
lation or servicing. After installation or servicing, cover the system chassis
before plugging the power cord.
Battery:
• Dangerofexplosionifbatteryincorrectlyreplaced.
• Replace only with the same or equivalent type recommend by the manufac-
turer.
• Disposeofusedbatteriesaccordingtolocalordinance.

1
9
Introduction
About the Package
The system board package contains the following items. If any of these items are
missing or damaged, please contact your dealer or sales representative for as-
sistance.
One system board
One IDE cable
One USB cable
Two Serial ATA data cables
Two Serial ATA power cables
One I/O shield
One user’s manual
One CD
One QR (Quick Reference)
The system board and accessories in the package may not come similar to the
information listed above. This may differ in accordance to the sales region or
models in which it was sold. For more information about the standard package in
your region, please contact your dealer or sales representative.
Before Using the System Board
Before using the system board, prepare basic system components.
If you are installing the system board in a new system, you will need at least the
following internal components.
• ACPU
• Memorymodule
• Storagedevicessuchasharddiskdrive,CD-ROM,etc.
You will also need external system peripherals you intend to use which will nor-
mally include at least a keyboard, a mouse and a video display monitor.
IGNORE

1
10
Introduction
Processor
Chipset
System Memory
Expansion Slots
Graphics
Audio
LAN
Serial ATA
Chapter 1 - Introduction
•Intel®CoreTM2 Penryn processor
•1066/800/667MHzFSB
•Intel®45nm transistor technology
•Intel®Trusted Execution Technology (Intel®TXT)
•Intel®VirtualizationTechnology(Intel®VT)DMA
•SupportsDataBusInversion(DBI)
•SupportsMessageSignaledInterrupt(MSI)
•SupportsIntel®architecture with Intel® Wide Dynamic Execution
•Processorsocket:SocketP478-pinMicroFCPGA
•Intel®chipset
- Northbridge: Intel®GM45 Express chipset
- Southbridge: Intel® ICH9M-E I/O Controller Hub (CA331-NR)
Intel®ICH9M I/O Controller Hub (CA331-P)
•Two204-pinSODIMMsockets
•Supports1066MHzDDR3SDRAM
•Maximumof8GBsystemmemory
•64-bitwideperchannel
•256Mb,512Mb,1Gband2Gbmemorytechnologies
•Supportsnon-ECCx8andx16DIMMs
•DDR3On-DieTermination(ODT)
•Supportspartialwritestomemoryusingdatamasksignals(DM)
•1PCIExpressx16slot
•1PCIExpressx4slot
•2PCIslots
•Intel®GMA4500 integrated graphics engine
- Supports 3D, 2D and video capabilities, DX10 and
OpenGL 2.1
• RealtekALC2622-channelHighDefinitionAudio
• Three stereo ADCs support 16/20-bit PCM format for mul-
tiple input streaming
• HighqualityanalogdifferentialCDinput
•16/20/24 -bit S/P DIF-OUT  and S/PDI F-IN support
44.1K/48K/96K/192kHz sample rate
• CA331-NR: Intel 82567 and Realtek RTL8111C-GR PCI Ex-
press Gigabit controllers
CA331-P: Realtek RTL8111C-GR only
• Integrated10/100/1000transceiver
• SupportsFullDuplexflowcontrol(IEEE802.3x)
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE
802.3ab
• Supportspowerdown/linkdownpowersaving
•FourSerialATAports
•Datatransferrateupto3Gb/s
• IntegratedAdvancedHostControllerInterface(AHCI)controller
• CA331-NR:supportsRAID0orRAID1(cannotcoexist)
Specifications

