Rosenbauer HEROS-titan AS Operation manual

HEROS-titan AS
User Information
(EN)
Protective helmet for structural
fire fighting certified to
AS/NZS 4067:2012 + A1:2014.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 1 31.10.17 09:22

Rosenbauer – HEROS-titan AS
2
User information
150509_VWI_HEROS-titan AS (Australien)_EN.indd 2 31.10.17 09:22

HEROS-titan AS – Rosenbauer
3
EN
Fire Helmet - User information guide
HEROS-titan AS
Protective Helmet for Structural Fire Fighting
AS/NZS 4067:2012 + A1:2014
BMP No 681002
Australian / New Zealand Standards
“This product is marked with BSI’s Benchmark Product Certification Mark.
This indicates that the conformity of our product is based upon technical
documentation and an annual review of our manufacturing and quality control
process to monitor our ability to consistently produce products in compliance
with AS/NZS 4067:2012 + A1:2014. Client BMP No 681002.”
“This Product Certification Mark is accredited by the Joint Accreditation System
of Australia and New Zealand (JAS-ANZ) see: www.jas-anz.com.au
DANGER! Only end user shall separate this guide from the helmet.
Fire fighting and techical rescue are extremely dangerous activities.
This manual must be carefully followed by all persons who have, or will have the
responsibility for using or maintaining this helmet.
This fire helmet will perform as designed only if used and maintained according
to the instructions.
Otherwise it could fail to perform as designed; and persons who rely on it for
their safety may sustain serious personal injury or death!
Do not use this helmet until you have read and understood all labels on your
helmet and this user information guide.
You may be killed or injured while using this product!
The product warranties by the manufacturer are voided if the helmet is not used and
maintained according to this manual.
Only end users shall separate this manual from the helmet.
If any information is unclear, contact Rosenbauer International or visit our
website at www.rosenbauer.com
150509_VWI_HEROS-titan AS (Australien)_EN.indd 3 31.10.17 09:22

4
Rosenbauer – HEROS-titan AS
Manufacturer's and customer service address
Rosenbauer International AG
A-4060 Leonding, Paschinger Str. 90, Austria
Tel.: [phone]
Fax: [phone]
[e-mail]
www.rosenbauer.com
Manufactured in Austria.
1. SAFETY CONSIDERATIONS / LIMITATIONS OF USE
DANGER / WARNING
IF SUBJECTED TO SEVERE IMPACT OR DETERIORATION, THE HELMET IS TO BE
RETURNED TO MANUFACTURER FOR INSPECTION, OR BE REPLACED.
DO NOT MODIFY OR REMOVE PARTS. DO NOT ADD ACCESSORIES WHICH ARE
NOT APPROVED BY THE MANUFACTURER.
MANUFACTURER´S INSTRUCTIONS SHOULD BE FOLLOWED FOR CLEANING –
HELMET AND FACESHIELD MAY BE SERIOUSLY DAMAGED BY CERTAIN
SUBSTANCES.
THIS HELMET MUST BE PROPERLY ADJUSTED AND SECURED TO THE HEAD,
WITH ALL COMPONENTS IN PLACE, TO PROVIDE THE DESIGNED LEVEL OF
PROTECTION.
FIRE FIGHTING IS AN EXTREMELY HAZARDOUS ACTIVITY. NO HELMET CAN
PROTECT THE WEARER AGAINST ALL POSSIBLE TYPES OF IMPACTS. EVEN WITH
THE USE OF THIS HELMET, FIRE FIGHTING WILL BE UNAVOIDABLY DANGEROUS!
DO NOT USE THIS HELMET UNTIL YOU HAVE READ AND UNDERSTOOD ALL
LABELS ON YOUR HELMET AND THIS USER INFORMATION GUIDE.
YOU MAY BE KILLED OR INJURED WHILE USING THIS PRODUCT.
Do not use this helmet until you have been trained by your fire department or
employer in fire fighting tactics, safety procedures and the proper use of your
helmet. Most performances of this helmet cannot be tested by the user in the field.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 4 31.10.17 09:22

