Safeline Universal+ 7WR 1PHAD Guide

UNIVERSAL+ 7WR 1PHAD
1
Image is merely illustrative
Universal+ 7WR 1PHAD
Astronomical time, programmable via Internet/Intranet
With one independent output relay and one dimmer
Easy, clear programming with programming file import and export function
Four independent time programmers:
- Astronomical daily/weekly
- Daily/ weekly (295 programs)
- Daily/monthly/yearly (1145 programs)
- Daily/monthly/yearly (vacations, holidays..., 285 programs)
Counter for ON hours, information and manual control
WebServer: programming, control and total monitoring in real time via Internet/Intranet
UNIVERSAL+ 7WR 2PHA y UNIVERSAL+ 7WR 2PH
With software version V1.0

UNIVERSAL+ 7WR 1PHAD
2
User’s installation manual - UNIVERSAL+ 7WR 1PHAD
It is imperative that the user/installer fully understand the present manual as also its pertinent accessories
manuals prior to using the unit. Should any doubt arise, please refer to the Authorised Distributor or the
Manufacturer.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means electronic,
mechanical, recording or photocopying or otherwise without the express prior consent of Safeline, S.L. Whilst every care has been taken to ensure that the
information contained herein is correct, no liability can be accepted by Safeline, S.L. for any damage caused by any errors in, or omissions from, the information
given. Neither is Safeline, S.L. liable for any damage arising from the incorrect use of this information.
Safeline, S.L., as also its affiliates, is not liable to the purchaser or to third parties for damages, be they material or personal, costs, etc. in which the purchaser or
third party may incur as a result of any accident or incorrect use of this product, nor as a result of any unauthorised modification, alteration or repair to same, nor
due to non-observance of the operation and maintenance instructions given by Safeline, S.L.
Always with an aim to improving the quality of its products, Safeline reserves the right to modify, without previous notice, any standard or characteristic in the
present manual and the products indicated herein. The technical characteristics set out in said standards are for information purposes.
Sureline is a trademark of Safeline, S.L.
Published in Spain by Safeline, S.L. 2nd edition (May 2020)

UNIVERSAL+ 7WR 1PHAD
3
I N D E X
CHAPTER 1 – GENERAL DESCRIPTION
Nomenclature......................................................................................................................................................... 5
Introduction ............................................................................................................................................................ 6
Características destacables UNIVERSAL+ 7WR 1PHAD .................................................................................... 7
Functioning ............................................................................................................................................................ 8
Functioning of daily/weekly astronomical time programmer ...................................................................................9
Functioning of daily/weekly time programmer...................................................................................................... 10
Functioning of daily/monthly/yearly time programmer.......................................................................................... 11
Functioning of daily/monthly/yearly time programmer (excepciones/holidays/vacations).................................... 12
Functioning chart ................................................................................................................................................. 14
CHAPTER 2 – SURFING INTERNET/INTRANET
Introduction ................................................................................................................................................................ 15
WEB page: Welcome, PIN/ “Close session” ............................................................................................................ 16
WEB page: Box: Information ..................................................................................................................................... 17
WEB page: Box: Manual control ............................................................................................................................... 17
WEB page: Box: Daily/weekly astronomical time programmer................................................................................ 18
WEB page: Box: Daily/weekly time programmer...................................................................................................... 21
WEB page: Box: Daily/monthly/yearly time programmer ......................................................................................... 21
WEB page: Box: Time programmer for exceptions: vacations/holidays .................................................................. 22
WEB page: Box: Unit configuration ........................................................................................................................... 23
CHAPTER 3 – USER’S GUIDE (front panel and LCD screen)
Function of the buttons............................................................................................................................................... 24
User PIN...................................................................................................................................................................... 24
LCD screen, 12x3 characters..................................................................................................................................... 25
LCD screen menu....................................................................................................................................................... 25
Manual control for output relays................................................................................................................................. 26
TCP/IP configuration.................................................................................................................................................. 26
Language.................................................................................................................................................................... 26
Changing user PIN ..................................................................................................................................................... 27
Acoustic warnings (beep) ........................................................................................................................................... 27
Screen backlighting..................................................................................................................................................... 27
Version........................................................................................................................................................................ 27
CHAPTER 4 – TECHNICAL CHARACTERISTICS
Technical characteristics ........................................................................................................................................... 28
Program recovery in the event of power cut............................................................................................................... 29
Description of connection terminals - UNIVERSAL+ 7WR 1PHAD .......................................................................... 29

