Salus RT200 User manual

Instruction Manual
Model No RT200
Electronic Room Thermostat
2
Salus RT200 Manual 002:89 23/11/10 11:05 Page 1

RT200 INSTRUCTION MANUAL
2
PRODUCT COMPLIANCE
This product complies with the essential requirements of the following EC
Directives:
•Electro-Magnetic Compatibility directive 2004/108/EC
•Low Voltage Directive 2006/95/EEC
•EC Marking directive 93/68/EEC
SAFETY INFORMATION
These instructions are applicable to the Salus Controls model stated on the
front cover of this manual only, and must not be used with any other make or
model.
These instructions are intended to apply in the United Kingdom only, and
should be followed along with any other statutory obligations.
This accessory must be fitted by a Competent person, and installation must
comply with the guidance provided in the current editions of BS7671 (IEE
Wiring Regulations) and Part ‘P’ of the Building Regulations. Failure to
comply with the requirements of these publications could lead to
prosecution.
Always isolate the AC Mains supply before carrying out any work on the
RT200 thermostat.
Please leave these instructions with the end user where they should be kept
in a safe place for future reference.
Salus RT200 Manual 002:89 23/11/10 11:05 Page 2

RT200 INSTRUCTION MANUAL 3
INTRODUCTION
A thermostat is a device that is used to switch
the heating system in your home on and off as
needed. It works by sensing the air
temperature and switching on the heating
when the air temperature falls below the
thermostat setting, and switching it off once
the set temperature has been reached.
The RT200 from Salus Controls is a stylish and
accurate electronic thermostat with a large,
easy to adjust setting dial. The thermostat has
been specifically designed to be used in 230V
AC heating applications.
Features
•Simple to use
•Large dial
•Stylish Casing
•LED heat call indicator
•Temperature range between 5 ºC and 35 ºC
OPERATION
The RT200 is adjusted very easily by turning the rotary dial on the front of
the thermostat to the required temperature setting. To adjust the set
temperature, turn the rotary dial to the left to set a lower temperature, or to
the right to set a higher temperature.
The Light Emitting Diode (LED) on the front panel will light when the
temperature is below the set value, showing that the thermostat is calling for
heat from the boiler. Once the room reaches the set temperature, the LED
will turn off and the RT200 will stop calling for heat from the boiler.
Salus RT200 Manual 002:89 23/11/10 11:05 Page 3

INSTALLATION
Please read the important safety information at the start of this manual before you
begin to install the thermostat.
The ideal position to locate the RT200 thermostat is about 1.5m above floor level, in
a location where the thermostat is accessible, reasonably lit and free from extremes of
temperature and draughts. Do not mount the thermostat on an outside wall, above a
radiator or in a location where it may be subjected to direct sunlight.
The electrical connections to the RT200 are made to the supplied industry standard
backplate. This simplifies installation, as no connections are made to the controller
itself. Connection details are shown below - no Earth connection is required for the
correct and safe operation of the RT200, but a parking terminal is provided to connect
an Earth wire if one is present.
RT200 INSTRUCTION MANUAL
4
Backplate Connections
Terminal Description Backplate
N Mains Neutral
L Mains Live
SL Switched Live
(Normally Open Contact)
Earth Parking (no electrical
connection)
After installing the backplate in a suitable location, wiring connections can be
made as shown above. The following criteria apply to the installation:
• The incoming AC mains supply should be 230V AC and fused at 5 amps.
• Optimum cable size for installation is 1.5 mm2; wiring colours should be in
accordance with the current requirements of the IEE Wiring Regulations.
• Cable entry should be from the rear of the backplate.
• All wiring connections should be securely made, and be firmly gripped
beneath the square brass washer on each terminal.
Salus RT200 Manual 002:89 23/11/10 11:05 Page 4

RT200 INSTRUCTION MANUAL 5
Do not restore the mains supply to the system until all associated items are fully installed.
NOTE: All electrical installation work should be carried out by a suitably qualified Electrician
or other competent person. If you are not sure how to install this thermostat consult either
with a qualified electrician, heating engineer or your boiler / heating system supplier for
advice on how to continue.
Do not remove or refit the RT200 onto the backplate without the mains supply to
the system being isolated.
ENERGY TIP
One way to set and use your room thermostat is to find the lowest temperature setting
that you are comfortable with, and then leave it set at this temperature. You can do
this by setting the room thermostat to a low temperature, (for example 17 °C) and
then increasing the setting by one degree each day until you are comfortable with
the room temperature - you won’t have to adjust the thermostat further, as
adjustment above this setting will waste energy - a 1 °C increase in temperature is
equal to 3% of your heating costs.
MAINTENANCE
The RT200 thermostat requires no special maintenance. Periodically, the outer casing
can be wiped clean using a dry cloth (please DO NOT use solvents, polishes, detergents
or abrasive cleaners, as these can damage the thermostat).
There are no user serviceable parts within the unit; any servicing or repairs should
only be carried out by Salus Controls or their appointed agents.
Should the RT200 thermostat fail to function correctly, check:
• The RT200 temperature has been set correctly.
• Heating system time switch or programmer is switched on.
WARRANTY
Salus Controls warrants that this product will be free from any defect in materials or
workmanship, and shall perform in accordance with its specification, for a period of
two years from the date of purchase. Salus Controls sole liability for breach of this
warranty will be (at its option) to repair or replace the defective product.
Salus RT200 Manual 002:89 23/11/10 11:05 Page 5

PRODUCT SPECIFICATION
Model: RT200
Type: Surface mounted electronic room
thermostat designed for 230V AC
heating applications.
Switching
Switching Voltage: 230V AC / 50Hz
Switching Current: 3A resistive, 1A inductive
Contact Type: Single Pole Single Throw (SPST)
Temperature
Range: 5 ºC to 35 ºC
Accuracy: ± 1 ºC at 25 ºC
Environment
Operating Temperature: 0 ºC to + 50 ºC
Storage Temperature: - 20 ºC to + 55 ºC
RT200 INSTRUCTION MANUAL
6
Salus RT200 Manual 002:89 23/11/10 11:05 Page 6

Salus Controls warrants that this product will be free from any defect in materials or
workmanship, and shall perform in accordance with its specification, for a period of
two years from the date of purchase. Salus Controls sole liability for breach of this
warranty will be (at its option) to repair or replace the defective product.
RT200 Warranty
Customer Name: ..............................................................
Customer Address: ...........................................................
.........................................................................................
Post Code: ......................... Tel No: ..................................
Email: ...............................................................................
Engineers Company: ........................................................
Tel No: .............................................................................
Email: ...............................................................................
Intallation Date: ...............................................................
Engineers Name: ..............................................................
Engineers Signature: ........................................................
RT200 INSTRUCTION MANUAL 7
Salus RT200 Manual 002:89 23/11/10 11:05 Page 7

Email: [email protected] Tel: [phone]
Email: [email protected] Tel: [phone]
Sales :
Technical :
Salus Controls plc, Salus House, Dodworth Business Park South,
Whinby Road, Dodworth, Barnsley S75 3SP
