Nokia 7500b User manual

Nokia 7500b User Guide
92XXXXX
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 1 May 14, 2007 3:20:53 PM

DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-250 product is in compliance
with the essential requirements and other relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be found at www.nokia.com/phones/
declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Care, Visual Radio, and Navi are trademarks or registered trademarks of Nokia
Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein
may be trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the
prior written permission of Nokia is prohibited.
US Patent No 5818437 and other pending patents. T9 text input software Copyright © 1997-2007. Tegic
Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in
connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer
engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a
licensed video provider. No license is granted or shall be implied for any other use. Additional information, including
that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://
www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any
of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS
LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT
DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF
ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS
DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications for these products may vary by region. Please check with your
Nokia dealer for details, and availability of language options.
The third-party applications providedwith your device may have been created and may be owned by persons or entities
not affiliated with or related to Nokia. Nokia does not own the copyrights or intellectual property rights to the third-
party applications. As such, Nokia does not take any responsibility for end-user support, functionality of the
0434
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 2 May 14, 2007 3:20:53 PM

applications, or the information in the applications or these materials. Nokia does not provide any warranty for the
third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF
ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE
THAT NEITHER NOKIA NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR THAT THE
APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
Export controls
This device may contain commodities, technology or software subject to export laws and regulations from the US and
other countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving
equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC
rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation. Any
changes or modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
Check www.nokia.com/support to get the latest version of this guide, contacts, information and
additional services and also to download PC Suite and other software. Consult the nearest service
point and set up your phone.
92XXXXX/Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 3 May 14, 2007 3:20:53 PM

Contents
For your safety ................................7
About your device...........................8
Network services.............................9
Shared memory...............................9
Enhancements...............................10
1. General information................11
Access codes....................................................11
Configuration setting service....................12
Download content........................................12
Software updates..........................................12
Nokia support.................................................13
2. Get started.................................14
Install SIM card and battery.......................14
Insert a microSD card...................................15
Charge the battery........................................16
Antenna............................................................17
Headset.............................................................17
Change the accent color frame.................18
Strap..................................................................18
3. Your device................................19
Keys and parts................................................19
Switch the device on and off.....................20
Standby mode................................................20
Flight mode.....................................................23
Keypad lock (keyguard)...............................24
Functions without a SIM card....................24
4. Call functions.............................24
Make a call.......................................................24
Answer or reject a call..................................26
Options during a call....................................26
5. Write text...................................27
Text modes......................................................27
Traditional text input...................................27
Predictive text input.....................................28
6. Navigate the menus.................28
7. Messaging..................................29
Text messages................................................29
Multimedia messages..................................30
Create a text or multimedia
message...........................................................30
Read a message and reply..........................31
Message sending process...........................31
E-mail................................................................31
Flash messages..............................................33
Nokia Xpress audio messaging.................34
Memory full.....................................................34
Folders..............................................................35
Instant messages..........................................35
Voice messages..............................................39
Info messages................................................40
Service commands........................................40
Delete messages............................................40
SIM messages..................................................40
Message settings...........................................40
8. Contacts......................................43
Save names and phone numbers.............43
Save details.....................................................44
Settings.............................................................44
Groups...............................................................45
Search for a contact......................................45
Copy or move contacts.................................45
Edit contact details.......................................45
Delete contacts...............................................46
Synchronize all...............................................46
Business cards................................................46
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 4 May 14, 2007 3:20:53 PM

