LFS-PM-T43 operating manual 1
Chapter 1 Introduction
1.1 Product introduction
LFS-PM-T43 is a automatic distance control system that based on the capacity
sensor. This system has a 4.3” TFT touch screen and can display the work status and
detecting capacity value. An advanced capacity detecting technology has been
applied to have a stable and anti-interference capacity result. With this sensor
detecting technology, the responsibility and accuracy have been improved. The key
functions are just like following:
1) Control servo or step motors, high responsibility and accuracy。
2) Support crash alarm, limit trigger protection and servo alarm protection.
3) Automatic calibration and can compatible with the third party’s laser head.
4) Support focus distance modified on line. capacitor detecting scale is
0~9.9mm.
5) Work status of the laser head indicates and alarm indicates.
6) Support different setting of the rising height. Rising speed can be modified.
7) Auxiliary gas control. Support 3 channels auxiliary gas control。
8) Firmware updated by U disk。

LFS-PM-T43 operating manual 2
Chapter 2 Functions
1.2 4.3”touch screen
This distance controller is included of a 4.3” touch TFT screen. The resolution is 480X272.
the laser head work status is displayed in the monitor and parameters can be modified with the
monitor. the display area is function button area, data display area, running status display area and
alarm display area.
The main interface is just as the following:
⚫Function button area：touch the buttons can enter different function control menu.
⚫Data display：here is used to display the detecting value of the capacitor sensor and other
set values。
Focus position：the distance between the nozzle and the work piece.
Actual position：the actual value of the capacitor detected.
Following error：the error between the focus position and the actual position.
Capacitor value：the value that the controller has detect from the capacity sensor；
⚫Running status ：display the status of the laser head.
⚫Alarm display：alarm status display. If there are several alarm triggered at the same time,
user can touch the “alarm info”to check the alarm information in detail.
功能触控按钮
数据显示
运动状态
显示
报警信息
显示
功能触控按钮
Main interface
The communication between the the controller and the touch screen monitor is by RS232.

LFS-PM-T43 operating manual 3
If all the electrical connections has been done correctly, when power on the controller, the
monitor of the controller will go to the main interface. If there are no error happened, that means
the automatic distance controller work well.
But if the monitor indicate that connection failed because of the cable fault or other
reasons，”connection failed” will be popped up. User should check the cable and the sensor
devices.
1.3 Control functions
2.2.1 Main interface introduction
◆“tracing on/off”：Enable or disable the tracing function. If it is tracing on, the color of
the button will changed into green, which means the controller is under the tracing
status. If the height of work sheet changes, the laser head will tracing the movement of
the work sheet and always keep the distance to be a constant value. If it is tracing off,
the tracing function is disabled. If the height of the work piece changes, the laser head
has no response to that during the motion of the cutting system.
◆“fast/slow”：is used to switch the manual speed to faster or slow.。
◆“menu”：there are children menus in the menu to set some functions.
◆“reset”： To reset the distance controller. Before running reset function, be sure that
the upper limit has been installed correctly.
NOTICE: There is danger during the reset operation because of the mechanical motion.
So all the section should be checked before that and try to avoid of human harm.
◆“±0.1”：modify the distance between the nozzle and the work sheet. Press one time,
0.1mm will increase or decrease 。
◆“move up、move down”： to control the laser head to move up or move down. If the
button is pressed, the laser head will be always moving until the button is released.
◆“alarm info”： Press the button; user will go to the alarm information records interface.
User can check the alarm information that happened recently. The maximum number of

LFS-PM-T43 operating manual 4
the alarm record is 9.
◆“Function”： go to the auxiliary gas test and capacitor calibration menu
◆“system info”：check the version of the controller and multi-language
selection.
◆“system time”：modify the system time。
2.2.2 Parameter setting
Press“menu”to enter the interface of craft parameter setting, height parameter setting,
velocity parameter setting, machine parameter setting and other parameters.
Notice : Before operating the distance controller, be sure that the parameters has already set
correctly.
The sense of the parameters is shown as the table：
Control
PID filter
Increase the value will improve the responsibility of the
laser head.
Alarm time
Filter time for crash alarm protection. If the value is too
small, the crash alarm will usually triggered because of the
metal dross during cutting. If the value is too big, this will
decrease the responsibility of the crash alarm protection.
Gas delay
Auxiliary gas release time before cutting or piercing.
Pierce gas
Auxiliary gas selection for piercing.
Cutting gas
Auxiliary gas selection for cutting。

