SAJ 8000B series User manual

Version code：8000B-E201208-1MB
8000B Series Enhanced Inverter
User Manual

-I-
8000B Series
TABLE OF CONTENTS
Notes for Safe Operation………………………………........…………01
Notes for Other Important Operations………………...............……06
Chapter 1 Select the Right Type……………………............………08
1.1 Description of Model……………………………………….........................…08
1.2 Description of Nameplate…………………………………..................………08
1.3 8000B Series Inverter Table……………………………..............……………09
1.4 Specications of 8000B Series Inverter……………….................…………10
1.5 Outline Drawing and Dimensions……….............................................……12
1.6 Selection Instruction Table of Brake Resistor and Brake Unit…….........…17
Chapter 2 Mechanical and Electric Installation………….............18
2.1 Mechanical Installation………………………………….....................………18
2.2 Electric Installation………………………………...........................…………19
Chapter 3 Wiring…………………………...................………………23
3.1 Standard Wiring Diagram………………………….................………………23
3.2 Terminal Descriptions of Main Circuit and Control Circuit…...............……27
Chapter 4 Operation……………………………………….............…32
4.1 Keypad Description………………………………..........................…………32
4.2 Operation Process…………………………………............................………33
Chapter 5 Function Code Table…………….............………………36
Chapter 6 Trouble Shooting………………………............…………64
6.1 Fault and Trouble Shooting………………...........................................……64
6.2 Common Faults and Solutions……………….....................…………………68
Chapter 7 Data Address Table of Function Code...…............…..69

-II-
8000B Series
PRECAUTION
Never modify the products. Failure to observe this warning
can result in electrical shock or personal injury. SAJ is not
responsible for any modification of the frequency products
made by the user, since that will void your guarantee.

-01-
8000B Series
Notes for Safe Operation
Read this instruction manual thoroughly before installation, operation,
maintenance or inspection of the frequency inverters. In this manual, safe
operation are classied as “WARNING” or “CAUTION”.
WARNING
Indicate a potentially dangerous situation which, if not avoided, could result
in death or serious injury to personnel.
CAUTION
Indicate a potentially dangerous situation which, if not avoided, could result
in minor or moderate injury and damage to equipment. It may also be used
for warning against unsafe practices.
Even items described as ( CAUTION) may result in a vital accident in some
situations. Please follow these important notes:
NOTE
These are steps to be taken to ensure proper operation.
Before Installation
WARNING
Do not install or operate any frequency inverter that is damaged or has
missing parts.
Choose the motor of insulation class B or above. Otherwise it may cause
an electrical shock.

-02-
8000B Series
Installation
WARNING
Install the frequency inverter on nonflammable material like metal.
Otherwise it may cause a fire.
WARNING
Make sure that the mounting environment away from metal dust. Otherwise
it may cause damage to the frequency inverter.
CAUTION
When mount over two inverters in the same cabinet or enclosure, install a
fan or other cooling device to keep the temperature inside below 50℃.
Do not let the conductor head or screws fall into the inside of the inverter.
Otherwise it may cause damage to the inverter.
Wiring
WARNING
Ensure only qualified personnel to operate. Otherwise it can cause an
electrical shock.
Make sure the inverter is isolated from power supply by the circuit breaker.
Otherwise it may cause a fire.
Verify that the power supply is turned OFF before start wiring. Otherwise it
may cause an electrical shock or fire.
Make sure that the ground terminal is grounded correctly. Otherwise it may
cause an electrical shock.