UNIVERSAL+ 7WR 1PHAD
4
CHAPTER 5 – USER’S/INSTALLER’S GUIDE
Precautions and warnings for the user/installer ......................................................................................................... 30
Wiring. Precautions and warnings for the user/installer ............................................................................................. 31
Transport and handling............................................................................................................................................... 31
Installation .................................................................................................................................................................. 31
Wiring ......................................................................................................................................................................... 31
Wiring diagrams ......................................................................................................................................................... 32
CHAPTER 6 – INTERNET/INTRANET CONFIGURATION
Point to point configuration .................................................................................................................................. 33
Internet/Intranet connection configuration ........................................................................................................... 35
Remote access configuration............................................................................................................................... 35
More than one WebServer in the same network.................................................................................................. 36
TCP/IP configuration. When the ex-factory IP domain is not within the IP range of user’s network.................... 36
Aid for a correct configuration .............................................................................................................................. 37
Aid: FAQ ................................................................................................................................................................ 37
CHAPTER 7 – DIAGNOSES AND TROUBLE-SHOOTING
Informative messages ......................................................................................................................................... 38
CHAPTER 8 – TECHNICAL SERVICE ................................................................................................................... 38
CHAPTER 9 – GUARANTEE CARD............................................................................................................................ 39

UNIVERSAL+ 7WR 1PHAD
5
CHAPTER 1 – GENERAL DESCRIPTION
Nomenclature UNIVERSAL+ 7WR 1PHAD
Four independent time programmers:
- Daily/weekly astronomical
- Daily/weekly (295 programs)
- Daily/monthly/yearly (1145 programs)
- Daily/monthly/yearly (vacations, holidays…, 285 programs)
7WR 1PHAD [ ] [ ]
1 2
1 – Load intensity (output relay RA)
[ 6A ] = 6A Max AC1 (250V AC Max)
[ 16A ] = 16A Max AC1 (250V AC Max)
2 – Supply voltage (terminals line neutral)
[ 230VU ] = Universal AC and DC power supply: (85V – 265V AC 47-440HZ) and (130V – 370V DC)
[ 12V ] = 12V DC (9V – 18V DC)
[ 24V ] = 24V DC (18V – 36V DC)
[ 48V ] = 48V DC (36V – 72V DC)
e.g UNIVERSAL+ 7WR 1PHAD 6A 230VU
Attention: please, consult identifying label on the side of the unit

UNIVERSAL+ 7WR 1PHAD
6
Introduction
The SURELINE UNIVERSAL+ 7WR 1PHAD incorporates innovative, cutting-edge technology for time-programming and
output relay and dimmer. It has four independent time programmers, is programmable, with built-in WebServer, and
protected by user PIN.
This small, compact unit for 35mm DIN rail, comes sealed from origin and all ready to be installed in a standard enclosure
and used in any installation or sector whatsoever.
Presentation: standard (EN 50 022) enclosure for 35mm DIN rail. This is a compact unit monitored by a 16-Bit
Microcomputer and is highly stable thanks to its built-in double process monitor (Watchdog)
The "UNIVERSAL+ 7WR" family is a series of units with WebServer, designed to provide electrical protection, control and
monitoring in real time via Internet/Intranet, permitting electrical installations to be protected and any process whatsoever to
be automised with inputs/outputs. These units are totally autonomous and, once configured, can communicate with each
other via Internet/Intranet to enable or disable relays/functions/processes.