5
HEROS-titan AS – Rosenbauer
EN
This helmet is designed to provide LIMITED protection to the head when worn
during structural fire fighting and technical rescue activities but will NOT protect
you from all burns, injuries or hazards.
Avoid exposure to flashover, collapses, falls and other conditions that may exceed
the protective capacity of this helmet.
If this helmet is exposed to heat, you may be burned with NO warning and NO sign
of damage to the helmet.
To reduce the risk of injury and for maximum protection, the helmet must fit firmly
on the head, must be properly adjusted with all retention straps, securely fastened
and with all components in place.
The helmet can only provide optimum protection, when it has been correctly
adjusted and sits perfectly on the head. The helmet may only be used in a
completely assembled condition. Removable parts may not be employed
separately.
Never wear your helmet without fastening and tightening the chinstrap.
The faceshields of this helmet provide LIMITED protection only to the facial area it
covers. The faceshields are NOT intended to provide primary eye protection.
The faceshields of this helmet are NOT shatterproof. High speed objects or large
objects may break or penetrate the faceshields and injure the wearer´s face or
eyes.
Improper use of the helmet for purposes other than those permitted according to
this user information guide can lead to serious injury or death.
Use only accessory equipment included in the original helmet or approved by the
manufacturer. Do NOT modify, change or alter your helmet. Changes to the helmet
assembly or the use of accessories not approved by the manufacturer may
dramatically change the performance of the helmet function and thus cause
serious injury or death.
Helmets absorb shock by partial destruction of the shell an liner. This damage may
not be visible. Therefore, if subjected to a severe blow, the helmet should be
replaced immediately, even if it is apparently undamaged.
The helmet may be damaged and rendered ineffective by such materials as
petroleum and petroleum products, cleaning agents, paints and adhesives,
150509_VWI_HEROS-titan AS (Australien)_EN.indd 5 31.10.17 09:22

6
Rosenbauer – HEROS-titan AS
without the damage being visible to the user.
Inspect the helmet assembly and the faceshields before and after EACH use
following the inspection procedure in this manual. Replace immediately ANY part
showing wear or damage.
In case of non-adherence to these stipulations, ROSENBAUER cannot give any
warranties concerning the protective function of this helmet! ROSENBAUER’s
conditions of liability and warranty are not extended due to this information.
This helmet may only be used for the purposes for which it has been designed
after careful study of the complete instructions.
This protective helmet must be used only under the direct supervision of your fire
department or employer consistent with applicable regulations.
The helmet is neither suitable nor certificated for uses, e.g. as a cycle helmet,
motor cycle helmet, as a seat, as an object for standing on, or similar activities.
Utilization for such purposes is unacceptable and forbidden.
This protective helmet must be handled, checked and maintained in the manner
described in this user information and the instructions for use.
In order to safeguard this helmet against premature aging, store it in a place
which offers maximum protection against light and moisture.
All repair work, component exchange and servicing on this helmet may only be
undertaken according to the appropriate guidelines pursuant to these instructions
for use. All activities must be logged. Only specialists authorized by ROSENBAUER,
may carry out fundamental maintenance and servicing work, not described in this
user information.
Before and after every use, each element of the helmet assembly must be
inspected carefully for cleanliness, tears, cracks, holes and any physical damage.
In the case of unusual damage (loads) on the helmet shell, the interior harness,
the chinstrap or other parts, these must be exchanged immediately in order to
guarantee the defined protective function.
Only original parts may be employed for the maintenance of this helmet.
Subsequently applied paint on the helmet surface, or stickers not approved by
ROSENBAUER, can alter the characteristics of the material and are not allowed.
No alterations may be made to the helmet assembly. No attachments should be
150509_VWI_HEROS-titan AS (Australien)_EN.indd 6 31.10.17 09:22
7
HEROS-titan AS – Rosenbauer
EN
added or alterations made to the helmet except those recommended by the
helmet manufacturer.
During operations in areas subject to the danger of explosions, the breathing
apparatus mask and the helmet should be treated with anti-static spray, or a
water film should be applied.
The helmet shell is covered with a functional paint coating (impact resistant).
Possible damage to the paint may have a negative effect upon the protective
function of the helmet and should therefore be repaired immediately by a
specialist.
The visors of this helmet are made of high-performance polycarbonate.
In extreme temperatures even the best helmet visor materials lose their stability.
Deformed visors (due to thermal loads) must be exchanged immediately. Visors
are wear parts and should be stocked in sufficient quantities.
The ear covers are made of soft, flexible material, offering limited mechanical
protection only.
Ear covers are wear parts and should be stocked in sufficient quantities.
This protective helmet will lower your ability to feel heat. Even though you do not
feel heat you can be burned or injured suddenly and without warning.
Be constantly alert to the possibility of exposure to heat and other hazards.
2. SIZING, FIT AND ADJUSTMENT
Before each use of this helmet, make sure that it is sized, fits and adjusted properly
The interior helmet harness allows the optimum adjustment of the helmet fit to the
head.
Individual setting can be carried out by means of the new method of adjusting the
headband to the respective head size from the outside.
The covering of the headband can be removed for easy cleaning. The headband can
be removed from the helmet for cleaning purposes without the need for tools. The
complete interior harness of the helmet can be easily exchanged.
The visor provides LIMITED protection only to the facial area it covers.
To provide this limited protection you must lower the visors fully to the detent,
no intermediate position is allowed.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 7 31.10.17 09:22