1
11
Introduction
IDE
AMT
(CA331-NR only)
Rear Panel I/O
Ports
I/O Connectors
BIOS
Energy Efficient
Design
Damage Free
Intelligence
Temperature
Humidity
PCB
•ITEIT8213FPCIExpresstoPATAhostcontroller
•SupportsNativeModeoperation
•SupportsPIOModes0,1,2,3,4
•SupportsMultiwordDMAModes0,1,2
•SupportsUltraDMA33/66/100/133
•SupportsATA/ATAPIcommand
•Out-of-bandsystemaccess
•Remotetroubleshootingandrecovery
•Hardware-basedagentpresencechecking
•Proactivealerting
•Remotehardwareandsoftwareassettracking
•Mini-DIN-6PS/2mouseportandPS/2keyboardport
•2DB-9serialports
•1DB-15VGAport
•1DVI-Iport(DVI-Dsignalonly)
•4USB2.0/1.1ports
•2RJ45LANports(CA331-NR);CA331-P:1LANportonly
•Mic-in,line-inandlineoutjacks
•4connectorsfor8additionalexternalUSB2.0/1.1ports
•1LCDbrightnesscontrolconnector
•1LVDSLCDpanelconnectorand1DigitalI/Oconnector
•1LCD/inverterpowerconnector
•1frontaudioconnectorforline-outandmic-injacks
•1CD-ininternalaudioconnector
•1S/PDIFconnectorand4SerialATAconnectors
•134-pinFDDconnectorand140-pinIDEconnector
•125-pinparallelconnectorand1frontpanelconnector
•124-pinATXpowerconnectorand2fanconnectors
•AMIBIOS
•32MbitSPIflashmemory(CA331-NR);CA331-P:16Mbit
•SupportsACPIspecificationandOSDirectedPowerManagement
•SupportsACPISTR(SuspendtoRAM)function
•Wake-On-Eventsinclude:
- Wake-On-PS/2 KB/Mouse and Wake-On-USB KB/Mouse
- Wake-On-LAN and Wake-On-Ring
- RTC timer to power-on the system
•Systempowermanagementsupported
•CPUstoppedclockcontrol
•Microsoft®/Intel®APM 1.2 compliant
•SoftPowersupported-ACPIv2.0specification
•ACpowerfailurerecovery
•MonitorsCPU/Systemtemperatureandoverheatalarm
•MonitorsVcore/12V/1.5V/1.05V/5V/5VSBvoltagesandfailurealarm
•MonitorsCPU/Chassisfanspeedandfailurealarm
•Readbackcapabilitythatdisplaystemperature,voltageand
fan speed
•Watchdogtimerfunction
•0oC to 60oC
•10%to90%
•6-layers,microATXformfactor
•24.4cm(9.6”)x24.4cm(9.6”)

1
12
Introduction
Features
Watchdog Timer
The Watchdog Timer function allows your application to regularly “clear” the sys-
tem at the set time interval. If the system hangs or fails to function, it will reset
at the set time interval so that your system will continue to operate.
DDR3
DDR3 delivers increased system bandwidth and improved performance. It offers
peak data transfer rate of up to 21 Gb/s bandwidth. The advantages of DDR3
are its higher bandwidth and its increase in performance at a lower power than
DDR2.
Graphics
The Intel northbridge chip comes integrated with the Intel Graphics Media Ac-
celerator 4500 delivering an excellent blend of graphics performance and features
to meet business needs. With support for Microsoft DirectX 10, Shader Model 4.0
and OpenGL* 2.0, Intel GMA 4500 delivers excellent video and 3D graphics with
outstanding graphics responsiveness. These enhancements deliver the perfor-
mance and compatibility needed for today’s and tomorrow’s business applications.
DVI
DVI (Digital Visual Interface) is a form of video interface technology made to
maximize the quality of flat panel LCD monitors and modern video graphics
cards. Data is transmitted using the TMDS (Transition Minimized Differential Sig-
naling) protocol, providing a digital signal from the PC’s graphics subsystem to
the display.
LVDS
TheIntel SCHsupportsaLow-Voltage DifferentialSignaling (LVDS) interfacethat
allows the Intel Graphics Media Adapter to communicate directly to the flat-panel
display.TheLVDSinterfacesupportspixelcolordepthsof18and24bits.
PCI Express
PCI Express is a high bandwidth I/O infrastructure that possesses the ability to
scale speeds by forming multiple lanes. The x4 PCI Express lane supports trans-
fer rate of 1 Gigabyte per second. The PCI Express architecture also provides a
high performance graphics infrastructure by enhancing the capability of a x16 PCI
Express lane to provide 4 Gigabytes per second transfer rate.

