RSA Lighting LYNX TZ3002 User manual

DESCRIPTION
www.cooperlighting.com
SPECIFICATION / FEATURES
Catalog # Type
Project
Comments
Prepared by
Date
30° Tilt
Adjustment
Flexible Conduit
Integral Electronic Low Voltage
Transformer with Thermal Protection
and Wiring Compartment in
Cylindrical Enclosure
Acoustical Tee
Mounting Brackets
6.00”
3.50”
2.10”
18.00”
6.00”
2.00”
A...Housing
All aluminum construction with 18” of
flexible conduit attached to a cylindrical
transformer/wiring enclosure. Mounting
hardware suited for TechZone™ ceilings
exclusively.
B ...Trim:
3.5” o.d. round trim with adjustable
gimbal (30º tilt). Finished in Armstrong®
white..
C ...System Protection:
Thermal protection inside housing.
Vent holes in housing provide cooler
operation. All aluminum construction
provides overall reduced temperatures.
D...Electrical
Electronic transformer housed in a
separate metal enclosure. Enclosure
includes a separated wiring compartment
and entry for primary leads.
E ...Lamp
12V MR16 37 watts max. (not included)
“POSI-GRIP” bi-pin lamp socket for firm,
mechanical lamp connection. Can accept
up to two (2) optical accessories.
LYNX
Armstrong® TechZone™
Compatible
TZ3002
3.5” Round
Downlight
Adjustable Gimbal
FOR 12V MR16 37 watts max.
ORDERING INFORMATION
TZ3002
3.5” Round Adjustable Gimbal Trim
Includes Housing with Integral Electronic Transformer and
J-box - Trim face has Armstrong White finish
12V MR16 37W max.
3.5” Round Downlight MR16 trim with 30º adjustable gimbal. For use with
Armstrong® TechZone™ Ceiling products.
Trim face has Armstrong White finish with flat black internal finish
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
TZ3002
rev. 072007
