SAJ C6 Series User manual

C6series
COMMERCIAL ON-GRID
SOLAR INVERTER User Manual
Specications are subject
to change without notice.
r25
Tel: [phone] Fax: [phone] Web: www.saj-electric.com
Add: SAJ Innovation Park,No.9, Lizhishan Road,Science City,
Guangzhou High-tech Zone , Guangdong, P.R.China
GUANGZHOU SANJING
ELECTRIC CO.,LTD
C6-75K-T6 / C6-100K-T9 / C6-110K-T12 / C6-125K-T12
C6-50K-T6-LV / C6-60K-T9-LV / C6-70K-T12-LV
V1.0
广州三晶电气股份有限公司
2023-02-01
技术资料专用章

Preface
Thank you for choosing SAJ solar inveer. We are pleased to provide you
rst-class products and exceptional seice.
This manual includes information for installation, operation, maintenance,
trouble shooting and safety. Please follow the instructions of this manual so
that we can ensure delive of our professional guidance and wholeheaed
seice.
Customer-orientation is our forever commitment. We hope this document
proves to be of great assistance in your journey for a cleaner, greener world.
Please check for the latest version at www.saj-electric.com
Guangzhou Sanjing Electric Co., Ltd.
The World’s Leading Provider of Digital Energy
Management Seices for Green Buildings

Contents
01 02
USER MANUAL SAJ SOLAR INVERTER

USER MANUAL SAJ SOLAR INVERTER
04
1.1
Safety Precautions
1.1Scope of Application
This User Manual describes instructions and detailed procedures for
installing, operating, maintaining, and troubleshooting of the following SAJ
on-grid inveer
C6-75K-T6 / C6-100K-T9 / C6-110K-T12 / C6-125K-T12
C6-50K-T6-LV, C6-60K-T9-LV, C6-70K-T12-LV
Please keep this manual all time available in case of emergency.
1.3
Target Group
Only qualied electricians who have read and fully understood all safety
regulations contained in this manual can install, maintain and repair the
inveer. Operators must be aware of the high-voltage device.
1.2
Safety Instruction
03
Safety Precautions
CAUTION
· CAUTION indicates a hazardous condition, which, if not avoided, can result in minor or
moderate inju.
DANGER
· DANGER indicates a hazardous situation, which, if not avoided, will result in death or
serious inju.
WARNING
· WARNING indicates a hazardous situation, which, if not avoided, can result in death or
serious inju or moderate inju.
NOTICE
· NOTICE indicates a situation that can result in potential damage, if not avoided.
1

USER MANUAL SAJ SOLAR INVERTER
06
Symbols
2.1
Symbols
05
DANGER
· There is possibility of danger to life due to electrical shock and high voltage.
· Do not touch non-insulated pas or cables.
· Disconnect the inveer from voltage sources and make sure it cannot be reconnected
before working on the device.
· Do not disconnect the DC connector under load.
· Do not touch the live pas and cables inside the inveer during operation, it might result
in burning or death.
· To prevent risk of electric shock during installation and maintenance, please make sure
that all AC and DC terminals are disconnected.
· Do not touch the suace of the inveer while the housing is wet, otherwise, it might
cause electrical shock.
· Do not stay close to the inveer while there are severe weather conditions including
storm, lighting, etc.
· Before opening the housing, the SAJ inveer must be disconnected from the grid and PV
generator; you must wait for at least ve minutes to le t the energy storage capacitors
completely discharged after disconnecting from power source.
WARNING
Danger to life due to re or explosion
· In the event of fault, do not conduct any direct action on the inveer.
· Disconnect PV array from inveer via an external disconnection device. If there is no
external disconnection device present, wait until no more DC power is applied to the
inveer.
· Disconnect the AC circuit breaker, or keep it disconnect if it is tripped, and secure it
against reconnection.
· Do not touch non-insulated pas or cables.
· Do not touch non-insulated pas or cables.
·The installation, seice, recycling and disposal of the inveers must be peormed by
qualied personnel only in compliance with national and local standards and regulations.
·Any unauthorized actions including modication of product functionality of any form may
cause lethal hazard to the operator, third paies, the units or their propey. SAJ is not
responsible for the loss and these warranty claims.
·The SAJ inveer must only be operated with PV generator. Do not connect any other
source of energy to the SAJ inveer.
·Be sure that the PV generator and inveer are well grounded in order to protect proper-
ties and persons.
CAUTION
·The solar inveer enclosure will become hot during operation. Please do not touch the
heat sink or enclosure during operation.
·Risk of damage due to improper modications.
·Public utility only.
·The solar inveer is designed to feed AC power directly to the public utility power grid; do
not connect AC output of the inveer to any private AC equipment.
NOTICE
2