7
HEROS-titan AS – Rosenbauer
EN
added or alterations made to the helmet except those recommended by the
helmet manufacturer.
During operations in areas subject to the danger of explosions, the breathing
apparatus mask and the helmet should be treated with anti-static spray, or a
water film should be applied.
The helmet shell is covered with a functional paint coating (impact resistant).
Possible damage to the paint may have a negative effect upon the protective
function of the helmet and should therefore be repaired immediately by a
specialist.
The visors of this helmet are made of high-performance polycarbonate.
In extreme temperatures even the best helmet visor materials lose their stability.
Deformed visors (due to thermal loads) must be exchanged immediately. Visors
are wear parts and should be stocked in sufficient quantities.
The ear covers are made of soft, flexible material, offering limited mechanical
protection only.
Ear covers are wear parts and should be stocked in sufficient quantities.
This protective helmet will lower your ability to feel heat. Even though you do not
feel heat you can be burned or injured suddenly and without warning.
Be constantly alert to the possibility of exposure to heat and other hazards.
2. SIZING, FIT AND ADJUSTMENT
Before each use of this helmet, make sure that it is sized, fits and adjusted properly
The interior helmet harness allows the optimum adjustment of the helmet fit to the
head.
Individual setting can be carried out by means of the new method of adjusting the
headband to the respective head size from the outside.
The covering of the headband can be removed for easy cleaning. The headband can
be removed from the helmet for cleaning purposes without the need for tools. The
complete interior harness of the helmet can be easily exchanged.
The visor provides LIMITED protection only to the facial area it covers.
To provide this limited protection you must lower the visors fully to the detent,
no intermediate position is allowed.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 7 31.10.17 09:22

8
Rosenbauer – HEROS-titan AS
The visors must be stowed in the full upright position when a SCBA facepiece is worn.
The trapezoidal shaped chinstrap is made of flame-retardant, highly heat-resistant
material. In combination with the integrated padding, the chinstrap ensures pleasant
wearing. The chinstrap can be individually adjusted both laterally and vertically in the
neck area.
The ear covers can be easily removed for cleaning purposes.
You must assure that the ear covers of this helmet are down and interface with your
hood, SCBA and coat collar so that there is no gap in protection during use.
2.1 Donning your protective helmet
General adjustment
The helmet can be smoothly adjusted between minimum and maximum size using the
external ratchet knob.
1. The integrity, fit, and proper assembly of the helmet, suspension system, ear covers, and
chinstrap must be checked before each use.
2. Release the headband by turning the ratchet knob counter-clockwise.
3. Put the helmet on and hold it down on your head.
4. Tighten the headband by turning the ratchet knob clockwise to obtain a snug fit. Never
tighten the ratchet beyond its limits – this could result in damage of parts of the ratchet
and in reduced protection.
5. Fasten the chin strap securely and adjust to a snug fit. Never wear your helmet without
fastening and tightening the chinstrap.
6. Assure that your helmet does not interfere with the seal of your SCBA face piece.
7. Assure that the ear covers of your helmet are down and interface with your hood, SCBA
and coat collar so that there is no gap in protection during use.
chin strap adjustment main size adjustment
150509_VWI_HEROS-titan AS (Australien)_EN.indd 8 31.10.17 09:22

9
HEROS-titan AS – Rosenbauer
EN
2.2 Additional adjustment possibilities
2.2.1 Center of gravity
To optimize the individual weight balance the helmet
shell can be moved against the inner harness to be fixed
in three different positions.
To do so, open the main screws left and right as shown.
The inner harness can then be adjusted to one of the
three possible positions (A,B,C). Be sure to adjust both
sides equally.
After adjustment to the right position, both screws left and right must be securely
fastened again to ensure the safety function of these elements.
2.2.2 Size adjustment of the headband
The headband can be adjusted on both sides to three different sizes.
Select position 1 for small heads, position 2 for medium-sized heads and position 3 for
large heads. Be sure to adjust both sides equally.
After adjustment to the right position, both elements left and right must be
securely locked again to ensure the safety function of these elements
150509_VWI_HEROS-titan AS (Australien)_EN.indd 9 31.10.17 09:22

10
Rosenbauer – HEROS-titan AS
2.2.3 Adjustment of the wearing height
The wearing height is easiest to adjust when the interior fittings are removed.

