Royal Enfield HIMALAYAN BS VI 2021 User manual

FOREWORD
Thank you for choosing the Royal Enfield Himalayan.
Your new motorcycle is the product born from Royal Enfield’s vast experience of riding in the Himalayas since decades,
from exhaustive testing in all conditions, and our continuous striving for superior reliability and performance.
Please read this Owner’s Manual carefully before riding so that you will be thoroughly familiar with the proper operation
of the Himalayan’s controls, its features and capabilities.
To ensure a long and trouble-free life for your motorcycle, give it the proper care and maintenance described in this manual.
This Owner’s Manual should be considered a permanent part of your motorcycle and should remain with it even if your
motorcycle is subsequently sold.
The Himalayan features a Tripper™ navigation system, powered by Google Maps and the Royal Enfield App. You can use
it to connect your smartphone with the motorcycle through Bluetooth. To use the Tripper™ and to explore the many rides
around you, install the Royal Enfield App and follow the steps to register your Himalayan.
For support and information, please call 18002100007 anytime between 9 AM - 9 PM any day of the week.
—Team Royal Enfield.

2 Royal Enfield Himalayan
NOTICE
Part No. RAM00 333 /B / Qty. 3000 / Sep. 2021 / 10134
Disclaimer
1. Wash the motorcycle only with plain water. Do not use
any cleaning agen ts or det ergents, especially on
painted surfaces, as it will cause discoloration and
damage to the paint.
2. Do not polish your motorcycle as it will increase the
gloss level and damage the paint.
3. Scratches or marks on painted / plastic surfaces cannot
be removed OR touched up.
4. Warranty is not applicable for discoloration of the
Silencer & Exhaust pipe, as it is a natural process that
will happen during usage.
All information in this manual is based on the latest product
information available at the time of publication. Due to
continuous improvements, there may be discrepancies
between the information in this manual and your motorcycle.
Royal Enfield reserves the right to make production changes
at any time without prior notice and without incurring any
obligation to make the same or similar changes to motorcycles
previously built or sold.
All images shown are for reference to explain and need not to
be exactly the same on the model you own. Technical
specifications are subject to change without prior notice.
“© Copyright 2021 Royal Enfield (A unit of Eicher Motors Ltd.).
All Rights Reserved. No part of this manual shall be copied,
distributed or otherwise dealt without th e express
permission in writing of Royal Enfield”.
NOTE:
This motorcycle meets the BS VI Emission Norms
02

3
CONTENTS
Personal and Motorcycle Information ................................. 4
Royal Enfield Himalayan
Technical Specifications ........................................................ 5
Recommended Lubricants ................................................... 12
Safety Definitions .................................................................. 13
Motorcycle Identification Numbers ..................................... 14
Location of Key Parts ............................................................ 15
Operation of Controls .......................................................... 18
Pre-Operational Checks ....................................................... 48
Safe & Happy Riding ............................................................. 49
Cargo & Accessories ............................................................. 53
Rules of the Road .................................................................. 56
Running in Period ................................................................. 59
Warning Indications & Safety Systems ................................. 60
Starting ................................................................................. 64
Gear Shifting, Riding & Stopping ......................................... 66
Environment Care ............................................................. 70
Parking ................................................................................. 68
Periodical Maintenance Chart ......................................... 71
Tools Kit ............................................................................... 78
First Aid Kit ......................................................................... 79
Minor Maintenance Tips ................................................... 80
Long Trip Precautions ....................................................... 107
Shock Absorber .................................................................. 108
Off Roading ......................................................................... 109
Washing Procedure ........................................................... 111
Storage Precautions .......................................................... 116
Trouble Shooting ................................................................ 118
Warranty Terms & Conditions ......................................... 122
Emission Warranty ............................................................ 126
Service / Maintenance Record ......................................... 131
Notes .................................................................................... 132
03

4 Royal Enfield Himalayan
PERSONAL & MOTORCYCLE INFORMATION
Name
Door No./Street
Locality/Town
City Country
Contact Res: Off:
Mobile : Email :
Licence No. Valid Till :
Model Color :
Engine No.
Vin No.
Tyre make Front : Rear :
Tyre Nos. Front : Rear :
Battery make Battery No.
Sold by
Date of Sale
04

