Sagem MYC-4 Guide




SITE TECHNICAL DOCUMENTATION
myC-4
Doc. No. : SCT U38 SSC DTS 0023
Version : B
Date : February 21, 2005
Produced by 
2, rue du Petit Albi, 95800 Cergy Saint-Christophe, France
Tel [phone] - Fax [phone]
Copyright 2002
SAGEM
Cergy Saint-Christophe, France

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page I
NO DISCLOSURE AGREEMENT
This document is SAGEM SA property. It can not be copied or communicated in all or part without written
authorisation.

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page II
CONTENTS
CHAPTER 1 - FOREWORD
1.1 HOW TO USE THE SITE TECHNICAL DOCUMENTATION.............................................................1-1
1.2 ABREVIATIONS .................................................................................................................................1-2
1.3 COMMENTS SHEET..........................................................................................................................1-3
CHAPTER 2 - DESCRIPTION - OPERATION
2.1 REMINDERS ABOUT THE GENERAL CHARACTERISTICS OF GSM AND PCS NETWORKS.....2-1
2.2 REMINDERS ABOUT myC-4 CHARACTERISTICS..........................................................................2-2
2.3 DATA/AUDIO/CHARGE CONNECTOR.............................................................................................2-5
2.3.1 Connector description................................................................................................................2-5
2.3.2 Signal description.......................................................................................................................2-5
2.4 IDENTIFICATION ...............................................................................................................................2-6
2.4.1 Illustration...................................................................................................................................2-6
2.4.2 Description………………………………………………….…………………………………………..2-6
2.4.3 Description after reparation .......................................................................................................2-7
2.5 PHONE BLOCK DIAGRAM................................................................................................................2-8
2.5.1 myC-4 block diagram.................................................................................................................2-8
2.5.2 Standards and environment.......................................................................................................2-8
2.6 EQUIPEMENTS..................................................................................................................................2-9
2.6.1 Battery packs .............................................................................................................................2-9
2.6.2 Mains modules.........................................................................................................................2-10
CHAPTER 3 - SYMPTOMS
3.1 GENERAL...........................................................................................................................................3-1
3.2 LIST OF REPORTED DEFECTS .......................................................................................................3-2
3.3 ERROR MESSAGES DURING START UP .......................................................................................3-4
3.4 OTHER ERROR MESSAGES............................................................................................................3-4
3.5 LIST OF OBSERVED DEFECTS .......................................................................................................3-6
3.6 INFORMATION ABOUT NEW NOTICED FAULTS ...........................................................................3.6
SYMPTOM SHEET ....................................................................................................................................3-7
SYMPTOM SHEET 01 : ENDURANCE BATTERY CHARGER………………………………………………3-8
SYMPTOM SHEET 02 : COMMUNICATION………….…………………………………………………….…3-9
SYMPTOM SHEET 03 : NO FAULT GIVEN…………………………………………………………………....3-10
SYMPTOM SHEET 04 : DISPLAY…………………………….…………………………………………………3-11

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page III
SYMPTOM SHEET 05 : KEYPAD…........................................................................................................3-12
SYMPTOM SHEET 06 : RING TONES....................................................................................................3-13
SYMPTOM SHEET 07 : VIBRATE .............................................….………………………………………..3-14
SYMPTOM SHEET 08 : LOUDSPEAKER/ MICROPHONE………………………………………………...3-15
CHAPTER 4 - TESTS AND CHECKS
4.1 GENERAL ABOUT TESTS ................................................................................................................4-1
4.2 TEST TOOLS .....................................................................................................................................4-1
4.3 INSTALLING ON A WORKSTATION.................................................................................................4-2
4.3.1 Minimum required configuration ................................................................................................4-2
4.3.2 Installing the CRA downloading kit ............................................................................................4-2
4.3.3 SMT functions............................................................................................................................4-2
TEST SHEET ..............................................................................................................................................4-3
TEST SHEET 01 : TEST CHECK BY SMT …………………………………………………...........................4-4
TEST SHEET 02 : CHARGER TEST……………………………………………………………………………4-13
TEST SHEET 03 : BATTERY TEST…………………………………………………………………...............4-14
TEST SHEET 04 : "HOTLINE" MENU …………………………… .............................................................4-15
TEST SHEET 05 : RADIO TEST………………………….. ........................................................................4-16
CHAPTER 5 – MAINTENANCE PROCEDURES
5.1 TECHNICAL WORK LEVELS.............................................................................................................5-1
5.2 SHORT LOOP PROCEDURE ............................................................................................................5-2
5.3 MAINTENANCE TOOLS ....................................................................................................................5-4
LEVEL 0 MAINTENANCE ..............................................................................................................................5-5
PROCEDURE SHEET 0 01 : REMOVING AND REPLACING THE BATTERY ........................................5-6
PROCEDURE SHEET 0 02 : REMOVING AND REPLACING THE ANTENNA........................................5-8
LEVEL 1 MAINTENANCE ............................................................................................................................5-10
PROCEDURE SHEET 1 01 : REMOVING AND REPLACING NUMBER KEYPAD................................5-11
PROCEDURE SHEET 1 02 : REMOVING AND REPLACING THE BACK COVER ...............................5-13
PROCEDURE SHEET 1 03 : REMOVING AND REPLACING EQUIPPED ELECTRONIC BOARD…. .5-15
PROCEDURE SHEET 1 04 : REMOVING AND REPLACING METAL DOME OF NUMBER KEYPAD.5-17
PROCEDURE SHEET 1 05 : REMOVING AND REPLACING BATTERY LOCKER ..............................5-19
PROCEDURE SHEET 1 06 : REMOVING AND REPLACING THE FRONT COVER OF THE LOWER
SLIDE .......................................................................................................................................................5-21
PROCEDURE SHEET 1 07 : REMOVING AND REPLACING THE BACK COVER OF THE UPPER
SLIDE .......................................................................................................................................................5-23