UNIVERSAL+ 7WR 1PHAD
7
Outstanding characteristics - UNIVERSAL+ 7WR 1PHAD
Digital time switch with 1 relay and 1 dimmer (Start – Stop – Speed).
Start: Initial value of dimmer (%).
Stop: Final value of dimmer (%).
Speed: Increase-decrease speed (s/%).
Programming “Start/Stop” from 0% - (0V) to 100% - (10V) in 1% steps
Programming “Speed” from 0.000 s/% - 999.9 s/%. (4 digits)
Maximum time from 0% - 100% or 100% - 0% with 999.9 s/% = 27.7 hours (resolution 0,001 s/%)
Minimum time from 0% - 100% or 100% - 0% with 0.000 s/% = instantaneous (resolution 0,001 s/%)
Resolution output dimmer 0,1% (0,01V)
Daily/weekly astronomical time programmer.
Daily/weekly time programmer. (295 programs).
Daily/monthly/yearly time programmer. (1145 programs).
Programador horario diario /mensual/yearly (excepciones/holidays/vacations, 285 programs).
Counter for number of ON hours
WebServer
Programming, control and total monitoring in real time via Internet/Intranet.
Information regarding status of relay and dimmer with number of ON hours, automatically refreshed
every 2 secs.
Manual control via Internet/Intranet and through the unit itself
Easy, clear and simple programming with file.txt export/import function
Geographic location (latitude, longitude and GMT), manually or automatically via Internet
Programming of internal clock (date and time), manually or automatically
Automatic Summer/Winter time switchover
Complete annual sunrise/sunset hours table
Three customisable styles for viewing the web page
Editable relay and dimmer names (16 characters)
Editable unit name (16 characters)
4-digit protection PIN
Green “Working" LED

UNIVERSAL+ 7WR 1PHAD
8
Functioning
The main aim of the UNIVERSAL+ 7WR 1PHAD is to give the user a clear and simple system to switch relay A on
and off; to program “Start”, “Stop” and “Speed” (percentage increase-decrease in s/%) of the dimmer (output 0-10V);
to know the number of ON hours for relay and dimmer and to afford an easy import/export of programming to other
7WR 1PHAD units. To this end, it has four well-differentiated time programmers.
Daily/weekly astronomical time programmer
Permits the user to program daily switching on and off of relay A and to program “Start”, “Stop” and “Speed”
(percentage increase-decrease in s/%) of the dimmer (output 0-10V) by means of a high-precision algorithm which
calculates sunrise and sunset for every day.
Daily/weekly time programmer
Permits the user to program daily switching on and off of relay A and to program “Start”, “Stop” and “Speed”
(percentage increase-decrease in s/%) of the dimmer (output 0-10V) depending on day/s of the week.
Daily/monthly/yearly time programmer
Permits the user to program daily switching on and off of relay A and to program “Start”, “Stop” and “Speed”
(percentage increase-decrease in s/%) of the dimmer (output 0-10V) for a day/month/year.
Daily/monthly/yearly time programmer (exceptions/holidays/vacations).
Permits the user to program daily switching on and off of relay A and to program “Start”, “Stop” and “Speed”
(percentage increase-decrease in s/%) of the dimmer (output 0-10V) for a day/month/year.
Simultaneous execution. These time programmers operate in parallel so that all programs run without delay, except
in the event of one of them having been programmed for holiday/vacation, in which case only the actions assigned to
this programmer would be carried out.
Normally, programming time programmers is a laborious business. Safeline has designed its software focussing the
utmost effort on ease of use. The flat, low-profile interface contributes to this as do also the automatic geolocation
detection (latitude, longitude and GMT) and internal clock (date and time).
Only needs to be configured once. An important aspect is its capacity of self-sufficiency. The automatic time
changeover by default and the daily calculations carried out by the unit to determine sunrise and sunset, all
guarantee that, once configured, no further action is needed.
Export/Import: Should the user wish to have the same configuration in different units or, simply, to have a copy of the
configuration, this is possible simply by exporting/importing files to/from the unit and the computer.