5
TECHNICAL SPECIFICATIONS
Royal Enfield Himalayan
ENGINE
Engine Type ............. Single Cylinder, 4 Stroke, SOHC,
................................. Air cooled, Fuel Injection
Bore ......................... 78 mm
Stroke ....................... 86 mm
Displacement .......... 410.94 cc
Compression ratio ... 9.5:1
Max Power ............... 24.3 bhp (17.88 kW) @ 6500 rpm
Max Torque .............. 32 Nm @ 4250 + 250 rpm
Idle rpm ................... 1300 + 100 rpm
Starting System ....... Electric Start
05
Air filter element ....... Paper element
Lubrication ............... Forced Lubrication, Wet sump
Engine oil capacity ... 2.3 l (Initial fill only),
.................................. 1.6 - 1.8 l (Subsequent Refills)
Engine oil grade........ SAE 15 W 50 API SL Grade
.................................. JASO MA 2 Semi Synthetic
Cooling ..................... Air cooled with Oil cooler
IGNITION SYSTEM
Ignition system ......... Electronic ECU / Variable
Spark plug ................. Bosch - UR5CC
Spark plug gap .......... 0.7 to 0.8 mm

6 Royal Enfield Himalayan
TRANSMISSION
Clutch ....................... Wet Multi Plates
Primary drive ............ Gear
Primary ratio ............. 2.312:1
Gear box ................... 5 Speed, Constant Mesh
Gear Ratios
st
1st Gear ................ 1 2.916:1
TECHNICAL SPECIFICATIONS
nd
2nd Gear ............. 2 1.833:1
rd
3rd Gear .............. 3 1.428:1
th
4th Gear .............. 4 1.173:1
th
5th Gear .............. 5 1.000:1
Secondary Drive ....... 5/8” Chain & Sprocket
Secondary Ratio ....... 2.533:1
Drive Chain links ....... 110 links
06

7
TECHNICAL SPECIFICATIONS
CHASSIS
Royal Enfield Himalayan
Frame ........................ Half duplex split cradle
Suspension
Front .................. Telescopic, Hydraulic Damping,
........................... Front wheel travel : 200 mm
Rear ................... Swing arm with Linkage type
........................... Hydraulic damping Mono shock,
........................... Rear wheel travel : 180 mm
Brakes
Brake system ..... Dual Channel ABS (Switchable
........................... to Single channel ABS -
........................... Rear Wheel ABS control
........................... deactivation)
07
Front Disc .......... 300 mm Dia disc.
Rear Disc ........... 240 mm Dia disc.
Tyre size
Front .................. 90 / 90 - 21
Rear ................... 120 / 90 - 17

8 Royal Enfield Himalayan
TECHNICAL SPECIFICATIONS
Steering lock ............. In built
Fuel Type .................. Unleaded Gasoline
CAUTION
n
Ethanol Content ....... E10 or less
The use of petrol containing more than the specified
ethanol may cause the fuel tank corrosion & paint
damage and may also damage the rubber tubes in the
fuel line as well.
nIt is recommended to use only unleaded petrol, as
leaded petrol may cause damage to the catalytic
converter.
08
Tyre Pressures
Solo
2
Front ................... 25 psi / 1.75 kg/cm
2
Rear ..................... 32 psi / 2.25 kg/cm
With Pillion
2
Front ................... 27 psi / 1.89 kg/cm
2
Rear ..................... 34 psi / 2.39 kg/cm

9
TECHNICAL SPECIFICATIONS
Royal Enfield Himalayan
* The above values are approximate and the actual
capacity may vary with each fuel tank.
09
Minimum Octane ..... 91 RON (Research Octane
rating Number) or Higher
Fuel tank capacity* ... 15 + 0.5 l approx *
Low fuel warning ..... Fuel Gauge (Red zone)
.................................. 5.5 + 0.5 l approx.*
Dead stock ................ 0.5 l approx.*
(unusable fuel)
ELECTRICALS
Flywheel magneto ....... 221 W @ 1500 rpm
Generation .................... Alternator, III Phase
System .......................... 12 V - DC
Battery .......................... 12 V - 8 AH Maintenance Free
Head lamp .................... 12 V, H4-60/55 W - BULB
Tail lamp / Brake lamp .. 12 V - 4/1 W LED
Licence Plate illuminator 12 V - LED
Front position lamp ...... 12 V - LED
Speedometer lamp ....... 12 V - LED

10 Royal Enfield Himalayan
TECHNICAL SPECIFICATIONS
WARNING
Using bulbs / electrical gadgets other than specified
rating may lead to overloading / erratic behaviour /
premature failure of electrical system.
Modifications or fitments which are not approved by
Royal Enfield, will seriously affect the performance of
the vehicle and will render the warranty void.
Hi beam indicator .......... 12 V - LED
Neutral lamp telltale ...... 12 V - LED
Turn signal telltale ......... 12 V - LED
Turn signal ..................... 12 V, 10 W * 4 Nos.
Horn ............................... 12 V, 2.5 A
Starter Motor.................. 12 V, 0.7 kW
Instrument Cluster ......... Digital cluster with LCD
Side Stand Indicator ....... LCD Indication
Malfunction Indicator ... 12 V - LED
ABS Indicator ................. 12 V - LED