-03-
8000B Series
CAUTION
Never connect the AC power supply to output terminals U, V and W.
Otherwise the inverter will be damaged and the guarantee is invalid.
Make sure that wiring conform to EMC requirements and local power safe
standard. Make sure to use right wire according to this instruction manual.
Otherwise it may cause an accident.
Braking resistor or braking unit cannot be directly connected to DC bus
terminals (P+) and (N-). Otherwise it may cause a fire.
Before Turn on the AC Power Supply
WARNING
Make sure that the voltage of inverter conforms to the local power supply
voltage. Verify that the wiring of input and output is correct and there is no
short-circuit in peripheral circuit. Tighten the terminal screws. Otherwise
these may cause damage to the inverter.
Turn on the input AC power only after the front cover is put correctly.
Otherwise it may cause an electrical shock.
CAUTION
Never perform a hi-pot or withstand voltage test of the inverter. Otherwise
it may cause damage to the inverter.
Make sure that the optional parts are connected correctly. Otherwise it
may cause damage to the inverter.

-04-
8000B Series
When the Power is On
WARNING
Do not open or remove the front cover when operation. Otherwise it may
cause an electrical shock.
Never touch the inverter and optional parts by wet hands. Never touch the
connection terminals. Otherwise it may cause an electrical shock.
When the power is on, the inverter will automatically check the power
supply circuit. Do not touch U, V, W terminals and motor connection
terminals. Otherwise it may cause an electrical shock.
CAUTION
It is dangerous for the personnel to approach the motor and load during
rotation of the motor. Do not change the factory parameters or settings
unnecessarily. Otherwise it may cause a damage or injury.
Operation
WARNING
When select the function of restart, do not approach the mechanical load.
Otherwise it may cause an injury if it restarts suddenly.
Do not touch the heat sink or discharging resistor. Otherwise it may cause
harmful burns to the body.
Never change or check signals if not a professional or qualified personnel.
Otherwise it may cause damage and injury.
CAUTION
Make sure nothing fall into the mechanical load or inverter. Otherwise it
may cause damage.
Start or stop inverter by corresponding buttons only. Otherwise it may
cause damage.

-05-
8000B Series
Maintenance
WARNING
After the main circuit power supply is OFF, make sure the charge LED
is OFF when maintain or inspect. Never maintain or inspect the inverter
and mechanical load when the power supply is still ON. Otherwise it may
cause damage and injury.
Only qualified or authorized professional personnel can maintain, replace
and inspect the inverter. Otherwise it may cause damage and injury.

-06-
8000B Series
Notes for Other Important Operations
CAUTION
1. Check Insulation of the Motor
Check insulation of the motor and wire when the motor is used again after
long time idle or for the rst time. Disconnect the wire between the motor and
the inverter before check insulation. Make sure the insulation resistor is not
below 5MΩ.
2. Thermal Overload Protection of the Motor
When the rated capacity of inverter is larger than that of the motor, install
thermal overload relay for the motor or regulate the motor protection
parameters of the inverter.
3. Consider the Bearing Capability of the Load
The inverter can provide output frequency from 0 Hz to 600 Hz. If the motor
needs to work at over 50 Hz, user should consider the bearing capability of
the load.
4. Avoid Mechanical Resonance Frequency
Regulate the skip frequency parameter of the inverter to avoid mechanical
resonance frequency of the load.
5. Prohibition of Installation of Phase Advancing Capacitor
If a phase advancing capacitor or surge suppressor is connected in order to
improve the power factor, it may become overheated and damaged by inverter
high harmonic components. Also, the inverter may malfunction because of
over current.
6. Installation of Magnetic Contactor
If a magnetic contactor is installed at the power supply side, do not use it to
control the start of the inverter. If necessary, the time span should be one hour
or above. Otherwise frequent switching may cause the inverter to malfunction.
If a magnetic contactor is installed between the output terminals and motor
(output side of the inverter), make sure there is no output of inverter before
switch on and off. Otherwise it may cause damage to the inverter.

