ROSEDALE LCO-6 Instruction manual

ENGINEERING STANDARDS
Rosedale Products, Inc. IOM Issue Date: 31JUL02
3730 West Liberty Road 7_3_5 Model LCO 6.wpd Revision: A
Ann Arbor, MI 48103 n:\iom\ Revision Date: 30May2003
Specification No.
7.3.5
PAGE: 1 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
INSTALLATION, OPERATION AND
MAINTENANCE MANUAL
ROSEDALE PRODUCTS, INC.
MODEL LCO-6
125 PSIG RATED FILTER UNIT
Table of Contents
I. INSTALLATION ................................................................. 2
II. OPERATION..................................................................... 3
III. SPAREPARTSLIST .............................................................. 4
IV. SPAREPARTSDIAGRAM ......................................................... 5

ENGINEERING STANDARDS
Rosedale Products, Inc. IOM Issue Date: 31JUL02
3730 West Liberty Road 7_3_5 Model LCO 6.wpd Revision: A
Ann Arbor, MI 48103 n:\iom\ Revision Date: 30May2003
Specification No.
7.3.5
PAGE: 2 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
I. INSTALLATION
Please remove all shipping and crating materials carefully. Be sure to remove the plugs from the inlet and
outlet openings. Dispose of all crating materials safely.
The Model LCO-6 Filter unit is capable of having several different piping variations based upon the outlet
style of your unit. The inlet service line should be connected to the inlet NPT coupling located near the top of
the unit (above basket level).
The outlet service line should be connected to the outlet coupling, located near the middle or bottom of the unit
depending upon the style of your unit (below basket level).
There are two 1/4" NPT ports on the shell of your Model LCO-6 Filter. These ports can remain plugged or
used for pressure gauges, vents, or special fitting as your application requires.
Some installations require electrical grounding of all equipment, be sure to provide adequate grounding where
necessary.
After completing installation be sure to double check connections for integrity. Your Model LCO-6 Filter unit
has been factory pressure tested leak free, therefore, any seepage problems usually occur from improper
installation connections.
You are now ready to install the filter basket and bag (if applicable). Remove cover by loosening the T-bolt
clamp sufficiently to allow removal of the clamp assembly, lift cover to remove.
The next step is to install the strainer or filter bag basket. When a strainer basket is utilized it is recommended
that an o-ring be installed under the rim of the strainer basket to prevent by-pass of unfiltered fluid (specify
basket seal on order).
If your installation requires a filter bag, place bag into the bag basket and insert bag and basket into the housing
making sure the filter bag ring is firmly seated on the I.D. of the housing. This configuration does not require a
basket seal, the bag ring serves as the seal.
Before replacing cover assembly, inspect cover seal gasket (replacing as necessary). Replace cover and
securely tighten T-bolt clamp closure to ensure a leak proof seal between cover and housing body.
Your Rosedale Model LCO-6 Filter is now ready for operation!

