INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
MODEL
LCO-8
INSTALLATION, OPERATION AND
MAINTENANCE MANUAL
ROSEDALE PRODUCTS, INC.
MODEL LCO-8
125 PSIG RATED FILTER UNIT
Table of Contents
I. Installation ............................................................... 2
II. Operation ................................................................ 3
III. SparePartsList ............................................................ 4
IV. SparePartsDiagram ........................................................ 5

ENGINEERING STANDARDS
Rosedale Products, Inc. Issue Date: 25MAR96
3730 West Liberty Road Revision: C
Ann Arbor, MI 48103 Revision Date: 30May2003
IOM
7_4_3 Model LCO-8
125.wpd
n:\iom\
Specification No.
7.4.3
PAGE: 2 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
I. Installation
Please remove all shipping and crating materials carefully. Be sure to remove the plugs from the inlet and
outlet openings. Dispose of all crating materials safely.
The MODEL LCO-8 Filter unit is capable of having several different piping variations based upon the outlet
style of your unit. The inlet service line should be connected to the inlet NPT coupling located near the top of
the unit (above the basket level).
The outlet service line should be connected to the outlet NPT coupling, located near the middle or bottom of the
unit (below the basket level). The MODEL LCO-8 is designed to utilize either the side NPT coupling as an
outlet or the bottom NPT coupling as an outlet, depending upon your application requirement. Simply install
the NPT plug to direct flow as needed.
There are two 1/4" NPT ports on the shell of the MODEL LCO-8 Filter unit. These ports can remain plugged
or used for pressure gauges or special fittings as your application requires.
Some installations require electrical grounding of all equipment, be sure to provide adequate grounding where
necessary.
After completing installation be sure to double check connections for integrity. Your MODEL LCO-8 Filter
unit has been factory pressure tested leak free, therefore, any seepage problems usually occur from improper
installation connections.
You are now ready to install the filter basket and bag. Remove cover by loosening the T-bolt clamp sufficiently
to allow removal of the clamp assembly.
Place the basket into the filter housing, make sure the basket flange is firmly seated onto the step on the inside
of the housing.
Insert bag into the bag basket making sure filter bag ring is firmly seated against the top of the basket flange.
For best results, be sure filter bag is installed fully extended to the bottom of the basket.
Before replacing cover and clamp assembly, inspect cover seal gasket (replacing as necessary). Replace cover
and tighten the T-bolt clamp assembly to ensure a leak proof seal between the cover and housing body.
Your Rosedale MODEL LCO-8 is now ready for operation!

ENGINEERING STANDARDS
Rosedale Products, Inc. Issue Date: 25MAR96
3730 West Liberty Road Revision: C
Ann Arbor, MI 48103 Revision Date: 30May2003
IOM
7_4_3 Model LCO-8
125.wpd
n:\iom\
Specification No.
7.4.3
PAGE: 3 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
II. Operation
Filter System Start-Up Procedure:
Prior to turning on the flow to the inlet service, please make the following checks:
1. Check inside filter unit to be sure basket and filter bag (if applicable) are in housing and do
not require cleaning or replacement. If necessary install a clean filter basket and bag (if
applicable).
2. Check that filter unit cover is securely fastened to housing. You are now ready to open the
flow to the inlet service line. Slowly open the inlet service line approximately 25% of normal
operational flow (open slowly as not to displace filter bag inside the housing). After filter
unit is pressurized and vented, slowly open outlet service line unit valve until completely
open. Complete opening of inlet service line until desired flow rate is reached.
Once the desired service flow has been established, the filter will operate efficiently until dirty. However,
under no circumstances should more than 15 PSI Differential Pressure through the filter be obtained.
Operating the filter unit with a high differential may cause filter bags to rupture and/or cause damage to filter
system and downstream equipment.
To prevent excessive drop through the filter unit, regular inspection of the filter media is required. Monitoring
of differential pressure through the housing can be utilized as a means of determining whether or not the filter
media needs cleaning or replacement.
When it becomes necessary to clean or replace filter media, follow the procedure outlined below:
1. First close the flow from the inlet service line.
2. Close the flow to the outlet service line. (In some applications closing flow to outlet is not
required.)
3. Relieve the pressure from the filter unit.
WARNING
CONTENTS UNDER PRESSURE
Relieve Pressure in accordance
with Manufacturer’s instructions
before opening Filter Vessel.
FAILURE TO DO SO MAY RESULT
IN SERIOUS BODILY INJURY.
4. Drain housing sufficiently to access filter basket.
5. Remove cover by loosening the T-bolt clamp sufficiently to allow removal of the clamp
assembly.
6. Remove filter basket and clean thoroughly, remove the filter bag (if applicable) and throw
away. (Cleaning and reusing the filter bag is not recommended.)
7. Remove debris and sludge from inside the inlet portion of housing to avoid interference with
flow of fluid being filtered.