LFS-PM-T43 operating manual 5
Height
Rise posi
The rising height for laser head during jump motion。
Alarm posi
When the alarm triggered, the laser head is on the stop
height
Stdby posi
When the cutting task is finished, the laser head is on the
position.
Focus posi
The distance between the nozzle and the work piece
Reset posi
When reset the laser head, the laser head will trigger the
limit switch and move reversely for this distance
Follow error
During a close control, the error between the actual position
and referenced poison should never beyond the value. If that
happened, system protection will be executed and generate
the alarm of following error over limit
SPEED
Rising spd
Rising speed
Tracing spd
The maximum tracing speed。
Reset spd
Laser head reset speed
fast
The manual fast speed
slow
The manual slow speed
machine
polarity
Set the rotation of the motor
acc
Motion acceleration。
Screw pitch
Screw pitch
resolution
When the motor rotate one round, the number of control pulse
should sent to the motor drive
Other
parameters
Reset En
Enable or disable the reset when power on
Crash En
If the crash alarm is enabled, when the laser head has touched
the work piece for a certain time(over the filter time), system
will rise up the laser head and stop the motion of the cutting
system
If it is disabled, the crash alarm will be neglected.
Lmt SNS
Set the sense of the limit switch. If a NPN limit switch is

LFS-PM-T43 operating manual 6
installed, user should set the polarity to be negative. If it is
PNP, the polarity should be set to positive.
LMT EN
If the limit protection is enabled, when the limit is triggered,
the motion protection will take affect such as rising the laser
head and stop motion.
2.2.3 Parameter management
Parameters management is used to save and restore the parameters of the distance controller.
Not everybody can operate this function. There are passwords for user to manage this function.
When user has configured all the parameters correctly, then these parameters can be set to be
default. So if the parameters have been changed, user can restore the right parameters from the
default. We suggest that user must save the correct parameters to be default when all the
parameters have been tuned correctly.
2.2.4 Alarm information
On the main menu, press “ALM INFO”to go to “ALM INFO”interface.
User can check the alarm information. The information include of the alarm time and alarm
source. The maximum records are 9 records that is saved. Press the “clear”, all the information is
cleared. User still can press “page up”or “page down”to check the information.

LFS-PM-T43 operating manual 7
2.2.5 Calibration
In the main menu, press “FUNCTION”to go to “CALIBRATION”interface.
Calibration is very important for a correct application of the distance controller. If the laser
head has stand by for a very long time or the environment has changed a lot, a calibration should
be done. If user has change or replace some parts of the capacitor, the calibration must be done
again.
Before calibration, slowly moving the laser head to close to metal work piece and let the laser
head to be standby status. Make sure that the metal sheet has been connected to the EARTH well
and the machine also connects to the EARTH well. Then we can start a calibration. If the metal
sheet is not connected to the earth well, the calibration may be failed. If the laser head is always
moving down to touch the metal sheet and never stop, user should check the metal sheet conduct
with the machine well or not. If the conduction is ok, then check the electrical connection and the
capacitor sensor is good or not.
The normal calibration is just as the following:
⚫Laser head move down toward the metal sheet
⚫Touch the metal sheet and stop for while
⚫Then rise up to reach a position
⚫Then move down slowly
⚫Touch the metal sheet again then rise up to standby position
When the calibration is finished, a calibration curve will drew on the screen. The detection
scale is also displayed. The curve indicates the response of the capacitor when the distance is

LFS-PM-T43 operating manual 8
changed. If the curve is smooth and the value is in the desired scale, that means the calibration is
successful. User can press “OK”to save the calibration data. If the calibration is not smooth and
there are noises on it, that means the calibration is failed. User can press “CANCEL”to ignore the
result. User should not save the calibration data. User should check the reason that has caused this
situation and do the calibration again and again until the curve is smooth.
Because the capacitor is a sensitive to temperature and humidity of the environment, user
should wait 3~5 minutes when power on to let the sensor and amplifier to reach a stable
temperature.
2.2.6 Auxiliary gas test
In the main menu, press “FUNCTION”to go to the “AUXI GAS”interface.
This function is used to test the auxiliary gas is good or not. Auxiliary gas testing include of 3
channels auxiliary gas testing.
Testing steps：example for test the auxiliary gas with high pressure，press ”HP gas”，then the
auxiliary gas channel is turned on. Release the button, then turn of the channel.
Notice ：Before testing the auxiliary gas, make sure the control system is in the standby
status. Or the testing can not be done.

LFS-PM-T43 operating manual 9
2.2.7 System info
Press “SYS INFO”to go to system information interface.
This page include of the language selection and the version of the controller.
2.2.8 System time
In the main menu, press the “date and time”to go to modify the date and time.

