Rosch Computer i910GML-DCQIC9 User manual

i910GML-DCQIC9 /
i915GM-DCQI
Intel® 910GMLE µFC-BGA 479 (or 915GM µFC-PGA 478)
Pentium®M / Celeron®M Mini ITX Main Board
User’s Manual
Ver. 1.00

i910GML-DCQIC9/ i915GM-DCQI
2
Contents
Safety Information ..........................................................................................................4
Technical Support ............................................................................................................5
Conventions Used in This Guide....................................................................................5
Packing List.......................................................................................................................6
Revision History ...............................................................................................................7
Specifications Summary..................................................................................................8
Block Diagram (i910GML-DCQIC9).............................................................................11
Block Diagram (i915GM-DCQI) ...................................................................................12
Production Introduction ...............................................................................................14
1.1 Before you Proceed ................................................................................................14
1.2 Motherboard Overview............................................................................................15
1.2.1 Placement Direction ....................................................................................................................... 15
1.2.2 Screw Holes ................................................................................................................................... 15
1.3 Motherboard Layout ................................................................................................16
1.3.1 Layout Content List ........................................................................................................................ 17
1.4 Central Processing Unit (CPU) (for i915GM-DCQI only).........................................19
1.4.1 Installing the CPU........................................................................................................................... 20
1.4.2 Installing the CPU Heatsink and Fan .............................................................................................22
1.4.3 Uninstalling the CPU Heatsink and Fan......................................................................................... 24
1.5 System Memory ......................................................................................................25
1.5.1 DIMM Sockets Location ................................................................................................................. 25
1.5.2 Memory Configurations .................................................................................................................. 26
1.5.3 Installing a DDR2 DIMM................................................................................................................. 27
1.5.4 Removing a DDR2 DIMM............................................................................................................... 27
1.6 Expansion Slots ......................................................................................................28
1.6.1 Installing an Expansion Card ......................................................................................................... 28
1.6.2 Configuring an Expansion Card ..................................................................................................... 28
1.6.3 Standard Interrupt Assignments..................................................................................................... 29
1.6.4 PCI Slots ........................................................................................................................................ 29
1.7 Jumpers ..................................................................................................................30
1.7.1 Clear CMOS (CLRRTC1)............................................................................................................... 30
1.7.2 COM Port 1, 2 RI/+5V/+12V Selection (JCOMPWR1)................................................................... 31
1.7.3 COM Port 3, 4 RI/+5V/+12V Selection (JCOMPWR2)................................................................... 31
1.7.4 CPU VCC Voltage Select (VCCA_SEL1)....................................................................................... 32

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
3
Contents
1.8 Connectors..............................................................................................................33
1.8.1 Rear Panel Connectors.................................................................................................................. 33
1.8.2 Amplifier Connector (AMPJ1)......................................................................................................... 35
1.8.3 CPU Fan Connector (CPU_FAN1)................................................................................................. 35
1.8.4 System Fan Connector (SYS_FAN1)............................................................................................. 36
1.8.5 Serial Port Connector 3 (COM3) .................................................................................................... 36
1.8.6 Serial Port Connector 4 (COM4) .................................................................................................... 37
1.8.7 Front Headphone Connector (F_AUDIO1)..................................................................................... 37
1.8.8 System Panel Connector (F_PANEL1) .......................................................................................... 38
1.8.9 USB 2.0 Connector (FRONT_USB1, FRONT_USB2) ................................................................... 39
1.8.10 Primary IDE Connector (IDE1)................................................................................................... 40
1.8.11 ATX Power Connector (JATXPWR1) ........................................................................................ 41
1.8.12 LCD Inverter Connector (JBKLT1)............................................................................................. 42
1.8.13 LVDS Connector (JLVDS1) ....................................................................................................... 42
1.8.14 Digital I/O Connector (JDIO)...................................................................................................... 43
1.8.15 Serial ATA Connector 1 & 2 [Black] (SATA1, SATA2) .............................................................. 43

