ULTRAFEED® INDUSTRIAL
TABLE SET-UP GUIDE
#120931, #120934 & #121091

Ultrafeed Industrial Sewing Table
With this table you can create a solid, stationary workstation for your Ultrafeed
sewing machine. This industrial-style table stand will provide a larger work
surface for projects of all sizes.
These instructions will help you set up your Ultrafeed Industrial Sewing Table
(#120934) as well as the Ultrafeed Industrial Sewing Table with Workhorse
Servo Motor (#120931, #121091).

Table Of Contents
Sewing Machine Safety............................................... 1
Ultrafeed®Industrial Table Setup
Power Stand Assembly .............................................. 2
Installing the Drawer................................................... 5
Adjusting the Height ................................................... 6
Oil Tray Installation..................................................... 7
Mounting the Thread Stand........................................ 8
Machine Installation.................................................... 9
Installing the Workhorse Servo Motor
Installing Foot Treadle .............................................. 11
Check Motor Rotation............................................... 13
Machine Installation.................................................. 14
Removing Ultrafeed Motor Housing ......................... 15
Belt Adjustment for the Workhorse Servo Motor ...... 16
Installing the Linkage Bar ......................................... 17
Attaching the Balance Wheel Belt Cover ................. 18
Support Pin Installation ............................................ 19

1 | Sailrite.com
SEWING MACHINE SAFETY
• Do not operate in conditions where you or the
machine are or may become wet.
• Operate the machine on a rm, level surface
where there is adequate room for safe
operation.
• Observe caution when placing your hands or
other parts of your body or clothing near any
moving parts including but not limited to the
following: the walking foot, the needle, the
drive belt, the balance wheel and any of its
parts.
• Do not run the machine without its covers.
• Do not stop the movement of the balance
wheel with your hands.
• Use caution in tilting the machine backwards
in its table and in lowering it back into the
table.
• Use proper lifting techniques when moving
the machine.
• Do not drop the machine.
• Always use the proper voltage required for
the motor and light.
• Wear protective eyewear when sewing.
• Wear shoes when operating the foot
pedal.
• Provide supervision when allowing others to
use the machine—particularly children and
those who are unfamiliar with the machine’s
operation.
• Do not use around ammable materials.
• Use both hands to guide the material while
the belt and balance wheel are in motion.
• Maintain a safe distance from the belt and
balance wheel when the machine is in motion.
• The operator’s hand should not be near the
wheel pinch point (where moving parts may
cause harm to the user) except to raise and
lower the needle, and only when the motor is
disengaged.
Please observe the following when using your Sailrite sewing machine
WARNING: Some products may be fabricated from materials which may contain chemicals known to
the state of California to cause cancer, birth defects or other reproductive harm.

Ultrafeed Industrial Table Set-Up Guide | 2
Power Stand Assembly
Find parts A, B, Cand D(Figure 1). Stand both
k-legs upright. Bolt the back support bar (H) to
the k-legs using the bottom hole on the back of
each leg (Figure 2).
Find parts E, Fand G. Turn the k-legs upside
down. Position the treadle mount bar (I) across
the k-legs (Figure 3). Bolt the bar into place toward
the back of the front slot on the legs (Figure 4).
A
B
D C
1
FE G
H
I
2
3
4

3 | Sailrite.com
Being careful to not scratch the surface, place
the tabletop face down on the oor. Line up
the k-legs squarely 1-1/2" from the back of the
tabletop and 1" in from the side closest to the
cutout (Figure 5). Be sure the k-legs are facing
the proper direction. For reference, the ruler is
on the front of the tabletop.
Using a pencil, trace around the perimeter
of each slot in the k-legs (Figure 6). With
the legs removed, use a 5/32" drill bit to drill
approximately 1/2" into the tabletop within each
pencil outline. Do not drill completely through
the tabletop.
5
6
1"
1-1/2"
BACK

Ultrafeed Industrial Table Set-Up Guide | 4
J
M
K
L
7
8
Realign the k-legs on the tabletop with the
pencil marks. Use the hex head lag screws (J),
locking washers (L) and washers (M) (Figure 7)
to bolt the frame to the tabletop at each position
(Figure 8).

5 | Sailrite.com
Installing the Drawer
Position the drawer as desired on the underside
of the tabletop (Figure 9) so the drawer will
pull out towards the front (Figure 10). Place
the drawer rails over the edges of the drawer.
Secure the rails using 6 of the included screws
(K) (Figure 7).
Tip: Do not over tighten the screws or they will
prevent the drawer from sliding freely.
Installing Rubber Foot Pads
Stretch the rubber foot pads onto each of the
k-leg's rectangular metal feet (Figure 11).
9
10
11
Drawer
Location
FRONT
FRONT

Ultrafeed Industrial Table Set-Up Guide | 6
12
Adjusting the Height
Flip the table upright.
Sit in front of the table and assess the table
height. If adjustments are needed, loosen the
four bolts toward the top of each leg (Figure 12).
Raise or lower the tabletop to the desired
position then tighten the bolts. Be sure to adjust
the height before installing the sewing machine
in the tabletop.