ENGINEERING STANDARDS
Rosedale Products, Inc. IOM Issue Date: 31JUL02
3730 West Liberty Road 7_3_5 Model LCO 6.wpd Revision: A
Ann Arbor, MI 48103 n:\iom\ Revision Date: 30May2003
Specification No.
7.3.5
PAGE: 3 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
II. OPERATION
Filter System Start-Up Procedure:
Prior to turning on the flow to the inlet service, please make the following checks:
1. Check inside filter unit to be sure basket and filter bag (if applicable) are in housing and do
not require cleaning or replacement. If necessary install clean filter basket and bag (if
applicable).
2. Check that filter cover is securely fastened to housing. You are now ready to open the flow
to the inlet service line. Slowly open the inlet service line to approximately 25% of normal
operational flow (open slowly as not to displace filter bag inside the housing). After filter
unit is pressurized and vented, slowly open outlet service line unit valve until completely
open. Complete opening of inlet service line until desired flow rate is reached.
Once the desired service flow has been established, the filter will operate efficiently until dirty. However,
under no circumstances should more than 15 PSI Differential Pressure through the filter be obtained.
Operating the filter unit with a high differential may cause filter bags to rupture and/or cause damage to filter
system and downstream equipment.
To prevent excessive drop through the filter unit, regular inspection of the filter media is required. Monitoring
of differential pressure through the housing can be utilized as a means of determining whether or not the filter
media needs cleaning or replacement.
When it becomes necessary to clean or replace filter media, follow the procedure outlined below:
1. First close the flow from the inlet service line.
2. Close the flow to the outlet service line. (In some applications closing flow to outlet is not
required.)
3. Relieve the pressure in the filter unit.
WARNING
CONTENTS UNDER PRESSURE
Relieve Pressure in accordance
with Manufacturer’s instructions
before opening Filter Vessel.
FAILURE TO DO SO MAY RESULT
IN SERIOUS BODILY INJURY.
4. Drain housing sufficiently to access filter basket.
5. Remove cover by loosening the T-bolt clamp sufficiently to allow removal of the clamp
assembly, lift cover to remove.
6. Remove filter basket and clean thoroughly, remove the filter bag (if applicable) and throw
away. (Cleaning and reusing the filter bag is not recommended.)
7. Remove debris and sludge from inside the inlet portion of housing to avoid interference with
cover seal or flow of fluid being filtered.

ENGINEERING STANDARDS
Rosedale Products, Inc. IOM Issue Date: 31JUL02
3730 West Liberty Road 7_3_5 Model LCO 6.wpd Revision: A
Ann Arbor, MI 48103 n:\iom\ Revision Date: 30May2003
Specification No.
7.3.5
PAGE: 4 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
8. Install clean filter basket and filter bag (if applicable). Be sure filter bag is properly seated
inside the housing.
9. Inspect cover gasket for cuts or other signs of failure, replace if necessary, and make sure it
is properly seated.
10. Reposition cover onto housing, install T-bolt clamp and securely tighten to ensure a leak
proof seal between the cover & housing body.
Your Rosedale Model LCO-6 Filter unit is now ready for operation. Refer to filter system start-up procedure.
III. SPARE PARTS LIST
Your Rosedale Model LCO-6 Filter unit will give many years of reliable service provided periodic inspections
are made of various components and replacement of worn parts are made promptly. The following is meant to
be a recommended spare parts list, these parts are illustrated on the following page.
SPARE PARTS LIST
Balloon Description Part Number Time-Frame
1 Cover Seal 6LCOCG-* as needed
2 Cover M-6-* as needed
3 Cover Clamp 6LCO-C as needed
4 T-Bolt 8T-BOLT as needed
5 T-Handle 8T-HANDLE as needed
6 Filter Bag (See Order) as needed
7 Filter Basket (See Order) as needed
8 Leg Assembly 6T18*S as needed
* Select Material Designation: C=Carbon Steel B=Buna N
S=304 Stainless Steel E=Ethylene Propylene
S316=316 Stainless Steel V=Viton
HC22=Hastelloy C-22 TEV=Teflon Encapsulated Viton
TSW=Teflon Solid White

ENGINEERING STANDARDS
Rosedale Products, Inc. IOM Issue Date: 31JUL02
3730 West Liberty Road 7_3_5 Model LCO 6.wpd Revision: A
Ann Arbor, MI 48103 n:\iom\ Revision Date: 30May2003
Specification No.
7.3.5
PAGE: 5 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
Figure 4
IV. SPARE PARTS DIAGRAM

ENGINEERING STANDARDS
Rosedale Products, Inc. IOM Issue Date: 31JUL02
3730 West Liberty Road 7_3_5 Model LCO 6.wpd Revision: A
Ann Arbor, MI 48103 n:\iom\ Revision Date: 30May2003
Specification No.
7.3.5
PAGE: 6 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
Rosedale Products, Inc.
3730 West Liberty Road
Ann Arbor, MI 48103 USA
734-665-8201
800-821-5373
Fax. [phone]
[e-mail]
http://www.rosedaleproducts.com