i910GML-DCQIC9/ i915GM-DCQI
4
Safety Information
Electrical safety
zTo prevent electrical shock hazard, disconnect the power cable from the electrical
outlet before relocating the system.
zWhen adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
zBefore connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
zSeek professional assistance before using an adapter or extension cord. These
devices could interrupt the grounding circuit.
zMake sure that your power supply is set to the correct voltage in your area. If you are
not sure about the voltage of the electrical outlet you are using, contact your local
power company.
zIf the power supply is broken, do not try to fix it by yourself. Contact a qualified service
technician or your retailer.
Operation safety
zBefore installing the motherboard and adding devices on it, carefully read all the
manuals that came with the package.
zBefore using the product, make sure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
zTo avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
zAvoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
zPlace the product on a stable surface.
zIf you encounter technical problems with the product, contact a qualified service
technician or your retailer.
The symbol of the crossed out wheeled bin indicates that the product
(electrical and electronic equipment) should not be placed in
municipal waste. Check local regulations for disposal of electronic
products.

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
5
Technical Support
If a problem arises with your system and no solution can be obtained from the user’s
manual, please contact your place of purchase or local distributor. Alternatively, please try
the following help resources for further guidance. Visit the Advansus website for FAQ,
technical guide, BIOS updates, driver updates, and other information:
http://www.advansus.com.tw/Support/Support.asp
Conventions Used in This Guide
To make sure that you perform certain tasks properly, take note of the following symbols
used throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when
trying to complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.

i910GML-DCQIC9/ i915GM-DCQI
6
Packing List
Before you begin installing your single board, please make sure that the following materials
have been shipped:
91 x i910GML-DCQIC9(or i915GM-DCQI) Mini ITX Main board
91 x CD-ROM contains the followings:
－User’s manual (this manual in PDF file)
－Drivers
91 x IDE HDD cable (40-pin)
92 x COM cable
92 x SATA cable (7-pin)
91 x Startup Manual
If any of the above items is damaged or missing, please contact your
retailer.

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
7
Revision History
Revision Revision History Date
V 1.0 First release for PCB 1.00 November 25, 2007

i910GML-DCQIC9/ i915GM-DCQI
8
Specifications Summary
i910GML-DCQIC9 i915GM-DCQI
1
Onboard Intel uFC-BGA 479
Celeron M 900MHz w/512K 2nd
Level Cache with 90nm process
technology
Supports Intel µFC-PGA 478 /
µFC-BGA 479 Pentium M / Celeron M
with 0.13 µ and 90nm process
technology
2 Intel 82910GMLE Express
Chipset
Intel 82915GME Express Chipset
3 Two 240-pin DIMMs up to 2 GB
DDR2 400 SDRAM
Two 240-pin DIMMs up to 2 GB
DDR2 400/533 SDRAM
4 DVI, Dual 18-bit LVDS
5 Realtek ALC655 5.1 ch. Audio (@ 5Wx2-CH Amplified)
6 Realtek RTL8110SC Gigabit LAN
7 1 PCI (supports 3 PCI Master), Type I/II CF
8 4 COM, 8 USB 2.0, 2 SATA
Features
System
CPU
Onboard Intel uFC-BGA 479 Celeron M
900MHz w/512K 2nd Level Cache
Supports Intel µFC-PGA 478 /
µFC-BGA 479 Pentium M / Celeron
M with 0.13 µ and 90nm process
technology
FSB 400MHz 400/533MHz
BIOS Award 4 Mb Flash BIOS
System Chipset Intel 82910GMLE GMCH/82801FBM
ICH6-M
Intel 82915GME GMCH/82801FBM
ICH6-M
I/O Chipset Winbond W83627EHG-A
Memory Two 240-pin DIMM socket supports up
to 2 GB DDR2 400 SDRAM
Two 240-pin DIMM socket supports
up to 2 GB DDR2 400/533 SDRAM
SSD One CompactFlash Type I/II socket
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor Monitoring CPU temperature and cooling fan status. Auto throttling control when
CPU overheats
Expansion Slots One PCI slot (PCI Rev. 2.2 compliant) supports 3 PCI master