UNIVERSAL+ 7WR 1PHAD
9
Functioning of daily/weekly astronomical time programmer
How does it work?
Thanks to the high-precision algorithm which the unit automatically calculates daily, the astronomical time-
programmer allows the user to control one relay and one dimmer at sunrise and sunset. An example of usage
would be in the management of street lighting.
Relay A has two positions, ON and OFF. The dimmer has “Start” (initial value in %), “Stop” (final value in %) and
“Speed” (increase - decrease in s/%). In each program, the dimmer will initiate the process with the “Start” value and
will transition to “Stop” at “Speed”. Relay A can be omitted by indicating “None” in the relay selector.
Geographical location: The user must specify the location where the unit is to calculate the sunrise and sunset.
This device’s process of acquisition of coordinates is automatic if “Automatic” is pressed. They can, however, also
be entered manually.
Adjustment of relay and dimmer according to days of the week: These are adjusted as per user’s requirements
on days of the week. All that is required is to select the days of the week for the activity, enable relay A on the
minimalist panel, program the dimmer’s “Start”, “Stop” and “Speed” (increase-decrease in s/%, output 0-10V) and
assign a status to relay A, viz. switching on or off at sunrise and sunset. Lastly, an offset (delay/advance) of up to
240 minutes can also be added to adjust more precisely in cases of valley and mountain locations.

UNIVERSAL+ 7WR 1PHAD
10
Vacations: Finally, it is necessary to define whether the astronomical programmer is to operate in vacations
or not. In other words, should one require it not to come into operation on a holiday. Holidays are
configured in the vacations time programmer.
Results: The astronomical programmer is now configured. All that remains is to indicate whether automatic
Summer or Winter switchover time is required. The unit will calculate sunrise and sunset daily every year from this
point on.

UNIVERSAL+ 7WR 1PHAD
11
Functioning of daily/weekly time programmer
How does it work?
Relay A has two positions, ON and OFF. The dimmer has “Start” (initial value in %), “Stop” (final value in %) and
“Speed” (increase - decrease in s/%). In each program, the dimmer will initiate the process with the “Start” value and
will transition to “Stop” at “Speed”. Relay A can be omitted by indicating “None” in the relay selector.
Import/export: If a program has already been exported and one wishes to import it, one must first import a
configuration file by pressing “Select file” and selecting one. Thus, one can easily program diverse units or, simply
make backup copies.
Programming: . Programming is simple as can be seen in the example below where relay A switches on during 5
minutes every day of the week. Say, for example, it is an irrigation system with lighting. Let’s assume that a new
plant is put in which requires more frequent watering. In this case, all days of the week are selected, relay A is set to
ON for example at 19:00. After this the process is repeated but at 19:05, relay A switches to OFF, thus avoiding the
irrigation being left on all night. The dimmer controls a light which will switch on at 11:05, going from 0% to 100% in
60 secs., It will then remain at 100% until 19:05 at which time it will decrease to 0% in 60 secs.
Program 001: Every day of the week at 11:05, relay A in ON position and dimmer goes from 0% to100% in 60secs.
Program 002: Every day of the week at 11:10, relay A in OFF position and dimmer remains at 100%.
Program 003: Monday,Wednesday,Friday and Sunday at 19:00, relay A in ON position and dimmer remains at100%.
Program 004: Monday,Wednesday,Friday and Sunday at 19:05, relay A in OFF position and dimmer goes from 0%
to100% in 60secs
Configuration management: At any time whatsoever, the lines in each program can be deleted or modified and
program files exported using the lower buttons.

