SAB Heli Division Goblin Helicopter Kraken User manual

8 – Head Assembly
9 – Assembling of the modules
10 – Installation of The Motor
11 – Installation ESC
12 – Tail Group Assembly
13 – Tail Boom Assembly
14 – Low Side Frame Installation
15 – Landing Gear Installation
1 – Introduction
2 – Important Notes
3 – Note for Assembly
4 – Carbon Rod Assembly
5 – Transmission Group Assembly
6 – Swashplate Servos Assembly
7 – Frame Group Assembly
INDEX
16 – Installation FBL/RX
17 – Installation Batteries
18 – Installation Canopy
19 – In flight
20 – Maintenance
21 – Transmission Module
22 – Check list
23 – Spare Parts
http://www.goblin-helicopter.com
Please read this user manual carefully, it contains instructions for the correct assembly of the model.
Please refer to the web site
www.goblin-helicopter.com for updates and other important information.
VERY IMPORTANT
It is extremely important that you take a moment to register your helicopter with us. This is the only way
to ensure that you are properly informed about changes to your kit, such as upgrades, retrofits and other
important developments. SAB Heli Division cannot be held responsible for any issues with your model
and will not provide support unless you register your model.
The Serial number is also engraved in the Aluminum part.
Thank you for your purchase, we hope you enjoy your new Goblin helicopter!
SAB Heli Division
You will find your serial number on the RED plate of the transmission module and on the product card
included with your kit.
Please take a moment to register your kit online via our web site at:
Page 1
INTRODUCTION

365mm
15
7
8mm
Typical Speed Controller: 12S, 160/200 A
Battery compartment: 12S, 4200/5500 mAh.
(max 56mmx70mmx320mm).
Suggested weight from 1400gr to 1700gr.
Typical Motor : 12S, 500-560 Kv, 4525 - 4530 series,
(max 62 mm diameter, max 70 mm height).
190mm
• AIRFRAME weight: 2720 ( with blades, no battery, no electronics ).
• Main rotor diameter: 1578 mm (with 700 mm blades).
• Main blade length: 650 to 730mm.
• Tail rotor diameter: 284 mm (with 105 mm tail blades).
• Tail blade length: 105 to 115 mm.
GOBLIN KRAKEN TECHNICAL SPECIFICATIONS
• Cyclic Servos: Standard size 40mm.
• Tail Servo: Standard size 40mm.
• Main Rotor Ratio : 11.8 to 8.8 ( 21T included: 10.1:1).
• Tail Rotor Ratio : 5.0-4.8:1 ( 27T included: 4.8:1 ).
• 690 mm main blades.
• 105 mm tail blades.
KIT Includes:
• 21T motor pulley (other pulley sizes available).
• 2 battery trays with straps.
Page 2
INTRODUCTION

IMPORTANT NOTES
*This radio controlled helicopter is not a toy.
*This radio controlled helicopter can be very dangerous.
*This radio controlled helicopter is a technically complex device which has to be built and handled very carefully.
*This radio controlled helicopter must be built following these instructions. This manual provides the necessary information to correctly assemble the model.
It is necessary to carefully follow all the instructions.
*Inexperienced pilots must be monitored by expert pilots.
*All operators must wear safety glasses and take appropriate safety precautions.
*A radio controlled helicopter must only be used in open spaces without obstacles, and far enough from people to minimize the possibility of accidents or of injury to property or persons.
*A radio controlled helicopter can behave in an unexpected manner, causing loss of control of the model, making it very dangerous.
*Lack of care with assembly or maintenance can result in an unreliable and dangerous model.
* Neither SAB Heli Division nor its agents have any control over the assembly, maintenance and use of this product. Therefore, no responsibility can be traced back to the manufacturer
. You
hereby agree to release SAB Heli Division from any responsibility or liability arising from the use of this product.
SAFETY GUIDELINES
*Fly only in areas dedicated to the use of model helicopters.
*Follow all control procedures for the radio frequency system.
*It is necessary that you know your radio system well. Check all functions of the transmitter before every flight.
*The blades of the model rotate at a very high speed; be aware of the danger they pose and the damage they may cause.
*Never fly in the vicinity of other people.
DAMAGE LIMITS
SAB HELI DIVISION SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE
PRODUCT, WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. Further, in no event shall the liability of SAB Heli Division exceed the individual price of
the Product on which liability is asserted. As SAB Heli Division has no control over use, setup, final assembly, modification or misuse, no liability shall be assumed nor accepted for any resulting
damage or injury. By the act of use, setup or assembly the user accepts all resulting liability. If you as the Purchaser or user are not prepared to accept the liability associated with the use of this
Product, you are advised to return this Product immediately in new and unused condition to the place of purchase.
LIMITED WARRANTY
SAB Heli Division reserves the right to change or modify this warranty without notice and disclaims all other warranties, express or implied.
(a) This warranty is limited to the original Purchaser (“Purchaser”) and is not transferable. REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER
This warranty covers only those Products purchased from an authorized SAB Heli Division dealer. Third party transactions are not covered by this warranty. Proof of purchase is required for
warranty claims.
(b) Limitations- SAB HELI DIVISION MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT NONIFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
OF THE PRODUCT. THE PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE.
(c) Purchaser Remedy- SAB Heli Division’s sole obligation hereunder shall be that SAB Heli Division will, at its option, replace any Product determined by SAB Heli Division to be defective In the
event of a defect, this is the Purchaser’s exclusive remedy. Replacement decisions are at the sole discretion of SAB Heli Division. This warranty does not cover cosmetic damage or damage due to
acts of God, accident, misuse, abuse, negligence, commercial use, or modification of or to any part of the Product. This warranty does not cover damage due to improper installation, operation,
maintenance or attempted repair by anyone.
Page 3
IMPORTANT NOTES

