RSA Lighting MINIACCURUS TZ5103 User manual

DESCRIPTION
www.cooperlighting.com
SPECIFICATION / FEATURES
Catalog # Type
Project
Comments
Prepared by
Date
30° Tilt x 90° Rotational Adjustment
30°
Flexible Conduit
Integral Electronic Low Voltage Transformer
with Thermal Protection and Wiring
Compartment in Cylindrical Enclosure
Acoustical Tee
Mounting Brackets
45°
45°
5.25”
3.90”
3.90”
1.70”
1.70”
18.00”
6.00”
2.00”
A...Housing
All aluminum construction with 18” of
flexible conduit attached to a cylindrical
transformer/wiring enclosure. Mounting
hardware suited for TechZone™ ceilings
exclusively.
B ...Trim:
3.9” o.d. square adjustable accent trim.
Finished in Armstrong® white.
C ...System Protection:
Thermal protection inside housing.
Vent holes in housing provide cooler
operation. All aluminum construction
provides overall reduced temperatures.
D...Electrical
Electronic transformer housed in a
separate metal enclosure. Enclosure
includes a separated wiring compartment
and entry for primary leads.
E ...Lamp
12V MR16 50 watts max. (not included)
“POSI-GRIP” bi-pin lamp socket for firm,
mechanical lamp connection. Can accept
up to two (2) optical accessories.
MINI
ACCURUS
Armstrong® TechZone™
Compatible
TZ5103
3.9” Square
Adjustable Trim
FOR 12V MR16 50 watts max.
ORDERING INFORMATION
TZ5103
3.9” Square Adjustable Accent Trim with 1.7” Square Opening.
Includes Housing with Integral Electronic Transformer and J-
box - Armstrong White finish with flat black internal finish
12V MR16 50W max.
3.9” Square Adjustable Accent MR16 trim. For use with Armstrong®
TechZone™ Ceiling products.
Trim face has Armstrong White finish with flat black internal finish
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
TZ5103
rev. 072007
