Russell Hobbs RHPH2001 User manual

Plug In Heater
For Customer Services & Spare Parts please call0345 2097461
Or visit us at https://mda.russellhobbs.com
PLEASE RETAIN
FOR FUTURE REFERENCE
Model Number:
RHPH2001
220-240V AC 50Hz 500W
This product is only suitable for well insulated spaces or occasional use

Page(s)
Safety Instructions and Electrical Safety
3 –6
Positioning
7
Feature
Diagram 8
Control Panel
9
Using
your Plug In Heater 9 - 11
Cleaning
and Care 12
Problem
Solving 13
Guarantee
and Customer Services 14
Connection
to the Mains Supply 15
Specification
16
Notes
17 -19
Disposable
Information 20
CONTENTS
Page 2

SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should
always be observed, including the following:
•Read all instructions.
•Check that the mains voltage corresponds with the rating on
the appliance.
•The appliance must not be left unattended while it is connected
to the mains supply.
•Do not touch hot surfaces. Use the handle or the controls.
•To protect against electrical shock do not immerse cord, plug, or
appliance in water or other liquid. Do not operate with wet
hands.
•Do not let the cord hang over the edge of a worktop, table etc.
or touch hot surfaces.
•Do not operate any appliance with a damaged cord or plug, or
after the appliance malfunctions or is dropped or damaged in
any manner.
•The use of accessory attachments is not recommended by the
appliance manufacturer may cause fire, electric shock or injury.
•This appliance must not be immersed in any liquid
•To disconnect, remove the plug from the mains outlet.
•Warning: In order to avoid overheating, do not cover the
heater.
•Never remove parts from the appliance, such as the feet,
screws and so on.
•Never use the appliance near a bath, shower or a swimming
pool.
Page 3

SAFETY INSTRUCTIONS
•Never place flammable objects or clothing on top of the
appliance.
•Allow a 30cm safe area around the appliance on the top and
bottom, 50cm safe area on the sides and a 150cm safe area at
the front.
•Never use the appliance in a room with explosive gas such as
petrol, or while using any kinds of flammable glues, sprays or
solvents.
•Prevent overheating of the appliance by keeping the air inlets
and outlets clean and free of anything that may cause blockage.
Check all inlets and outlets regularly for accumulated dust. DO
NOT COVER.
•Do not place any part of your body near the air inlet or outlet,
to avoid personal injury, electric shock or fire.
•If overheating should occur, the built-in overheating safety
device will shut the appliance off. Note, the appliance will turn
on again when it has cooled down sufficiently.
•Do not insert any foreign objects into the ventilation or grill.
•Keep all ventilation clear of any draped fabric or curtains.
•The appliance must not be plugged in a extension lead or plug
adaptor. A fire risk exists if the appliance is covered or
positioned incorrectly.
•Caution: Some parts of this product can become very hot and
cause burns. Particular attention must be given when children
or vulnerable people are present.
•Do not operate this appliance for anything other than its
intended use.
•This appliance is not intended for commercial use.
•This product is intended for household use only. Do not use
outdoors.
Page 4

SAFETY INSTRUCTIONS
•This product is only intended for heating.
•Warning: It is hazardous for anyone other than a competent
person to carry out any service or repair operation which
involves the removal of a cover which gives protection against
exposure to electrical parts.
•When scrapping the heater, follow the regulations concerning
the disposal.
•Warning: Children should not use this appliance. Close
supervision is necessary when any appliances are used near
children.
•Warning: Children of less than 3 years should be kept away
unless continuously supervised.
•Warning: Children aged from 3 years and less than 8 years shall
only switch on/off the appliance provided that it has been
placed or installed in its intended normal operating position and
they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved.
•Warning: Children aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance or perform user
maintenance.
•Warning: This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to make sure that they do not play with or
use the appliance.
Page 5

SAFETY INSTRUCTIONS
•Warning: In order to avoid overheating, do not cover the heater
•Warning: This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to make sure that they do not play with or
use the appliance.
•Warning - Do not touch hot surfaces, do not block openings or
cover appliance.
Electrical Safety
THIS APPLIANCE MUST BE PLUGGED INTO AN EARTHED SOCKET
•Before switching on, make sure that the voltage of your
electricity supply is the same as that indicated on the rating
plate. This product is designed to operate on 220 –240V AC;
50Hz. Connection to any other power source may damage the
unit.
•This product may be fitted with a non re-wireable plug. If it is
necessary to change the fuse in the plug, the fuse cover must be
refitted. If the fuse cover becomes lost or damaged, the plug
must not be used until a suitable replacement is obtained.
•If the plug has to be changed because it is not suitable for your
socket, or becomes damaged in any way, it should be cut off and
an appropriate plug fitted. This should be carried out by a
qualified electrician. The plug removed must be disposed of
safely, as insertion into a 13 Amp socket is likely to cause an
electrical hazard.
Page 6