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page IV
PROCEDURE SHEET 1 08 : REMOVING AND REPLACING THE NAVIGATOR KEYPAD..................5-25
PROCEDURE SHEET1 09 : REMOVING AND REPLACING THE FRONT COVER .............................5-27
PROCEDURE SHEET1 10 : REMOVING AND REPLACING THE METAL DOME OF TH NAVIGATOR
KEYPAD...................................................................................................................................................5-29
PROCEDURE SHEET 1 11 : REMOVING AND REPLACING THE VIBRATING DEVICE.....................5-31
PROCEDURE SHEET 1 12 : REMOVING AND REPLACING THE MICROPHONE..............................5-33
PROCEDURE SHEET 1 13 : REMOVING AND REPLACING THE DISPLAY MODULE.......................5-35
PROCEDURE SHEET 1 14 : REMOVING AND REPLACING THE LOUDSPEAKER............................5-37
PROCEDURE SHEET 1 15 : ELECTRONIC BOARD EXCHANGE........................................................5-39
LEVEL 3 MAINTENANCE ............................................................................................................................5-42
PROCEDURE SHEET 3 01 : RETURN TO SAGEM FACTORY.............................................................5-44
PROCEDURE SHEET 3 02 : RETURN TO CUSTOMER……………………………………………………5-45
CHAPTER 6 - ACCESSORIES
6.1 PEDESTRIAN HANDSFREE KIT.......................................................................................................6-1
6.1.1 Description.................................................................................................................................6-1
6.1.2 Characteristics ...........................................................................................................................6-1
CHAPTER 7 – TECHNICAL INFORMATION BULLETIN
7.1 PURPOSE ..........................................................................................................................................7-1
7.2 APPLICATION ....................................................................................................................................7-1
CHAPTER 8 – ILLUSTRATED PARTS CATALOG
8.1 myC-4 SPARE PARTS.......................................................................................................................8-1
8.2 myC-4 EXPLODED VIEW ..................................................................................................................8-2
APPENDIX 1 – COMPOSITION TABLE

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page 1-1
CHAPTER 1 - FOREWORD
This document is common to all phones in the SAGEM. It is composed of independent sheets:
−Symptom sheets = Symp Sheet XX
−Test and check sheet = Test Sheet XX
−Maintenance procedure sheet = Proc Sheet X XX
The applicability of a procedure is indicated in the independent sheets title block:
−All types = GSM 850/900, GSM 1800/1900 and dual band.
These sheets are updated from time to time in Technical Information Bulletins (TIB).
The information contained in this document is non-contractual, since phone characteristics can change.
Phones are managed based on SAGEM handset codes; any order for spare parts must refer to these codes
(typical code 25 xxx xxx-x).
1.1 HOW TO USE THE SITE TECHNICAL DOCUMENTATION
This is a modular document. Each sheet is unique and independent. In some cases several sheets may
have to be used in order to determine the complete procedure to be applied.
A troubleshooting chapter (chapter 3) is provided and is sorted according to the type of reported fault, to
determine the maintenance procedure to be carried out.
These sheets describe the procedure to be followed. They refer to test sheets or removal and replacement
maintenance sheets. Maintenance ,executed by the repair centre, terminates either by returning the product
to the customer, or by dispatching it to level 3 maintenance (return to factory).
Symp Sheet (Chap. 3)
Test Sheet (Chap. 4)
Proc Sheet (Chap. 5)
Test Sheet (Chap. 4)
Customers
Symptoms
Maintenance
Tests
Checks
Return to SAGEM
level 3
level 0-2