LFS-PM-T43 operating manual 10
Chapter 2 Electrical Connection
1.4 Interface of the distance controller
The wiring diagram is just as follows：
+24V 直流电源
DC POWER
GND
PGND
被加工物体
CN7
1
2
3
4 5 6
Out3
Out2
Out1
Air
Blow_L
BloW_H
CN8
1
2
3 4 5
GND
DIR+
DIR-
PULSE+
PULSE-
CN3
6
5
4
3
2
1
Lmt+
Lmt-
EmStp
In1
In3
CN4
6
5
4
3
2
1
Trace
Punch
WrkOk
UpOk
DnOk
AlmOut
CN5
3
2
1
PGND
GND
+24V_IN
AC220V~50Hz
控制高压气
电磁阀
急停按钮
控制低压气
电磁阀
控制空气
电磁阀
1
2
3
4
5
6
Trace
Punch
WrkOk
UpOk
DnOk
AlmOut
OUT1
OUT2
OUT0
L_IN
FootSW
DrProc
RDC633xM主板 调高控制器
CN2
CN2
CN2
CN5
CN3
CN3
1 2
OVCC
OGND
CN6
In2
+24V
GND
+24V
GND
PGND
GND
上限位开关
下限位开关
2
1
Lmt+ CN3
CN3Lmt-
电机驱动器
Pul+
Pul-
Dir+
Dir-
激光切割头
3
2
4
4
3
2
RDC633XM主板
调高控制器
触摸屏
放大器连接线
注：主板相关接线请参考
主板接线说明
放大器
传感器连接线
电容传感器
喷嘴
CN4
CN4
CN4
CN4
CN4
CN4
3
GND
CN2 1CN1
GND

LFS-PM-T43 operating manual 11
3.1.1 Sensor interface
This interface is to connect the amplifier and distance controller。
When installing the amplifier, the shield of the amplifier should be have good conduction
with the laser head (sensor and nozzle). There a wiring terminal on the shield of the amplifier.
User can connect the terminal to the laser head. The metal sheet should still have a good
conduction with the machine. Or the capacity sensor will not work normally.
3.1.2 CN1 ----RS232
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN 1
TXD
send data
—
PIN 2
RXD
Receive data
—
PIN 3
GND
GND
—
3.1.3 CN2----analog interface
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN1
AGND
Analog GND
PIN2
Analog In
Analog input
Input scale：0—10V
PIN3
Analog Out
Analog output
Output scale：0—10V
3.1.4 CN3----general input and output
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN1
Lmt+
UP limit
24V level
PIN2
Lmt-
Down limit
24V level
PIN3
EmStp
Emergency input
Low level valid
PIN4
In1
General input
—
PIN5
In2
General input
—
PIN6
In3
General input
—
Limit switch include of up limit and down limit in the Z axis. support N.C and
N.O mode. If the limit is N.O, the polarity should be set to be negative. If the
limit is N.C, the polarity should be set to be positive.

LFS-PM-T43 operating manual 12
The limit switch can be mechanical, opto-electric and magic type. But all the
limit should be 24V standard. It can be OC interface mode.
3.1.5 CN4 control input
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN1
Trace
随动控制信号输入
低电平时，处于随动下降并跟随，高电平
时，处于随动上升
PIN2
Punch
穿孔信号输入
板卡穿孔信号，穿孔时，为低电平
PIN3
WrkOk
工作完成信号输入
工作完成状态信号输入，用于指示当前工
作是否完成
PIN4
UpOk
上升到位信号输出
调高器上升到位则输出低电平
PIN5
DnOk
下降到位信号输出
调高器下降到位则输出低电平
PIN6
AlmOut
报警信号输出
当调高器发生报警时，该信号输出高电平，
正常情况下输出低电平
控制主板与调高器之间采用 IO 口控制，其中包括：随动信号、穿孔信号、工作完成信
号、上升到位信号、下降到位信号以及报警信号。接线如下图所示。
1
2
3
4
5
6
Trace
Punch
WrkOk
UpOk
DnOk
AlmOut
OUT1
OUT2
OUT0
L_IN
FootSW
DrProc
RDC633xM主板 调高控制器
CN2
CN2
CN2
CN5
CN3
CN3
3
2
4
4
3
2
CN4
CN4
CN4
CN4
CN4
CN4
3
GND
CN2 1CN1
GND
3.1.6 CN5 为外部输出接口
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN1
+24V_IN
+24V 电源输入
+24V 电源输入，电源电流输出能力大于 2A
PIN2
GND
电源参考地
—
PIN3
PGND
外部屏蔽地
一般接大地、机壳
3.1.7 CN6 为外部输出接口
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN1
OGND
外部电源参考地
外部参考地
PIN2
OVCC
外部+24V 电源输入
为CN7 端子输出 IO 口提供 24V 电源