1
13
Introduction
Intel Active Management Technology (AMT)
Intel Active Management Technology (Intel®AMT) allows remote access and man-
agement of networked systems even while PCs are powered off, remotely repair
systems after OS failures and has the capability to remotely update all systems
with the latest security software.
S/PDIF
S/PDIF is a standard audio file transfer format that transfers digital audio sig-
nals to a device without having to be converted first to an analog format. This
prevents the quality of the audio signal from degrading whenever it is converted
to analog. S/PDIF is usually found on digital audio equipment such as a DAT
machine or audio processing device. The S/PDIF connector on the system board
sends surround sound and 3D audio signal outputs to amplifiers and speakers
and to digital recording devices like CD recorders.
Serial ATA
Serial ATA is a storage interface that is compliant with SATA 1.0a specification.
With speed of up to 3Gbps, it improves hard drive performance faster than the
standard parallel ATA whose data transfer rate is 100MB/s.
Gigabit LAN
The PCI Express Gigabit controllers support up to 1Gbps data transmission.
USB
The system board supports USB 2.0 and USB 1.1 ports. USB 1.1 supports 12Mb/
second bandwidth while USB 2.0 supports 480Mb/second bandwidth providing a
marked improvement in device transfer speeds between your computer and a
wide range of simultaneously accessible external Plug and Play peripherals.
Wake-On-Ring
This feature allows the system that is in the Suspend mode or Soft Power Off
mode to wake-up/power-on to respond to calls coming from an external modem
or respond to calls from a modem PCI card that uses the PCI PME (Power Man-
agement Event) signal to remotely wake up the PC.
Important:
The 5V_standby power source of your power supply must support
≥720mA.

1
14
Introduction
Wake-On-LAN
This feature allows the network to remotely wake up a Soft Power Down (Soft-
Off) PC. It is supported via the onboard LAN port or via a PCI LAN card that uses
the PCI PME (Power Management Event) signal. However, if your system is in the
Suspend mode, you can power-on the system only through an IRQ or DMA inter-
rupt.
Important:
The 5V_standby power source of your power supply must support
≥720mA.
Wake-On-PS/2
This function allows you to use the PS/2 keyboard or PS/2 mouse to power-on
the system.
Important:
The 5V_standby power source of your power supply must support
≥720mA.
Wake-On-USB
This function allows you to use a USB keyboard or USB mouse to wake up a sys-
tem from the S3 (STR - Suspend To RAM) state.
Important:
If you are using the Wake-On-USB Keyboard/Mouse function for 2 USB
ports, the 5V_standby power source of your power supply must support
≥1.5A. For 3 or more USB ports, the 5V_standby power source of your
powersupplymustsupport≥2A.
RTC Timer
The RTC installed on the system board allows your system to automatically pow-
er-on on the set date and time.

1
15
Introduction
ACPI STR
The system board is designed to meet the ACPI (Advanced Configuration and
Power Interface) specification. ACPI has energy saving features that enables PCs
to implement Power Management and Plug-and-Play with operating systems that
support OS Direct Power Management. ACPI when enabled in the Power Manage-
ment Setup will allow you to use the Suspend to RAM function.
With the Suspend to RAM function enabled, you can power-off the system at
once by pressing the power button or selecting “Standby” when you shut down
Windows®without having to go through the sometimes tiresome process of
closing files, applications and operating system. This is because the system is
capable of storing all programs and data files during the entire operating session
into RAM (Random Access Memory) when it powers-off. The operating session will
resume exactly where you left off the next time you power-on the system.
Important:
The 5V_standby power source of your power supply must support
≥720mA.
Power Failure Recovery
When power returns after an AC power failure, you may choose to either power-
on the system manually or let the system power-on automatically.