UNIVERSAL+ 7WR 1PHAD
12
Functioning of daily/monthly/yearly time programmer:
How does it work?
En el daily/monthly/yearly time programmer es donde van las acciones más específicas. Este programador permite el
encendido y el apagado del relay A y el control de un dimmer según el día, el mes y el año en una hora específica.
Relay A has two positions, ON and OFF. The dimmer has “Start” (initial value in %), “Stop” (final value in %) and
“Speed” (increase - decrease in s/%). In each program, the dimmer will initiate the process with the “Start” value and
will transition to “Stop” at “Speed”. Relay A can be omitted by indicating “None” in the relay selector.
Import/export: If a program has already been exported and one wishes to import it, one must first import a
configuration file by pressing “Select file” and selecting one. Thus, one can easily program diverse units or, simply
make backup copies.
Programming: Programming is simple. For example, in the hottest months (June, July and August), the irrigation
system starts up every day at 15:00 and lasts 5 minutes. Then, should September be forecast as hot, it can be
added. It is important to ensure that relay is set back to OFF to avoid the irrigation being left on throughout the whole
period.
Configuration management: At any time whatsoever, the lines in each program can be deleted or modified and
program files exported using the lower buttons.

UNIVERSAL+ 7WR 1PHAD
13
Functioning daily/monthly/yearly time programmer (exceptions/holidays/vacations)
How does it work?
The daily/monthly/yearly programmer is for those more specific actions such as those to be executed on holidays. One
must bear in mind that, in the case of other time programmers, the programmed actions will not be carried out when
falling on a holiday. Nevertheless, the user can decide whether the astronomical timer comes into play in vacational
periods. This is explained in the corresponding section regarding this programmer.
Relay A has two positions, ON and OFF. The dimmer has “Start” (initial value in %), “Stop” (final value in %) and
“Speed” (increase - decrease in s/%). In each program, the dimmer will initiate the process with the “Start” value and
will transition to “Stop” at “Speed”. Relay A can be omitted by indicating “None” in the relay selector.
Import/export: If a program has already been exported and one wishes to import it, one must first import a
configuration file by pressing “Select file” and selecting one. Thus, one can easily program diverse units or, simply
make backup copies.
A la hora de programar: Programación muy sencilla. Por ejemplo, Si durante los días de vacaciones de una
empresa se desea hacer un control del relay y el dimmer diferente, lo único que tendrá que hacerse es seleccionar
el periodo de vacaciones y configurar los nuevos programs. De este modo, el equipo no ejecutará las acciones
programadas en los otros programadores y sólo ejecutará estas acciones hasta que finalice dicho periodo.
Programming: For example, if a company wishes to effect a different control of relay and dimmer during the
vacation period, the user must select the vacation period and configure the new programs In this way, the unit will
not execute those actions programmed in other programmers and will only execute this action until the end of the
period.
Configuration management: At any time whatsoever, the lines in each program can be deleted or modified and
program files exported using the lower buttons.

UNIVERSAL+ 7WR 1PHAD
14
Functioning chart
Option: Astronomical programmer with vacations = NO (the exceptions for vacations/holidays DO NOT affect)
Option: Astronomical programmer with vacations = YES (the exceptions for vacations/holidays DO affect)
Normal program flow (GREEN)
Time programmers 2, 3and 4are always executed (as shown on the chart), except when there is a vacations program
(time programmer 1– RED flow).
Program flow when there is an exception for vacations (RED)
When there is a vacations program (time programmer 1), time programmers 2, 3and 4 are omitted.
This latter (4), however, does have a programmable option whereby it can avoid being omitted.
Hour/Minutes
= clock?
Next reading clock
N
Precision reading clock
Day/Date/Month/Year
Hour/M
inutes
Time prog. Vacations, holidays
(Daily/Monthly/Yearly)
Day/Month/Year = clock?
Time prog. Daily/Monthly/Yearly
Day/Month/Year = clock?
Time prog. Daily/Weekly
Day of the Week = clock?
N
N
Y
Y
ON/OFF
Relay
dimmer
Hour/Minutes
= clock?
Y
Y
ON/OFF
Relay
dimmer
N
Hour/Minutes
= clock?
Y
Y
ON/OFF
Relay
dimmer
N
N
Astronomical time prog. daily/weekly
Hour (Sunset/Sunrise) = clock?
N
Y
ON/OFF
Relay
dimmer
Option: Programmer astronomical with vacation?
=
Yes
Option:
A
stronomical
p
rogrammer with vacation? = NO
Exception
Exception
1
2
3
4

