pag. 2
Series Mini 3 REV. 2015
3.
OPENING OF PACKAGE
1.
2.
3.
4.
5.
4.
CONNECTION AND STARTING
5.
COMPULSORY
TROLLEY
CONNECTION
HAND WHEEL FOR
STEAM ADJUSTMENT WATER LOADING
Fig. 2
Open the box containing MINI 3, take the instructions manual and read it carefully.
Remove MINI 3 from the box, insert the cable support deep into the special
support holder (fig. 1) placed on the back side of the generator.
Fix iron cable to the support hook (avoid twining).
For MINI 3 supplied with trolley (optional): screw the trolley knob on the proper
connection under the base of the machine (fig. 2).
HAND-WHEEL
With MINI 3 switched off and disconnected plug:
1. Unscrew the security valve plug (fig. 1), fill the
boiler with water (fig. 2) till overflow or at
pleasure. Take the plug by the plastic part and
screw it again: do not tighten too much or its
gasket might get spoilt.
Insert the plug into a 220 V 16 A socket.
Switch on the boiler (fig. 2 B), the iron (fig. 2 A)
and adjust the thermostat (fig. 3) on “cotton”.
Wait for the boiler lamp to switch off (fig. 2 C).
At this point seize the iron by cork handle and
press red button 3 or 4 times (fig. 4), so that
steam comes out: this operation must be carried
out in order to heat up the tubes which take
steam to the iron. In this way you prevent also
the falling of small drops of water on garments.
To adjust steam flow, you must work on the
hand-wheel for steam adjustment (fig. 2). During
ironing operation, the boiler lamp switches on
and off (fig. 2 C).
2.
3.
4.
Use only normal water coming from the aqueduct.
Never add additives to water.
Empty the boiler only when it is switched off and cold (with no
pressure). For carrying out this operation, wear gloves against possible
burns.
1.
2.
3.
Put the iron on its rubber iron rest (Fig.1).
