Safeline 1000 User manual

Manual
Eng v2.01
SafeLine 1000

Hisselektronik
www.safeline.se
Hisselektronik AB, Antennvägen 10, 135 48 TYRESÖ, Sweden. Phone:[phone]. Fax:[phone].
Support number: [phone] E-mail: [email protected]
Webb: www.safeline.se Support: www.safeline.se/support
Content
Content
Introduction 1
Assembly instructions 3
Hints 3
Programming with hand unit 5
Simplified programming 7
Dial tone programming 9
Common settings 11
Volume control 12
Connections 13

Hisselektronik
www.safeline.se
Introduction
The content in this catalogue is
protected by the copyright laws.
The name SafeLine™ is a
registered trademark. All content
in this catalogue is owned by
Hisselektronik AB.

2
Hisselektronik
www.safeline.se
1
2
3
1
2
3
4
56
Introduction
1. Cable for connections.
2. Rs232 PC connection.
3. Volume settings.
4. Relay output connection.
5. Jumper for NO/NC button.
NO = without jumper.
NC = with jumper.
6. Jumper for lift/entry phone.

3
Hisselektronik
www.safeline.se
Assembly instructions
Assembly instructions
Complete telephone assembly in the elevator car requires a space of
only 70X130mm for installation.
The alarm signal button can be changed between normally-open/
normally-closed.
It is possible to use the existing alarm button.
The telephone is using P100 or CPC protocol for communication with the
operator that receives the alarm.
P100 and CPC protocol is the most frequent alarm receiving system
used in Scandinavia, and it is also used in our own alarm receiver
equipment.
Check that the alarm-receiving operator has a receiver fitted for P100/
CPC protocol voice call if you plan to use this protocol.
Hints:
When the alarm signal switch is activated the telephone will call
up after 5 seconds of delay time. To do so, there must be a telephone
number programmed and a telephone line connected.
When the telephone starts calling, the connection sound is clearly heard
from the speaker.
Adjust the volume if needed with the volume control.
The first two telephone numbers (primary and secondary) are
pre-programmed for P100. There must be an 8-digits alarm code
programmed to make the P100 or CPC alarm work. The last two
telephone numbers (third and forth) are programmed for vocal
connection.
Vocal connection means a standard telephone call.
The receiving party does not have to do anything to get a vocal
connection, it is automatically done.

4
Hisselektronik
www.safeline.se Hints
To disconnect a vocal connection the receiving party should press “9” or “#”
otherwise the line will be busy up to 90 seconds after the call is completed.
To call the lift telephone just call the connecting telephone number, the
telephone will automatically answer after two signals.
Disconnect after the call is completed by pressing “9” or “#”.
To call the lift telephone if more then one phone is connected in series:
The telephones must be programmed with different unit numbers (see
programming). When calling to the lift, the telephone will answer after 2 signals,
chose the unit number that corresponds with the telephone you want to call.
Ex: You want to talk to unit number 3.
Call the telephone number, and when the telephone answers, press “3”
repeatedly on your dialtone telephone or mobile telephone, until you hear 2
distinctive calling tones –witch indicates that the call is connected to the right
telephone.
Disconnect after the call is completed by pressing “9” or “#”.
If it does not work, check:
Is there a connection?
Is there power?
- The diode lamp should be flashing.
Is there any telephone number programmed?
- Check with the hand unit.
Is there any alarm code programmed?
- Check with the hand unit.
Is it calling the right number?
- Check by calling on a regular phone.
Has the alarm-receiving operator the right equipment?
- Check with the operator.

5
Hisselektronik
www.safeline.se
To program the telephone, a programming unit HT99-H is needed.
It is also possible to program the telephone by using a dial tone telephone,
or with our Window-based PC software Safeline Pro (can be down loaded at
no cost from our web-site www.safeline.se).
Programming with Safeline Hand Unit HT99-H
It is possible to register all alarm codes and telephone numbers long before
programming the telephone. The hand unit is battery powered and saves all
codes and numbers in the memory, even if the power is turned off
or the battery is changed.
SafeLine™ 1000 Programming
Step by
step… The display shows: Explanation: Next to do: Tip:
Turn on the
power Handunit for
Safeline 1000/2000
-----------------
Version 1.15
After about 3 seconds
the next text will show.
Step 2: _
ALARM CODE 1 =
#=NEXT D=HELP
Type the 8-digits P100/
CPC alarm-code given
to you by your alarm-
receiving operator.
This is the “Primary
code”
This code is to be used
for lift alarm.
Press ”#” to go
to next text
Step 3: _
ALARM CODE 2 =
#=NEXT D=HELP
Write the second 8-digits
P100/CPC alarm-code
given to you by your
alarm-receiving operator.
This is the “Secondary
code”
This code is to be used
for battery alarm.
Press ”#” to go
to next text If you anytime between all steps press “C” you will
continue directly to Step 15.
Step 4: _
TEL.NUMBER 1 =
#=NEXT D=HELP
Write the 1:st telephone
number you want to call
in case of emergency
alarm.
Press ”#” to go
to next text Phone numbers can be 16 digits long. “ * “ means 1
second pause. That can be
useful when calling through
a switchboard. Press B to
change alarmcode
Tel.nr1normally P100-
numbers
Programming with hand unit