LFS-PM-T43 operating manual 13
3.1.8 CN7 output
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN1
Blow_H
High pressure gas control
Drive relay
PIN2
Blow_L
normal pressure gas control
Drive relay
PIN3
Air
Air control
Drive relay
PIN4
Out1
General output
—
PIN5
Out2
General output
—
PIN6
Out3
General output
—
3.1.9 CN8 motor control interface for step mode
PIN
SIGNAL
DEFINITION
DESCRIPTION
PIN1
Pulse-
—
—
PIN2
Pulse+
—
—
PIN3
Dir-
—
—
PIN4
Dir+
—
—
PIN5
GND
GND
—
1) To control step motor, differential mode and common-anode mode can be applied. We
recommend user to select differential mode .
PULSE+
PULSE-
DIR-
DIR+
DIR-
PULSE+
PULSE-
DIR+
调高器
电机驱动器
GND GND
2) To control servo motor, please set the parameters correctly according to the operation
manual of the servo drive。
◆Set the servo drive to work at the position mode.
◆The polarity of the pulse and direction.
◆The number of pulse/per round
3.1.10 MOTOR control interface for servo mode

LFS-PM-T43 operating manual 14
PIN（color of wire）
signal
definition
PIN1（yellow）
SPEED
+/-10V speed command
PIN2（blue）
OS
Zero speed
PIN3（black）
A+
Encoder A+
PIN4（orange）
B+
Encoder B+
PIN5（red）
Z+
Encoder Z+
PIN6（green）
SON
Servo on
PIN7（green/white）
CLR
Alarm clear
PIN8（brown）
+24V
+24V output
PIN9（yellow/white）
AGND
Analog GND
PIN10（blue/white）
GND
GND
PIN11（black/white）
A-
Encoder A-
PIN12（orange/white）
B-
Encoder B-
PIN13（red/white）
Z-
Encoder Z-
PIN14（purple）
ALM
Servo alarm input
PIN15（brown/white）
GND
GND
3.1.11HMI
The connection between the distance controller and the displayer is shown as
follows:
5芯线颜色 触摸屏端子
R
V
T
红色
蓝色
棕色
黄色
G
3.1.12 USB
USB is a U disk interface that used to upgrade the firmware.
LAN is a ETHERNET interface.

LFS-PM-T43 operating manual 15
1.5 Led Indicator
LED name
Description
+24V
24V Power indicator
Run
System running indicator
Trace
Tracing signal indicator.
Punch
Piercing indicator
WrkOk
Work finish indicator
UpOk
Rising up ok indicator
DnOk
Tracing down ok indicator
AlmOut
Alarm indicator.
Lmt+
Up limit indicator. Low level input will turn on the led
Lmt-
Down limit indicator. Low level input will turn on the led
EmStp
Emergency stop input. Low level input will turn on the led
In1
Low level input will turn on the led
In2
Low level input will turn on the led
In3
Low level input will turn on the led
Status
U disk status
Alm
Servo alarm input. Low level input will turn on the led
Clr
Servo alarm clear. Low level input will turn on the led
Os
Zero speed status. Low level input will turn on the led
Son
Low level input will turn on the led
Pulse
Pulse signal indicator. Low level input will turn on the led
Dir
Direction signal indicator. Low level input will turn on the led
Blow_H
High pressure gas control output. Low level input will turn on the led
Blow_L
Normal pressure gas control output. Low level input will turn on the led
Air
Air control output. Low level input will turn on the led
Out1
Low level input will turn on the led
Out2
Low level input will turn on the led
Out3
Low level input will turn on the led

LFS-PM-T43 operating manual 16
Chapter 2 Test and Run
Test and run is based the RDC6332M cutting controller and the control software is Metal
Cut.
1.6 Distance controller test
Before we start the distance controller test and run, the cutting control system and the
distance controller should be wired correctly.
When you want to start a normal testing, the user parameter and vendor parameter should
be configured correctly. Shown as the following:
MetalCut→FILE→VENDOR SETTING→OTHERS→to enable “ENABLE PROTECT”：
MetalCut→VENDOR SETTING→SPECIAL→(the password is rdtsmm)→height controller
type(common)→check follow up(use trigger)→check follow(use trigger).
Shown as following:
