Safe Fleet Prime Design VCC TC21B User manual

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: i[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
2
2
3
4
6
7
8
1
5
9
Channels (2X)
M6 Sealing Washer (10X) Foam Pad (10X)
Mounting Plate (10X)
M6 Locknut (10X) End Caps (4X) Brackets (4X)
M6 x 30MM Bolt (10X)
“ Washer (10X)
10
VCC-TC21B ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
1—FBM-0007 ........................................................ (Qty 1)
Channels with hardware
CONTENTS OVERVIEW
2—Rear Crossbar Assembly.................................. (Qty 1)
3—Front Crossbar Assembly................................. (Qty 1)
4—Handle Latch Assembly ................................... (Qty 2)

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
3
VCC-TC21B ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
7—Quick Clamp Tube Splice Assembly ................ (Qty 2)
5.00“
9—HD Front Hook Assembly ................................. (Qty 2)
6—Clamp Down Tube ............................................ (Qty 2)
80.00”
8—Removeable Horn with Cap ............................. (Qty 2)
15.00”
5—Clamp Down Handle Assembly ....................... (Qty 2)
M8 Lock Nut (1X) Flat Washer (2X)
M8 x 45MM (1X)
11—Anti-Seize........................................................ (Qty 1)
10—USQSG-Ergorack ............................................ (Qty 1)
Quick Start Guide, Clamp Down
Anti-Seize (1X)
Once rack installation is complete, place the Quick Start Guide into
the vehicle’s glove box for future ladder setup and adjustment.

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
4
3
1
4
5
6
2
2
Rear
Front
Left
Right
2.00”
Channel Front
6.25”
Channel Rear
VCC-TC21B ASSEMBLY INSTRUCTIONS–FBM MOUNTINGS
FBM-0007
1.1
Foam pad
Mounting Plate
1.2 Install the fasteners through the innermost factory roof
holes as shown then torque the nuts to 60 in-lbs.
Do not install or fasten Hardware to the outer front
and rear roof holes until Step 1.4.
Install three sets of Channel Hardware per channel
as shown below.
RIGHT CLAMP DOWN ASSEMBLY

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
5
Rear
Front
Left
Right
72.00”
7.00”
Channel Rear Channel Front
VCC-TC21B ASSEMBLY INSTRUCTIONS–CROSSBAR INSTALLATION
Loosen bolts
1.3
1.5 Set to distances then torque all the Mounting Brackets
to 90 in-lbs.
1.4 Install the remaining front and rear fasteners through
the factory roof holes as shown then torque the nuts
to 60 in-lbs.
Install the Mounting Brackets along with the remaining
Channel Hardware as shown below.
Do not tighten the Mounting Brackets until Step 1.5.
Loosen bolts

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
6
Rear
Front
7.75” 7.75”Front
7.75” 7.75”Rear
VCC-TC21B ASSEMBLY INSTRUCTIONS–RIGHT SIDE CLAMP DOWN
3
4.2
4.1
4.3
4.4
Torque to 90 in-lbs
Torque to 90 in-lbs
CLAMP DOWN TUBECLAMP DOWN HANDLE
CROSSBARS CROSSBAR ADJUSTMENT
2.1
Torque to
90 in-lbs 2.2

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
7
7
8
9
10
VCC-TC21B ASSEMBLY INSTRUCTIONS–RIGHT SIDE CLAMP DOWN
LEFT CLAMP DOWN ASSEMBLY
HANDLE LATCH FRONT LADDER HOOK
SEE QUICK START GUIDE FOR ADJUSTMENTS
5.2 Torque to 90 in-lbs
5.1
6.2
Torque to 90 in-lbs
6.1

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
8
VCC-TC21B ASSEMBLY INSTRUCTIONS–LEFT SIDE CLAMP DOWN
USAM-VCCTC21B-US01 Rev-C 0718
HANDLE LATCH FRONT LADDER HOOK
SEE QUICK START GUIDE FOR ADJUSTMENTS
9.2
Torque to 90 in-lbs
9.1
10.2
Torque to 90 in-lbs
10.1
CLAMP DOWN HANDLE CLAMP DOWN TUBE
7
8.2
8.1
8.3
8.4
Torque to 90 in-lbs
Torque to 90 in-lbs