11Royal Enfield Himalayan
DIMENSIONS
Length ............................ 2190 mm
Width .............................. 840 mm
Height ............................. 1370 mm
Wheel base ..................... 1465 mm
Ground clearance ........... 220 mm
TECHNICAL SPECIFICATIONS
Saddle Height ................. 800 mm
nValues / Dimensions mentioned above are for reference only.
nIn view of continuous improvements being done on our motorcycles, the specifications are subject to change without
prior notice.
WEIGHTS
Kerb weight (90% fuel & oil) .... 199 kg
Gross Vehicle Weight ................. 365 kg

12 Royal Enfield Himalayan
RECOMMENDED LUBRICANTS
Capacity
SAE 15 W 50 API SL Grade JASO MA 2
Semi Synthetic
ENGINE OIL
Grade
NOTE
Oil level should be up to “MAX” level. Do not overfill as it will affect the clutch functioning.
CAUTION
Using Non Recommended / In-Correct oils, can cause serious damage to the moving parts, affect performance of the
motorcycle AND void the warranty.
NOTE
Recommendation subject to change without notice.
FRONT FORK OIL
Capacity
Grade
455 ml/leg
10 W/Fork Oil
(Viscosity range 35)
BRAKE FLUID
Capacity
Grade
Front / Rear :
100 ml
DOT 4
2.3 l (First Fill only ) 1.6 - 1.8 l Approx.
(during oil & filter element replacement in
periodical maintenance)

13Royal Enfield Himalayan
The information given under the titles : Warning, Caution and Note are for your safety and for the care and safety to your
motorcycle and others. Please read these carefully and if disregarded may result in injury to yourself or others and damages
SAFETY DEFINITIONS
to the motorcycle.
NOTE
Indicates important and useful messages for clearer understanding.
All Images shown in subsequent pages are for reference to explain and need not to be exactly the same on the model you
WARNING
Indicates a potentially hazardous situation. Disregarding this message may result in injury to rider or other persons.
CAUTION
This message if disregarded may result in damage to the motorcycle.
own.

14 Royal Enfield Himalayan
MOTORCYCLE IDENTIFICATION NUMBERS
FRAME NUMBER
Punched on steering head tube right side.
ENGINE NUMBER
Punched on crankcase top side.
CAUTION
It is illegal to tamper with OR alter the VIN / Engine numbers of the motorcycle as it will not only against the law BUT will
render the vehicle registration and warranty VOID.

15
LOCATION OF KEY PARTS
1. Horn Button
Royal Enfield Himalayan
2. Turn Signal Switch
3. Head Lamp Dip Switch
4. Rear View Mirror Left Side
5. Instrument Cluster
6. Wind Shield
7. Tripper
8. Rear View Mirror Right Side
9. Engine Stop Switch
10. Electric Start Switch
11. Fuel Tank Cap

16 Royal Enfield Himalayan
LOCATION OF KEY PARTS
1. Front Trafficator Right Side
2. Horn
3. Oil Level Window
4. Rear Brake Pedal
5. Rider Foot rest Right Side
6. ABS Module
7. Pillion Foot rest Right Side
8. Rear Trafficator Right Side

17
LOCATION OF KEY PARTS
1. Front Trafficator Left Side
Royal Enfield Himalayan
2. Head Lamp
3. Tail Lamp
4. Rear Trafficator Left Side
5. Licence plate illuminator
6. Pillion Foot rest Left Side
7. Side Stand
8. Center Stand
9. Rider Foot rest Left Side
10. Gear Change Lever
11. ABS Module
12. Canister

18 Royal Enfield Himalayan
OPERATION OF CONTROLS
UNLOCKING:
nInsert key, turn clockwise to ignition “OFF” position. If
required, gently shake handle bar to help unlock
CAUTION
Do not force or attempt to lock / unlock steering if the
steering easily.
handle bar is not in extreme left or right side. Failure to
adhere to this caution will damage the lock and also cause
the key to bend or break.
WARNING
STEERING LOCK
LOCKING:
nTurn handle bar to extreme
left or right position.
nSwitch “OFF” ignition,
gently depress key and turn
anticlockwise further till
steering is locked and remove key. After unlocking steering AND before starting engine, check
the handle bar free movement by turning to both left and
right sides, several times.
Failure to do so may cause unstable riding, leading to a
potential accident, resulting in serious injury to both rider
and other road users, besides causing severe damage to
the motorcycle.