Canopy
Boom
Foam Box
Bag Box
Blades Holder
Blades, Tail Blades,
Carbon Rod
Landing Gear Bag
2 Low Side Frame
Manual
Product Card
Extra Card
*Generic pliers.
*Hexagonal driver, size 1.5, 2, 2.5, 3mm.
*4/5mm T-Wrench.
*5.5mm Socket wrench (for M3 nuts).
*8mm Hex fork wrench (for M5 nuts).
*Medium threadlocker (SAB p/n HA116-S).
*Strong retaining compound (SAB p/n HA115-S).
*Spray lubricant (eg. Try-Flow Oil).
*Synthetic grease (eg. Microlube 261).
*Cyanoacrylate adhesive.
*Pitch Gauge (for set-up).
*Soldering equipment (for motor wiring).
*Electronic Motor
*Speed controller
*Batteries: 12S – 4200/5500mAh
*1 flybarless 3 axis control unit
*Radio power system.
*3 cyclic servos
*1 tail rotor servo
*6 channel radio control system on 2.4 GHz
The assembly process is described in the following chapters.
Each chapter provides you with the box, bag and/or foam
numbers you will need for that chapter. The information
is printed in a black box in the upper corner of the page.
INSIDE THE MAIN BOX THERE ARE:
Green screw and Green bearing
in the illustration means you
need to use:
Use retaining compound
( SAB HA115-S )
Use Proper Lubricant Use CA Glue
Indicates that for this
assembly phase you need
materials that are:
Foam xxx, BAG xxx.
Important
ADDITIONAL COMPONENTS REQUIRED TOOLS, LUBRICANTS, ADHESIVES
Blue screw and blue bearing
in the illustration means you
need to use:
Thread Locker Medium
Strength
( SAB HA116-S)
Foam xx, BAGxx
NOTES FOR ASSEMBLY
Please refer to this manual for assembly instructions for this model. Follow the order of assembly
indicated. The instructions are divided into chapters, which are structured in a way that each step is
based on the work done in the previous step. Changing the order of assembly may result in additional
or unnecessary steps.Use thread lockers and retaining compounds as indicated. In general, each bolt
or screw that engages with a metal part requires thread lock. It is necessary to pay attention to the
symbols listed below:
Page 4
NOTE FOR ASSEMBLY

Approx 728mm
13mm 13mm
NOTE:
Threaded Rod M2.5x40mm
(HC242-S)
Threaded Rod M2.5x40mm
(HC242-S)
Carbon Rod
2.5x 4x702mm
(HC537-S)
Aluminum Bushing Aluminum Bushing
BAG1
Page 5
CARBON ROD ASSEMBLY

