Safavieh PAT6742 User manual

MODEL # PAT6742
Product Dimension: 19.69”Wx49.21”Dx31.1”H
NOTICE
Please make sure that you have all parts indicated
before you begin assembly of this item.
CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when it is not in use.
Dust regularly with small brush or vacuum.Spills should be taken care of
immediately before they harden or stain with a slightly dampened sponge.
PIECE DESCRIPTION PICTURE QUANTITY
Part List and Hardware List
1X
1 X
Allen key
2 X
Allen bolt
1 X
1 X
Seat
4 X
Allen screw
1 X
2 X
Bolt extra
Right side
Left side
Back
Support bar 1 X
Screw
1 X
M6x50
M6x55
M6x70
M4x35
A
B
C
D
F1
F2
F3
F4
E
F5
Warning : Do not torque bolts / screws
Warning : Do not stand on the bench
Weight capacity : 600 lbs.

Before beginning the assembly of the product,make sure all parts are present.
Compare the parts with package contents list and hardware contents list.
If any parts are missing or damaged,do not attempt to assemble the product.
Tool required for assembly (included): Allen key.
12
Step1: attach the left side (A) and the right side (B) to the
back (C) and the Support bar (E) as shown on the picture
by using the Allen bolts (F1).Tighten all with the Allen
key (F5).
Step 2: use the Allen screw (F2) to fit the back (C) to the
side parts (A) and (B) as shown on the picture by using the
Allen key (F5).
C
F1
F2
F5
F4

Step 3: put the seat (D) inside the bench as shown on
the picture.
Step 4: use the screw (F3) to fit the seat (D) as shown on
the picture and tighten all with a screwdriver.
34
F3