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page 1-2
All sheets include illustrations to make it easier to read the procedure.
Chapter 1 : Foreword, describes general data about this document.
Chapter 2 : Description - Operation, describes general data and options available in the myC-4.
Chapter 3 : Symptoms, contains troubleshooting procedures to be carried out on equipment.
Chapter 4 : Tests and checks, contains tests and check procedures to be performed on the equipment.
Chapter 5 : Maintenance procedures, contains level 0 to 2 maintenance procedures to be carried out
on the equipment, and the procedure to return to SAGEM level 3.
Chapter 6: Accessories, describes the characteristics of accessories for myC-4 phones.
Chapter 7: Technical Information Bulletins, contains the various modifications made to this
documentation.
Chapter 8: Illustrated Parts Catalogue, contains the various reference for spare parts.
Appendix 1: Composition table, contains the various SAGEM references codes for equipment
described in this document.
1.2 ABREVIATIONS
AAC Advanced Audio Coder
ADPCM Adaptive Differential Pulse Codec Modulation
ALS Alternative Line Services
AOC Advice Of Charge
CCD Charged Coupled Device
CLI Calling Line Identification
CLIP Calling Line Identification Presentation
CSTN Colored Super Twisted Nematic
DCS Digital Cellular System
EFR Enhanced Full Rate
EMS Enhanced Message Service
FDN Fix Dial Number
GPRS General Packet Radio Service
GSM Global System for Mobile
IMEI International Mobile Equipment Identity
ISO International Standard Organisation
LCD Liquid Crystal Display
LU Livret d’Utilisation (User’s guide)
MMS Multimedia Message Service
PCS Personnal Communication Service
PIN Personal Identity Number
PUK PIN Unlocking Key
RF Radio Frequency

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page 1-3
SAR Specific Absorption Rate
SIM Subscriber Identify Module
SMS Short Message Service
SMS CB Short Service Message Cell Broadcast
SMT Sagem Mobiles Tools
TFT Thin Film Transistors
USSD Unstructured Supplementary Service Data
VGA Video Graphics Array
WAP Wireless Application Protocol
WiFi Wireless Fidelity
WSP Wireless Session Protocol
1.3 COMMENTS SHEET
Broad experience is very beneficial in several respects. Please let us know your comments so that we can
improve the contents and presentation of this document.
Your suggestions will be read carefully by:
- the design laboratory,
- production,
- the purchasing department,
- the after sales service,
- all users of this document.
All your suggestions are valuable, they will help us to better satisfy you.
Please photocopy and fill in the sheet 1-4.

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 - Index B - February 21, 2005 Page 1-4
Document title: Site Technical Document for myC-4
Reference : SCT U38 SSC DTS 0023
Date :
Please fill in the following table :
Excellent Good Fairly good Passable
Easy to find the required information
Clarity of information provided
Quality and accuracy of information given
Document outline
Document presentation and appearance
Quality of illustrations
General satisfaction
Do you think this document could be improved ? if so, how ? :
Improve the overall view
Improve the table of contents
Improve the structure
Add illustrations
Add details
Add information
Comments : ____________________________________________________________________________
______________________________________________________________________________________
_________________________________________
Would you like to discuss the problems mentioned in this questionnaire? If so, state :
Name of the person to be contacted : ________________________ Phone : ________________
Company : _____________________________________________ Date : _________________
Address : ________________________________________________________________
THANK YOU FOR PARTICIPATING IN THIS ENQUIRY. YOUR COMMENTS WILL HELP US CONTINUE
TO IMPROVE THE QUALITY OF OUR DOCUMENTATION AND THUS BETTER SATISFY YOUR NEEDS.
When you have filled in this questionnaire, please send it :
SAGEM S.A.
Support Service Client / URD 38
2 rue du petit Albi
BP 8250
95801 Cergy Saint-Christophe
FRANCE