Rear Servo Mount
(H1207-S)
Socket Head Cap
Screw M3x8mm
(HC050-S)
Rear Servo Mount
(H1405-S)
Socket Head Cap
Screw M3x8mm
(HC050-S)
Finishing
Washer M2.5
(H0255-S)
Foam 1, BAG2
TRANSMISSION GROUP
ASSEMBLED AND VERIFIED
The unit is ready to use
Check page 39 for more
information.
Free Wheel Clutch
grease HA075
Bushing
(H1275-S)
Main Pulley Z56
(H1291-S)
Socket Head Cap
Screw M4x22mm
(HC104-S)
Front Tail Pulley Z34
(H1271-S)
Shim
12x 16x0.1mm
(HC538-S)
Metric Hex Nylon Nut M4
(HC212-S)
Alu Servo
Mount Base
(H1273-S)
Anti-rotation Guide
(H1378-S)
Socket Head Cap
Screw M2.5x6mm
(HC018-S)
Front Servo Mount Assembly
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
Front Servo Mount
Assembly
Page 6
TRANSMISSION GROUP ASSEMBLY

18mm
Servo Tool
SERVO ASSEMBLY
Standard Servo
Servo Arm
(HA050-S)
Socket screw M3x6mm
(HC044-S)
Uniball M2
(H0064-S)
The linkage ball must be positioned 18 mm out on the servo arm. The recommended servo arm to
use is: SAB p/n [HA050/HA051].
Ensure the alignment of the servo arms (and sub trim is set) before installation of the servos in the
model.
Proceed with installation following the instructions below. You can use the G10 servo tool to align
the front servo arms with the theoretical horizontal line. (Figure 3)
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
Servo Spacer
(H0075-S)
Front Servos Rear Servo
Socket screw M2x6mm
(HC004-S)
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
Servo Spacer
(H0075-S)
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
BAG 3
Page 7
SWASHPLATE SERVOS ASSEMBLY

Bushing on this side
Low Side Frame Mount
(H1069-S)
Low Side Frame Mount
(H1069-S)
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
Flat Head Cap
Screw M2.5x5mm
(HC128-S)
Socket Head Cap
Screw M2.5x8mm
(HC020-S)
Battery Guide
(H1067-S)
Alu Pin
(H1085-S)
Main Frame
(H1403-S)
Main Frame
(H1403-S)
RIGHT FRAME ASSEMBLY
LEFT FRAME ASSEMBLY
BATTERY GUIDE ASSEMBLY
CF Pin
Support
(H1085-S)
BAG4
CF Xcross
(H1085-S)
Battery Tray CAM
[H1177]
NOTE:
With the eccentric bushing,
you can adjust the play of
the battery tray.
Socket Head Cap
Screw M2.5x12mm
(HC026-S)
Bushing on this side
Page 8
FRAME GROUP ASSEMBLY

RIGHT MAIN FRAME ASSEMBLED
LEFT MAIN FRAME ASSEMBLED
BATTERY GUIDE ASSEMBLED
Socket Head Cap
Screw M3x6mm
(HC044-S)
Socket Head Cap
Screw M3x6mm
(HC044-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Frame Spacer
(H1076-S)
BAG4
Washer 3.2x 6x0.5mm
(HC180-S)
Washer
3.2x 6x0.5mm
(HC180-S)
By installing 2 washers (HC180-S) on the battery
tray guide screws (just the 2 in the middle), it
creates a little preload to reduce any lateral play.
Page 9
FRAME GROUP ASSEMBLY

TRANSMISSION GROUP
ASSEMBLED
FRAME GROUP
ASSEMBLED
Don't install this screw at this time.
Socket Head Cap
Screw M3x8mm
(HC050-S)
Finishing Washer M3
(H0007-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Canopy Base
(H1101-S)
Socket Head Screw M3x6mm
(HC044-S)
CF Canopy
Base Support
(H1404-S)
Canopy Base
(H1101-S)
CF Canopy Base Support
(H1404-S)
Socket Head Cap
Screw M3x6mm
(HC044-S)
Finishing
Washer M3
(H0007-S)
Socket Head Cap
Screw M3x10mm
(HC056-S)
Finishing Washer M3
(H0007-S)
Socket Head Cap
Screw M3x8mm
(HC050-S)
BAG5
Finishing
Washer M3
(H0007-S)
Finishing Washer M3
(H0007-S)
Finishing
Washer M3
(H0007-S)
Page 10
FRAME GROUP ASSEMBLY