Dialing shortcuts............................................46
Info, service, and my numbers..................47
9. Call log.........................................47
10. Settings....................................48
Profiles..............................................................48
Themes.............................................................48
Tones.................................................................49
Display...............................................................49
Time and date................................................49
My shortcuts....................................................50
Bluetooth.........................................................51
Packet data......................................................53
Data transfer...................................................54
USB data cable................................................55
Call......................................................................56
Phone................................................................56
Enhancements................................................57
Configuration..................................................58
Security.............................................................59
Software updates over the air..................60
Restore factory settings..............................61
11. Operator menu.......................61
12. Gallery.......................................61
Folders and files.............................................62
Print images....................................................62
Memory card...................................................62
13. Media........................................64
Camera and video.........................................64
Music player.....................................................65
Radio.................................................................67
Voice recorder................................................69
Equalizer...........................................................69
Stereo widening............................................70
14. Push to talk..............................70
PTT channels...................................................70
Switch PTT on and off..................................71
Make and receive a PTT call........................71
Callback requests...........................................73
Add a one-to-one contact...........................73
PTT settings.....................................................74
Configuration settings.................................74
15. Applications.............................74
Launch a game...............................................75
Launch an application..................................75
Application options......................................75
Download an application............................75
16. Organizer.................................76
Alarm clock......................................................76
Calendar............................................................77
To-do list..........................................................78
Notes.................................................................78
Calculator.........................................................78
Timers...............................................................79
Stopwatch........................................................79
17. Web...........................................80
Set up browsing.............................................80
Connect to a service......................................80
Browse pages.................................................81
Bookmarks.......................................................81
Appearance settings.....................................82
Security settings............................................83
Download settings........................................83
Service inbox...................................................83
Cache memory................................................84
Browser security............................................85
18. SIM services.............................86
19. PC connectivity........................87
Nokia PC Suite.................................................87
Packet data, HSCSD, and CSD......................87
Bluetooth.........................................................88
Data communication applications...........88
20. Battery......................................88
Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 5 May 14, 2007 3:20:53 PM

Battery information......................................88
Nokia battery authentication
guidelines........................................................89
Care and maintenance.................92
Disposal............................................................93
Additional safety
information....................................93
Small children.................................................93
Operating environment...............................93
Medical devices..............................................94
Vehicles.............................................................95
Potentially explosive
environments.................................................96
Emergency calls..............................................96
CERTIFICATION INFORMATION
(SAR)..................................................................97
Index................................................99
Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 6 May 14, 2007 3:20:53 PM

For your safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read the
complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off near medical equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the device at a refueling point. Do not use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the device where blasting is in progress.
USE SENSIBLY
Use only in the positions as explained in the product documentation. Do not
touch the antenna areas unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 7 May 14, 2007 3:20:53 PM

ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all important
information stored in your device.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone function of the device is switched on and in service. Press
the end key as many times as needed to clear the display and return to the
standby mode. Enter the emergency number, then press the call key. Give your
location. Do not end the call until given permission to do so.
About your device
The wireless device described in this guide is approved for use on the GSM 850,
1800, and 1900 networks. Contact your service provider for more information
about networks.
When using the features in this device, obey all laws and respect local customs,
privacy and legitimate rights of others, including copyrights.
Copyright protections may prevent some images, music (including ringing
tones), and other content from being copied, modified, transferred, or
forwarded.
About your device
8
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 8 May 14, 2007 3:20:53 PM

Warning: To use any features in this device, other than the alarm clock, the
device must be switched on. Do not switch the device on when wireless device
use may cause interference or danger.
Network services
To use the phone you must have service from a wireless service provider. Many of the
features require special network features. These features are not available on all
networks; other networks may require that you make specific arrangements with your
service provider before you can use the network services. Your service provider can give
you instructions and explain what charges will apply. Some networks may have
limitations that affect how you can use network services. For instance, some networks
may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device menu. Your
device may also have a special configuration such as changes in menu names, menu
order, and icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP protocols. Some
features of this device, such as multimedia messaging (MMS), e-mail application, instant
messaging, remote synchronization, and content downloading using the browser or
MMS, require network support for these technologies.
Shared memory
The following features in this device may share memory: gallery, contacts, text messages,
multimedia messages, and instant messages, e-mail, calendar, to-do notes, Java™ games
and applications, and note application. Use of one or more of these features may reduce
the memory available for the remaining features sharing memory. Your device may
display a message that the memory is full when you try to use a shared memory feature.
Network services
9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 9 May 14, 2007 3:20:53 PM

In this case, delete some of the information or entries stored in the shared memory
features before continuing.
Enhancements
Practical rules about accessories and enhancements
•Keep all accessories and enhancements out of the reach of small children.
•When you disconnect the power cord of any accessory or enhancement, grasp and pull
the plug, not the cord.
•Check regularly that enhancements installed in a vehicle are mounted and are
operating properly.
•Installation of any complex car enhancements must be made by qualified personnel
only.
Enhancements
10
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 10 May 14, 2007 3:20:53 PM