6
Hisselektronik
www.safeline.se
Step by
step… The display shows: Explanation: Next to do: Tip:
Step 5: _
TEL.NUMBER 2 =
#=NEXT D=HELP
Write the 2:nd telephone
number you want to call
in case of emergency
alarm.
Press ”#” to go to
next text Telephone number 2 are normally P100-numbers. To
change Alarm type press “B”.
Step 6: _
TEL.NUMBER 3 =
#=NEXT D=HELP
Write the 3:rd telephone
number you want to call
in case of emergency
alarm.
Press ”#” to go to
next text Telephone number 3 and 4 are normally voice
connection. To change Alarm
type press “B”.
Step 7: _
TEL.NUMBER 4 =
#=NEXT D=HELP
Write the 4:th telephone
number you want to call
in case of emergency
alarm.
Press ”#” to go to
next text Telephone number 3 and 4 are normally voice
connection. To change Alarm
type press “B”.
Step 8: _
TEL.CODE TO
MINICALL
#=NEXT D=HELP
Write the code that is to
be sent to a beeper. Press ”#” to go to next text This code will show on the beeper’s display.
Step 9: _
TESTALARM/
STATUS
TEL. NUMBER.
#=NEXT D=HELP
Write the telephone
number that will receive
test alarm and status
report.
Press ”#” to go to
next text If no telephone number is given, there will be no test
alarm sent.
Step 10: _
DAYS BETWEEN
TESTALARM
#=NEXT D=HELP
Write number of days
between test alarms.
It could be 1-99 days
Press ”#” to go to
next text If the value is set to “0” no test alarm will be sent.
Step 10B: CALLTONES
BEFORE ANSWER
#=NEXT D=HELP
Write number of calltones
before telephone answers
00-16 is accepted by
telephone,
2 digits must always be
written.
Press ”#” to go to
next text If it is set to ”00” The telephone will never
answer.
Step 11: _
SUPERV. ALARM
TEL. NUMBER.
#=NEXT D=HELP
Write the telephone
number that will receive
the supervision alarm
(only for Safeline 2000)
Press ”#” to go to
next text Breakdown alarm can only be sent if there is a special
Breakdown alarm card
mounted in the unit *
Step 12: _
BATTERYALARM
TEL. NUMBER.
#=NEXT D=HELP
Write the telephone
number that will receive
the battery alarm. The
battery condition is check
once per week. It is done
by discharging the battery
and measures the battery
voltage. (only for Safeline
2000)
Press ”#” to go to
next text The battery alarm sends the secondary alarm-code as
identifier.
Step 13: _
SET/CHANGE
PASSWORD
#=NEXT D=HELP
Write the password to be
used when programming/
configuring from an
external telephone or with
our PC-software *
Press ”#” to go to
next text A maximum of 9 telephones can be coupled on the
same line with “cascade
connections”
Step 14: _
SET/CHANGE
UNITADDRESS
#=NEXT D=HELP
Write the address to the
telephone in question, if
you connect more than
one telephone on the
same line.
Press ”#” to go to
next text 9 telephones can be coupled on the same line with
“cascade connections”with
full functionality, if skipping
unit address up to 25 units in
series can be coupled.
Programming with hand unit