Approx 75-76mm
Foam 2, BAG6
LINKAGE ROD A ASSEMBLY ...X2
Plastic Ball Link
(H0402-S)
Linkage Rod M3x50mm
(H0417-S)
Plastic Ball Link
(H0402-S)
CENTER HUB ASSEMBLY
eg: Microlube
GL261
Spindle
(H0079-S)
Center Hub
(H1043-S)
Oring 90
(HC529-S)
Damper B Delrin
(H1046-S)
RADIUS ARM ASSEMBLY ...X2
Flanged Bearing
3x 7x3mm
(HC402-S)
Radius Arm
(H0132BM-S)
Spacer Arm
3x 5x2.7mm
Spacer Arm
2.5x 4x6.3mm
Uniball Radius Arm
(H0205-S)
UNIBALL RADIUS ARM ASSEMBLY ...X2
Flanged Bearing
2.5x 6x2.5mm
(HC400-S)
Flanged Bearing
2.5x 6x2.5mm
(HC400-S)
Flanged Bearing
3x 7x3mm
(HC402-S)
Page 11
HEAD ASSEMBLY

Note: Larger ID
Note: Smaller ID
Socket Head Cap
Screw M6x10mm
(HC124-S)
Washer
6x 14 x1.5mm
(HC194-S)
Bearing
10x 19x5mm
(HC422-S)
Washer
10x 16x1mm
(HC230-S)
Thrust Bearing
10x 18x5.5mm
(HC438-S)
Washer
10x 16x1mm
(HC230-S)
Socket Head Cap Screw M3x16mm
(HC068-S)
Washer
3x 4x0.5mm
Socket Head Cap
Screw M2.5x18mm
(HC032-S)
Blade Grip Arm
(H1045-S)
Uniball M3
(H0065-S)
Socket Head Cap
Screw M4x10mm
(HC102-S)
Blade Grip
(H1044-S)
NOTE:
Washer 10x 16x0.2mm
[HC232-S]
The HPS head should be assembled with one, 1mm shim (HC230) on each side. The
blade grips must move freely, but they should not move just under their own weight.
After approximately 10/20 flights, please check preload, you can add one or two 0.2mm
shim (HC232) if preload has changed.
eg: Microlube
GL261
Foam 2, BAG7
LINKAGE ROD
ASSEMBLED
RADIUS ARM
ASSEMBLED
Already assembled
with 1 bearing
UNIBALL RADIUS ARM
ASSEMBLED
Page 12
HEAD ASSEMBLY

HEAD GROUP
ASSEMBLED
FRAME & TRANSMISSION
GROUP ASSEMBLED
Socket Head Cap
Screw Shoulder M4x24mm
(HC111-S)
Socket Head Cap
Screw M3x12mm
(HC062-S)
Socket Head Cap
Screw M3x12mm
(HC062-S)
Metric Hex
Nylon Nut M4
(HC212-S)
eg: Microlube GL261
Reference Pin
(H1048-S)
Uniball M3
(H0065-S)
Uniball M3
(H0065-S)
Uniball M3
(H0065-S)
SWASHPLATE ASSEMBLY
Swashplate SET
(H1047-S)
Foam 2, BAG8
Page 13
ASSEMBLING OF THE MODULES

44mm
37mm
23mm
66mm
Approx 46mm
Approx 53mm
Initial length for the rods from the servos to the swash plate.
LINKAGE ROD FRONT SERVO ASSEMBLY ... X2
Set Screw M2.5x18mm
(HC140-S)
Plastic ball link
(H0066-S)
Plastic ball link
(H0066-S)
LINKAGE ROD REAR SERVO
ASSEMBLY
BAG8
LINKAGE ROD REAR SERVO ASSEMBLY ... X1
Initial length for the rods from the servos to the swash plate.
Set Screw M2.5x28mm
(HC618-S)
Plastic ball link
(H0066-S)
Plastic ball link
(H0066-S)
LINKAGE ROD FRONT SERVO
ASSEMBLY
Page 14
ASSEMBLING OF THE MODULES

TRANSMISSION SETUP
It is important to choose the right reduction ratio to maximize efficiency based on your required flight performance.
It is recommended to use wiring and connectors appropriate for the currents generated in a helicopter of this class.
If you are using a head speed calculator which requires a main gear and pinion tooth count, use 212 teeth for the main gear
(this takes into account the two stage reduction) and the tooth count of your pulley as the pinion count.
BELOW IS A LIST OF AVAILABLE REDUCTION RATIOS:
H0175-18-S - 18T Pinion = ratio 11.8:1 H0175-22-S - 22T Pinion = ratio 9.6:1
H0175-19-S - 19T Pinion = ratio 11.2:1 H0175-23-S - 23T Pinion = ratio 9.2:1
H0175-20-S - 20T Pinion = ratio 10.6:1 H0175-24-S - 24T Pinion = ratio 8 .8:1
H0175-21-S - 21T Pinion = ratio 10.1:1 H0175-25-S - 25T Pinion = ratio 8.4:1
GOBLIN KRAKEN RAW CONFIGURATIONS
Rev:01
Battery Motor ESC
Pinion
( a, b )
RPM Max
( a, b)
Pitch
12S
4200/5500 mAh
Xnova 4525-530kv
lightning
HW-200A
Kosmik 160
YGE 205HVT
SCORPION II 14-200A
21T / 22T
2100/2200 ± 12
Pyro 750-560
TENGU 4525HT/550KV
20T / 21T
Scorpion
HKII 4525-520 UL
22T / 23T
12S
4500/5500 mAh
Xnova 4530-525kv
lightning
HW-200A
Kosmik 200
YGE 205HVT
SCORPION II 14-200A
22T / 23T
2200/2300 ± 13 Pyro 800-480 24T / 25T
Scorpion HKII 4530-540
TENGU 4525HT/550KV
21T / 22T
Page 15
INSTALLATION OF THE MOTOR