1. General information
Access codes
Security code
The security code (5 to 10 digits) helps to protect your phone against
unauthorized use. The preset code is 12345. You can change the code, and set
the phone to request the code. See "Security," p. 59.
PIN codes
The personal identification number (PIN) code and the universal personal
identification number (UPIN) code (4 to 8 digits) help to protect your SIM card
against unauthorized use. See "Security," p. 59.
The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is required
for some functions.
The module PIN is required to access the information in the security module.
See "Security module," p. 85.
The signing PIN is required for the digital signature. See "Digital
signature," p. 86.
PUK codes
The personal unblocking key (PUK) code and the universal personal unblocking
key (UPUK) code (8 digits) are required to change a blocked PIN code and UPIN
code, respectively. The PUK2 code (8 digits) is required to change a blocked PIN2
code. If the codes are not supplied with the SIM card, contact your local service
provider for the codes.
Restriction password
The restriction password (4 digits) is required when using Call restrictions.
See "Security," p. 59.
11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 11 May 14, 2007 3:20:53 PM

Configuration setting service
To use some of the network services, such as mobile internet services, MMS,
Nokia Xpress audio messaging, or remote internet server synchronization, your
device needs the correct configuration settings. For more information on
availability, contact your service provider or the nearest authorized Nokia
dealer, or visit the support area on the Nokia website. See "Nokia
support," p. 13.
When you have received the settings as a configuration message and the
settings are not automatically saved and activated, Configuration settings
received is displayed.
To save the settings, select Show > Save. If required, enter the PIN code
supplied by the service provider.
To discard the received settings, select Exit or Show > Discard.
Download content
You may be able to download new content (for example, themes) to your phone
(network service).
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
For the availability of different services, pricing, and tariffs, contact your service
provider.
Software updates
Nokia may produce software updates that may offer new features, enhanced
functions, or improved performance. You may be able to request these updates
through the Nokia Software Updater PC application. To update the device
software, you need the Nokia Software Updater application and a compatible
PC with Microsoft Windows 2000 or XP operating system, broadband internet
access, and a compatible data cable to connect your device to the PC.
General information
12
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 12 May 14, 2007 3:20:53 PM

To get more information and to download the Nokia Software Updater
application, visit www.nokiausa.com/softwareupdate or your local Nokia
website.
If software updates over the air are supported by your network, you may also
be able to request updates through the device.
See "Software updates over the air," p. 60.
Downloading software updates may involve the transmission of large amounts
of data through your service provider's network. Contact your service provider
for information about data transmission charges.
Make sure that the device battery has enough power, or connect the charger
before starting the update.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
Nokia support
Support information
Check www.nokia.com/support or your local Nokia website for the latest
version of this guide, additional information, downloads, and services related
to your Nokia product.
Configuration settings service
You may also download free configuration settings such as MMS, GPRS, e-mail,
and other services for your device model at www.nokia.com/support.
Nokia PC Suite
You may find PC Suite and related information on the Nokia website at
www.nokia.com/support.
General information
13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 13 May 14, 2007 3:20:53 PM

Customer service
If you need to contact customer service, check the list of local
Nokia Care contact centers at www.nokia.com/
customerservice.
Maintenance
For maintenance services, check your nearest Nokia service center at
www.nokia.com/repair.
2. Get started
Install SIM card and battery
Always switch the device off and disconnect the charger before removing the
battery.
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider or other vendor.
This device is intended for use with a BL-4B battery. Always use original Nokia
batteries. See "Nokia battery authentication guidelines," p. 89.
The SIM card and its contacts can be easily damaged by scratches or bending,
so be careful when handling, inserting, or removing the card.
1. Slide the release button
(1) to unlock and remove
the back cover (2).
Remove the battery as
shown (3).
Get started
14
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 14 May 14, 2007 3:20:53 PM

2. Open the SIM card holder
(4). Insert the SIM card (5)
with the contact surface
facing down into the
holder. Close the SIM card
holder (6).
3. Observe the battery
contacts (7), and insert the
battery (8). Place the upper
part of the back cover on the
device (9), and close it (10).
Insert a microSD card
Use only compatible microSD cards approved by Nokia for use with this device.
Nokia uses approved industry standards for memory cards, but some brands
may not be fully compatible with this device. Incompatible cards may damage
the card and the device and corrupt data stored on the card.
1. Switch the device off, and remove the back cover and the battery of the
device.
2. Slide the memory card holder to unlock (1).
Get started
15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 15 May 14, 2007 3:20:53 PM