7 | Sailrite.com
Oil Tray Installation
Locate the two hinge cushions (A), two chrome
hinges (B), two wood screws (C), and four nails
(D) (Figure 13).
With the table upright, place the two hinge
cushions (A) in the back cutouts (Figure 14).
Secure by driving a wood screw (C) directly
through the center of the cushion. Using a
power drill makes the process easier.
Position the oil tray so its top edge is just below
the bottom of the hinge cushions and the right
edge of the tray does not encroach on the belt
slot cutout (E) (Figure 15). Use the 4 nails (D),
to secure the tray.
Note: Positioning the oil tray too far to the right
can cause the timing belt to rub against it
causing unnecessary wear on the belt.
13
14
15
AB
CD
E

Ultrafeed Industrial Table Set-Up Guide | 8
Mounting the Thread Stand
Find the threaded insert and its corresponding
Allen wrench. Locate the pre-drilled hole (F) in
the tabletop just to the right of the belt slot
cutout. Use the Allen wrench to carefully screw
the threaded insert into the hole (Figure 16).
Note: Running a bar of soap along the threads
of the insert will help prevent the melamine
surface of the table top from cracking as the
insert is screwed in.
Sailrite's Integrated Thread Stand (not included)
can now be installed via the threaded insert
(Figure 17). If another thread stand is being
used, it can be placed on or screwed into the
table near this same location.
If you have the Ultrafeed Industrial Sewing Table
only (#120934), you won’t need to install the
foot treadle. The parts should be saved in case
a Workhorse Motor is added in the future.
If you purchased the Ultrafeed Industrial
Sewing Table & Workhorse Servo Motor
(#120931 or #121091), skip to page 10 to
complete the setup.
16
17
F

9 | Sailrite.com
Machine Installation
To remove the Ultrafeed from its carrying case
or wooden base, tilt the machine back and
loosen the two set screws (A) that hold the
machine on the hinges (Figure 18). Carefully
slide the sewing machine off the case/base
hinges.
Insert the chrome Euro hinges (B) into the two
holes on the back of the sewing machine head.
Carefully lift the sewing machine head and set it
in the cutout so the hinges rest in the hinge
cushions (C) (Figure 19). Tilt the sewing
machine back and tighten the set screws (A).
Plug in your foot control and you are ready to
sew! Assembly of the Ultrafeed Industrial
Sewing Table is complete.
18
19
B
C
C
A A
Upgrade Options
To upgrade an Ultrafeed sewing machine with the
Industrial Sewing Table to the Workhorse Servo Motor
setup, the following add-ons can be purchased and the
remaining instructions followed:
• Sailrite Workhorse Servo Motor
#120260 (110V) #121091 (220-240V)
• Cogged Timing Belt 42" #120580
• Belt Cover & Bracket for Ultrafeed with Workhorse
#120930
• Support Pin for Sailrite Utlrafeed Industrial
Sewing Table #120866
• Idler Pulley for Ultrafeed #W061-A
Note: A new idler pulley is only required for Ultrafeed sewing
machines purchased prior to March 17, 2016.

Ultrafeed Industrial Table Set-Up Guide | 10
The Ultrafeed Industrial Sewing Table &
Workhorse Servo Motor #120931 & #121091
This package transforms the portable Ultrafeed Sewing Machine into a stationary, industrial machine!
The Workhorse Servo Motor provides top notch power at the slowest speeds so you can sew stitch-
by-stitch in even heavy assemblies.
With this larger motor setup, we recommend oiling the machine more frequently than with the portable
motor. A good rule of thumb is to oil after 40 hours of continual use or if the machine has been sitting
for more than 30 days without running. Oiling locations can be found in the Ultrafeed Guidebook.

11 | Sailrite.com
DD
20
21
Installing Foot Treadle
Locate the foot treadle and its accompanying
large bolts, small bolts and washers.
The foot treadle is typically installed to the right
side of the treadle mount bar, but it can be set to
the user’s preference anywhere on the bar.
Determine the desired location of the treadle
and ip the table onto its back side (Figure 20).
Locate the two end pivots (D). Very loosely bolt
the end pivots to the treadle mount bar in the
desired location. Then install the foot treadle by
placing the pins on the end pivots into the holes
on the side of the treadle (Figure 21). The side
of the treadle with the bolt holes for the
L-bracket (page 12, E) should be facing towards
the back of the table.
Once the treadle is in place, tighten the bolts.
Test the treadle to be sure it moves freely once
the bolts are tightened.

