SAJ H2 Series User manual

H2 series
HYBRID SOLAR INVERTER
user manual
Tel: [phone] Fax: [phone] Web: www.saj-electric.com
Add: SAJ Innovation Park,No.9, Lizhishan Road,Science City, Guangzhou High-tech Zone , Guangdong, P.R.China.
GUANGZHOU SANJING ELECTRIC CO.,LTD
V1.1

HYBRID SOLAR INVERTER USER MANUAL

TABLE OF
contents
4. ELECTRICAL CONNECTION----------17
4.1 Safety Instruction -----18
4.2 Specications for Electrical Inteace-----18
4.3 AC Grid Wire and Backup Output Connection-----19
4.4 PV Connection-----21
4.5 Batte Connection-----24
4.6 Eah Fault Alarm-----25
4.7 Communication Connection-----26
4.7.1 Serial Po Denition-----26
4.7.2 RJ45 Pin Po Denition-----26
4.7.4 Sma Meter Connection-----27
4.8 Connection Diagram-----28
4.9 Ground Connection-----29
4.10 External AC Circuit Breaker and Residual Current Device-----29
5. DEBUGGING INSTRUCTIONS----------31
5.1 Introduction of LED Indicator-----32
5.2 Commissioning-----34
1.1 Scope of Application-----02
1.2 Safety-----02
1.2.1 Safety instruction-----02
1.2.2 Explanations of Symbols-----03
1.2.3 Safety Instructions-----04
2. PRODUCT OVERVIEW ----------05
2.1 packing list-----07
2.2 Appearance-----07
2.3 Datasheet-----09
3. INSTALLATION INSTRUCTION----------11
3.1 The Determination of the
Installation Position-----12
3.1.1 Mounting position-----12
3.2 Mounting-----14
1. SAFETY PRECAUTIONS ----------01
4.7.3 Inse the communication cable-----27
6. FAULT CODE----------35
7. RECYCLING AND DISPOSAL----------37
5.2 eSolar APP Connection-----34

1.1 Scope of
Application
1.2 Safety
1.
SAFETY
precautions
· DANGER indicates a hazardous situation, which, if not avoided, will result in death or serious inju.
· WARNING indicates a hazardous situation, which, if not avoided, can result in death or serious inju or moderate inju.
· CAUTION indicates a hazardous condition, which, if not avoided, can result in minor or moderate inju.
· NOTICE indicates a situation that can result in potential damage, if not avoided.
This User Manual describes instructions and detailed procedures for installing, operating,
maintaining, and troubleshooting of the following SAJ hybrid solar inveers:
Please read the user manual carefully before any installation, operation and maintenance and
follow the instruction during installation and operation. Please keep this manual all time
available in case of emergency.
Only qualied electricians who have read and fully understood all safety regulations
contained in this manual can install, maintain and repair the inveer. Operators must be
aware of the high-voltage device.
H2-5K-T2, H2-6K-T2, H2-8K-T2, H2-10K-T2
1.2.1 Safety instruction DANGER
WARNING
CAUTION
NOTICE
0201
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