USER MANUAL SAJ SOLAR INVERTER
2.2
Explanations of Symbols
07 08
Symbol Description
Dangerous electrical voltage
This device is directly connected to public grid, thus all work to the inveer
shall only be carried out by qualied personnel.
Danger to life due to high electrical voltage!
There might be residual currents in inveer because of large capacitors. Wait
for 5 minutes before you remove the front lid.
Danger of hot suace
The components inside the inveer will release a lot of heat during operation.
Do not touch metal plate housing during operating.
An error has occurred
Please go to Chapter 9 “Troubleshooting” to remedy the error.
This device shall not be disposed of in residential waste
Please go to Chapter 8 “Recycling and Disposal” for proper treatments.
CE Mark
Equipment with the CE mark fullls the basic requirements of the Guideline
Governing Low-Voltage and Electro-magnetic Compatibility.
CQC Mark
The inveer complies with the safety instructions from China's Quality Center.
Notice, danger!
This is directly connected with electricity generators and public grid.
5min

C6 Applicable Grid
Figure 3.2
C6 applicable grid
L1
L2
L3
PE
C6 inveer
L1
L2
L3
N
PE
C6 inveer
L1
L2
L3
N
PE
C6 inveer
L1
L2
L3
PEN
C6 inveer
C6 inveer
L1
L2
L3
N
PE
USER MANUAL SAJ SOLAR INVERTER
Product Information
3.1
Application Scope of Products
C6 series product is grid-tied three phase inveer without transformer.
The product conves the DC generated by solar panels into AC which is in
accordance with the requirements of public grid and send the AC into the
grid, Figure 3.1 shows the structural diagram of the typical application
system of C6 inveer.
Figure 3.1
C6 series application
Solar array C6 inveer AC Distribution
box
AC Distribution
cabinet
Transformer grid
09 10
3

1045mm 361mm
660mm
USER MANUAL SAJ SOLAR INVERTER
3.2
Specication for
Product Model
3.3
Oveiew of products
3.4
Dimensions of products
C6 – XK – TX - LV
① ② ③ ④
① C6 means for product name.
② XK means rated power XkW of inveer, for example, 125K means
125kW.
③ T means three phase; X represents the number of MPPT of inveer
④ LV means that the AC output voltage is 220V; If no LV sux, AC output
voltage is 380V/400V
Item Name
ALED Display Board
Wiring Cabinet Cover
Handle (Base)
DC Switch
Communication Po
AC Output
Mounting Bracket (Beam)
Mounting Bracket (side hanger)
DC Input
Handel (Side)
B
C
D
E
F
G
H
I
J
3.5
Datasheet
Model
Input (DC)
Output (AC)
Max. PV Array Power[kWp]@STC 112.5 150
1100
180 ～ 1000
600
200
180
2
Integrated
6*30 9*30 12*30
6*45 9*45 12*45
165 180
Max. Input Voltage[V]
MPP Voltage Range[V]
Nominal Input Voltage[V]
Staup Voltage[V]
Min. Input Voltage[V]
Max. Input Current[A]
Max. Sho-Circuit Current[A]
Number of Strings per MPP Tracker
Number of MPP Trackers
DC Switch
Rated AC Output Power[kW]
Max. AC Output Power[kW]
Max. AC Apparent Power[kVA]
Rated AC Output Current[A]
Max. AC Output Current[A]
Nominal AC Voltage[V]
Nominal AC Grid Frequency/ Range
[Hz]
Total Distoion Harmonic[THDi]
Adjustable Power Factor
Eciency
Feed-in phases/AC connection
phases
Max. Eciency
Euro. Eciency
98.8%
98.5%
C6-75K-T6 C6-100K-T9 C6-110K-T12 C6-125K-T12
C6-75K/100K/110K/125K-T6/T9/T12
75 100 125
82.5 110 125
82.5 110 125
108.3 144.3
158.8
3+N+PE,230/400
50, 60 / 44-55, 54-65
<3%
0.8 leading ～ 0.8 lagging
3/3
180.4
119.1 180.4
110
121
121
158.8
174.6
6912
11 12
A
B
CDE F