-07-
8000B Series
7. Allowable Voltage Range and Power Supply Phase
Make sure the inverter works under allowable voltage range. If necessary, use
boosting transformer or step-down transformer to change the voltage of power
supply. Never change the 3-phase of inverter into 2-phase. Otherwise it will
cause damage to the inverter.
8. Thunder Stroke Protection
Even there is protection device to protect the inverter from induction thunder
stroke, it’s necessary for users in frequent thunder stroke area to install other
protective device.
9. Altitude and Degradation Use
At an altitude of 1000m or above, it could be better that use the motor with
lower rated capacity. Otherwise the inverter may become overheated because
of rare air. For example, in order to control the motor of 4kW rated capacity, it
could be better to use 5.5kW inverter.
10. Dispose of Scrap Inverter
The scrap capacitor of main circuit and PCB (printed-circuit board) may
explode when it is burned. In order to protect the environment, do not burn
waste plastic parts and scrap capacitor.
11. Choose the Right Matching Inverter for the Motor
The standard matching motor is 4-pole inductive motor. If not, choose the right
matching inverter according to the rated current of the motor.
According to the actual working situation of the motor, the factory setting
of motor standard parameter can be revised. Otherwise it may cause low
efciency to the unit.

-08-
8000B Series
Chapter 1 Select the Right Type
1.1 Description of Model
1.2 Description of Nameplate

-09-
8000B Series
1.3 8000B Series Inverter Table
Inverter Model
G/P
Power
capacity
kW
Rated Input
Current
A
Rated Output
Current
A
Motor
Capacity
kW G/P
Single-phase 220V±15%
8000B-2SR75GB 0.75 8.2 4.5 0.75
8000B-2S1R5GB 1.5 14.2 7 1.5
8000B-2S2R2GB 2.2 23 10 2.2
Three-phase 380V±15%
8000B-4TR75GB 0.75 3.4 2.5 0.75
8000B-4T1R5GB 1.5 5 3.7 1.5
8000B-4T2R2GB 2.2 5.8 5.0 2.2
8000B-4T004GB/4T5R5PB 4/5.5 10/15 9/13 4/5.5
8000B-4T5R5GB/4T7R5PB 5.5/7.5 15/20 13/17 5.5/7.5
8000B-4T7R5GB 7.5 20 17 7.5
8000B-4T011GB/4T015PB 11/15 26/35 25/32 11/15
8000B-4T015GB/4T18R5PB 15/18.5 35/38 32/37 15/18.5
8000B-4T18R5GB 18.5 38 37 18.5
8000B-4T022G/4T030P 22/30 46/62 45/60 22/30
8000B-4T030G/4T037P 30/37 62/76 60/75 30/37
8000B-4T037G 37 76 75 37
8000B-4T045G/4T055P 45/55 90/105 90/110 45/55
8000B-4T055G/4T075P 55/75 105/140 110/150 55/75
8000B-4T075G/4T093P 75/93 140/160 150/176 75/93
8000B-4T093G/4T110P 93/110 160/210 176/210 93/110
8000B-4T110G 110 210 210 110
8000B-4T132G/4T160P 132/160 240/290 250/300 132/160
8000B-4T160G/4T185P 160/185 290/330 300/340 160/185
8000B-4T185G 185 330 340 185
8000B-4T200G/4T220P 200/220 370/410 380/415 200/220
8000B-4T220G/4T250P 220/250 410/460 415/470 220/250
8000B-4T250G/4T280P 250/280 460/500 470/520 250/280
8000B-4T280G/4T315P 280/315 500/580 520/600 280/315
8000B-4T315G 315 580 600 315
8000B-4T350G 350 620 640 350
8000B-4T400G 400 670 690 400