1.2.2 Explanations of Symbols 1.2.3 Safety Instructions
Symbol
Dangerous electrical voltage
This device is directly connected to public grid, thus all work to the inveer shall only be
carried out by qualied personnel.
Danger to life due to high electrical voltage!
Notice, danger!
This is directly connected with electricity generators and public grid.
Danger of hot suace
An error has occurred
Please go to Chapter 9 “Troubleshooting” to remedy the error.
This device SHALL NOT be disposed of in residential waste
Please go to Chapter 8 “Recycling and Disposal” for proper treatments.
Without Transformer
This inveer does not use transformer for the isolation function.
CE Mark
RCM Mark
No unauthorized peorations or modications
Description
There might be residual currents in inveer because of large capacitors. Wait 5 MINUTES
before you remove the front lid.
The components inside the inveer will release a lot of heat during operation. Do not
touch metal plate housing during operating.
With CE mark & the inveer fullls the basic requirements of the Guideline Governing
Low-Voltage and Electro-magnetic Compatibility.
Equipment meets safety and other requirements as required by electrical safety laws/
regulations in Australian and New Zealand.
Any unauthorized peorations or modications are strictly forbidden, if any defect or
damage (device/person) occurred, SAJ shall not take any responsibility for it.
DANGER
· There is possibility of dying due to electrical shock and high voltage.
· Do not touch the operating component of the inveer; it might result in burning or death.
· To prevent risk of electric shock during installation and maintenance, please make sure that all AC and DC terminals
are plugged out.
· Do not touch the suace of the inveer while the housing is wet, otherwise, it might cause electrical shock.
· Do not stay close to the inveer while there are severe weather conditions including storm, lighting, etc.
· Before opening the housing, the SAJ inveer must be disconnected from the grid and PV generator; you must wait for
at least ve minutes to let the energy storage capacitors completely discharged after disconnecting from power source.
· The installation, seice, recycling and disposal of the inveers must be peormed by qualied personnel only in
compliance with national and local standards and regulations.
· Any unauthorized actions including modication of product functionality of any form may cause lethal hazard to the
operator, third paies, the units or their propey. SAJ is not responsible for the loss and these warranty claims.
· The SAJ inveer must only be operated with PV generator. Do not connect any other source of energy to the SAJ inveer.
· Be sure that the PV generator and inveer are well grounded in order to protect propeies and persons.
WARNING
· The inveer will become hot during operation. Please do not touch the heat sink or peripheral suace during or
sholy after operation.
· Risk of damage due to improper modications.
CAUTION
· Public utility only.
· The inveer is designed to feed AC power directly to the public utility power grid; do not connect AC output of the
inveer to any private AC equipment.
NOTICE
Ris k of ele c tric sh o c k ! Only
authorized personnel are allowed
to do disassembly, modication or
maintenance. Any resulting defect
or damage (device/person) is not
coverde by SAJ guaranty.
ATTENTION!
03 04
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

Figure 2.1
System oveiew
2.
PRODUCT
oveiew
H2 series
H2 series is a hybrid photovoltaic inveer and it is applicable to both on-grid and o-grid
solar systems. The energy generated by PV system will be fed to loads rst, and then the
surplus energy can charge the batte for later use, if there is still excess more energy, it will
be expoed to the grid. H2 inveer can signicantly improve the self-consumption rate of
solar energy and lower the dependency on grid.
H2 Series Hybrid inverter
PV Array
On-grid Load
AC Distribution Box
Back-up Load
Grid
APP
WebeSolar Poal
Wi-Fi/ 4G/ Ethernet
B2 Lithium Battery
05 06
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

2.2 Appearance
2.1 Packing list
Inveer AC Cover PV Plug Plug-in Connector Screw & expansion
bolt & washer
Figure 2.2
Dimensions of H2 series Product
549 mm 207 mm
433 mm
0807
Batte Plug
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