USER MANUAL SAJ SOLAR INVERTER
Protection
Model
AFCI Protection
PV String Current Monitoring
Integrated
Optional
Optional
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Type II
Type II
Integrated
Integrated
Internal Temperature Detection
Residual Current Monitoring Unit
DC Insulation Resistance Detection
Anti-islanding Protection
DC Reverse Polarity Protection
DC Surge Protection
AC Surge Protection
AC Overcurrent Protection
AC Sho-Circuit Protection
AC Oveoltage Protection
PID Recove
Inteace
AC Connection
DC Connection
Display
Communication Po
Communication Mode
General Data
Topology
Operating Temperature Range
Nighttime Power Consumption[W]
Cooling Method
Ambient Humidity Max. Operating
Altitude[m]
Intelligent fan cooling
0% ～ 100% non-condensing4000 (>3000 power derating)
RS232+RS485
OT/DT Terminal (Max. 240 mm²)
MC4
LED+APP (Bluetooth）
Wi-Fi/Ethernet/4G/PLC(Optional）
Non-isolated
<2
-30℃～ +60℃ [45℃ to 60℃ with derating]
General Data
Model
Noise[dBA] <60
IP66
Wall mounting
1045*660*361
93 98
5(Standard)/10/15/20 (Optional)
EN50549-2,IEC/EN62109-1/2 EN61000-6-2/4,PPDS,
RD1669,RD413, UNE217001,IEC 62116,
IEC61727,G99, CEI 0-16, C10/11
Ingress Protection
Mounting
Dimensions [H*W*D][mm]
Weight[kg]
Warranty[Year]
Ceications
13 14
C6-75K-T6 C6-100K-T9 C6-110K-T12 C6-125K-T12 C6-75K-T6 C6-100K-T9 C6-110K-T12 C6-125K-T12

15 16
USER MANUAL SAJ SOLAR INVERTER
Model
Input (DC)
Output (AC)
Max. PV Array Power[kWp]@STC 75 90
1100
180 ～ 1000
380
200
180
2
Integrated
6*30 9*30 12*30
6*45 9*45 12*45
105
Max. Input Voltage[V]
MPP Voltage Range[V]
Nominal Input Voltage[V]
Staup Voltage[V]
Min. Input Voltage[V]
Max. Input Current[A]
Max. Sho-Circuit Current[A]
Number of Strings per MPP Tracker
Number of MPP Trackers
DC Switch
Rated AC Output Power[kW]
Max. AC Output Power[kW]
Max. AC Apparent Power[kVA]
Rated AC Output Current[A]
Max. AC Output Current[A]
Nominal AC Voltage[V]
Nominal AC Grid Frequency/ Range
[Hz]
Total Distoion Harmonic[THDi]
Adjustable Power Factor
Eciency
Feed-in phases/AC connection
phases
Max. Eciency
Euro. Eciency
98.8%
98.5%
C6-50K-T6-LV C6-60K-T9-LV C6-70K-T12-LV
C6-50K-T6-LV,C6-60K-T9-LV,C6-70-T12-LV
50 60 70
55 60 70
55 60 70
131.2 157.5
157.5
3+N+PE,127/220
50, 60/44-55, 54-65
<3%
0.8 leading ～ 0.8 lagging
3/3
183.7
144.3 183.7
6 9 12
Protection
Model
AFCI Protection
PV String Current Monitoring
Integrated
Optional
Optional
Integrated
Integrated
Integrated
Integrated
Integrated
Integrated
Type II
Type II
Integrated
Integrated
Internal Temperature Detection
Residual Current Monitoring Unit
DC Insulation Resistance Detection
Anti-islanding Protection
DC Reverse Polarity Protection
DC Surge Protection
AC Surge Protection
AC Overcurrent Protection
AC Sho-Circuit Protection
AC Oveoltage Protection
PID Recove
Inteace
AC Connection
DC Connection
Display
Communication Po
Communication Mode
General Data
Topology
Operating Temperature Range
Nighttime Power Consumption[W]
Cooling Method
Ambient Humidity
Intelligent Fan Cooling
0% ～ 100% Non-condensing
C6-50K-T6-LV C6-60K-T9-LV C6-70K-T12-LV
RS232+RS485
OT/DT Terminal (Max. 240 mm²)
MC4
LED+APP (Bluetooth）
Wi-Fi/Ethernet/4G/PLC(Optional）
Non-isolated
<2
-30℃～ +60℃ [45℃ to 60℃ with derating]