-10-
8000B Series
1.4 Specications of 8000B Series Inverter
Characteristics
of Controlling
Control Mode Sensorless vector control V/F control
Start Torque 0.5Hz 150% 0.5Hz 100%
Rotation Speed
Ratio 1:200 1:100
Precision
of Speed
Regulation
±0.5% ±1.0%
Overload
Capability
M o d e l G : 15 0 % a b o v e t h e r a t e d c u r r e n t f o r 6 0
seconds;180% above the rated current for one second.
M o d e l P :12 0 % a b o v e t h e r at e d c u r r e n t f o r 6 0
seconds;150% above the rated current for one second.
V/F curve Three selection t ype: Linear type,Square t ype and
Multipoint type.
DC Brake
DC brake frequency:0.00~max. frequency;
brake time:0.1~50.0s;
Brake cur rent:0 ~15 0% of rated cu r rent(mo de l G);
0~100% of rated current:model P);
Brake waiting time:0.0~50.0s
Jog Operation
Jog frequency range:0.00-max.frequency;
Accel./Decel. time of jog operation:0.1~3600s.
Accel./Decel.
Time Accel./Decel. time range:0.1~3600s
Torque
Boosting Manual setting:0.1~30.0%; Automatic setting:0.0
I/O
Characteristics
Start
Frequency 0.50~10Hz
Input Voltage 220V/380V ± 15%
Input
Frequency 50/60Hz,fluctuation range:±5%

-11-
8000B Series
I/O
Characteristics
Input
Frequency
Resolution
Analog setting:max. frequency × 0.1%;
Digital setting:0.01Hz
Output Voltage 0~rated input voltage
Output
Frequency
Range
0.00~600Hz
Digital Input
Terminals Six (programmable)
Analog Input
Terminals AVI:0~10V; ACI:0~10V or 0/4~20mA
Relay Output 1 relay output
Open Collector
Output Provide 1 channel programmable
Analog Output
0.75~2.2kW:FM:0~10V; AM:0/4~20mA
4~400kW:FM:0~10V; AM:0~10V / 0/4-20mA
Basic
Functions
Frequency
Setting
Channels
Three channels:setting by keyboard, setting by control
terminals, setting by serial communication inter face.
These channels can be switched.
Frequency
Setting Source
8 methods including panel knob setting, UP/DOWN key
setting and PID setting, etc.
Simple PLC
Function
16 steps speed control can be carried out by simple PLC
function inside and terminals.
PID Function Close-loop controlling system can be carried out by PID
inside.
Swing
Frequency
Function
Suitable for textile and chemic al fiber machine by
controlling the triangular frequency.
AVR Function Automatically keep the output voltage constant when
power supply is not stable.

-12-
8000B Series
Other
Functions
LED Display
16 parameters can by displayed including running
frequency, DC bus voltage, output voltage, output
current, etc.
Communication
Function RS485 with standard MOBUS protocol.
Password
Setting
Four-digit password can be set and become effective
after 1 minute.
Parameter Lock
Function
This function can be used to lock the parameter when
running or stop in order to avoid wrong operation.
Fault Protection
Function
O v e r- c u r r e n t , o ve r v o l t a g e , u n d e r- v o l t a g e , ov e r
temperature, lack of phase, etc.
Application
Environment
Location Indoor away from sunlight, dust, corrosive gas, oil fog,
water drop, steam.
Elevation 1000m or less
Ambient
Temperature -10℃~+40℃
Humidity 95% RH or less
Vibration < 5.9 m/s2 (0.6G)
1.5 Outline Drawing and Dimensions
1.5.1 Outline Drawing

-13-
8000B Series
1.5.2 Dimensions
1.5.2.1 Dimensions Drawing
W
A
B
H
D
W
A
B
H
D
W
A
B
H
D
0.75kW~2.2kW (model G)
A
W
B
H
D
A
W
B
H
D
4kW~7.5kW (model G)
11kW~110kW (model G)

-14-
8000B Series
132kW~185kW (model G)
200kW~250kW (model G)
280kW~400kW (model G)

