Salus RT520RF User manual

RT520RF THERMOSTAT - FULL USER MANUAL

TABLE OF CONTENTS
1. Introduction...............................................................................................................................................................4
1.1 Product Compliance ......................................................................................................................................................................4
1.2 Safety Informations.......................................................................................................................................................................4
2. Product Overview .......................................................................................................................................................5
2.1 Example of boilers compatible with the OpenTherm OT+ 4.0 protocol..........................................................................................6
2.2 Montage........................................................................................................................................................................................7
2.3 Package content............................................................................................................................................................................7
2.4 Proper thermostat location ...........................................................................................................................................................7
3. RXRT520 receiver ........................................................................................................................................................8
3.1 Receiver’s switches description......................................................................................................................................................8
3.2 LED indications in the receiver.......................................................................................................................................................9
3.3Wall mounting of the receiver .....................................................................................................................................................10
3.4 Connection description................................................................................................................................................................11
I A - Boiler connection ........................................................................................................................................................11
I B - Pump /Valve connection.............................................................................................................................................11
4. Before you start (rst power up) ................................................................................................................................12
4.1 LCD icon description ....................................................................................................................................................................12
4.2 Button description.......................................................................................................................................................................12
4.3 First power up sequence and conguration.................................................................................................................................13
4.4 OpenTherm - HotWater conguration.........................................................................................................................................17
4.5 Max boiler temperature settings.................................................................................................................................................17
5. User settings ............................................................................................................................................................18
5.1 Manual mode..............................................................................................................................................................................18
5.2 Schedule mode - programming schedule....................................................................................................................................19
5.3 Switching between manual and schedule mode.........................................................................................................................20
5.4 BOOST mode - hourly temperature override (+Hr)......................................................................................................................21
5.5 Control and Heat/Cool settings....................................................................................................................................................22
5.6 OFFSET temperature calibration..................................................................................................................................................23
5.7 Landlord settings ........................................................................................................................................................................24
5.8Time/Date ...................................................................................................................................................................................26
5.9 Holiday mode..............................................................................................................................................................................27
5.10 Language ..................................................................................................................................................................................28
6. RT520RF thermostat pairing with the receiver............................................................................................................29
7. Test the pairing process.............................................................................................................................................30
8. Factory Reset............................................................................................................................................................31
9. Error codes ...............................................................................................................................................................31
10. Battery change .......................................................................................................................................................31
11. Cleaning and Maintenance ......................................................................................................................................32
12. Technical Informations ............................................................................................................................................32
13. Warranty ................................................................................................................................................................33

4
This product complies with the essential requirements and other relevant provisions of Directives 2014/53/EU and 2011/65/EU. The full text of the EU
Declaration of Conformity is available at the following internet address: www.saluslegal.com.
• Before starting installation work and before using the product, read the entire manual.
•The information contained in the instructions is essential for proper functioning.
•To avoid accidents resulting in personal injury and material damage, please follow all safety precautions, specied in this manual.
• The device should not be used by people with limited mental, sensory or mental abilities, without experience, of insucient knowledge as well as
children.
• Do not use an unassembled device (eg without a cover).
•The device may only be opened by a qualied person.
• Keep electrical devices out of the reach of children and ensure that they do not play with it. Children should not be left unattended. If necessary,
disconnect the control system for the entire room.
• Do not leave the packaging, cabinet, or any loose parts of the device unattended, as they pose a risk to children.
WARNING!
• Installation must be carried out by a qualied person with appropriate electrical qualications in accordance with standards and regulations in force in
the given country and in the EU.
• Never try to connect the device other than as described in the manual.
• Before assembly, repair or maintenance as well as during any connection works it is absolutely necessary disconnect the mains supply and make sure
that the terminals and electric wires are not live.
•The device may not be exposed to extreme temperatures, strong vibrations or subjected to mechanical shock.
• The device should not be used in unfavorable environmental conditions or in rooms where there is a concentration of ammable gases, fumes or dust.
WARNING!
•There may be additional protection requirements for the entire installation that the installer is responsible for maintaining.
1. Introduction
1.1 Product Compliance
1.2 Safety Informations
Care for the natural environment is of paramount importance to us.The awareness that we manufacture electronic devices obliges us
to dispose of used electronic components and devices safely.Therefore the company has received a registration number issued by the
ChiefInspector for Environmental Protection.The crossedoutsymbol the trashcan on the product means thatthe product must not be
disposed of with ordinary waste containers. Sorting waste for recycling helps to protect the environment. It is the user’s responsibility
to surrender used equipment to a designated collection point for recycling waste from electrical and electronic equipment.