ENGINEERING STANDARDS
Rosedale Products, Inc. Issue Date: 25MAR96
3730 West Liberty Road Revision: C
Ann Arbor, MI 48103 Revision Date: 30May2003
IOM
7_4_3 Model LCO-8
125.wpd
n:\iom\
Specification No.
7.4.3
PAGE: 4 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
8. Install clean filter basket and filter bag (if applicable). Place the basket into the filter housing,
make sure the basket flange is firmly seated onto the step on the inside of the housing. Insert
bag into the bag basket making sure filter bag ring is firmly seated against the top of the
basket flange. For best results, be sure filter bag is installed fully extended to the bottom of
the basket.
9. Inspect cover gasket for cuts or other signs of failure and make sure it is properly seated.
Your Rosedale MODEL LCO-8 Filter unit is now ready for operation. Refer to filter system start-up
procedure.
III. Spare Parts List
Your Rosedale MODEL LCO-8 Filter unit will give you many years of reliable service provided periodic
inspections are made of various components and replacement of worn parts are made promptly. The following
is meant to be a recommended spare parts list, these parts are illustrated on the following page.
SPARE PARTS LIST
Balloon Description Part Number Time-Frame
1 Cover Seal 8LCOCG-* as needed
2 Clamp Assembly 8LCO-C-Clamp as needed
3 Cover 8C-LCO-* as needed
4 T-Bolt 8T-Bolt as needed
5 T-Handle 8T-Handle as needed
6 Filter Bag (See Order) as needed
7 Filter Basket (See Order) as needed
8 Tripod Legs 8T22*S as needed
* Select Material Designation: C=Carbon Steel B=Buna N
S=304 Stainless Steel E=Ethylene Propylene
V=Viton

ENGINEERING STANDARDS
Rosedale Products, Inc. Issue Date: 25MAR96
3730 West Liberty Road Revision: C
Ann Arbor, MI 48103 Revision Date: 30May2003
IOM
7_4_3 Model LCO-8
125.wpd
n:\iom\
Specification No.
7.4.3
PAGE: 5 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
IV. Spare Parts Diagram

ENGINEERING STANDARDS
Rosedale Products, Inc. Issue Date: 25MAR96
3730 West Liberty Road Revision: C
Ann Arbor, MI 48103 Revision Date: 30May2003
IOM
7_4_3 Model LCO-8
125.wpd
n:\iom\
Specification No.
7.4.3
PAGE: 6 of 6
INSTALLATION, OPERATION, & MAINTENANCE MANUAL
Rosedale Engineering Standards are the property of Rosedale Products, Inc. A Rosedale standard or copy thereof shall not be distributed (except with express approval of Rosedale
Products, Inc.) to any individual or firm beyond the intended recipient firm or individual. Firms of individuals acting contrary to the above may be subject to suit, ineligibility for continued or
future employment, or removal from Rosedale’s "Approved Manufacturers and Specialty Contractors List".
Rosedale Products, Inc.
3730 West Liberty Road
Ann Arbor, MI 48103 USA
734-665-8201
800-821-5373
Fax. [phone]
[e-mail]
http://www.rosedaleproducts.com
Important Notice
Warranty: In the event any Rosedale Products, Inc. filtration product is found to be defective in material, workmanship, or not
in conformance with any express warranty for a specific purpose, Rosedale’s only obligation and your exclusive remedy, shall
be to repair, replace or refund the purchase price of such parts or products upon timely notification thereof and substantiation
that the product has been stored, maintained and used in accordance with Rosedale’s written instructions.
EXCLUSIONS TO WARRANTY: THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY IMPLIED WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR OTHER WARRANTY OF QUALITY, EXCEPT OF
TITLE AND AGAINST PATENT INFRINGEMENT.
LIMITATION OF LIABILITY: Except as provided above, Rosedale shall not be liable or responsible for any loss or damage,
whether direct, indirect, incidental, special or consequential, arising out of sale, use or misuse of Rosedale filtration products,
or the user’s inability to use such products.
THE REMEDIES SET FORTH HEREIN ARE EXCLUSIVE.