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
9
Specifications Summary
i910GML-DCQIC9 i915GM-DCQI
System
S3 S3 Support
SmartFan Control YES
I/O
MIO 1 xEIDE (Ultra DMA 100), 2 x SATA, 4 x RS-232,1 x K/B, 1 x Mouse, (COM1~4
with Power output)
USB 8 x USB 2.0
DIO 16-bit General Purpose I/O for DI and DO
Internal I/O
2 x USB connectors support additional 4 USB ports
1 x 20-pin ATX Power connector
1 x IDE 40-pin connector for two devices
2 x COM port header
2 x SATA connectors
1 x Front panel audio connector
1 x Audio amplifier connector
1 x System panel connector
1 x LVDS connector
1 x Inverter Power connector
1 x CPU Fan connector
1xSystemFanconnector
1 x Digital IO header
Back Panel
1 x PS/2 Keyboard and 1 x PS/2 Mouse
2 x RS-232
1 x VGA port
1 x DVI port
4 x USB 2.0/1.1
1 x RJ45 Port
5.1 CH Audio I/O (3 jacks)
Display
Display Memory Intel DVMT 3.0 supports up to 128 MB video memory
Resolution 2048 x 1536 @ 32 bpp (85 Hz)
Dual Display CRT + LVDS, or CRT + DVI-D
LVDS Dual-channel 18-bit LVDS
DVI Chrontel CH7307C DVI transmitter up to 165M pixels/second

i910GML-DCQIC9/ i915GM-DCQI
10
Specifications Summary
i910GML-DCQIC9 i915GM-DCQI
Audio
Audio Codec Realtek ALC655 supports 5.1 ch. Audio
Audio Interface Mic in, Line in,Line out
Audio Amplifier TPA3005D2 Stereo 5Watt per channel
Ethernet
LAN1 Realtek RTL8110SC Gigabit LAN
Mechanical & Environmental
Power Type ATX
Operating Temperature 0 ~ 60°C (32 ~ 140°F)
Operating Humidity 0% ~ 90% relative humidity, non-condensing
Size (L x W) 6.69" x 6.69" (170 mm x 170 mm)
Weight 0.88 lbs (0.4 Kg)
* Specifications are subject to change without notice.

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
11
Block Diagram (i910GML-DCQIC9)

i910GML-DCQIC9/ i915GM-DCQI
12
Block Diagram (i915GM-DCQI)

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
13
This chapter describes the main board
features and the new technologies
it supports.
1
Product
introduction
1
Product
introduction

i910GML-DCQIC9/ i915GM-DCQI
14
Production Introduction
1.1 Before you Proceed
Take note of the following precautions before you install motherboard components or
change any motherboard settings.
zUnplug the power cord from the wall socket before touching any
component.
zUse a grounded wrist strap or touch a safely grounded object or a
metal object, such as the power supply case, before handling
components to avoid damaging them due to static electricity
zHold components by the edges to avoid touching the ICs on
them.
zWhenever you uninstall any component, place it on a grounded
antistatic pad or in the bag that came with the component.
zBefore you install or remove any component, ensure that the ATX
power supply is switched off or the power cord is detached from
the power supply. Failure to do so may cause severe damage to
the motherboard, peripherals, and/or components.

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
15
1.2 Motherboard Overview
Before you install the motherboard, study the configuration of your chassis to ensure that
the motherboard fits into it. Refer to the chassis documentation before installing the
motherboard.
Make sure to unplug the power cord before installing or removing the
motherboard. Failure to do so can cause you physical injury and
damage motherboard components.
1.2.1 Placement Direction
When installing the motherboard, make sure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
1.2.2 Screw Holes
Place four (4) screws into the holes indicated by circles to secure the motherboard to the
chassis.
Do not over tighten the screws! Doing so can damage the
motherboard.
Place this side towards the rear of the
chassis.