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-1
CHAPTER 2 - DESCRIPTION - OPERATION
2.1 REMINDERS ABOUT THE GENERAL NETWORKS CHARACTERISTICS
Table 1 below gives the characteristics of the radio interface for the GSM 850 / 900, GSM 1800 systems :
GSM 900 GSM 1800
Frequency Band (MHz) 890 - 915
925 - 960
1710 - 1785
1805 - 1880
Number of time intervals per TDMA
frame 8
Width 2 x W simplex (MHz) 2 x 25 2 x 75
Duplex spacing (MHz) 45 95
Modulation speed (kbit/s) 271
Speech throughput (kbit/s) 13 (5,6)
Maximum data throughput (kbit/s) 12
Multiple access Frequency and temporal
multiplexing / frequency duplexing
Cell radius (km) 0,3 to 30 0,1 to 4
SAGEM terminal power (W) 2 1
Table 1 : Radio Interface
Table 2 shows powers as a function of the network :
GSM 900 GSM 1800
Class number Maximum nominal
power (W) Allowable interval (W) Maximum nominal power (W) Allowable interval (W)
1 - - 1 [0,63 ; 1,6]
2 8 [5,0 ; 12,7] 0,25 [0,16 ; 0,4]
3 5 [3,2 ; 7,9] 4 [2,5 ; 6,3]
4 2 [1,3 ; 3,2]
5 0,8 [0,5 ; 1,3]
Table 2: Terminals power class
Table 3 shows power classes :
Class 1 Class 2 Class 3 Class 4 Class 5
GSM 900 43 dBm 39 dBm 37 dBm 33 dBm 29 dBm
GSM 1800 30 dBm 24 dBm 36 dBm - -

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-2
Table 3: RF power classes

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-3
2.2 REMINDERS ABOUT THE CHARACTERISTICS AND OPTIONS OF myC-4
Remark: This information is given for guidance, and is in no way contractual characteristics vary according to
customers and countries.
GENERAL CHARACTERISTICS
Size
Dimension (
LxWxH, mm)
89.7x44.5x22.9mm (L= 129.7mm
when open)
Weight (g)
91g
Volume (cm3)
90
Power Management
Battery type
L
i-ion 700mAh
Charging time 2h
Talk time (TW.09) Up to 3,5h
Standby time (TW.09) Up to 320h
Display and User Interface
Screen type CSTN
Colours 65536
Number of lines Up to 8 lines
Screen size LxH (mm) 28x28
Screen resolution (pixels) 128x128
Backlight yes
Soft keys / navigation Yes, 2 programmable keys
Sub LCD (clam design) n/a
Customisation
Handset colours Bright red
Interchangeable covers No
Radio
GSM Band 900, 1800 MHz
Automatic switching between bands Yes
Voice codecs EFR,HR,FR,AMR (voice memo only)
CONNECTIVITY
Radio
GPRS
Yes, class 10 (4+1 & 3+2)
UMTS
No
Internet
Browser WAP 1.2.1
Push Yes, factory previsioning
Built-in data / fax Modem Yes
Data Transfer
Serial No
IrDA (Obex or other standard) No
Bluetooth
No
USB Yes, USB cable as optional accessory
WiFi (802.11b,a) No
PC/MAC directory synchronisation yes
MULTIMEDIA
Messaging
SMS MO/MT/CB
EMS Yes, v5

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-4
MMS Yes, v4
MULTIMEDIA (
cont'd)
Notification Yes
Predictive text input T9
Video & Images
Camera No
Video Player No
Image features Yes
Image Format
BMP, WBMP, PNG, JPEG, GIF
Audio
Audio Recorder
Yes
Polyphonic
ringtones
Yes
Hi-Fi
ringtones
Yes
Audio formats IMELODY, MIDI, WAV (PCM, ADPCM), AMR, C-MIDI
Entertainment
Wallpaper Yes
Screensaver Yes
Clock display Yes, analog or digital
Icons Yes
Embedded games Yes
JAVA Yes, MIDP 2.0
OTA Downloads
Protocol supported EMS, MMS, WSP-Get, WAP save as, PC sync
Wallpaper / screensaver Yes, via EMS, MMS, WAP, PC download (MPAS)
Animation Yes, via EMS, MMS, WAP, PC download (MPAS)
Menu icon Yes
Ringing melodies Yes
Music no
Java application Yes
Game Yes
CALL MANAGEMENT
Voice features
Mute mode Yes
Integrated handsfree mode Yes
Address book features
Call group Yes
Personal information management (V-card) Yes
Ringtone / Icon customisation Yes
Advanced Features
Conference call
Yes
Call list (dialled, received and missed)
Yes
Caller ID
Yes
Anonymous mode
Yes
Call wait / call hold / call transfer Yes
Call forwarding Yes
Sim toolkit Yes
Vibrate mode Yes
Speed dialling Yes, voice mail only by long press on 1
Automatic redial Yes
Any key answer no
Active flap/ active slide yes
SPECIAL FEATURES
Bio Features