USER MANUAL SAJ SOLAR INVERTER
17 18
General Data
Model
Noise[dBA]
Max. Operating Altitude[m]
<60
IP66
Wall mounting
660*1045*361
93 98
5(Standard)/10/15/20 (Optional)
IEC/EN62109-1/2, EN61000-6-1/2/3/4
Ingress Protection
Mounting
Dimensions [H*W*D][mm]
Weight[kg]
Warranty[Year]
Ceications
C6-50K-T6-LV C6-60K-T9-LV C6-70K-T12-LV
4000 (>3000 Power Derating)

USER MANUAL SAJ SOLAR INVERTER
20
Instruction for Installation
4.1
Safety Instruction
4.2
Pre-installation Check
4.3
The Determination of
the Installation
Method and
Position
DANGER
· Dangerous to life due to potential re or electricity shock.
· Do not install the inveer near any inammable or explosive items.
· This inveer will be directly connected with HIGH VOLTAGE power generation device; the
installation must be peormed by qualied personnel only in compliance with national and
local standards and regulations.
NOTICE
· This equipment meets the pollution degree II.
· Inappropriate installation environment may jeopardize the life span of the inveer.
· Installation directly exposed under intensive sunlight is not recommended.
· The installation site must be well ventilated.
Although SAJ’ s inveers have thoroughly tested and are checked before
delive, it is unceain that the inveers may suer damages during trans-
poation. Please check the package for any obvious signs of damage, and
if such evidence is present, do not open the package and contact your
dealer as soon as possible.
① The equipment employs natural convection cooling, and it can be installed indoor
or outdoor.
② Veical installation on eye level is recommended. Mount veically or tilted back-
wards by max. 15 ° . Never install the inveer tilted forwards, sideways, horizontally or
upside down.
③ Considering convenience for maintenance, please install the equipment at eye level.
④ When mounting the inveer, please consider the solidity of wall for inveer, includ-
ing accessories, make sure the wall has enough strength to hold the screws and bear
the weight of products. Please ensure the mounting bracket mounted tightly.
Please refer to the packing list inside the package container.
19
4
4.3.1
Mounting methods
Fig 4.1
Mounting methods
4.2.1
Check the Package
4.2.2
Scope of Delive

USER MANUAL SAJ SOLAR INVERTER
4.4
Mounting Procedure
4.4.1
Wall Mounting
Mark the Positions of the Drill Holes of the Mounting Bracket
The mounting position should be marked as below.
Fig 4.3
Dimensions of mounting bracket
(Dimensions in mm)
Fig 4.4
mounting panel drill holes' position
Fig 4.5
Mount the mounting bracket
Fig 4.2
Installation clearance
DO NOT expose the inveer to direct solar irradiation as this could cause
power derating due to overheating.
The ambient temperature should be between -40 ° C ～ +60 ° C (-40 ° F ～
140° F) to ensure optimum operation.
Choose locations with sucient air exchange. Ensure additional ventila-
tion, when necessa.
DO NOT install the inveer near any inammable and explosive items.
>600mm
>500mm
>800mm >800mm >1000mm
21 22
Drill Holes and Place the Expansion Tubes
Follow the given guides, drill 3 holes in the wall (in conformity with posi-
tion marked in Figure 4.4), and then place expansion tubes in the holes
using a rubber mallet.
Mount the Screws and the Mounting Bracket
The brackets should be mounted in the mounting position by screws as
below.
1044
1003

USER MANUAL SAJ SOLAR INVERTER
4.4.2
Bracket Installation
Fig 4.7
Dimensions of mounting bracket
(Dimensions in mm)
Fig 4.8
Drill holes’ dimensions (dimensions in mm)
Fig 4.6
Mounting inveer
Fig 4.9
Mount the mounting bracket
Fig 4.10
Mounting inveer
23 24
Mount the Inveer
Carefully mount the inveer to the mounting bracket. Make sure
that the rear pa of the equipment is closely mounted to the
mounting bracket.
Mount the Screws and the Mounting Bracket
The brackets should be mounted in the mounting position by
screws as below.
Mount the Inveer
Carefully mount the inveer to the mounting bracket. Make sure
that the rear pa of the equipment is closely mounted to the
mounting bracket.
Mark the Positions of the Drill Holes of the Mounting Bracket
The mounting position should be marked as below.
Drill Holes and Place the Expansion Tubes
Follow the given guides, drill 3 holes in the wall (in conformity
with position marked in Figure 4.4), and then place expansion
tubes in the holes using a rubber mallet.
1044
1003
1003