5
The RT520RF room thermostat simply switches the heating system on and o as necessary. It works by sensing the air temperature, switching on the
heating when the air temperature falls below the thermostat setting, and switching it o once this set temperature has been reached.
Turning a room thermostat to a higher setting will not make the room heat up any faster. How quickly the room heats up depends on the design of the
heating system, for example, the size of boiler and radiators. Neither does the setting aect how quickly the room cools down.Turning a room thermostat
to a lower setting will result in the room being controlled at a lower temperature, and saves energy.
The heating system will not work if a time switch or programmer has switched it o.
The way to set and use your room thermostat is to nd the lowest temperature setting that you are comfortable with, and then leave it alone to do its
job. The best way to do this is to set the room thermostat to a low temperature – say 18⁰C – and then turn it up by one degree each day until you are
comfortable with the temperature.
You won’t have to adjust the thermostat further. Any adjustment above this setting will waste energy and cost you more money.
If your heating system is a boiler with radiators, there will usually be only one room thermostat to control the whole house. But you can have dierent
temperatures in individual rooms by installing thermostatic radiator valves (TRVs) on individual radiators. If you don’t have TRVs, you should choose a
temperature that is reasonable for the whole house. If you do haveTRVs, you can choose a slightly higher setting to make sure that even the coldest room
is comfortable, then prevent any overheating in other rooms by adjusting theTRVs.
Room thermostats need a free ow of air to sense the temperature, so they must not be covered by curtains or blocked by furniture. Nearby electric res,
televisions, wall or table lamps may prevent the thermostat from working properly.
Thermostat is compatibile with OpenTherm OT+ 4.0 version.
The OpenTherm protocol is an open standard communication protocol used in central heating systems for two-way communication between a central
heating boiler and a room thermostat.Thanks to the communication protocol, the boiler power is modulated, which can signicantly increase the energy
eciency of the heating system while maintaining the set temperature in the room. OpenTherm modulation, compared to standard communication (ON
/ OFF), occurs by setting the desired temperature of water from the boiler (boiler power), and not by its cyclical switching on and o.
PLEASE NOTE!
Make sure your gas combi boiler is compatible with OT + 4.0 communication protocol.
The list of compatible boilers is on the next page.
Product advantages:
• set is factory-paired and ready to work
• option to choose Hysteresis or built-inTPI algorithm for all types of heating
• works with time schedules
• service mode protected by a PIN code
• maximum / minimum temperature limitation
• can temporarily change the temperature (overwriting until the next program change)
• has unique transmission codes
• operates at 868 MHz - a stable and noise-resistant signal
2. Product Overview