H2-5K-T2 H2-6K-T2 H2-8K-T2 H2-10K-T2
MODEL
Efficiency
Max. Efficiency
Euro Efficiency
MPPT Efficiency
Max. Battery Charging/ Discharging Efficiency
Protection
AC Short Circuit Protection
Overload Protection
Residual Current Monitoring Unit
Battery Input Reverse Polarity Protection
Anti-islanding protection
AC Surge Protection
DC Surge Protection
AFCI
Interface
PV Connection Type
Battery Connection Type
AC Output
Display
Communication port
Communication
General Data
Topology
Ingress Protection
Operating Temperature Range
Ambient Humidity
Altitude
Noise [dBA]
Cooling method
Dimensions [H*W*D][mm]
Weight [kg]
Standard Warranty [year]
Applicable Standard
98.0%
97.6%
>99.9%
97.6%
Integrated
Integrated
Integrated
Integrated
Integrated
Type III
Type III
Optional
MC4
Quick Connector
Plug-in Connector
LED+APP
CAN/ RS485/ DRM/ RS232
Wi-Fi/ Ethernet/ 4G (Optional)
Transformerless
IP65
-40°C to +60°C
0~100% No Condensing
4000m (>3000m power derating)
<30
Natural Convection
433*549*207
25
5
CEI 0-21, VDE4105-AR-N, VDE0126-1-1, EN50438, G98, G99, EN50549, AS4777.2
IEC62109-1&-2, IEC62040-1 , EN61000-6-1/2/3/4
2.3 Datasheet
H2-5K-T2 H2-6K-T2 H2-8K-T2 H2-10K-T2
1000
180~900
600
180
15 / 15
18 / 18
2
1/1
Lithium battery
180~600
30/30
220/ 380Vac, 230/ 400Vac, 3L/ N/ PE
50/ 60 ± 5
0.8 leading~0.8 lagging
<3%
220/ 380Vac, 230/ 400Vac, 3L/ N/ PE
50/ 60 ± 5
<3%
7500 9000 12000 15000
5000
5000
5500
7.2
8.3
5000
8.0
10000, 60s
6000
6000
6600
8.7
10.0
6000
9.6
12000, 60s
8000
8000
8800
11.6
13.3
8000
12.8
16000, 60s
10000
10000
11000
14.5
16.7
10000
15.9
16500, 60s
MODEL
DC Input
Max.PV Array Power [Wp]@STC
Max. DC Voltage [V]
MPPT Voltage Range [V]
Nominal DC Voltage [V]
Start Voltage [V]
Max. DC Input Current [A]
Max. DC Short Circuit Current [A]
No. of MPPT
No. of Strings per MPPT
Battery Data
Battery Type
Voltage Range [V]
Max. Charging/ Discharging Current [A]
Rated Charging/ Discharging Power [W]
AC Output [On-grid]
Rated AC Power [W]
Max. AC Power [VA]
Rated AC Current [A]@230Vac
Max. AC Current [A]
Nominal AC Voltage [V]
Rated Grid Frequency / Range [Hz]
Power Factor [cos φ]
Total Harmonic Distortion [THDi]
AC Output [Back-up Mode]
Rated Output Power [W]
Max. Output Current [A]
Rated Output Voltage [V]
Rated Output Frequency [Hz]
Total Harmonic Distortion of Voltage
Peak Output Apparent Power [VA]
H2-5K/ 6K/ 8K/ 10K-T2
1009
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

3.
INSTALLATION
instruction
DANGER
NOTICE
· Dangerous to life due to potential re or electricity shock.
· Do not install the inveer near any inammable or explosive items.
· This equipment meets the pollution degree 󶀅.
· Inappropriate or the harmonized installation environment may jeopardize the life span of the inveer.
· Installation directly exposed under intensive sunlight is not recommended.
· The installation site must be well ventilated.
3.1 The Determination
of the Installation
Position
3.1.1 Mounting position The equipment employs natural convection cooling, and it can be installed indoor or outdoor.
(1) Do not expose the inveer to direct solar irradiation as this could cause power derating due
to overheating.
Figure 3.1
Mounting Method
Max 15
1211
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

(2) Mount veically or tilted backwards by max. 15°. Never install the inveer tilted forwards,
sideways, horizontally or upside down.
(3) Install the inveer at eye level for convenience when checking the LCD display and
possible maintenance activities.
(4) When mounting the inveer, please consider the solidness of wall for inveer, including
accessories. Please ensure the Rear Panel mount tightly.
To make sure the installation spot is suitably ventilated, if multiple SAJ hybrid solar inveers
are installed same area.
50CM
Figure 3.2
Minimum Clearance
50CM30CM
50CM50CM
3.2
Mounting
Procedure
(1) Mark the Positions of the Drill Holes of the Rear Panel
The mounting position should be marked as shown in Figure 3.3.
(2) Drill Holes and Place the Expansion Tubes
Drill 4 holes in the wall (in conformity with position marked in Figure 3.4, and then place expansion
tubes in the holes using a rubber mallet.
Figure 3.4
Drill holes dimensions of H2 inveer
Figure 3.3
Dimensions of rear panel of H2 inveer
Φ8
146 mm
16 mm
8 mm
360 mm
360 mm
146 mm
1413
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