Electrical connection must only be operated on by professional techni-
cians. Please keep in mind that the inveer is a bi-power supply equip-
ment. Before connection, necessa protective equipment must be em-
ployed by technicians, including insulating gloves, insulating shoes and
safety helmet.
USER MANUAL SAJ SOLAR INVERTER
Electrical Connection
5.1
Safety Instruction
5.2
Specication for
Electrical Inteace
Figure 5.1
Electrical terminals
Table 5.1
Specications for inteace
DANGER
Dangerous to life due to potential re or electricity shock.
· The PV panel string will produce lethal high voltage when exposed to sunlight.
· Disconnect DC and AC circuit breakers before staing electrical connections.
· Ensure all the cables have no voltage before conducting cable connection
Item Name
ADC Switch
DC Input
RS232 Communication
RS485 Communication
AC Output
Ground Connection
Ground Connection
B
C
D
E
F
G
25 26
5
WARNING
· Any improper operations during cable connection can cause device damage or
personal inju.
· All cables must be undamaged, rmly attached, properly insulated and adequately
dimensioned.
NOTICE
· When power-on, the equipment should be in conformity with national rules and
regulations.
· The direct connection between the inveer and high voltage power systems must be
operated by qualied technicians in accordance with local and national power grid
standards and regulations.

Note: The additional cable and OT/DT terminal should be prepared by user
themselves.
Remove the screw of grounding terminal and secure the additional
grounding cable by inse a screw into the screw hole in the OT/DT
terminal.
Note: Do not connect Aluminum OT/OD terminal with AC output terminal,
as it will have electrochemical reaction with AC output terminal and aect
the reliability of connection. Please choose the OT/OD terminal material
according to the cable conductor material as below.
USER MANUAL SAJ SOLAR INVERTER
5.3
AC Connection
5.3.1
Electrical Connection
Oveiew
5.3.2
Cable Specication
5.3.3
Circuit Breaker
Specication
5.3.5
Connection of Additional
Grounding
Table 5.3
Recommended power grid connecting
cable specication
Table 5.5
Specication of cables
Table 5.6
Specication of cable conductor material
Table 5.4
Recommended circuit breaker specication
Fig 5.2
Electrical connection oveiew
Table 5.2
Electrical connection oveiew
27 28
12 3
4
5
DC
AC
GND
COMM 6
Item Name
1PV Array
C6 Inveer
Inveer enclosure grounding connection
Circuit Breaker
Grid
Monitoring Platform
2
3
4
5
6
Cable type Scope (S) Recommended
grounding cable (Spe)
External diameter
（mm）
Three core, four core
ve core cable
Four single core cable
Spe≥S/2
14-32
38-66
95-240
Model Recommended circuit breaker
rated voltage Recommended circuit breakerrated current
C6-100K-T9/C6-60K-T9-LV
C6-75K-T6/C6-50K-T6-LV
C6-110K-T12/C6-70K-T12-LV
C6-125K-T12
≥400V
160A
200A
225A
250A
L1/L2/L3/N cable terminal PE cable terminal
Specication:
5.3.4
OT/OD Terminal
Specication
b
a
d
c
Fig 5.3
OT/OD terminal
Cross-sectional area of cables（mm²）
L1/L2/L3/N cable terminal M12 size a≤46mm, 13mm≤b≤15.5mm
PE cable terminal M8 size c≤30mm, 8mm≤d≤11mm
Cable conductor material Recommended OT/OD terminal material
Copper Copper
Copper clad aluminum Copper
Aluminum Copper to aluminum adapter terminal
WARNING
· The ground connection of this additional grounding connection cannot replace the AC
cable PE terminal connection.
· Make sure that all the grounding points on the enclosures are equipotential connected
when there are multiple inveers
· Connect this additional grounding cable before AC cable connection, DC cable connec-
tion and communication cable connection.