Ultrafeed Industrial Table Set-Up Guide | 12
Install the L-bracket (E) on the back of the
treadle starting with the hole farthest to the right
on the treadle. Hand tighten the bolts. Then
slide the L-bracket over so that the curved end
is directly over the second hole from the left on
the treadle. Tighten the bolts (Figure 22 & 23).
BEFORE CONTINUING: See “Attaching a
Pulley” and “Installing the Workhorse Servo
Motor” in the Workhorse Servo Motor
Instructions.
E
E
22
23

13 | Sailrite.com
24
Check Motor Rotation
The machine’s motor shaft should rotate
counterclockwise when viewed from the motor
shaft end. Plug in the motor, switch the power
on and press down on the foot treadle to conrm
operation.
If motor rotation is not counterclockwise
(Figure 24), please refer to “Changing Motor
Rotation” in the Workhorse Installation
Instructions.
Due to the immense amount of power and
speed the Workhorse provides, do not set
the top sewing speed above 25. The motor
will arrive pre-set at 30. Be sure to turn the
speed down to 25 prior to sewing. For more
information, reference “Operation” in the
Workhorse Servo Motor Instructions.

Ultrafeed Industrial Table Set-Up Guide | 14
A A
Machine Installation
To remove the Ultrafeed from its carrying case
or wooden base, tilt the machine back and
loosen the two set screws (A) that hold the
machine on the hinges (Figure 25). Carefully
slide the sewing machine off the case/base
hinges.
Insert the chrome Euro hinges (B) into the two
holes on the back of the sewing machine head.
Carefully lift the sewing machine head and set it
in the cutout so the hinges rest in the hinge
cushions (C) (Figure 26). Tilt the sewing
machine back and tighten the set screws (A).
25
26
B
C
C

15 | Sailrite.com
27
28
E
G
G
D
F
H
Removing Ultrafeed Motor Housing
To utilize the Workhorse Servo Motor, the
portable Ultrafeed motor (D) and motor housing
(E) must be removed (Figure 27).
To begin, remove the Posi-Pin, Posi-Pin nut and
the balance wheel from the Ultrafeed. Remove
the bottom screw in the black belt cover (F)
(Figure 28). Then unscrew the two screws
holding the motor housing to the machine (G)
(Figure 27). Keep one of these screws near as
it will be used in a future step.
Tilt the motor housing and use a screwdriver to
push the belt off the motor pulley (H). Then
remove the motor and housing. Place all of
these components in a safe location so you can
make your machine portable again. Replace the
balance wheel, Posi-Pin and Posi-Pin nut.

Ultrafeed Industrial Table Set-Up Guide | 16
Belt Adjustment for the
Workhorse Servo Motor
Before installing the drive belt, loosen the
adjustment screw (A) at the top of the motor
bracket to allow the Workhorse Servo Motor to
freely pivot (Figure 29). This will prevent the
belt from being stretched out of shape before
proper adjustments are made.
With the machine tilted back, slip the drive belt
onto the balance wheel track and guide it onto
the motor pulley. Carefully lower the machine
into the cutout (Figure 30). Lightly push the
motor back until the belt is taut. Tighten the
adjustment screw (A), locking the motor
position.
Once installed, the belt should not touch the
table and should be relatively centered on the
track of both the balance wheel and motor
pulley. If adjustments need to be made, loosen
the nuts where the motor bracket is attached to
the table and slide to the left or right. Test new
motor positions by rotating the balance wheel
on the machine a few times by hand. When the
correct position is found, tighten the nuts.
Remove the belt so the pulley bracket can be
installed in a later step.
29
30
A

17 | Sailrite.com
Installing the Linkage Bar
Locate the linkage bar (B) and release the
center nut to expand the two halves.
Using the attached nuts and washers on the
linkage bar, bolt one end of the linkage bar to
the outer most hole of the motor operation
lever (C) on the Workhorse Servo Motor. Attach
the opposite end of the linkage bar to the
L-bracket (D) on the foot treadle. Push the two
arms into the center bracket and nger tighten
the bolt (E). Be sure the treadle is angled all the
way up and tighten the center bolt (Figure 31).
Note: Ensure the motor operation lever (C) is in
the upmost position. If it is not, the motor will not
work when turned on.
BEFORE CONTINUING: See “Installing the
Pulley Cover” in the Workhorse Servo Motor
Instructions.
31
B
C
D
E