SAFETY INSTRUCTIONS
Positioning
•The heater can be positioned in the upright position (Control panel
is at the top):
•The distance between the heater bottom and the ground should be
more than 30cm.
•The distance between the side of the heater and the wall or any
other object should be more than 50cm.
•Heats up to 10 square metre (107 square foot) room.
Page 7

FEATURE DIAGRAM
For Customer Services & Spare Parts please call 0345 209 7461
Or visit us at https://mda.russellhobbs.com
1. Control panel & display
2. Buttons
3. Air outlet
4. Power indicator light
5. ON/OFF switch
Page 8
1
2
35
4

CONTROL PANEL
Page 9
On/Standby
Speed Fan mode selection (low/high)
Temp + Increase the temperature setting
Temp - Decrease the temperature setting
Timer Timer setting function (0 –12 hours)
USING YOUR PLUG IN HEATER
Heats up to 10 square metre (107 square foot) room
1. Plug the heater into a suitable power outlet, ensuring all the
positioning instructions are followed.
Note: The heater must be in the upright position (Control panel
is at the top). The distance between the heater bottom and the
ground should be more than 30cm, the distance between the
side of the heater and the wall or any other object should be
more than 50cm.

USING YOUR PLUG IN HEATER
Page 10
2. Press the ‘ON/OFF’ switch on side of the unit to “On” position.
The heater will turn on.
3. Press the ‘ ‘ button, the heater start running
4. Press the ‘Temp. +’ button to increase the temperature setting
or press the ‘Temp. –’ button to decrease the temperature
6. To adjust the speed of the fan to high or low press the ‘Temp. –’
and ‘Temp. +’ buttons simultaneously. The display will show LL for
low mode and HH for high mode
7. To set the timer function (0 – 12 hours) press the ‘Timer’
button. The display will show 0, press the timer button until you
have set the timer to the number of hours you want the heater to
run for before it will power itself off. The hour options for the
timer are from 0 to 12 hrs. (in 1 hr increment).
8. When finished, press the ‘ ‘ button and the heater will stop
the heating process immediately. However the fan will continue to
operate for approximately 1 minute to allow for the interior
components to cool. The fan will then turn off automatically. Turn
the power switch at the side of the heater to the ‘OFF’ position
and unplug heater from power outlet.
Note:
•The product will run continuously unless the timer has been
set or you turn off the power.
•When powering off the heater, the heater will stop the
heating process immediately. However the fan will continue
to operate for approximately 1 minute to allow for the interior
components to cool. The fan will then turn off automatically.

USING YOUR PLUG IN HEATER
Page 11
Safety Protective Devices
The appliance is fitted with an over heat protection system
•Overheat protection - the power to the heating elements
will automatically cut off if the temperature of the heating
elements exceeds a certain limit. In the event of
overheating, the heater will stop operating. Switch the
appliance off and allow it to completely cool.
Note: Overheating can be caused by obstruction to the air
intakes on the back of the machine or the grill on the front. If
this occurs please disconnect the machine and allow it to cool
for 30 minutes. Remove any obstruction and turn the
machine back on.

CLEANING AND CARE
Page 12
WARNING: Electrical Shock Hazard.
Before you clean the appliance, disconnect the mains plug from
the wall socket.
•Allow the appliance to cool down completely before
cleaning.
•Do not immerse cord, plug or appliance in any liquid or allow
moisture to come into contact with electrical parts.
•Clean the outer surface using a moist cloth and wipe over
with a dry, soft cloth.
•Do not use harsh detergents, abrasives or spray on cleaners.
•Don’t allow water to seep into the openings or come into
contact with electrical connections.
•Allow sufficient drying time before operating again.
•Clean the air inlets and outlets regularly with a vacuum
cleaner using the brush attachment (with a regular use, at
least twice a year).
•When the appliance is not in use. We recommend that, the
heater is re-packed in its original packaging and stored in a
cool, dry place.