3. Open the card holder (2), and insert the memory
card into the card holder with the contact surface
facing inward (3).
4. Close the card holder (4), and slide it to lock (5).
5. Insert the battery, and attach the back cover to the device.
Charge the battery
Check the model number of any charger before use with this device. This device
is intended for use when supplied with power from the AC-3 or AC-4 charger.
Warning: Use only batteries, chargers, and enhancements approved
by Nokia for use with this particular model. The use of any other types
may invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer.
When you disconnect the power cord of any enhancement, grasp and pull the
plug, not the cord.
1. Connect the charger to a wall socket.
2. Connect the lead from the charger to the socket on
the bottom of your device.
If the battery is completely discharged, it may take a few
minutes before the charging indicator appears on the
display or before any calls can be made.
The charging time depends on the charger used.
Charging a BL-4B battery with the AC-3 charger takes approximately 2 hours
Get started
16
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 16 May 14, 2007 3:20:53 PM

and 15 minutes while the device is in the standby mode.
Antenna
Your device has an internal antenna.
Note: As with any other radio
transmitting device, do not touch the
antenna unnecessarily when the
device is switched on. Contact with
the antenna affects call quality and
may cause the device to operate at a
higher power level than otherwise
needed. To optimize antenna
performance and battery life, avoid
contact with the antenna area when
operating the device.
Headset
Warning: Listen to music at a moderate level. Continuous exposure to
high volume may damage your hearing.
Pay special attention to volume level if you connect any other headsets to the
device.
Warning: When you use the headset, your ability to hear outside
sounds may be affected. Do not use the headset where it can endanger
your safety.
Do not connect products that create an output signal as this may cause
damage to the device. Do not connect any voltage source to the Nokia
AV Connector.
When connecting any external device or any headset, other than those
approved by Nokia for use with this device, to the Nokia AV Connector,
pay special attention to volume levels.
Get started
17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 17 May 14, 2007 3:20:53 PM

Change the accent color frame
Replace the color accent frame to change to look of your device.
1. Remove the back cover of your device.
2. Detach the color accent frame first at the upper
part of your device (1) and remove it.
3. To mount a color accent frame, affix it at the lower
part of your device (3) and attach it successively
from bottom to top (4, 5). Press it from the top to
snap it in.
4. Attach the back cover of your device, and ensure that it is closed properly.
Strap
Thread the strap as shown in the picture and tighten it.
Get started
18
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 18 May 14, 2007 3:20:53 PM

3. Your device
Keys and parts
1 — Earpiece
2 — Display
3 — Navi™ key: 4-way scroll key and middle selection key
4 — Left selection key
5 — Call key
6 — Keypad
7 — Right selection key
8 — End key
9 — Microphone
10 — Charger connector
11 — Nokia AV Connector (2.5 mm)
12 — Mini USB cable connector
13 — Camera key
14 — Camera flash
15 — Volume down key
16 — Volume up key
Your device
19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 19 May 14, 2007 3:20:53 PM

17 — Power key
18 — Loudspeaker
19 — Camera lens
Warning: The power key (17) and metallic trim in this device may
contain nickel. It is not designed for prolonged contact with the skin.
Continuous exposure to nickel on the skin may lead to a nickel allergy.
Switch the device on and off
To switch the device on or off, press and hold the power key.
If the device prompts for a PIN or a UPIN code, enter the code (displayed as
****), and select OK.
The device may prompt you to set the time and date. Enter the local time, select
the time zone of your location in terms of the time difference with respect to
Greenwich mean time (GMT), and enter the date. See "Time and
date," p. 49.
When you switch on your device for the first time and the device is in the
standby mode, you may be prompted to get the configuration settings from
your service provider (network service). For more information refer to Connect
to support. See "Configuration," p. 58. See "Configuration setting
service," p. 12.
Standby mode
When the device is ready for use, and you have not entered any characters, the
device is in the standby mode.
Your device
20
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
file:/D:/temp/overmode/GUID-431D2638-1BD0-45C5-83AF-C38B84F5117C.20070514145238033.en1179145165145/en/1/
GUID-0114949A-2FD0-4027-894A-63EEE9257447.xml Page 20 May 14, 2007 3:20:53 PM
