Ryobi RY09056 Quick setup guide

RYOBI
Blower/Vacuum
Manufacturing No. 090155034
Item No. RY09056
Repair Sheet

RYOBI BLOWER/VACUUM – ITEM NUMBER RY09056
2
Figure A
8
10
4
9
13
15
19
22
4
4
18
17 16
16
17
12 11
7
6
See Figure B
14
3
1
4
2
21
20
5

RYOBI BLOWER/VACUUM – ITEM NUMBER RY09056
3
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE A)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
BLOWER/VACUUM or when ordering repair parts.
1 678726001 Vacuum Door Spring ................................................................................................................1
2 940654088 Combustion Label....................................................................................................................1
3 521500008 Vacuum Door............................................................................................................................1
4 660621001 Vacuum Tube Screw (10-14 x 1/2 in.) ......................................................................................4
5 940705075 Logo Label (Large) ...................................................................................................................1
6 941727004 Warning Label ..........................................................................................................................1
7 940752006 Logo Label (Small)....................................................................................................................1
8 870174001 * Spark Plug (RCJ6Y)..................................................................................................................1
9 901696001 Filter .........................................................................................................................................1
10 310816015 Fuel Cap Assembly ..................................................................................................................1
11 940868001 Choke Label .............................................................................................................................1
12 940734083 Starting Label...........................................................................................................................1
13 310804001 Air Filter Cover (Inc. Key 14).....................................................................................................1
14 590461001 Knob.........................................................................................................................................1
15 521504001 Vacuum Handle ........................................................................................................................1
16 650027001 E-Ring ......................................................................................................................................2
17 660880001 Screw (1/4-20 x 3/4 in.)............................................................................................................2
18 580892001 Upper Vacuum Tube.................................................................................................................1
19 570562001 Lower Vacuum Tube.................................................................................................................1
20 580956002 Vacuum Bag Adaptor ...............................................................................................................1
21 360152002 Blower Tube Assembly.............................................................................................................1
22 900960001 Vacuum Bag w/Shoulder Strap................................................................................................1
Not Shown:
991000155 Operator’s Manual (960606012)
5-20-16
(Rev:02)

RYOBI BLOWER/VACUUM – ITEM NUMBER RY09056
4
Figure B
1
6
7
7
89
10
11
24
25
26
27
28
29
30
31
54
55
33
35
20
20
36
34
32
12 13
14
15 16 1718
48
21
20
19
23
22
1
37
40
52
53
41
42 43
44
45
46
47
49
50
51
38
39
57
4
3
5
56
2

RYOBI BLOWER/VACUUM – ITEM NUMBER RY09056
5
29 521316001 Starter Pulley .......................................................1
30 638389001 Pulley Retainer..................................................... 3
31 660967001 Screw (M4 x 14 mm, T.F.) .................................... 3
32 650017002 Washer.................................................................1
33 308811007 Flywheel Assembly ..............................................1
34 308892021 Short Block Assembly (Incl. Key Nos. 51-53)...... 1
35 308461001 Engine Cover .......................................................1
36 901362003 Muffler Gasket .....................................................1
37 309327009 Muffler Assembly.................................................1
38 638442009 Muffler Heat Shield..............................................1
39 660638003 Screw (10-24 x 2-1/8 in.) .....................................2
40 660927007 Screw (10-24 x 2.5 in.)......................................... 2
41 518920001 Heat Dam.............................................................1
42 638659002 Washer.................................................................2
43 660927003 Screw (M5 x 25 mm)............................................2
44 521505001 Baffle....................................................................1
45 901552002 Heat Dam Gasket ............................................... 1
46 308054034 Carburetor ...........................................................1
47 561635001 Primer Bulb..........................................................1
48 290469001 Ground Wire Kit ...................................................1
49 521309004 Air Box Base........................................................1
50 678868001 Hex Nut (10-24) ...................................................2
51 901550003 Crankcase Cover Gasket.....................................1
52 638337001 Crankcase Cover.................................................1
53 660925003 Screw (M4 x 12 mm)............................................6
54 310752028 Fuel Tank Assembly w/Cap .................................1
55 660970002 Screw (M4 x 14 mm, Shoulder) ...........................3
56 310976001 Fuel Filter .............................................................1
57 901551001 Intake Gasket.......................................................1
The model number will be found on a label attached to the engine housing. Always mention the model number in all correspondence regarding your
BLOWER/VACUUM or when ordering repair parts.
PARTS LIST (FIGURE B)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
1 660629002 Screw (10-14 x 3/4 in.).........................................9
2 521313014 Outer Volute ........................................................1
3 660561007 Blower Fan Nut.................................................... 1
4 650016001 Washer ................................................................1
5 518265003 Fan ......................................................................1
6 638517001 Spacer ................................................................1
7 660970001 Screw (M4 x 17 mm, T.F.) ....................................4
8 660666001 Screw (8-14 x 1 in., T.F.).......................................1
9 678125001 Washer.................................................................1
10 518160010 Cruise Control Lever............................................ 1
11 308981042 Lower Housing .................................................... 1
12 518603002 Throttle Lever.......................................................1
13 661141001 Screw (M3.5 x 7.5 mm)........................................1
14 521503001 Throttle Trigger ....................................................1
15 518602001 Trigger Lock......................................................... 1
16 760961002 Momentary Contact Switch.................................1
17 290157002 Wire Assembly.....................................................1
18 270031002 Throttle Cable ......................................................1
19 521501001 Handle Cover ...................................................... 1
20 660466001 Screw (M4 x 18 mm)............................................5
21 660968001 Screw (M4 x 19 mm, T.F.) .................................... 2
22 850108031 Ignition Module....................................................1
23 308563022 Lower Housing w/Starter
(Incl. Key Nos. 24-31) ..........................................1
24 900849012 Starter Rope (42 in.).............................................1
25 525485002 Starter Grip ..........................................................1
26 638088004 Eyelet...................................................................1
27 521535001 Shield...................................................................1
28 638033001 Spring & Container ..............................................1