(3) Secure the Screws and the Rear Panel
The panels should be secured onto the mounting position by screws as shown in Figure 3.5.
(4) Mount the Inveer
Carefully mount the inveer into the rear panel . Make sure that the rear pa of the equipment
is closely mounted into the rear panel.
Figure 3.6
Mount H2 inveer
Figure 3.5
Mount the Rear Panel of H2 inveer
1615
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

4.
ELECTRICAL
NOTICE
4.1
Safety Instruction
connection
4.2
Specications for
Electrical Inteace
Figure 4.1
Electrical Inteace of H2 inveer
· Dangerous to life due to potential re or electricity shock.
· When power-on, the equipment should in conformity with national rules and regulations.
· The direct connection between the inveer and high voltage power systems must be operated by qualied
technicians in accordance with local and national power grid standards and regulations.
· The PV arrays will produce lethal high voltage when exposed to sunlight.
Electrical connection must only be operated on by professional technicians. Please keep in
mind that the inveer is a bi-power supply equipment. Before connection, necessa
protective equipment must be employed by technicians including insulating gloves, insulating
shoes and safety helmet.
DANGER
· Any improper operation during cable connection can cause device damage or personal inju
A B C D E F G H I J
1817
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

Procedure:
(1) Open the waterproof cover, feed the AC cable through the AC waterproof hole.
(2) Fix the cables according to conductor marks of L, N and PE.
Figure 4.3
Connect the Cables
Figure 4.2
Thread the cables
Table 4.1
Specications for Inteace
Code
A
B
C
D
E
F
G
H
I
J
Name
DC Switch
PV Input
PV Input
Batte Input
BMS/ CAN/ METER/ DRM
CT/ Inveer Parallel po
4G/ Wi-Fi/ Ethernet
Backup
Grid
Ground Connection
4.3
AC Grid Wire
and Backup
Output
Connection
Caution：
For safety operation and regulation compliance, it is requested to install a breaker (32A)
between grid and inveer.
Cable Cross-sectional area（mm²） External diameter（mm）
Range
8~14
Recommend
14
Recommend
4.0
Range
2.5~6.0
Table 4.2
Recommended Specications of AC Cables
If the grid-connection distance is too far, please amplify diameter selection of the AC cable as
per the actual condition.
BACK_UP-R
N
PE
BACK_UP-S
BACK_UP-T
GRID-R
GRID-T
PE
N
GRID-S
2019
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

Figure 4.6
Connecting Cables
4.4
PV Connection
Figure 4.4
Screw the Connector
(3) Secure all pas of the grid and backup connector tightly.
(4) During o-network operation time, null line at the BACK-UP end will remain to be connected
with the null line at the power grid end inside the machine. (Only applicable to market in Australia)
DC connector is made up of one positive connector and one negative connector
Table 4.3
Recommended Specications of DC Cables
Cable Cross-sectional area（mm²） External diameter（mm）
Range
4.2~5.3
Recommend
5.3
Recommend
4.0
Range
4.0~6.0
Figure 4.5
Positive and negative connectors
NOTICE
· Please place the connector separately after unpacking in order to avoid confusion for connection of cables.
· Please connect the positive connector to the positive side of the solar panels, and connect the negative connector
to the negative side of the solar side. Be sure to connect them in right position.
Connecting Procedures:
(1) Use specied strip tool to strip the insulated enclosure of the positive and negative cables
with appropriate length (8-10mm).
2221
positive connector
negative connector
8-10mm positive cable
8-10mm negative cable
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