PROBLEM SOLVING
Page 13
My appliance does not work when I turn it on:
1. Check that your appliance is plugged in and the power is
turned on at the mains socket.
2. Try another mains socket.
3. Check the appliance is in an upright position.
4. Check that the thermostat setting has not been set too low.
5. The air inlets are not obstructed
6. If the appliance still doesn’t work, do not try to repair it
yourself.
If your appliance power is automatically cut off, follow the step
below:
1. Unplug your appliance from the mains socket and allow it to
completely cool down.
2. Inspect your appliance. Clean the air inlet and air outlet with
a vacuum cleaner if necessary. If there are any signs of
physical damage (e.g. melting, or burning of the case), do
not attempt to use the appliance. Please leave all
maintenance work to qualified personnel.
3. Plug in the appliance and switch it on again. If it cuts off
again, move the appliance to a better ventilated location.

At Russell Hobbs, we take all our customer feedback seriously.
Feel free to contact our Customer Service Team, on 0345 209 7461,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the original
purchase. If any defect arises due to faulty materials or workmanship,
the faulty product must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with the original proof of
purchase.
• The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
• It must be used for domestic purposes only and for its intended use.
• This warranty does not cover wear and tear, damage, misuse or
consumable parts.
This does not affect your statutory rights.
Imported by
G2S LIMITED
WIGAN
WN2 4AY
GUARANTEE AND CUSTOMER
SERVICES
Page 14
For Customer Services & Spare Parts please call 0345 209 7461
Or visit us at https://mda.russellhobbs.com

CONNECTION TO THE MAINS
SUPPLY
Page 15
This appliance is designed to operate from a mains supply of
220-240V~50Hz.
Check that the voltage marked on the product corresponds
with your supply voltage.
How to change the fuse
1. Slot the end of a screwdriver into the recess in the fuse
holder of the plug.
2. Pull the fuse holder upwards until free of the plug and slide
the fuse out.
3. Replace the fuse and replace fuse holder, pushing down
until locked into place.
Important: Only ever use a 5 amp fuse.

SPECIFICATION
Page 16
Model number RHPH2001
Rated voltage 220V -240V ~ 50Hz
Power consumption 500W
Product dimensions (CMS) (H)18 x (W)10.6 x (D)11.4
Model number
RHPHP2001
Item Symbol Value Unit Item Unit
Heat output
Type of heat input, for electric storage local space heaters only
Nominal heat
output
Pnom 0.5 kW
manual heat charge control, with
integrated thermostat
NA
Minimum
heatoutput
(indicative)
Pmin 0 kW
manual heat charge control with
room and/or outdoor temperature
feedback
NA
Maximum
continuous heat
output
Pmax,c 0.5 kW
electronic heat charge control with
room and/or outdoor temperature
feedback
NA
fan assisted heat output
NA
Auxiliary electricity consumption
Type of heat output/room temperature control
At nominal heat
output
elmax 0 kW
single stage heat output and no
room temperature control
No
At minimum heat
output
elmin 0 kW
Two or more manual stages, no
room temperature control
No
In standby mode
elSB 0.00038 kW
with mechanic thermostat room
temperature control
Yes
with electronic room temperature
control
No
electronic room temperature
control plus day timer
Yes
electronic room temperature
control plus week timer
No
Other control options (multiple selections possible)
room temperature control, with
presence detection
No
room temperature control, with
open windowdetection
No
with distance control option
No
with adaptive start control
No
with working time limitation
Yes
with black bulb sensor
No
Contact details
G2S LIMITED
WIGAN, WN2 4AY

NOTES
Page 17

NOTES
Page 18

NOTES
Page 19

Page 20
This symbol is known as the 'Crossed-out wheelie bin Symbol'. When
this symbol is marked on a product/batteries, it means that the
product/batteries should not be disposed of with your general
household waste. Only discard electrical/electronic/battery items in
separate collection schemes, which cater for the recovery and recycling
of materials contained within. Your co-operation is vital to make sure the
success of these schemes and for the protection of the environment. For
your nearest disposal facility, visit www.recycle-more.co.uk or ask in
store for details. We reserve the right due to possible changes to design
to alter the instruction manual without prior notice.
Revision 1
Model Number:
RHPH2001
For Customer Services & Spare
Parts please call 03452097461
Or visit us at
https://mda.russellhobbs.com