16
2Hardware Installation
System Board Layout
Chapter 2 - Hardware Installation
Front audio
1
SATA 0
USB 4-5 USB 6-7
1
S/PDIF
1
1
KB
Mouse
COM 2
COM 1
LAN 1
(Realtek)
USB 1
USB 0
Mic-in
CD-in
1
PCI 2
CPU fan
VGA
DVI -I
USB 8-9
USB 10-11
1
IDE
SATA 1
1
SATA 2
1
SATA 3
1
SPI Flash BIOS Intel
ICH9M-E
1
1
1
Clear CMOS (JP8)
33
11 1
23
LVDS LCD panel
40
39 1
2
1
Chassis
intrusion
1
1
USB 0-1 power
select (JP5)
1
System
fan
1
Power-on
select ()JP12
1
4
3
6
Panel power
select (J )P6
1
PS/2 power
select ()JP1
1
LCD brightness
(J5)
Intel
G45M
FDD
1
Parallel
1
COM 4
1
15
1
ATX
power
13
12 24
1
Front
panel
DIO
Battery
PCIE x16
PCI 1
USB 4-7 power
select (JP10)
DVI-I port
(DVI-D signal only)
DDR3_2 SODIMM
DDR3_1 SODIMM
LAN 2
(Intel)
USB 3
USB 2
Line-in
Line-out
1
34
2
DVI-D/PEG x16
select ()JP4
Chrontel
CH7318C
Realtek
RTL8111C
LCD/Inverter power
USB 2-3 power
select (JP2)
DVI-D/PEG x16
select ()JP7
Realtek
ALC262 PCIE x4
2
9
10
1
2
19 1
2
39
40
USB 8-11 power
select (JP11)
1111
Standby
LED
2
11
Intel
82567
2
3334
12
25
ITE
IT8213F
Winbond
W83627UHG
Socket P
478-pin
COM 3
26
COM3 RS232/485
select ()JP3
CA331-NR

17
2
Hardware Installation
Front audio
1
SATA 0
USB 4-5 USB 6-7
1
S/PDIF
1
1
KB
Mouse
COM 2
COM 1
LAN
USB 1
USB 0
Mic-in
CD-in
1
PCI 2
CPU fan
VGA
DVI -I
USB 8-9
USB 10-11
1
IDE
SATA 1
1
SATA 2
1
SATA 3
1
SPI Flash BIOS Intel
ICH9M
1
1
1
Clear CMOS (JP8)
33
11 1
23
LVDS LCD panel
40
39 1
2
1
Chassis
intrusion
1
1
USB 0-1 power
select (JP5)
1
System
fan
1
Power-on
select ()JP12
1
4
3
6
Panel power
select (J )P6
1
PS/2 power
select ()JP1
1
LCD brightness
(J5)
Intel
G45M
FDD
1
Parallel
1
COM 4
1
15
1
ATX
power
13
12 24
1
Front
panel
DIO
Battery
PCIE x16
PCI 1
USB 4-7 power
select (JP10)
DVI-I port
(DVI-D signal only)
DDR3_2 SODIMM
DDR3_1 SODIMM
USB 3
USB 2
Line-in
Line-out
1
34
2
DVI-D/PEG x16
select ()JP4
Chrontel
CH7318C
Realtek
RTL8111C
LCD/Inverter power
USB 2-3 power
select (JP2)
DVI-D/PEG x16
select ()JP7
Realtek
ALC262 PCIE x4
2
9
10
1
2
19 1
2
39
40
USB 8-11 power
select (JP11)
1111
Standby
LED
2
11
2
3334
12
25
ITE
IT8213F
Winbond
W83627UHG
Socket P
478-pin
COM 3
26
COM3 RS232/485
select ()JP3
CA331-P

18
2Hardware Installation
System Memory
Important:
Electrostatic discharge (ESD) can damage your system board, processor,
disk drives, add-in boards, and other components. Perform the upgrade
instruction procedures described at an ESD workstation only. If such a
station is not available, you can provide some ESD protection by wearing
an antistatic wrist strap and attaching it to a metal part of the system
chassis. If a wrist strap is unavailable, establish and maintain contact
with the system chassis throughout any procedures requiring ESD pro-
tection.
DDR3-2
DDR3-1
The system board is equipped with two 204-pin SODIMM sockets that support
DDR3 memory modules.

19
2
Hardware Installation
Installing the SODIMM
1. Make sure the PC and all other peripheral devices connected to it has been
powered down.
2. Disconnect all power cords and cables.
3. Locate the SODIMM socket on the board.
4. Note the key on the socket. The key ensures the module can be plugged into
the socket in only one way.
5. Grasping the module by its edges, align the module into the socket at an
approximately 30 degrees angle. Note that the socket and module are both
keyed, which means the module can be plugged into the socket in only one
direction.

20
2Hardware Installation
Clip
6. To seat the module into the socket, apply rm even pressure to each end
of the module until it slips down into the socket. The contact ngers on the
edge of the module will almost completely disappear inside the socket.
Note:
The board used in the following illustrations may not resemble the actual
one. These illustrations are for reference only.
7. Push the module down until the clips at each side of the socket lock into
position. You will hear a distinctive “click”, indicating the module is correctly
locked into position
Clip