40mm
CF ESC Mount
(H1068-S)
Plastic ESC Support
(H1068-S)
Motor Pulley 21T
(H0175-21-S)
Motor Mount
(H1058-S)
Motor Bushing
(H0176-S)
Use with 6mm
motor shaft
Metric Hex
Nylon Nut M5
(HC218-S)
Washer
5.3x 15x1mm
(HC188-S)
Flat Head Cap
Screw M3x10mm
(HC135-S)
Socket Head Cap
Screw M3x14mm
(HC064-S)
Flat Head Cap
Screw M4x6mm
(HC351-S)
Socket Head Cap
Screw M3x8mm
(HC050-S)
Set Screw M4x4mm or M4x6
in according with motor pulley/shaft
(HC152-S)/(HC153-S)
The set screw must be under the
surface of the teeth.
3
rd
bearing support for the motor, H0143-S
Install the support after installing the pulley and
after mounting the motor.
H0143 does not need to be used with an 8mm
motor shaft.
Foam 1, BAG 9
NOTE:
Motor wires pointing forward.
Socket Head Cap
Screw M3x6mm
(HC044-S)
Max height of the motor shaft:
Bushing
(H1068-S)
Page 16
INSTALLATION OF THE MOTOR

M3 Head Screw
Socket Head Cap
Screw M3x8mm
(HC050-S)
Finishing
Washer M3
(H0007-S)
Finishing
Washer M3
(H0007-S)
MOTOR BELT TENSION
*Fit the motor assembly into position.
*Move it to the minimum centre distance.
*First put the belt on the motor pinion.
*Then put the belt around the big pulley.
*Rotate the motor several times by hand.
*Pull on the motor mount to tension the belt.
*Rotate again the motor several times by hand.
*Provide the correct force, and properly tension the belt.
*Tighten the M5 nuts first, then the (2) M3 screws later.
You can use a 4-5mm shaft as a lever to set proper
motor belt tension.
BAG10
Motor Belt
(HC601-S)
Socket Head Cap
Screw M3x8mm
(HC050-S)
Page 17
INSTALLATION OF THE MOTOR

Socket Head Cap
Screw M2.5x10mm
(HC022-S)
Metric Hex Nylon
Nut M2.5mm
(HC200-S)
BAG11
NOTE:
You can install some zip ties here.
Page 18
INSTALLATION ESC

Note: S >> Left Side
Note: S >> Right Side
Note: Smaller ID
Note: Larger ID
Spindle Shaft
(H0329-S)
Oring
(HC335-S)
Spacer
5x 8.5x0.75mm
(H0330-S)
Uniball
M2.5x
5H6
(H0064-S)
Socket Head Cap
Screw M2x6mm
(HC004-S)
Spacer
7.5x 10x0.5mm
(H0330-S)
Thrust Bearing
5x 10x4mm
(HC435-S)
Button Head Cap
Screw M4x6mm
(HC096-S)
Tail Blade Grip Assembled
(H1033-S)
TAIL PITCH SLIDER ASSEMBLED
(H1112-S)
Tail Pitch Slider Link
(H0261-S)
Spacer
2x 3x3mm
Socket Head Cap
Screw M2x6mm
(HC004-S)
NOTE:
It is a normal for the tail to feel a bit tight after initial
assembly as the tail spindle preload is usually high when
the helicopter is brand new. The preload will loosen up
after 2-5 flights allowing the system to become smooth.
eg: Microlube GL261
Tail Shaft Assembled
(H1089-S)
eg: Microlube GL261
Foam 2, BAG12
Page 19
TAIL GROUP ASSEMBLY