Figure 4.9
Batte Terminal
Figure 4.7
Connect the Inveer
If lithium batte is connected, it is not required to install a breaker between batte and
inveer.
Figure 4.8
Open the waterproof cover
(2) Feed the positive and negative cables into corresponding lock screws and crimp them
tightly with a wire crimper. Make sure that the withdrawal force of the pressed cable is larger
than 400N.
(3) Plug in the pressed positive and negative cables into relevant insulated enclosure, a
“click” sound should be heard when the contact cable assembly is seated correctly.
(4) Fasten the lock screws on positive and negative connectors into corresponding insulated
enclosure and make them tight.
(5) Connect the positive and negative connectors into positive and negative DC input
terminals of the inveer, a “click” sound should be heard when the contact cable assembly is
seated correctly.
NOTICE
· Before inse the connector into DC input terminal of the inveer, please make sure that the DC switch of the
inveer is OFF.
· Please use the original H4 terminal to install.
1. Connection Po
4.5
Batte
Connection Cable Cross-sectional area（mm²） External diameter（mm）
Range
4~6
Recommend
5
Recommend
5
Range
4~6
Table 4.4
Recommended Specications of DC Cables
Procedure:
(1) Open the waterproof cover, feed the AC cable through the AC waterproof hole.
(2) Strip o the insulation skin of DC cable, the core is exposed to 10mm, and use a special
tool to press the Batte Terminal.
2423
1
1
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

Figure 4.10
Connect the Batte Cable
H2 series hybrid inveer has a RS232 communication po integrated.
Figure 4.11
9-Pin serial po
4.7
Communication
Connection
(3) Fix the batte cable on the batte copper terminal by positive and negative in order.
4.6
Eah
Fault Alarm This inveer complies with IEC 62109-2 clause 13.9 for eah fault alarm monitoring. If an
Eah Fault Alarm occurs, the second LED indicator will be lit up until the error being solved
and inveer functioning properly.
4.7.1 Serial Po Denition 1 2 3 4
Table 4.4
Recommended Specications of DC Cables
Pin Number
1
2
3
4
Description
+7V
RS-232 TX
RS-232 RX
GND
Eect
Power supply
Send data
Receive data
Ground wire
USB inteace with Wi-Fi module, please reference Wi-Fi module user manual.
4.7.2 RJ45 Pin Po Denition
NC
NC
NC
NC
NC
NC
RS485-A+
RS485-B-
1
2
3
4
5
6
7
8
Figure 4.12
Inteace denition
Table 4.5
RJ45 pin po denition
RS485/ Meter
2625
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
DRM 1/5
DRM 2/6
DRM 3/7
DRM 4/8
RefGen
Com/DRM 0
V+
V-
1
2
3
4
5
6
7
8
DRM
NC
NC
NC
CANH
CANL
NC
NC
NC
CAN
1
2
3
4
5
6
7
8
CT
R/CT.I+
R/CT.1-
S/CT.1+
S/CT.I-
T/CT.1+
T/CT.1-
NC
NC
1
2
3
4
5
6
7
8
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