6
COMPANY MODEL
Alpha Heating
E-Tec S
E-tec Plus
E-tec
Evoke
Intec GS
Atag
iC
iC Economiser
iS
Baxi
100 Combi
200 Combi
400 Combi
600 Combi
Daikin
D2CND 24Kw
D2CND 28kw
D2CND 35kw
Ferroli i25 Condensing Combination Boiler
i29 Condensing Combination Boiler
Ideal
Independent + Combi
Independent Combi
Independent System
Logic Combi+ Combi C
Logic Combi C24, C30, C35 (via a separate bundle set)
Logic Code Combi (via a separate bundle set)
I-mini C24, c30 (via a separate bundle set)
Vogue Combi C26,C32, C40
Logic + System
Logic + Heat
Intergas
Intergas Rapid
Intergas Rapid Plus
Combi Compact, Compact Range
ECO RF
Xtreme
Xclusive
Main Eco Compact Combi 25-30
Navien Navien NCB
Ravenheat
Avanta, Quinta Ace
Quinta Pro
Gas 110 Eco
Vokera
Evolve C
Evolve S
Linea One (przez OpenTherm Kit Part_1221179)
Vision Combi (requires a control interface 294501430
Compact A (requires a control interface 29450143)
Verve (only heating mode)
Mynute I (only heating mode)
Vision System (only heating mode)
Unica I
Vibe
Vision C
COMPANY MODEL
Vokera
Linea HE
Mynute A
Mynute HE
Unica HE
Viessmann
Vitodens 100WTyp WB1A (Connection: X3.3 and X3.4)
Vitodens 100W Typ WB1B (Connection: X21.1 and
X21.2)
Vitodens100WTypWB1C(Connection:X21.1 andX21.2)
Vitodens 200-W WB2B 26+ 35 kW (via Expansion Mo-
dule OT and OT-A8 + _Terminal -10 and +10 are on the
extension of the A8 boiler)
Vitodens 200-W WB2C, B2HA,B2JA, B2LA (via icm
Expander OpenTherm)
Vaillant
(viaVaillant
VR33 module)
Ecotec Pro
Ecotec Plus
Ecotec Exclusive
Ecot Pure
Worcester
Bosch
(via Net
EMS-OT
OpenTherm
converter)
EMS capable boilers
Greenstar i
Greenstar i Junior (Made in July 2013)
Greenstar Si Compact
Greenstar CDi Compact
Greenstar CDi Classic (Made after 16.01.2007 with
CF12.10 software version and newer)
Greenstar Highow CDi
Greenstar 12i System – 24i System (On condition that
an optional integrated diverter valve manufactured
after February 2011 is installed)
Greenstar 27i System – 30i System (Provided the optio-
nal Integrated Changeover Valve is installed Greenstar
CDi Classic System (provided the optional Integrated
Changeover Valve manufactured after 02/16/2007 with
software version CF12.10 and above is installed))
2.1 Example of boilers compatible with the OpenTherm OT+ 4.0 protocol

7
2.2 Montage
2.3 Package content
1) RT520RF thermostat
2)Thermostat bracket
3) RXRT520 receiver
4) 2x AA batteries
5) Short instruction
6) Mounting screws
2.4 Proper thermostat location
Please note:
The ideal position to thermostat mounting is about 1,5m under oor level far from heating or cooling sources. Thermostat can’t be
exposed to sunlight or any extreme conditions like for example draft.
Because of re and explosion risk there is not allowed to use thermostat in atmosphere of explosive gases and ammable liquids (eg coal dust). In case
if any of listed dangers occur you have to use additional protection measures – anti-dust and explosive gases (tight cover) or prevent their formation.
Furthermore, thermostat can’t be used in condensation of water vapor conditions and be exposed to water action.
1
4
2 3
56

8
3. RXRT520 receiver
3.1 Receiver’s switches description
The thermostat communicates wirelessly with the RXRT520 receiver. The receiver should be supplied with 230VAC, the maximum load of the receiver is
16A. Avoid installing the device in places directly exposed to water, moisture and air condensation. The RXRT520 receiver can operate in two dierent
modes - AUTO (automatic) and MANUAL (manual).To select a specic mode, use the buttons on the front of the receiver.
For the receiver to work with the thermostat, set the switches to the ON / AUTO position.
2.
4.
3.
1.
TOP SWITCH
1. ON - Manual mode - receiver ON
2. OFF - Manual mode - receiver OFF
BOTTOM SWITCH
3. AUTO - Receiver works in AUTO mode (according to
the thermostat’s command)
4. MANUAL - Receiver works in manual mode
(according to the top switch)
REMEMBER!:

9
The status of the RXRT520 receiver is indicated by two LEDs.These are
LEDs with the following colors:
- red (upper one),
- green (lower one).
A detailed explanation of the meaning of the LEDs can be found in the table below:
MEANING
The red LED lights up
The receiver is connected to the 230V power supply and is paired with the thermostat.
The receiver can be thermostat-enabled if it is in automatic mode when the lower switch is in the AUTO position.
The receiver can be started manually when the lower switch is in the MANUAL position.
The red LED ashes
The receiver is in the pairing mode and is looking for a signal from the thermostat (then you must activate the
“PAIRING”option in the thermostat)
(or)
The receiver was paired but lost communication with the thermostat due to out of range or low battery in the
thermostat. The receiver starts ashing after one hour of time when it does not receive a signal from the thermostat.
The red diode is o The receiver is disconnected from the 230V power supply or the upper switch is in the OFF position.
The green diode lights up
In automatic mode, the receiver received a heating signal from the thermostat.
The receiver was started in manual mode (upper ON switch, lower MANUAL switch)
The green diode is o The receiver does not send a heating signal.
3.2 LED indications in the receiver
1
2
1
2

