Royal garden FCS70438RSTRGDS User manual

USE AND CARE GUIDE
7-PIECE STEEL SLING PADDED DINING SET - CHAIR
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday
[phone]
WWW.ROYALGARDEN.COM
THANK YOU
We appreciate the trust and condence you have placed in Royal Garden through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!
Model #FCS70438RSTRGDS

2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Care and Cleaning........................................................12
Warranty
Safety Information
Assembly ......................................................................5
Package Contents ....................................................................4
Hardware Included
....................................................................3
Safety Information .......................................................2
Product Caution .................................................................... 2
Safety Warnings ..................................................................... 2
PRODUCT CAUTION
This chair was made for theexplicit purpose of providing outdoor functions and is not to be used as a toy. This product is intended for
normal outdoor use; however, the manufacturer recommends storing and / or covering this chair when any formidable / severe weather is
he product.
Children under the age of 10, near the product, should be supervised by a competent adult at all times. Thisproduct is NOT intended for
commercial use and will void the warranty.
SAFETY WARNINGS
WARNING: Weightlimit for the chairsis 250 lbs CAUTION: When not in use, secure the product in acool
and covered location.
!
WARNING: Thischair unitis heavy, and may require two CAUTION: Do not place heavy objects on the chair.
!
1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
We warrant the frame and fabric to be free ofmanufacturing defects to the original purchaser for one year.
It remains thecustomer’s responsibility for freightand packaging charges to and from our servicecenter. This warranty does not cover
s warranty.
We reserve therightto make substitutions with similar merchandise, ifthemodel in question isnolonger in production.
(113.39 kg) for each seat.
adults for safe assembly.
Contact the Customer Service Team at [phone] or visit WWW.ROYALGARDEN.COM

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
AA
Part
Description
Quantity
AA M6x30combination bolt
36+1
BB
M6x15combination bolt 48+1
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size. NOTE: Hardware not shown to actual size. NOTE: Hardware not shown to actual size.
BB CC
DD EE FF
CC
M8x28combination hexbolt 24+1
DD
M8x20combination hex bolt 24+1
EE
Hex wrench 1
FF
Wrench 1
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.

4
Pre-Assembly
PACKAGE CONTENTS
Chair bucket
Left arm
Right arm
Support bar
6
6
6
6
A
B
C
D
Part Description Quantity
C
A
B
G
E
D
F
Left leg 6E
Right leg 6F
Connection bar
12
G

5
Assembly
1
Attach the right arm (C) to the chair bucket (A) using M6x30 combination bolts (AA).
Do not fully tighten the bolts at this step.
Connecting the right arm to the chair bucket
NOTE: Loosely tighten the bolts using the hex wrench (EE).
A
AA
C
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.

6
Assembly (continued)
2
Attach the left arm (B) to the chair bucket (A) using M6x30 combination bolts (AA).
Do not fully tighten the bolts at this step.
Connectingthe left arm to the chair bucket
A
AA
B
NOTE: Loosely tighten the bolts using the hex wrench (EE).

3
l
7
Assembly (continued)
Attach the support bar (D) to the chair bucket (A) using M8x20 combination hex bolts (DD).
Do not fully tighten the bolts at this step.
Connecting the support bar to the chair bucket
D
DD
DD
A
NOTE: Loosely tighten the bolts using the wrench (FF).
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.

l
8
Assembly (continued)
4
Connecting the left leg to the support bar
Attach the left leg (E) to the support bar (D) using M8x28 combination hex bolts (CC).
Do not fully tighten the bolts at this step.
E
D
CC
CC
NOTE: Loosely tighten the bolts using the wrench (FF).

5
l
9
Assembly (continued)
Connecting the right leg to the support bar
Attach the right leg (F) to the support bar (D) using M8x28 combination hex bolts (CC).
Do not fully tighten the bolts at this step.
F
D
CC
CC
.
NOTE: Loosely tighten the bolts using the wrench (FF).
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.

Attach the connection bar (G) to the front of the left leg (E) and the right leg (F) using M6x15 combination bolts (BB).
Do not fully tighten the bolts at this step.
l
10
Assembly (continued)
6
Connecting the connection bar
BB
BB
F
G
E
NOTE: Loosely tighten the bolts using the hex wrench (EE).