Figure 4.13
Connection of communication cable
4.8
Connection
Diagram
Open the waterproof cover, pass the prepared communication cable through each component,
inse corresponding communication po, then tighten the screws.
Figure 4.15
H2 Connection diagram
4.7.3 Inse the
communication cable
Figure 4.14
Sma meter wiring
4.7.4 Sma
Meter Connection
Notice: The hybrid inveer is with expo
limitation function, which can be realized by
connecting SAJ recommended sma meter to
the hybrid energy storage system. Users can
contact SAJ for fuher details for the sma
meters. If users have no intention to set the
expo limitation function, please ignore
chapter 4.7.4.
If users have purchased the sma meter that
recommended by SAJ, before setting the
expo limitation function, users shall connect
the meter to the system with procedures
below:
SET SE C
3 6 9 10
Meter
IA(Blue)
IB(Blue)
IC(Blue)
IA(White)
IB(White)
IC(White)
RS485 A
RS485 B
L1
N
L2
L3
13 14 16 1 7 19 2 1 24 25
1 4 7 10
27
Note：The sequence of Grid wire must be connected correctly, otherwise, an "Master Grid Phase Error" will be occured (refer to chapter 6). If this
fault occured, please switch the position of L2 and L3 cable.
DC breaker
Battery
SET S EC
1 4 7 10
3 6 9 10
Meter
On-grid Load
Grid
Back-up Load
Power Meter
BMS
RS485
AC Breaker
AC Breaker
CT-A
CT-B
CT-C
13 14 16 17 19 21 24 25
PV Array
L1
L3
N
PE
L
1
L3
N
P
E
L2
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL
28

4.9
Ground
Connection Remove the screw on the ground terminal and secure the cable with a screwdriver.
Figure 4.16
Inveer ground protection
4.10
External AC
Circuit Breaker
and Residual
Current Device
Please install a circuit breaker to ensure the inveer is able to disconnect from grid safely.
The inveer is integrated with a RCMU, however, an external RCD is needed to protect the
system from tripping, either type A or type B RCD are compatible with the inveer.
The integrated leakage current detector of inveer is able to detect the real time external
current leakage. When a leakage current detected exceeds the limitation, the inveer will be
disconnected from grid quickly, if an external residual current device is connected, the
action current should be 30mA or higher.
3029
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

5.
DEBUGGING
instructions
5.1
Introduction of
LED Indicator
Figure 5.1
LED indicators
3231
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL

5.2
Commissioning
Talbe 5.1
Instructions of the Inteace
LED o
Breathing
Solid
Breathing
Solid
Solid
On 1s, o 1s
On 1s, o 3s
O
Solid
On 1s, o 1s
On 1s, o 3s
O
Solid
On 1s, o 1s
On 1s, o 3s
O
Solid
On 1s, o 1s
O
Solid
On 1s, o 1s
O
Solid
On 1s, o 1s
On 1s, o 3s
O
Solid
On 1s, o 1s
O
Sta up:
(1) Connect the AC circuit breaker
(2) Connect the DC circuit breaker between inveer and batte (if applicable)
(3) Turn ON the batte (if applicable)
(4) Turn ON the DC switch on the inveer
(5) Install the communication module into the inveer
(6) Setup the initial setting for inveer on eSolar APP
(7) Obsee the LED indicators on the inveer to ensure the inveer is running properly
Status
Inveer power o
Inveer is at initial state or standby state
Inveer running properly
Inveer is upgrading
Inveer is faulty
Impoing electricity from grid
Expoing electricity to grid
Not impoing and expoing at all
O-grid
Batte is discharging
Batte is charging
SOC low
Batte is disconnected or inactive
Connected to grid
Counting down to grid connection
Grid is faulty
No grid
PV array is running properly
PV array is faulty
PV array is not operating
AC side load is running properly
AC side load overload
AC side is turned o
Both BMS and meter communication are good
Meter communication is good, BMS communication is lost
Meter communication is lost, BMS communication is good
Both meter and BMS communication are lost
Connected
Connecting
Disconnected
Description
LED indicator
System
Batte
Grid
PV
Backup
Cloud
Communication
3433
5.3
eSolar APP
Connection Login to eSolar O&M APP and click on “My” and select “Remote Conguration”
Click on “Bluetooth” and activate the Bluetooth function on your phone, then click on “Next”
Choose your inveer according to your inveer SN’s tail numbers
Click on the inveer to enter inveer setting
Step 1
Step 2
Step 3
Step 4
ROOFTOP SOLAR INVERTER INSTRUCTION MANUAL
