Rostra 250-8290 User manual

BEFORE INSTALLATION PLEASE READ THIS MANUAL, AFTER
INSTALLATION LEAVE WITH THE VEHICLE FOR THE END USER.
250-8290 QUAD VIEW MONITOR
WWW.ROSTRA.COM
ALL RIGHTS RESERVED 7/30/2018
ROSTRA ACCESSORIES INC.
3056 NC HWY 5
ABERDEEN NC. 28315
800-782-3379
All instructions, warranties and other collateral documents are
subject to change at the sole discretion of Rostra Accesories, Inc.
For the latest available information or product literature,
visit www.rostra.com and click on the support tab.

Controls & Features Wiring Connections
1: Removable Sun Shade
2: Locking Screws
3: U-Bracket
4: 9" LCD Panel
5: MENU Button
6: CH1 / Left Select Button
7: CH2 / Right Select Button
8: Power On/Off Button
9: CH3 / Down Select Button
10: CH4 / UP Select Button
11: Mode Button - Selects View Mode
BROWN CH1 Trigger - Front
GREEN CH2 Trigger - Rear
BLUE CH3 Trigger - Left
GREY CH4 Trigger - Right
CH 1 A/V Input
CH 2 Video Input
CH 3 Video Input
CH 4 Video Input
RED + 12-24 Vdc
BLACK - Ground
To remove the sun shade carefully press up at the bottom
of both sides. The Screen will release, then carefully lift
away from the LCD panel. DO NOT force the shade or
put pressure on the panel.

1 Audio Input, 4 Video Inputs, 4 Seperate Triggers
Switches Between PAL & NTSC Automatically
U Type Bracket Included
Mirror Image Selectable & Adjustable Image Delay After Trigger On All Inputs
Specifications
English, Deutsch, Francais, Espanol, Portugais, Italiano, Chinese, Turkish
Selects Picture, Volume, Mirror Image, Language, Delay,
Full Screen, 2 Split, 3 Split, 4 Split
03 04
1 Channel Audio On Input #1
Menu Options
Picture:
Bright, Contrast, Color, Tint, Reset.
Volume:
Adjusts the Volume from Camera 1
Mirror:
Select Normal or Mirror image on this camera.
System:
Changes the OSD Menu Language
Clock:
Set Camera View Delay after trigger is off. Select from

Press the MENU button to enter the OSD.
Press MENU again to move to the next Option Screen.

Use the UP/Down Arrow buttons to select a option.
Use the Right/Left Arrow buttons to increase or decrease the
selected option.
0 - 10 Seconds delay for each camera input.
12 V - 24 V
Included, Removable

- Optional Mount 250-8132 Not Included
1: Find a location for the mount, Rostra does not recommend using mounts with double sided
tape on 9" monitors. The Monitor may come loose and be a hazard or get damaged. If
using this type of mount, use screws to securely attach the base.
Self tapping Screws
or nuts and bolts are recommended
2: Slide the T-Bolt into the slot in the
rear of the monitor. Do Not use the
u-bracket when using a slid mount.
3: Adjust To the required level.
1: Remove the U-Bracket from the Monitor. Find a location that is desired for proper viewing.
Before mounting the bracket insure the Monitor doe not block any safety device or the drivers view.
2: Mount the U-Bracket securely uing self tapping screws or nuts and bolts (not provided).
3: Re-attach the monitor to the bracket and adjust to a desired viewing angle. Tighten the
thumb screws to insure the monitor is secure.
0605

08
Contents
1. Monitor
4: Turn the thumb screw clockwise to tighten into place at the desired height.
5: Adjust to the desired viewing angle and tighten the base thumb screw to secure.
07 08
WARNINGS:
ROSTRA ACCESSORIES IS NOT RESPONSIBLE FOR IMPROPER INSTALLATION, DAMAGE
TO THE VEHICLE, OR ACCIDENTS DUE TO IMPROPER USE. CAMERA SYSTEMS ARE ONE
OF MANY SAFETY FEATURES AND THE DRIVER HAS THE RESPONSIBILITY TO ALWAYS
INSURE SAFE OPERATION OF THE VEHICLE.
ALWAYS CONSULT A PROFESSIONAL INSTALLATION TECHNICIAN TO INSURE THE
INSTALLATION MEETS ALL LOCAL AND FEDERAL LAWS . SEE WWW.ROSTRA.COM FOR
WARRANTY INFORMATION.
