Parts
Instructions for Hanging
Instruction Sheet
Step 1
For use with poster paper or thinner substrates.
Score and fold or staple poster edge and slide
into the QuickGrip Holder. When using staples,
place staples 1/4” from top and bottom edges of
poster. Fig. 1
or
For use with thicker graphics up to 2mm.
Starting at one corner push the QuickGrip
Holder onto the graphic. Work your way down
the holder tapping it firmly down to seat the
graphic fully. Fig. 2
Step 2
Place cable into inner channel of CableClip.
The cable should snap into place. Fig. 3
Step 3
Align one end of the CableClip with the top
channel of the plastic holder. Then insert one
round end, press down on the other round end
and slide CableClip into rail. Fig. 4 Repeat step
3 for second CableClip.
Step 4
Push end caps into place. Fig. 5
Suspend poster. Fig. 6
Important note:
Please save and reuse the QuickGrip
Holder, End Caps and CableClips
for future projects.
End Caps
06-5525
QuickGrip™
Incept-11.13.02
The QuickGrip is a registered trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or damage
resulting from the use of these products. Part #02INSQuickGCCLoop
QuickGrip
12-0500
Figure 6Figure 5
Figure 3 Figure 4
Figure 2
Figure 1
Loop & Saucer
16-0018SL
Cable Clips
06-5050