7
Hisselektronik
www.safeline.se
Step 15: SEND ALL
CHANGES TO
SAFELINE ?
A=YES B=NO
Press “A” to send
all changes to the
telephone.
Press “B” to save
everything in the hand
unit.
The cable must be
connected to the telephone
when the changes are sent.
Step 16: <------------------------>
FINISHED !
POWER OFF AND
DISCONNECT
CABLE
Turn off the power and
disconnect the cable After about 8 seconds the text will start from Step 1
Example on how to simplify the programming:
At repetition programming only the alarm-codes need to be changed.
If battery alarm is not used, only alarm-code 1 is needed.
Step by
step… The display shows: Explanation: Next to do: Tip:
Turn on the
power Handunit for
Safeline 1000/2000
-----------------
Version 1.15
After about 3 seconds
the next text will show.
Step 2: _
ALARM CODE 1 =
#=NEXT D=HELP
Write the 8-digits P100/
CPC alarm-code given
to you by your alarm-
receiving operator.
This is the “Primary
code”.
This code to be used for
lift alarm.
Press ”#” to go
to next text
Step 3: _
ALARM CODE 2 =
#=NEXT D=HELP
Write the second 8-digits
P100/CPC alarm-code
given to you by your
alarm-receiving operator.
This is the “Secondary
code”.
This code to be used for
battery alarm.
Press ”C”
to finish the
programming.
The cable need to be
connected only when the
changes are sent.
Step 15: SEND ALL
CHANGES TO
SAFELINE ?
A=YES B=NO
Press “A” to send
all changes to the
telephone.
The cable need to be
connected only when the
changes are sent.
Step 16: <---------------------
------>
FINISHED !
POWER OFF AND
DISCONNECT
CABLE
Turn off the power and
disconnect the cable. After about 8 seconds the text will start from Step1.
Simplified programming

8
Hisselektronik
www.safeline.se
To set the internal memory to zero
Step by
step… The display shows: Explanation: Next to do: Tip:
Turn on the
power Handunit for
Safeline 1000/2000
-----------------
Version 1.15
Press ”D” within 3
seconds.
The
display will
automatically
show
Initialising The internal memory is
set to zero. This will automatically
take you to
Step 2.
Step by
step… The display shows: Explanation: Next to do: Tip:
Turn on the
power Handunit for
Safeline 1000/2000
-----------------
Version 1.15
Press ”C” within 3
seconds. The cable has to be connected to read the
telephone.
The
display will
automatically
show
****************
Reading from
Safeline
****************
All codes and telephone
number are read from
the telephone.
This will
automatically
take you to
Step 2.
Now you can go through and
check/change all codes and
telephone numbers.
To read all codes and telephone number from an existing telephone:
To change alarm types: Follow the programming to Step 4
Step by
step… The display shows: Explanation: Next to do: Tip:
Step 4: _
TEL.NUMBER 1 =
#=NEXT D=HELP
Press ”B” to change
alarm type.
P100 -- to call alarm
receiver operator.
VOICE -- to call a
standard telephone.
MINICALL -- to call
to leave a code to a
beeper.
Press ”#” to go
to next text
Step 5-7: Repeat all as above. Press ”#” to go
to next text Press ”#” to read out active alarm type, press “#” again
to change alarm type.
To save press ”#”.
Simplified programming

9
Hisselektronik
www.safeline.se
Programming from a dial tone telephone:
It is possible to program the telephone by calling to it.
By using different dial tone commands it is possible to program all codes
and telephone numbers to the telephone.
This is how to do it:
If only one telephone is connected to the line:
Call the lift telephone. It will answer with 3 tones after 2 signals (this is
standard but can be changed to 0-16 signals).
If more then one telephone are connected to the line:
Call the alarm telephone. After 2 signals the telephone will answer
(always 2 signals when more than one connected lift telephone).
To get to e.g. telephone number 3, press “3” repeatedly until 3 distinctly
signals are heard and the connection is made.
Dial “00”, the lift telephone will answer with “OK” (2 short signals) or
“Wrong” (1 long signal).
Dial the password - * XXXX # where XXXX stands for the password. The
default password is “0000”.
The lift telephone answers with “OK” (2 short signals) or “Wrong” (1 long
signal).
Change codes and/or telephone numbers according to the below table.
There is a time span of 5 seconds between the digits, after that time there
will be a “Wrong” signal and the registration has to start all over again.
After 30 seconds without activity the lift telephone will disconnect the call.
After a successful registering the code/telephone number will be saved.
If there is a “Wrong” signal or if the call is disconnected, all successful
registering are saved.
Always discontinue the call: *00*#
1.
1.
2.
3.
4.
5.
6.
Dial tone programming