10
3.3 Wall mounting of the receiver
Wall mounting the receiver: drill two ø6 mm holes in the wall. Insert the plugs and, by putting the plate to the wall (included in the set), put the two
screws through the holes and then screw them in. Connect the necessary cables to the receiver. Next, hang the receiver on the board using the handles
designed in the receiver, marked in the picture below.
Loosen the screws with a scre-
wdriver just enough to tilt the
back housing.
Attach the back housing to the wall
(keeping the correct positioning of the
plastic„hinges”) using the marked holes
(see the picture above).
Put the receiver from above on the back
housing attached to the wall, according to
the position of the plastic„hinges”.
Tighten the screws from the
bottom of the back housing.
Tilt the receiver cover upwards
(according to the position of the
„hinge”).
Then, correctly connect the wires
included in the set with the
receiver (see„connection diagrams”
on page 11).
1
3
5 6
2
4
3
....

11
3.4 Connection description
RT520TX
L
AC 230V
COM
lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510
RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
RT520TX
L
AC 230V
COM lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
RT520TX
L
AC 230V
COM lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
RT520TX
L
AC 230V
COM lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
RT520TX
L
AC 230V
COM lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
RT520TX
L
AC 230V
COM lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
RT520TX
L
AC 230V
COM lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
RT520TX
L
AC 230V
COM
lub
NO
NN
LL
N
L
AC 230V
N
A
B
RXRT510
RXRT510
N
L
PODŁĄCZENIE KOTŁA*
N
L
OPENTHERM*
3V
2 x AA
BOILER CONNECTION*
or
I B - Pump / Valve connection
I A - Boiler connection
RT310TX
L
AC 230V
COM
lub
NO
NN
LL
N
L
AC 230V
N
COM
NO
RXRT510
RXRT510
N
L
MAX
16 (5) A
PODŁĄCZENIE KOTŁA*
3V
2 x AA
RXRT520
RXRT520
RXRT520
L, N - power supply 230V
NO, COM, NC - voltage-free output
A, B - OpenTherm CommunicationWire
- fuse
Legend: Symbols explanation:
Valve
Pump
Boiler - Boiler connection*
- Boiler’s contacts for ON/OFF
thermostat (according to the
boiler’s instructions)
M
(ON / OFF)
OpenTherm

12
4. Before you start (rst power up)
4.2 Button description
4.1 LCD icon description
1. Text Bar
2. Temperature Unit
3A. Day of the week (numeric)
3B. Day of the week (alphabetic)
4. Clock
5. AM / PM
6. Cooling Mode On
7. Holiday Mode On
8. Manual Mode On
9. Heating Mode On
10. Low battery status
11. Wireless connection with the receiver
12. Service Mode On
13. Temperature measured / set
14. Program number
15. Settings
16. Program indicator
17. Boost function
PLEASE NOTE! The LCD screen can be activated by using any button.
6
2
7
9
11
17
3A 3B
13
5
4
14
15
16
1
8
10
12
123456
1. MENU / RETURN - enter the menu options,
press and hold for 3 sec to return to main screen
or to deactivate Boost or Manual modes.
2. SELECT - conrm changes and enter menus.
3. DOWN - decrease the temperature and
move through the menus.
4. UP - increase the temperature and move
through menus.
5. BOOST - activate Boost Mode.
6. MANUAL - press once to activate / press and
hold for 3 sec to deactivate Manual Mode.