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-5
Bio-Rhythm No
Bio-Calendar No
SPECIAL FEATURES (
cont’d)
Keyboard Features
Scroll key No , navigator only
Keypad lock Yes
Silent key Yes, by long press on *
International access key
Yes, by long press on 0
Personal Management Features
Calculator
Yes
Alarm Clock
Yes
Organizer
Yes
To Do
Yes
Voice memo
Yes, AMR
codec
Currency converter
Yes
Languages
Up to 8 languages embedded
Compatible Accessories
Data cord
Yes, only as accessory
Universal charger
Yes
Hands free kit
Yes
MEMORY
Internal phone book (positions)
Depending on
available free
memory
Messaging memory SMS/EMS/MMS/Email
Depending on
available free
memory
Redial list (positions)
Depending on
available free
memory
Additional multimedia memory
No
Embedded memory (Max size for total user objects)
4,7Mbytes

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-6
2.3 DATA/AUDIO/CHARGE CONNECTOR
2.3.1 Connector description
This connector is located at the bottom of the transmission module and enable the connection to various
accessories. It comprises power supply pins and signals.
2.3.2 Signal description
SYMBOL PIN No. SIGNAL FUNCTION
BFTXP 1 Differential input from microphone
BFTXN 2Differential input from microphone
BFRXP 3 Differential output to earphone
BFRXN 4 Differential output to earphone
VBAT 5POWER SUPPLY IMAGE VOLTAGE, connect this signal
to «CHARGER» (pin n°1) to switch the module on.
DETECT 6 Accessories detection
CTS 7 Clear To Send
RTS 8 Request To Send
DSR 9 Data Send Ready
DTR 10 Data Terminal Ready
TXD1 11 UART transmit 1
TXD2 12 UART transmit 2
GND 13 ZERO VOLT
RXD1 14 UART receive 1
RI 15 Ring Indicator
DCD 16 Data Carrier Detect
RXD2 17 UART receive 2
CHARGER 18 Phone set power ON and power supply signal.
Connector
GSM
1 18

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-7

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-8
2.4 IDENTIFICATION
All phones are identified with an identification label sticked on the antenna.
2.4.1 Illustration
2.4.2 Description
a : IMEI (bar code),
b : IMEI (15 characters)
c : Reference of product / aesthetic used (bar code)
d: Reference of product / aesthetic used ( 9 characters)
e : Date code + Manufacturing level + Production area Indication,
Ex. F274/02 = (F) fabrication area (F : Fougères), (274) day of year, (02) last digit of year
(02→2002).
Ex: B254: Manufacturing level
Ex: Made in China: Production area Indication
f : Product designation
g :Module serial number (bar code)
h: Module serial number (10 characters),
i: Sim card Indication (Sim 3V…)

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-9
2.4.3 Description after repair
A new sticker is positioning by Repairing Centre near the sim card connector:
This extra line will appear if the mobile has already been repaired.
-CRA XXX N°of CRA,
-203/N03 Date of repair: (203) repairing day, (03) last digit of year (03→2003).

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-10
2.5 PHONE BLOCK DIAGRAM
2.5.1 myC-4 block diagram
2.5.2 Standards and environment
Conformance Document
SAGEM SA declare under its sole responsibility that the product Dual Band GSM/DCS Type B2003
conforms to the
requirements of the following EEC directives:
EEC Directive 1999/5/CE
Safety EN 60950
EMC EN 301 489-1 / EN 301 489-7
Low voltage directive 73/23/CEE
Network 3GPP TS 51.010-1 v 5.2.0 selected with GCF-CC v 3.10.0 included
Requirements GT01 v 4.7.0 / TBR 19 Edition 5 /TBR 20 Edition 3 / TBR 31 Edition 2
TBR 32 Edition 2 / EN 301 419-1 /EN 301511
Health EN 50360 / EN 50361
LCD / KEYPAD
BASEBAND RADIO

Technical Site Documentation myC-4
Ref. SCT U38 SSC DTS 0023 – Index B - February 21, 2005 Page 2-11
2.6 EQUIPEMENTS
The description and operation of SAGEM myC-4 are given in the "User’s handbook" supplied with the phone.
This chapter only describes equipment that operates with the myC-4 phones .
2.6.1 Battery packs
Over view
2.6.1.1 Characteristics
Technology Weight Voltage capacity
Li-ion 24g 700mAh
2.6.1.2 Description
Li-ion type batteries are used. They are rechargeable using:
-mains power supply modules,
Batteries caution use:
•Store the batteries in a dry and cool place (excessive cold and heat damage the batteries reliability).
•They must never be stored in bulk, even the rejects, to avoid any short circuits.
•Do not dismantle the battery packs. (Li-Ion regulations).
•Only use original mains power supply module.
•All the out of order batteries must be returned to SAGEM.