10
Hisselektronik
www.safeline.se Dial tone programming
CODE DATA NOTE
Alarm codes
P100 ID code *01* - - - - - - - - # P100 always 8 digits
CPC ID code *02* - - - - - - # CPC 6-8 digits
Q23 ID code *03* - - - - - - - - - - - - # Q23 always 12 digits
Phone number:
1st Phone no.: *11* - - - - - - - - - # Phone no. To alarm receiver 0-16 digits.
2nd Phone no.: *12* - - - - - - - - - # Phone no. To alarm receiver 0-16 digits.
3rd Phone no.: *13* - - - - - - - - - # Phone no. To alarm receiver 0-16 digits.
4th Phone no.: *14* - - - - - - - - - # Phone no. To alarm receiver 0-16 digits.
Alarm type:
Alarm type 1st no.: *21* - # Change alarm type 1-4th number:
Alarm type 2nd no.: *22* - # 0=P100, 1=VOICE, 2=Q23, 3=CPC
Alarm type 3rd no.: *23* - #
Alarm type 4th no.: *24* - #
Alarm type LMS no.: *30* - # LMS alarm type only CPC/P100
Test alarm/battery alarm:
LMS Phone no.. *16* - - - - - - - - - # LMS phone number.
To alarm receiver / SLCC
Test alarm *17* - - - - - - - - - # Phone number.
To test alarm receiver / SLCC
Days between tests *27* - - # Days between tests.
00-99 days.
Test alarm protocol. *31* - # Protocol test alarm 0 = P100 (SLCC),
3 = CPC
Alarm character:
Alarm character 1st no.: *41* - - # Alarm character. Only when CPC is used
Alarm character 2nd no.: *42* - - # as alarm protocol normally 10 or 27.
Alarm character 3rd no.: *43* - - # Check with your alarm central!
Alarm character 4th no.: *44* - - #
Alarm character LMS *45* - - # LMS (Battery alarm) Normally 17
Alarm character Test alarm *46* - - # Test alarm= Normally 26
Number of ring signals.*72* - - # Ring signals before re-dial. (02-50)
Hot Line *75* - # 0 = Standard phone line (standard)
1 = Hot line
Automatic answering *81* - - # Set to 00-16 00=Don’t answer.
(standard = 02)
Unit number. *82* - # 0 (standard) - 9
Dial tone detect *83* - # 0=Off 1=On (standard)
Set to 0 if SafeLine is having problems detecting
the dial tone.
Receipt to SLCC *84* - # 0 = Off (don’t send receipt), 1 = On (send receipt)
Break on new alarm *86* - # 0 = Off 1 = On (standard)
Password *91* - - - - # Change password (standard=0000)
Simulate an alarm event *94* - # Simulates an alarm event.
Note! LMS no. *16* must be programmed.
1 = Emergency alarm.
2 = Test alarm.
5 = Receipt on voice call.
Restore to default: *99* 1 # Restores unit to factory default.
End programming:
End programming. *00# *00# End programming.

11
Hisselektronik
www.safeline.se
Example on common alarm telephone settings
To register a P100/CPC code 11335588
Primary number to custodian (voice call) 046-443322
Secondary number to alarm-receiving operator 031-223344
If only one telephone is connected to the line:
Call the alarm telephone. It will answer after 3 distinctive tones after 2 ring
signals (can be changed to 0-16 signals).
If more than one telephone is connected to the line:
Call the lift telephone. After 2 signals the telephone will answer
(always 2 signals when more than one alarm telephone is connected).
To get to i.e. telephone number 3, press “3” repeatedly until 3 distinctly signals
are heard and the connection is made.
Dial “00”, the lift telephone will answer with “OK” (2 short signals) or “Wrong”
(1 long signal).
Dial the password - * XXXX # where X stands for the password. The default
password is “0000”.
The lift telephone answers with “OK” (2 short signals) or “Wrong”
(1 long signal).
Dial *01*11335588# to register the P-100 code. The lift telephone answers
with “OK”.
Dial *11*046443322# to register the Primary number. The lift telephone
answers with “OK”.
Dial *12*031223344# to register the Secondary number. The lift telephone
answers with “OK”.
Dial *21*1# to change the alarm type on the primary number to “Voice”. The
lift telephone answers with “OK”.
Dial *00*# to discontinue programming. The lift telephone answers with “OK”.
1.
1.
2.
3.
4.
5.
6.
7.
8.
Common settings

12
Hisselektronik
www.safeline.se
Programming with SafeLine Pro
You can also program SafeLine™ 1000 with our free PC-
software. The program is free and can be downloaded from our
web site www.safeline.se/.
Volume control
Volume control

13
Hisselektronik
www.safeline.se
Connections
Power 0 volt
Power +10-30 volt
Emergency signal button
Phone line OUT to next SafeLine
Phone line IN
+ AT ALARM

Hisselektronik AB
Hisselektronik AB
Antennvägen 10
Antennvägen 10
SE-135 48 Tyresö
SE-135 48 Tyresö
SWEDEN
SWEDEN
Phone: [phone]
Phone: [phone]
Fax: [phone]
Fax: [phone]
E-mail:. [email protected]
E-mail:. [email protected]
Webb: www.safeline.se
Webb: www.safeline.se
Support forum: www.safeline.se/support
Support forum: www.safeline.se/support