 



Remove both front fixing points left and right
Remove both rear fixing points left and right
Pull out the axle from the rotary knob
Remove the inner harness
Adjust both sliders equally to achieve the proper
wearing height
Reassemble all parts in the reverse sequence
After adjustment to the right position, both screws
left and right must be securely fastened again to
ensure the safety function of these elements
2.2.4 Visor adjustment
The integrated visor should be pulled down until it locks. No intermediate position is
allowed. The visor is pushed up in the reverse sequence, but is first secure when tangible
locking occurs.
1/2
1/2
The optional eye protection visor is pulled down until it locks using both lateral levers.
It is pushed up in the reverse sequence, but is first secure when tangible locking
occurs.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 10 31.10.17 09:22

11
HEROS-titan AS – Rosenbauer
EN
IMPORTANT: Protection of the visor is only provided in the final position (end locking,
no intermediate position).
IMPORTANT: The eye protector (optional) should be moved only by using both levers
(left and right) smoothly. Otherwise the visors can be scratch-damaged.
These kinds of damages are NO warranty claim!
2.3 Doffing your protective helmet
a) Helmet is not contaminated after use:
∙Remove the helmet in reverse order from that described above for donning the
helmet.
∙Inspect each item of the helmet assembly for any damage or change in
condition.
∙Any damage or change in condition must be corrected before the helmet is
used again.
∙Clean and store the helmet as recommended under „Maintenance“.
b) Helmet is contaminated after use:
Protective helmets contaminated with blood, bodily fluids, toxins, radioactivity,
chemicals, and hazardous materials.
Strictly avoid unprotected bodily contact with any contaminated area of your
helmet assembly.
Avoid spreading the contaminants from your helmet assembly to your
personal belongings, your living quarters and/or interior spaces in buildings
and vehicles.
Place contaminated helmet assembly in a sealable, leak-proof, air tight bag.
Dispose of in accordance with applicable federal, state and local laws.
If the helmet is to be reused, it must be decontaminated by a decontamination
professional in accordance with applicable federal, state and local laws.
2.4 Cleaning
∙You must keep your protective helmet assembly clean
∙Clean the helmet assembly after each use, but before inspection
∙NEVER use a helmet that is not thoroughly cleaned and dried
∙Clean the helmet shell, the visors and all plastic parts with warm water and mild
detergent using a soft sponge or cloth
NEVER clean any part of the helmet or visor with abrasives, solvents, petrol,
acids, etc., as this can have negative effects on the protective function.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 11 31.10.17 09:22

12
Rosenbauer – HEROS-titan AS
∙The fabric head band covers can easily be removed from the headband and can be
washed in a washing machine at low temperature (use a mild detergent only).
Dry all materials completely before reassembling and before use.
∙Chinstrap cleaning
The chinstrap should be cleaned as required.
After removal from the helmet shell it can be washed in a washing machine at low
temperature (use a mild detergent only).
Dry all materials completely before reassembling and before use.
Reassemble the chinstrap carefully!
After reassembling of the chinstrap take care that all fixing parts must be securely
locked again to ensure the safety function of all elements.
2.5 Inspection
Inspect each element of the helmet assembly after EACH use carefully for function,
cleanliness, tears, cracks, holes and any physical, impact, thermal and use damage.
Disassemble and carefully inspect helmets that have been exposed to excessive heat
ore have taken an impact. Replace ANY part showing wear or damage.
Helmets absorb the energy of a blow by partial destruction of, or damage to, the
helmet. Even though such damage may not be readily apparent, any helmet subjected
to a severe impact should be replaced immediately.
If there is a damage, remove the helmet from service immediately and repair or replace
the damaged part before using the helmet again.
NEVER use a damaged helmet !
Helmet Shell – Replace if any of the following conditions are evident
a) Any cracks, dents or deep scratches > 1mm
b) Deformations (from mechanical impacts, exposure to excessive heat, flame etc.)
Visors – Faceshields
a) Replace if blistered, bubbled, cracked, or charred
b) Replace if deformations or other heavy damages occur
c) Replace if lens does not stay in the stowed position and/or cannot be adjusted
Edge Trim
a) Reattach if separated but intact (ask manufacturer for special heat resistant glue)
b) Replace if damaged
150509_VWI_HEROS-titan AS (Australien)_EN.indd 12 31.10.17 09:22