Fig 5.4
Installating additional grounding cable
Fig 5.5
AC side electrical connection
USER MANUAL SAJ SOLAR INVERTER
Table5.7
Recommended specications of DC cables
Fig 5.6
Positive connector
Fig 5.7
Negative connector
5.3.6
AC Side Electrical Connection
5.4.1
DC cable specication
5.4
DC Side Electrical Connection
5.4.2
PV Connector Assembly
29 30
1.Strip o wire insulation skin and AC cable insulation skin to a proper
length
2.Crimp the AC cable with OT/OD terminal
3.Disconnect AC circuit breaker, open the wiring cabinet cover
4.Inse the cable through waterproof cable gland and housing
5.Inse the conductors into the corresponding pos and x it with screws
6.Secure the cable gland by fastening sealing nut
7.Plug the AC connector into the AC connector po of inveer
Cross-sectional area of cables（mm²） External diameter of the cables（mm）
Scope
4≤S≤6
6mm-9mm
1.Insulated enclosure 2. Lock screw 3. Positive connector
1.Insulated enclosure 2. Lock screw 3. Negative connector
1 2 3
1 2 3
DANGER
Dangerous to life due to electric shock when live components or DC cables are touched.
· The PV panel string will produce lethal high voltage when exposed to sunlight. Touching
live DC cables results in death or lethal injures.
· DO NOT touch non-insulated pas or cables
· Disconnect inveer from voltage sources.
· DO NOT disconnect DC connectors under load.
· Wear suitable personal protective equipment for all work.
WARNING
· Make sure the PV array is well insulated to ground before connecting it to the inveer.
· Make sure the maximum input voltage of each string is not exceeding 1100V
· When input voltage is between 950V~1100V, the inveer will enter standby mode. When
the input voltage returns to MPPT operating voltage range, which is 180V~950V, the
inveer will return to normal mode.
· Make sure the maximum sho-circuit current of DC side is within the permissible range.

USER MANUAL SAJ SOLAR INVERTER
31 32
Position Description
B
C
D
E
ADIP Switch
Alarm Output D Contact
Emergency Stop D Contact
Meter Output
Connecting Procedures:
1. Tighten the lock screws on positive and negative connector.
2. Strip the insulation of the positive and negative cables with 8-10mm
length.
The inveer is integrated with alarm output d contact and emergency
stop d contact.
Alarm output d contact:
Relay can be set to normal open contact (COM&NO) or normal close con-
tact (COM&NC), when inveer is in alarm/fault state, the fault status can
be indicated by LED indicator or other external display device.
USB L
CN9
CN10
H
150.00
A2 B2 PE A2 B2 PE A1 B1 PE A1 B1 PE
METER
LOCAL STOP
DRM
ALARM
RS485
METER
USB
Alarm output
d contact
Emergency stop
d contact
L
CN9
CN10
H
150.00
A2 B2 PE A2 B2 PE A1 B1 PE A1 B1 PE
METER
LOCAL STOP
DRM
ALARM
RS485
METER
1. Positive cable
2. Negative cable
OFF 120Ω NO OFF 120Ω NO OFF 120Ω NO
RS485
SW1 CAN SW3 METER SW2
C1
RT2
M9
M12
RT1
NC NO COM
RS485
RS485
DI+ DI- DI+ DI-
NC NO COM
RS485
RS485
DI+ DI- DI+ DI-
OFF 120Ω NO OFF 120Ω NO OFF 120Ω NO
RS485
SW1 CAN SW3 METER SW2
C1
RT2
M9
M12
RT1
1
1
4.Inse the positive and negative connectors into positive cable and nega-
tive cable whose insulated enclosure has been stripped o, and crimp
them tightly with a wire crimper. Make sure that the withdrawal force of
the pressed cable is bigger than 400N.
5. Plug in the pressed positive and negative cables into relevant insulated
enclosure, a “click” should be heard or felt when the contact cable assem-
bly is seated correctly.
6. Fasten the lock screws on positive and negative connectors into respec-
tive insulated enclosure and make them tight.
3.Feed the positive and negative cables into corresponding lock screws.
7.Make sure the DC switch is at OFF position
8.Connect the positive and negative connectors into positive and negative
DC input terminals of the inveer, a “click” should be heard or felt when
the contact cable assembly is seated correctly.
1. Connection po
RS485 Communication Po
Fig 5.8
Striping o the insulation skin of cables
Fig 5.9
Inseing cables to lock screws
Fig 5.10
Inseing crimped cables to connectors
Fig 5.12
Plug in connectors
Fig 5.11
Securing the connectors
Table 5.8
Terminal description
Fig 5.13
Communication terminal oveiew
Fig 5.14
D contact oveiew
5.5.1
Communication
Terminal Oveiew
5.5
Communication
Connection
5.5.2
D Contact Connection