7
l
11
Assembly (continued)
Connecting the connection bar
Attach the connection bar (G) to the rear of the left leg (E) and the right leg (F) using M6x15 combination bolts (BB).
Do not fully tighten the bolts at this step.
NOTE: Loosely tighten the bolts using the hex wrench (EE).
G
BB
BB
E
F
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.

l
12
Assembly (continued)
8
Checking the chair
Onceall of thebolts are in place, fully tighten thebolts.
Turn the assembled chair right sideup.
Ensure all connectionsare securebefore use.
Care and Cleaning
For best results, clean the frame and fabric with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the chair in a dry, sheltered place when not in use.
Keep the chair away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.

Retain this manual for future use.
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday
[phone]
WWW.ROYALGARDEN.COM

USE AND CARE GUIDE
7-PIECE STEEL SLING PADDED DINING SET - TABLE
Questions, problems, missing parts? Before returning to the store
call Royal Garden Customer Service.
6 a.m. - 9 p.m., EST, 9 a.m. - 5p.m., PST Monday - Friday
[phone]
WWW.ROYALGARDEN.COM
THANK YOU
We appreciate the trust and condence you have placed in Royal Garden through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Royal Garden!
Model #FCS70438RSTRGDS

2
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included ................................................................
Package Contents ..................................................................
3
4
Warranty
1 YEAR FRAME WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchaser for one year.
WHAT IS NOT COVERED
Safety Information
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty. We
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Assembly ........................................................................5
Care and Cleaning ....................................................... 8
Safety Information .......................................................2
Product Caution .................................................................... 2
Safety Warnings ..................................................................... 2
PRODUCT CAUTION
This table was made for the explicit purpose of providing outdoor functions and is not to be used as a toy. This product is intended for
normal outdoor use; however, the manufacturer recommends storing and / or covering this table when any formidable / severe weather is
approaching. Do not locate thisproduct near open flames. Do not use this product as a support. Do not shake, lean or climb on the product.
Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is NOT intended for
commercial use and will void the warranty.
SAFETY WARNINGS
WARNING: Please keep children out of the assembly
area before assembly.
WARNING: This table unit is heavy, and may require
two adults for safe assembly.
CAUTION: Do not locate the product near any
heat source.
!
Contact the Customer Service Team at [phone] or visit WWW.ROYALGARDEN.COM

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
AA M6x30 combination bolt
Description QuantityPart
BB M6x25combination bolt
CC Hex wrench 1
12+1
12+1
CC
BB
AA
NOTE: Hardware not shown to actual size.
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part
Description
Quantity
Table rim 1
1
4
2
6
4
4
1
Leg connector
Tableleg
Support tube
Long tile
Middletile
Short tile
Stamped metal
A
B
C
D
E
F
G
H
A
B
C
D
EF
H
G

1
l
5
Assembly
Place the table rim (A) upside down on a soft surface.
Attach the table legs (C) and the support tubes (D) to the table top (A) using M6x30 combination bolts (AA).
Do not fully tighten the bolts at this step.
ATTACHING THE TABLE LEGS AND THE SUPPORT TUBES TO THE TABLE RIM
A
C
AA AA
D
NOTE: Loosely tighten the bolts using the hex wrench (CC).
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.

2
l
6
Assembly (continued)
Attach the Leg connector (B) to the table legs (C) and the support tubes (D) using M6x25 combination bolts (BB).
Do not fully tighten the bolts at this step.
ATTACHING THE LEG CONNECTOR TO THE TABLE LEGS AND THE SUPPORT TUBES
BB
BB
B
C
D
NOTE: Loosely tighten the bolts using the hex wrench (CC).

3
l
7
Assembly (continued)
Once all of the bolts are in place, fully tighten the bolts.
Turn the table right side up.
Carefully place the long tiles (E), the middle tiles (F), the short tiles (G) and the stamped metal (H) onto the table rim (A).
PLACING THE TILES
E
F
G
E
F
G
H
A
WWW.ROYALGARDEN.COM
Please contact [phone] for further assistance.