13
HEROS-titan AS – Rosenbauer
EN
Reflective Trim
a) Replace if damaged, nonreflective or missing
Chinstrap – Replace if any of the following conditions are evident
a) Frayed, missing, or broken parts
b) Frayed, cut or broken stitching
c) Worn-out hook and loop parts
d) Broken, worn-out or missing release buckle
Suspension straps - Replace if any of the following conditions are evident
a) Cut, or broken stitching
b) Tears or abrasions on straps
c) Brittleness
d) Discoloration
Head band - Replace if any of the following conditions are evident
a) Brittleness
b) Cracked or broken
c) Ratchet system does not work properly
Ear covers - Replace if any of the following conditions are evident
a) Cut, or broken stitching
b) Nomex layer discoloured, charred or perforated
General
a) Inspect carefully for all screws to be securely tightened
2.6 Retirement criteria
Your fire department or employer must determine whether or not your protective
helmet assembly is ready for retirement and replacement.
The service life of this protective helmet will vary depending upon how much it has
been used and how well it has been cleaned and maintained.
If you are unsure whether your protective helmet should be retired, do NOT use it.
Unless the responsible authority determines that your protective helmet is ready for
retirement earlier, the over all service life of this protective helmet shall not exceed a
total period of 15 years.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 13 31.10.17 09:22

14
Rosenbauer – HEROS-titan AS
3. MAINTENANCE
Take extreme care that at all time as well as after replacement of elements all fixing
parts, screws, sliders etc. must be securely locked again and adjusted properly to
ensure the safety function of all elements.
3.1 Chinstrap replacement
The chinstrap can be simply removed using an Allen key for the screws left and right
and loosen the neck strap velcro fixing. Replace the chinstrap and reinsert using the
reverse procedure.
3.2 Visor replacement (face shield)
First, the two screws (hexagonal socket) left and right helmet side must be removed.
The visor should then be removed from its anchorage.
A new visor is then inserted onto the seating bolts and the supports pushed into the
plastic lugs in the reverse sequence. These are then secured by the holding screws.
Take care that the enclosed washers sit properly and all screws are securely
tightened (both face shield and eye shield).
3.3 Visor replacement (eye shield)
First, remove the inner harness from the helmet shell
(see point 2.2.3, adjustment of the wearing height).
Then, remove both screws left and right (hexagonal socket)
at the pivot point of the visor.
Replace the visor and reassemble in the reverse sequence.
150509_VWI_HEROS-titan AS (Australien)_EN.indd 14 31.10.17 09:22

15
HEROS-titan AS – Rosenbauer
EN
3.4 Ear Cover replacement


Remove the ear cover following step 1-2 as shown
in above figure, reassembling using the reverse sequence.
4. STORAGE
Store the helmet in a dry, clean and ventilated area, where the helmet is not exposed
to sunlight, heat, cold or humidity as this could impair the protective function of your
helmet.
NEVER store other equipment that is not authorized by the manufacturer inside or
on your helmet. Storage of such equipment could dramatically impair the protective
function of your helmet!
4.1 Limited Warranty
Rosenbauer International AG warrants to the original purchaser that this protective
helmet is free from defects in material or workmanship under normal use and service
for a period of two years from the date of manufacture. This warranty does NOT cover
normal wear or unusual exposures.
This warranty is in lieu of all other warranties, expressed or implied, including but not lim-
ited to, implied warranties of marketability and/or fitness for a particular purpose.
Repair or replacement for breach of this warranty shall be the exclusive remedy available.
Under NO circumstances Rosenbauer International AG will be liable for economic, in-
cidental or consequential damages or losses caused by reason of the non-operation of
this protective helmet.
5. TRANSPORT AND PACKAGING:
In separate box with protective wrap
Manufacturer:
Rosenbauer International AG
Paschinger Str. 90
4060 Leonding/AUSTRIA
Tel.: [phone]
[e-mail];
www.rosenbauer.com
150509_VWI_HEROS-titan AS (Australien)_EN.indd 15 31.10.17 09:22

Rosenbauer International AG
Paschinger Straße 90
4060 Leonding, Austria
Tel.: [phone]
Fax: [phone]
[e-mail]
www.rosenbauer.com
Text and illustrations are not binding. The illustrations
may show optional extras only available at extra charge.
Rosenbauer retains the right to alter specifications and
dimensions given here in without prior notice.
VI0998/HEROS-titan AS_EN_2017_11_150509
150509_VWI_HEROS-titan AS (Australien)_EN.indd 16 31.10.17 09:22