i910GML-DCQIC9/ i915GM-DCQI
16
1.3 Motherboard Layout

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
17
1.3.1 Layout Content List
Slots
Label Function Note Page
CF1 CompactFlash socket (Optional) N/A
DIMMA1 240-pin DDR2 DIMM slot N/A
DIMMB1 240-pin DDR2 DIMM slot N/A
PCI1 PCI slot N/A
Jumpers
Label Function Note Page
CLRRTC1 Clear CMOS 3 x 1 header, pitch 2.54mm 30
JCOMPWR1 COM port 1,2 RI/+5V/+12V
selection
5 x 2 header, pitch 2.00mm 31
JCOMPWR2 COM port 3,4 RI/+5V/+12V
selection
5 x 2 header, pitch 2.00mm 31
VCC_SEL1 CPU VCC Voltage Select 3 x 1 header, pitch 2.54mm 32
Rear Panel Connector
Label Function Note Page
J1 PS/2 keyboard and mouse 6-pin Mini-Din 33,34
DUALCOM1 Serial port connector x 2 D-sub 9-pin, male 33
VGA_DVI-D1 VGA & DIV port D-sub 15-pin, female 33,34
LAN_USB1 RJ-45 Ethernet connector x 1
USB connector x 2
33,34
USB2 USB connector x 2 34
AUDIO Line-in port, Line-out port,
Microphone port,
6-Channel Audio I/O (3 jacks) 34

i910GML-DCQIC9/ i915GM-DCQI
18
Internal Connector
Label Function Note Page
AMPJ1 Amplifier connector 4 x 1 header, pitch 2.54mm 35
CPU_FAN1 CPU fan connector 3 x 1 wafer, pitch 2.54mm 35
SYS_FAN1 System fan connector 3 x 1 wafer, pitch 2.54mm 36
COM3 Serial port connector 3 5 x 2 header, pitch 2.54mm 36
COM4 Serial port connector 4 5 x 2 header, pitch 2.54mm 37
F_AUDIO1 Front headphone connector 5 x 2 header, pitch 2.54mm 37
F_PANEL1 System panel connector 5 x 2 header, pitch 2.54mm 38
FRONT_USB1 USB 2.0 connector 5 x 2 header, pitch 2.54mm 39
FRONT_USB2 USB 2.0 connector 5 x 2 header, pitch 2.54mm 39
IDE1 Primary IDE connector 20 x 2 header, pitch 2.54mm 40
JATXPWR1 ATX power connector 10 x 2 header 41
JBKLT1 LCD Inverter connector 5 x 1 header, pitch 2.00mm 42
JLVDS1 LVDS connector HIROSE DF13S-40DP-1.25V 42
JDIO Digital I/O connector 10 x 2 header, pitch 2.00mm 43
SATA1 Serial ATA connectors [black] 7-pin header 43
SATA2 Serial ATA connectors [black] 7-pin header 43

User’s Manual
i910GML-DCQIC9 / i915GM-DCQI
19
1.4 Central Processing Unit (CPU) (for i915GM-DCQI only)
The motherboard i915GM-DCQI comes with a surface mount 479-pin Zero Insertion Force
(ZIF) socket designed for the Intel® Pentium® M / Celeron M processor (Supports
mPGA479M, Micro-FCPGA).
Take one of the marked corner (with gold
triangle) on the CPU. This mark should
match a specific corner on the socket to
ensure correct installation.
zMake sure the AC power is off before you install the CPU.
zIf installing a dual-core CPU, connect the CPU fan cable to the
CPU_FAN1 connector to ensure system stability.
zYour boxed Intel® Pentium® M / Celeron M processor (supports
mPGA479M, Micro-FCPGA) package should come with
installation instructions for the CPU, heatsink, and the retention
mechanism. If the instructions in this section do not match the
CPU documentation, follow the latter.
zUpon purchase of the motherboard, make sure that the PnP cap
is on the socket and the socket contacts are not bent. Contact
your retailer immediately if the PnP cap is missing, or if you see
any damage to the PnP cap/socket contacts/motherboard
components. Your place of purchase or local distributor will
shoulder the cost of repair only if the damage is
shipment/transit-related.
zKeep the cap after installing the motherboard. Your place of
purchase or local distributor will process Return Merchandise
Authorization (RMA) requests only if the motherboard comes with
the cap on the socket.
zThe product warranty does not cover damage to the socket
contacts resulting from incorrect CPU installation/removal, or
misplacement/loss/ incorrect removal of the PnP cap.

i910GML-DCQIC9/ i915GM-DCQI
20
1.4.1 Installing the CPU
1. Locate the CPU socket on the motherboard.
Before installing the CPU,
make sure that the socket
box is facing towards you.
2. The processor socket comes with a
screw to secure the processor, please
unlock the screw first.