UNIVERSAL+ 7WR 1PHAD
15
CHAPTER 2 – SURFING INTERNET/INTRANET
Introduction
The WebServer permits all the unit’s parameters to be displayed and configured via Internet/Intranet on any PC,
laptop, smartphone, tablet or PDA conveniently, easily and clearly.
In order for the data dispatch and command reception of the WebServer to function correctly, a good quality Internet
connection or an Internet line connection (optic fibre or similar) is imperative.
It has three customizable styles for its display on the website.These styles are memorised in each browser
through the use of cookies.
Safeline
Minimalist
Classic

UNIVERSAL+ 7WR 1PHAD
16
Welcome page and PIN request / “Close session”
The first page displayed upon accessing the unit is the welcome page where the user’s PIN is requested. The default
PIN enabled at the factory is “1, 2, 3, 4”. Once said PIN has been entered, the main page is accessed. Surfing with
the WebServer UNIVERSAL+ 7WR 1PHAD is simple and intuitive:
In order to change any value, one must always enter the current PIN in the box next to “Save”
The purpose of the “Close session” button is to impede any unauthorised person from surfing the unit at will. If the
button is not pressed and one only closes the browser, the next time the user accesses the content, the access PIN
will not be requested and the session can be resumed as from the last page visited. . If the session is not closed, an
automatic session closure is generated after one hour.
On pressing “Close session”, the welcome page opens up and the user PIN is requested.
The user PIN represents a high degree of security for the owner since this is the sole means whereby the
programmed parameters can be validated. Any changes in programmed values only come into effect once said PIN
has been entered.
Made up of 4 digits, each one from 0 to 9
oDefault PIN enabled at factory: 1,2,3,4
oThe user PIN can be changed if one is in possession of the current one
oThe PIN is one and the same for surfing Internet/Intranet
ATTENTIÓN: For security reasons, no master code exists. In case of loss, the user must contact the
manufacturer to have the unit re-programmed and thoroughly verified. It is recommended that this PIN be
noted down and kept in a safe place.
Close session. The WebServer will request the PIN anew the next time the unit is accessed.
The session having been closed, the next time the user attempts to access the content, the access PIN will be
requested. For security reasons, an automatic session closure is generated every hour should the session have been
quitted without “close session ”having been pressed.
.

UNIVERSAL+ 7WR 1PHAD
17
Surfing
The first page displayed upon accessing the unit is the welcome page where the user’s PIN is requested. The default
PIN enabled at the factory is “1, 2, 3, 4”. Once said PIN has been entered, the main page is accessed. Surfing with the
WebServer is simple and intuitive since it is organized with the following 8 main buttons:
WEB page: Box “information”
Displayed here are the date and time of the internal clock; name, status and number of ON hours of relay A; name, status,
programming and ON hours (≥5%) of the dimmer. The green background is refreshed every 1 sec.
WEB page: Box “Manual control”
Permits the user to switch relay A ON or OFF and also to program all the dimmer’s parameters manually. It also permits
him to reset the selected hour counter to zero.

UNIVERSAL+ 7WR 1PHAD
18
WEB page: Box “Daily/weekly astronomical time programmer”
Once the page has been loaded, the unit’s current saved setttings are displayed.
The geographical location is indicated by the latitude, longitude and GMT selectors. If the programming is effected at this location,
the coordinates can be obtained automatically. Select the days of the week, enable prog 1’s general box, configure status, offset
and dimmer, enter user PIN and press “save changes” in order to send and save settings.
NOTE: The internal calculation effected by the unit can differ by ± 1 o 2 mins from the result shown on the web page.

UNIVERSAL+ 7WR 1PHAD
19

UNIVERSAL+ 7WR 1PHAD
20
