Rowley R-Tec Automation RTMDCHCBP User manual

© 2021 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 1
High Capacity Battery Pack
RTMDCHCBP
The small profile allows for optimal placement in the window pocket,
fully recharges in about 6 hours and can be paired with the optional
Solar Panel Battery Charger for continuous recharging.
High Capacity Battery Pack - The rechargeable Li-ion
Battery Pack enables DC Tubular Motors to operate
wirelessly and without the constraints of traditional battery
wands with disposable batteries.
FEATURES
Up to 500
Up / Down Cycles
on Single Charge
Recharges
in 6 hours
Battery Health
Status in R-TEC
Automation®App
Optional Solar
Panel for Continuous
Recharging
Small
Profile
1 2 3 4 5 6
500

© 2021 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 2
TABLE OF CONTENTS
Compliance Statement 3
Technical Data / Pack Contents 3
Product Specifications
Safety 4
Installation 5 - 6
Charging
Attachment Methods
Motor Connections
Scenario Example Using the Solar Panel Y Cable
Dimensions 7

© 2021 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 3
COMPLIANCE STATEMENT
This device complies with the essential requirements and is tested to comply with:
• UN38.3 - UN Transport Test and Criteria for Lithium Batteries.
• UL 2595, CSA C22.2 No. 0.23 - General Requirements for Battery-Powered Appliances.
Testing is conducted to cover all aspects of the UN Model Regulations, Manual of Test and Criteria, Part III, subsection 38.3,
including:
• Altitude Simulation
• Thermal Test
• Vibration
• Shock
• External Short Circuit
• Impact / Crush
• Overcharge
• Forced Discharge
Additionally, all battery products assemblies utilize an integrated charge management circuit which protects against over or
under charging. This circuit also enables individual cell balancing which ensures the longevity and integrity of the entire battery
pack.
Specification Value
TECHNICAL DATA / PACK CONTENTS
PRODUCT SPECIFICATIONS
Input Volts 12.6 V
Output Volts 12.0 V
Capacity 2600 mAh
Insulation Class III
Battery Size / Type 1 1/4" x 1 1/4" x 10" / Li-ion Rechargeable
Temperature Working Range 32º F - 140º F

© 2021 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 4
SAFETY
Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.
WARNING
Do no dispose of in general waste.
Please recycle batteries and damaged electrical
products appropriately.
CAUTION
• Do not expose to moisture or extreme temperatures.
• Do not allow children to play with this device.
• Use or modification outside the scope of this instruction manual will void warranty.
• Installation and programming to be performed by a suitably qualified installer.
• For use within DC Tubular Motors.
• Ensure correct crown and drive adaptors are used for the intended system.
• Do not cut power cables.
• Use only R-TEC Automation®hardware.
• Before installation, remove any unnecessary cords and disable any equipment not needed for powered operation.
• Do not drill into battery body.
• The routing of cable through walls shall be protected by isolating bushes or grommets.
• Ensure power cable is clear and protected from moving parts.
• If any cables are damaged, do not use.
IMPORTANT SAFETY INSTRUCTIONS TO BE READ PRIOR
TO OPERATION
• It is important for the safety of persons to follow the enclosed instructions. Save these instructions for future reference.
• Persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge
should not be allowed to use this product.
• Keep battery away from acid, aklali, heat and fire.

© 2021 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 5
CHARGING
ATTACHMENT METHODS
Charging uses the 2 pin locking “SMR” style connector.
Connect the High Capacity Battery Pack to the Battery Charger RTMLBC
or optional Solar Panel Battery Charger RTMSOLAR2.
Charge for 6 hours.
Install as required. See below attachment methods.
INSTALLATION
Rechargeable Battery Pack must be fully charged prior to
first use to prolong battery lifespan.
IMPORTANT
Do not install Rechargeable Battery Pack where it will be exposed to direct sun light.
IMPORTANT
Hook Screw Double Sided Tape*
High Capacity
Battery Pack
Battery
Charger
2 pin locking “SMR”
style connector

© 2021 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 6
After first full charge, battery condition can be
maintained through the use of an optional solar panel.
BEST PRACTICE
DC Tubular Motor
High Capacity Battery Pack
Solar Panel Y Cable
Solar Panel
Solar Panel
Battery Charger
OPTIONAL
OPTIONAL
RECOMMENDED
MOTOR CONNECTIONS
SCENARIO EXAMPLE USING SOLAR PANEL Y CABLE
Motor connections use the 2 pin, non-locking “JST” style connector
DC Tubular Motor Connection Cable

© 2021 Rowley®Company. All rights reserved. R-TEC Automation®is a registered trademark of the Rowley®Company, LLC. 7
DIMENSIONS
Any Questions?
Contact our R-TEC Automation®in-house experts at 866.985.3423. Email us at [e-mail].
10 1/2"7"
5 1/2"
1 3/8"
Mounting the Battery Pack to the Dustboard
*Power Cords plug into each other from the Motor to the Battery Pack. Keep cords away from rotating parts of the shade during operation.
Power
Cords*
Battery PackMotor
(fits inside Aluminum Roller)
Dustboard
