REARSIGHT MIRROR/MONITOR
250-8208/300-3000-002 Installation Instructions
Parts Identification Page 1
Vehicle Preparation Page 1
System Layout Page 2
Installation Page 2
Testing/Reassembly/Troubleshooting Page 3
Parts Identification
Item Qty. Part Number Description
1A 1 250-8208 4.3” LCD Mirror/Monitor with Extensions Harness
OR
1B 1 300-3000-002 3.5” LCD Mirror/Monitor with Extensions Harness
Vehicle Preparation
Before beginning your installation, familiarize yourself with the installation instructions and the RearSight
camera system components.
To ensure your safety, (A) apply the emergency brake and (B) read this entire manual before beginning.
CAUTION: It is advisable to disconnect the negative battery cable for 3 minutes befor
e
b
eginning
installation, to avoid unintended air bag deployment. Note and record any anti- theft radio codes prior to
disconnecting.
Form #5404, Rev. A, 01-24-13

Rostra Precision Controls, Inc. - 2519 Dana Dr. - Laurinburg, NC 28352 - 800-782-3379 - rostra.com Page 2
System Layout
Installation
1. Remove the existing mirror from the windshield and replace with RearSight mirror
tightening the mirror’s stem to the windshield with a Phillips screwdriver. (Some vehicles
require a mirror removal tool).
2. Connect the mirror’s Red Wire to a fused Ignition 12-volt power circuit, Black Wire to a
vehicle ground point, and Green Wire to the reverse power circuit at the fuse panel or the
rear lamp.
3. Connect the video feed from your camera (not included) to the yellow female RCA camera-
in plug.
Adjusting LCD Screen Brightness
While the LCD screen built into this mirror dims automatically depending upon the light inside the
vehicle, it can also be adjusted manually. When the vehicle is shifted into reverse and the LCD
monitor is displaying the image of the area behind the vehicle, the brightness of the screen can be
adjusted by pressing the Power button on the face of the monitor.

Rostra Precision Controls, Inc. - 2519 Dana Dr. - Laurinburg, NC 28352 - 800-782-3379 - rostra.com Page 3
Testing and Reassembly
Testing
1. Reconnect the negative battery cable and torque to 3 ft-lbs.
2. Re-enter any theft deterrent information (if applicable).
3. Turn the ignition switch to the ON position.
4. Shift the vehicle into reverse and confirm video feed to your device.
Note: If there is no picture present, re-check all harness connections.
Reassembly
1. Reinstall all trim pieces taking special care to ensure harnesses and wiring connections are properly secured.
2. Make sure no harnesses are bent or pinched by trim pieces.
3. Reconnect all disconnected bulbs and check for function.
Installation Tips
•Confirm proper cable extension connector orientation and always verify proper ends are routed in correct
direction.
•It is a good idea to dry-fit all pieces in this kit before permanently attaching them to ensure proper
orientation and operation before beginning installation for familiarization with components.
•Always treat any metal exposed during installation with a rust preventative compound to prevent system
failure due to rust and/or corrosion.
•Always seal any holes drilled with the provided sealing putty to prevent water infiltration through
unprotected areas.
•Confirm integrity of mechanical and electrical connections before moving to next installation sequence.
Troubleshooting
Mirror/Monitor Not Working No Video No Reverse Override
Verify 12-volts to monitor red
wire. Verify extension harness connection to camera. Check connectivity of green reverse wire.
Verify ground < 10 Ohms
resistance. Verify harnesses are mated correctly at camera. Verify extension harness connection to camera.
Verify secure connection to
monitor extension harness. Verify 12-volts and ground connection at camera.