13
4.3 First power up sequence and conguration
Press .
Using or , choose
the time format.
Using or , set the
minutes and then press .
Using or , set the day
and then press .
Using or , select the
week format.
Press to conrm.
Using or , set the year
and then press .
Using or , set the month
and then press .
Press to conrm. Using or , set the hour
and then press .
Using or , choose your
language and then press .
After inserting the batteries, the
thermostat will power up.
2
1
4 5 6
3
7 8 9
Please make the receiver connections and power the receiver before inserting the batteries into the thermostat.
10 11 12

14
Using or , enable or
disable DST (Daylight SavingTime).
Using or , select your
temperature accuracy.
Press to conrm. When OpenTherm is connected, the
device software will automatically
adjust to the OpenTherm settings.
Press to conrm. Press .
13 14 15
181716

15
Press to confirm.
Press .
Using or , select the Span
value.
Span is the temperature difference, between which thermostat operates and keeps
setpoint temperature. For example, if you set setpoint temperature to 20°C and if the
hysteresis is ± 0.5°C, heating will be turned on when the room temperature drops to
19.5°C and turned off when the room temperature reaches 20.5°C.
22
23 24
Press .
Press to confirm.
Using or , select the TPI type you want to use.
TPI (Time Proportional & Integral) is a self-learning, time-proportional algorithm.
TPI type of regulation ensures economical system operation through more accurate
temperature maintenance during controlling process and limits overload conditions. In
addition to the exact and stable room temperature, the advantage of this system is the
minimization of energy consumption and significant savings. RT520RF offers 3 types
of TPI control: 1. for radiator (6CPH); 2. for underfloor heating (3CPH); 3. for electric
heating (9CPH).
19
20 21

16
Using or ,
select ON or OFF.
Press to confirm.
Press .
Press .
The optimization function is an energy-saving algorithm for the effective control of the
heating device, ensuring better thermal comfort at certain times of the day. When the
OPTIMUM START function is active, the thermostat sends a heating signal to the heat
source beforehand so that the preset temperature in the room is reached at the time
specified in the schedule.
25
25 26
The thermostat will go to
the main screen.
Using or ,
select ON or OFF.
Press .
Press to confirm.
When the OPTIMUM STOP function
is active, the thermostat, taking into
account the inertia of the system,
switches off the heat source earlier,
keeping the temperature set in the
schedule.
27
28 29 30
3

17
Using or ,
set MAX temperature for boiler.
Confirm by button.
Press .
Press .
Using or , adjust the
temperature and then press .
Using or , navigate to
Hot Water submenu and press .
Using or , navigate to CH
MAX submenu and press .
Confirm by button.
The text bar indicates that hot water
is in operation.
Thermostat will go back to the main
screen with saving all settings.
The thermostat will return to the
main screen. Press any button.
1
1 2 3
2 3
54
4.4 OpenTherm - Hot Water conguration
4.5 Max boiler temperature settings
RT520RF can be congured in Hot Water OPENTHERM system.To congure it follow steps below:
In this chapter you will learn how to set max temperature for connected boiler. Follow steps below:
3
4 5
3

18
5. User settings
5.1 Manual mode
In manual mode, the thermostat maintains a constant temperature set by the user.To exit mode, press and hold button for 3 seconds. A hand icon
is displayed when manual mode is active.
1
4 5
2 3
Press button. A hand icon will appear, which means
that thermostat is in manual mode.
To set temperature use
or button.
Confirm your choice using
button.
Thermostat will maintain the
temperature until manual change or
manual mode exit (press and hold
button for 3 seconds).
3

19
5.2 Schedule mode - programming schedule
In this mode, user can set the schedules for thermostat (temperature setpoints for specic periods of time). Programmed schedules should use all time
periods.
Using or , select the
program type between: 5
Individual (set a daily schedule).
Using or , set the
temperature and then press .
Press .
+2 (schedule for the working days
and for the weekend)
Using or , set the hour
and then press .
Press to confirm.
Press .
All (set one schedule for
the entire week)
Using or , set the
minutes and then press .
Repeat the process for all time periods.
123
54 6
7
3

20
5.3 Switching between manual and schedule mode
In this option, user can switch between manual and schedule mode by using button.To do that please follow steps below:
123
Press button. A hand icon will appear, which means
that thermostat is in manual mode.
Now press and hold button.
Thermostat is in the shedule mode
again.
3 sec. 3