USER MANUAL SAJ SOLAR INVERTER
33 34
Pin Number Wire color Function
2
3
4
5
6
7
8
1
Orange
White-orange NC
NC
NC
NC
NC
NC
RS485-A
RS485-B
White-green
Blue
White-blue
Green
White-brown
Brown
1.LED indicator as the alarm/fault indicator. When relay is in normal close
contact (NC) and no alarm/fault occurs, LED indicator is on; When there is
fault occurs, relay is in normal open contact (NO), LED indicator is o.
The inveer is integrated with RS485 communication terminal and meter
communication terminal. RS485 communication terminal is mainly for mul-
tiple inveers communication which can be connected in a daisy chain
manner. Meter communication terminal is mainly for data interaction be-
tween monitoring device and inveer.
Note: Meter and RS485 communication have two kinds of inteace, one is
RJ45 terminal, another is terminal block, these two pos peorm the same
function but with dierent wiring. Please choose either one inteace for
cable connection.
Multiple inveer d contact connection
2.LED indicator as the alarm/fault indicator. When relay is on normal open
contact (NO) and no alarm/fault occurs, LED indicator is o; When there is
fault occurs, relay is on normal close contact (NC), LED is on.
Emergency stop d contact:
When DI+ contact and DI- contact are shoed by external controlled
switch, the inveer will stop immediately.
COM1NC1NO1 COM1NC1NO1
COM1NC1NO1 COM1NC1NO1
DI + DI- DI+ DI-
Inveer 1 Inveer 2 Inveer 3
Switch
150.00
A1 B1 PE A1 B1 PE
USB L
CN9
CN10
H
A2 B2 PE A2 B2 PE
METER
LOCAL STOP
DRM
ALARM
NC NO COM
RS485
METER
DI+ DI- DI+ DI-DI+ DI- DI+ DI- DI+ DI- DI+ DI-
RS485 DIP swich
Meter (RJ45) po
Meter (Terminal block)
po
RS485 (Terminal block)
po
Meter (Terminal block) po
RS485
RS485
DI+ DI- DI+ DI-
OFF 120Ω NO OFF 120Ω NO OFF 120Ω NO
RS485
SW1 CAN SW3 METER SW2
C1
RT2
M9
M12
RT1
LOCAL STOP
5.6
RS485 Communication
Connection
Table 5.9
RS485 pin po description
Fig 5.15
Relay is in normal close contact
Fig 5.16
Relay is in normal open contact
Fig 5.18
Multiple inveer d contact
Fig 5.19
RS485 communication
Fig 5.17
Emergency stop d contact
Fig 5.20
RS485 pin

USER MANUAL SAJ SOLAR INVERTER
35 36
Pin Number Description Function
2
3
4
1 +5V Power supply
Send data
Receive data
Ground wire
RS-232 TX
RS-232 RX
GND
Single inveer terminal block connection:
Multiple inveer terminal block connection:
USB inteace could be externally connected with eSolar WiFi /4G/AIO3
communication module, for operation in details please refer to communi-
cation module Quick Installation Guide in https://www.saj-electric.com/.
Pin name Function
B1
PE
A1
B1
PE
A1 RS485-A+ RS485 in, RS485A dierential signal +
RS485 in, RS485B dierential signal -
GND, shielded eahing point
RS485 in, RS485A dierential signal +
RS485 in, RS485B dierential signal -
GND, shielded eahing point
RS485-B-
PE
RS485-A+
RS485-B-
PE
Terminal block:
Note: When there are multiple inveers connected, please connect a ter-
minating resistor between A1 and B1 by switching the RS485 DIP switch,
to ensure the communication quality.
A1 B1 P1 A1 B1 PE
A2 B2 PE A2 B2 PE
RS485_1
A2 B1 PE A1 B1 PE A2 B1 PE A1 B1 PE
A1 B1 PE A1 B1 PE
5.7
RS232/USB Connection
Figure5.24
RS232 pin
Table 5.11
USB pin po denition
Table 5.10
Terminal block description
Fig 5.21
RS485 terminal block
Fig 5.22
Single inveer terminal block
Fig 5.23
Multiple inveer terminal block
