Catalog #
Type
Project
COMBOLIGHT® COMBO CLASSIC RECESSED
LAMP GROUP 3 - CONFIGURATION “D”
TWO (2) Halogen or Metal Halide lamps - TWO (2) Fluorescent lamps
New Construction Recessed Housing - Trim or Trimless
ORDERING EXAMPLE:
= Two PAR38 Metal Halide 70W lamps with Two BIAX® 40W Fluorescent • Black Interior • White Trim • 120 volts
CR338M70 DBX40 BK WH 120
Fluorescent >> BX40 BX50 PLL80 PLT26 PLT32 PLT42 T528 T535 T5HO39 T5HO54
Lamp Group 3
A68.98” 68.98” 68.98” 33.98” 34.98” 36.98” 115.98” 139.98” 91.98” 115.98”
B85.78” 85.78” 85.78” 50.78” 51.78” 53.78” 132.78” 156.78” 108.78” 132.78”
C25.50” 25.50” 25.50” 8.00” 8.50” 9.50” 49.00” 61.00” 37.00” 49.00”
RSA LIGHTING®
RSA LIGHTING LLC 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: [phone] • www.rsalighting.com
©2003 RSA Lighting LLC All Rights Reserved • Specifications subject to change without notice.
SPECIFY - D
380º x 45º locking
angular adjustment
45º visual cut-off
Fluorescent lamp cell
w/ integral ballast
accessible from below
Integral reflector
Butterfly Brackets for
Black Iron Mounting
Thermal Protector
Aromat® Electronic
Metal Halide
Ballasts
0.75" Trim
8.90"
10.38"
10.75"
8.80"
8.80"
B
A
C
Ceiling compund
is applied right
to the edge of the
fixture opening
T
R
I
M
L
E
S
S
D
E
T
A
I
L
T
R
I
M
D
E
T
A
I
L
Must specify a diffuser or louver
for fluorescent cell. See below.
Ballast
C
Integral reflector
Ballast
Optional Accessories - See RSA Combo Classic accessory page for details.
Baffle Snoots Louvers Lenses
Fluorescent Diffusers and Louvers - Please specify
❑ TWD - Textured White Diffuser ❑ CB1 - 2” Parabolic Louver
❑ MPD - Conical Prism Diffuser ❑ CB2 - 1” Parabolic Louver
Custom configurations are available with Combo Classic fixtures.
Also available with T8 fluorescent lamps. Consult RSA for details
DESCRIPTION:
An adjustable recessed fixture
suitable for multiple downlighting
applications with one point of elec-
trical entry. Mixes the use of metal
halide lamps with fluorescent
lamps. Powder coat finish on hous-
ing & lamp assembly.
CONSTRUCTION:
Housing, Plaster Frame & Trim
Assembly: 18 gauge CRS. J-Box
Assembly: 16 gauge CRS (galva-
nized). Fixture is offered with a .75”
ceiling trim or as a trimless fixture.
Can accommodate 0.50” to 1.00”
ceiling thickness.
LAMP ASSEMBLY:
Two Halogen or Metal Halide lamp
cells with two fluorescent lamp
cells . Can accept up to two optical
accessories. 380º x 45º locking
lamp adjustment. Provides 45º
visual cut-off.
SYSTEM PROTECTION:
Thermal protection provided to
guard against overheating, and
misuse of insulation over and
around fixture. Vent holes in hous-
ing provide cooler operation
ELECTRICAL:
Fixture is two circuit.
Circuit 1: Integral Aromat® elec-
tronic metal halide ballasts for
metal halide lamps. Halogen
lamps are line voltage.
Circuit 2: Integral electronic bal-
lasts for fluorescent lamps.
Lutron® dimming ballasts avail-
able upon request.
Junction box is UL listed for
through branch wiring, for 8 #12,
90°C supply conductors or 60°C for
end of run (access above ceiling
not required).
Made in the USA.
Item # / Lamp Type Configuration Fluorescent Lamp Cell Interior Finish Trim Finish Voltage
Lamp
Group 3
CR338 - PAR38 120V D - Two Halogen or Metal
Halide lamp cells with
Two Fluorescent lamp
cells
BX40 - 40W BIAX® BK - Black BK - Black 120 - 120 Volts
CR338M70 - PAR38MH 70W BX50 - 50W BIAX® WH - White WH - White 277 - 277 Volts
CR338M100 - PAR38MH 100W PLL80 - 80W PL-L S - Silver S - Silver
PLT26 - 26W PL-T PT - Custom PT - Custom
PLT32 - 32W PL-T TR - Trimless
PLT42 - 42W PL-T
T528 - 28W T5
T535 - 35W T5
T5HO39 - 39W T5HO
T5HO54 - 54W T5HO
T8 lamps also available