-15-
8000B Series
1.5.2.2 Dimensions Table
Inverter Model
Installation
Dimensions
(mm)
Appearance Dimensions (mm)
Hole
Diameter
(mm)
A B H H1 W W1 D
8000B-2SR75GB
92 142.7 151.7 101 126.8 ø58000B-2S1R5GB
8000B-2S2R2GB
8000B-4TR75GB
92 142.7 151.7 101 126.8 ø58000B-4T1R5GB
8000B-4T2R2GB
8000B-4T004GB/4T5R5PB
144.4 237 249.5 155.5 159.5 ø5.98000B-4T5R5GB/4T7R5PB
8000B-4T7R5GB
8000B-4T011GB/4T015PB
156.6 378.3 364 396 214 221.7 190.5 ø68000B-4T015GB/4T18R5PB
8000B-4T18R5GB
8000B-4T022G/4T030P
235 447 424 463 285 289.6 210.3 ø78000B-4T030G/4T037P
8000B-4T037G
8000B-4T045G/4T055P
260 580 544 595.5 380 390 284.8 ø10
8000B-4T055G/4T075P
8000B-4T075G/4T093P
343 674 650 701.5 473 485 318 ø108000B-4T093G/4T110P
8000B-4T110G
8000B-4T132G/4T160P
449 902.5 927 1359 580 384 ø108000B-4T160G/4T185P
8000B-4T185G
8000B-4T200G/4T220P
420 1162 1131.5 1481.6 680 400.5 ø128000B-4T220G/4T250P
8000B-4T250G/4T280P
8000B-4T280G/4T315P
520 1300 1355 1765 800 392.5 ø14
8000B-4T315G
8000B-4T350G
8000B-4T400G

-16-
8000B Series
1.5.2.3 Dimensions of Extension Keyboard
0.75kW~2.2kW (model G)
4kW~7.5kW (model G)
11kW~400kW (model G)

-17-
8000B Series
1.6 Selection Instruction Table of Brake Resistor and Brake Unit
Inverter Model
Recommended
Power of Brake
Resistor
Recommended
Resistance Value
of Brake Resistor
Brake Unit
8000B-2SR75GB 80W ≥150Ω
Standard
Accessory
Inside
8000B-2S1R5GB 100W ≥100Ω
8000B-2S2R2GB 100W ≥70Ω
8000B-4TR75GB 150W ≥300Ω
8000B-4T1R5GB 150W ≥220Ω
8000B-4T2R2GB 250W ≥200Ω
8000B-4T004GB/4T5R5PB 300W ≥130Ω
8000B-4T5R5GB/4T7R5PB 400W ≥90Ω
8000B-4T7R5GB 500W ≥65Ω
8000B-4T011GB/4T015PB 800W ≥43Ω
8000B-4T015GB/4T18R5PB 1000W ≥32Ω
8000B-4T18R5GB 1300W ≥25Ω
8000B-4T022G/4T030P 1500W ≥22Ω
Additional
Accessory
(external)
8000B-4T030G/4T037P 2500W ≥16Ω
8000B-4T037G 3.7 kW ≥16.0Ω
8000B-4T045G/4T055P 4.5 kW ≥16Ω
8000B-4T055G/4T075P 5.5 kW ≥8Ω
8000B-4T075G/4T093P 7.5 kW ≥8Ω
8000B-4T093G/4T110P 4.5 kW×2 ≥8Ω×2
8000B-4T110G 5.5 kW×2 ≥8Ω×2
8000B-4T132G/4T160P 6.5 kW×2 ≥8Ω×2
8000B-4T160G/4T185P 16kW ≥2.5Ω
8000B-4T185G 20 kW ≥2.5Ω
8000B-4T200G/4T220P 20 kW ≥2.5Ω
8000B-4T220G/4T250P 22 kW ≥2.5Ω
8000B-4T250G/4T280P 12.5 kW×2 ≥2.5Ω×2
8000B-4T280G/4T315P 14kW×2 ≥2.5Ω×2
8000B-4T315G 16kW×2 ≥2.5Ω×2
8000B-4T350G 17kW×2 ≥2.5Ω×2
8000B-4T400G 14 kW×3 ≥2.5Ω×3
