Samson XPD2 USB Digital Wireless System brings the convenience of
wireless to your computer recordings and beyond. With a wireless receiver
built into a USB stick and a handheld transmitter, the Stage XPD2 allows
you to wirelessly record stunning audio straight to your Mac/PC and favorite
digital audio software. It’s the ideal wireless system for presentations,
podcasting, YouTube performances, karaoke video games, voice over projects
and much more. Additionally, the Stage XPD2 is the perfect accessory for
expanding the Samson Expedition Series Portable PA Systems that include
USB wireless ports, for full range wireless capability in live applications.
XPD2 operates in the license-free 2.4GHz frequency band, is extremely
fast and easy to setup and with 100 feet of operating range (environment
dependent) the system provides plenty of room to work wirelessly.
We recommend you keep the following records for reference, as well as a
copy of your sales receipt.
Serial number: _______________________________
Date of purchase: _______________________________
If you have any questions or comments regarding the XPD2 USB Digital
Wireless System or any other products from Samson, do not hesitate to
contact us at [email protected].
With proper care and maintenance, your XPD2 USB Digital Wireless System
will operate trouble-free for many years. Should your XPD2 USB Digital
Wireless System ever require servicing, a Return Authorization (RA) number
must be obtained before shipping your unit to Samson. Without this number,
the unit will not be accepted. Please visit www.samsontech.com/ra for an
RA number prior to shipping your unit. Please retain the original packing
materials and, if possible, return the unit in its original carton. If your XPD2
USB Digital Wireless System was purchased outside of the United States,
contact your local distributor.
Introduction

XPD2 USB Digital Wireless System 5
RXD2 Controls
1. USB Connector - Plugs into the USB jack
on the rear panel of a wirelessly enabled
Samson audio device. The receiver can
also plug directly into a computer USB
port and will be recognized as a USB
audio device. The unit passes audio to the
device and receives power from the device
through this connector. If connecting
the LINE output to an analog device, the
RXD2 can be powered using a standard 5
Volt adapter.
2. PAIR Switch - Press >5 seconds to enter
pairing mode.
3. STATUS Indicator - This LED displays the
operation mode:
Amber: Normal Operation
Flashing Amber: Pairing
No Light: Not paired; Transmitter out of
range; No Power
4. LINE / Headphone Output - Use this 3.5mm
jack when connecting to an analog line
input or headphones for monitoring.

6
HXD1 Controls
1. Status Indicator - This LED
displays the operation mode:
Amber: Normal Operation
Flashing Amber: Pairing / Low
Battery
2. Power/Pair Switch - Press less
than 5 seconds to turn the
unit on or off. Press more
than 5 seconds to enter pair-
ing mode.
3. Battery Cover - Unscrew the
battery cover and slide down
to open the HXD1 battery
compartment.
4. Battery Holder - Open the
battery holder by pressing
the tab and lifting the cover.
Insert two standard AA (LR6)
batteries here, being sure to
observe the plus and minus
polarity markings shown.
WARNING: Do not insert the
batteries backwards; doing so
can cause severe damage to
the HXD1 and will void your
warranty.
5. Input GAIN Control - This
control adjusts the transmitter
input sensitivity.
6. Screwdriver - Used to adjust
the input GAIN control.

XPD2 USB Digital Wireless System 7
1. Plug the RXD2 USB receiver into the USB jack on a wireless-enabled
Samson audio device, or to an available USB port on a computer.
Note: When using the XPD2 wireless system with a computer, you
must set the computer’s audio input device to “Samson RXD Wireless
Receiver”. In most computer operating systems, an audio software
must be used to record or monitor the audio from the USB receiver.
2. Place a fresh set of AA (LR6) batteries in the transmitter battery
holder, taking care to observe the polarity markings.
3. If using a Samson audio device, turn the wireless level knob on the
audio device completely counterclockwise, then turn the power of the
audio device to the ON position.
4. Turn on the power to the transmitter by pressing and holding Power
switch; the indicator LED will light amber.
5. If the transmitter and receiver have not been previously paired, press
and hold the button on the RXD2 receiver for >5 seconds, until it
begins to flash. Press and continue to hold the Power button on
the transmitter until the LED indicators on both units light steady,
indicating that the receiver and transmitter are paired and ready for
operation.
6. Speak or sing into the microphone at a normal performance level and
raise the input level on the audio device until the desired level is
reached. For best signal-to-noise operation, set the input Gain control
as high as possible without overloading.
7. If you hear distortion turn down the input level on the audio device.
If distortion is still audible, use the supplied screwdriver to turn the
Gain control in the HXD1 transmitter slowly counterclockwise until the
distortion disappears.
Conversely, if you hear a weak, noisy signal at the desired volume
level and with the wireless level control of the audio device is set to
maximum, use the screwdriver to turn the Gain control in the HXD1
transmitter slowly clockwise until the signal reaches an acceptable
level.
Quick Start

8
Computer Setup
Windows
1. The first time you plug the
XPD2 into a USB port,
Windows will install the USB
driver for that port.
2. To set the XPD2 as your default
input/recording device, or
to change its settings, open
the Control Panel, Hardware
& Sound settings, then click
SOUND. Under Recording
tab, select the “Samson RXD
Wireless Receiver” from the list
of devices and press the Set
Default button to set it as the default audio input device.
3. To set the gain of the microphone, click the Properties button, and
then select the Levels tab. Slide the control until the desired level is
reached.
Apple MAC OSX
1. Plug the RXD2 receiver into an available USB port.
2. Select the XPD2 as the computer’s audio input, open System
Preferences from the dock or the main Apple Menu.
3. Next, open the Sound preferences, choose the Input tab and select
“Samson RXD Wireless Receiver”. To set the gain of the microphone,
adjust the Input volume slider at the bottom of the Sound dialog box.
The Input Level meter will show the recording level.

XPD2 USB Digital Wireless System 9
Connecting to a Line Input
The XPD2 wireless system can work
with any audio gear that accepts a
line input like a mixer or portable PA
system. Follow these steps to connect
your XPD2 system using the analog
output:
1. Plug the RXD2 receiver into a
standard 5 Volt USB adapter
and plug the adapter into an
available AC outlet.
2. Turn the volume on the input
channel that you are connecting
to the XPD2 system all the way
down.
3. Using a 1/8” (3.5mm) cable, connect the RXD1 LINE / Headphone
output to the line input on the audio device.
4. Turn on the power to the transmitter by pressing and holding Power
switch; the indicator LED will light amber.
5. Speak or sing into the microphone at a normal performance level and
raise the input level control on the input channel until the desired
level is reached.

10
The RXD2 receiver can be used with a smartphone to add a
wireless microphone to your live streams or mobile filmmaking.
To use the XDP2 system with an iPhone or iPad, you will
need to use the Apple Lightning to USB Camera Adapter (not
included).
To use the XPD2 system with an Android device, you will need
to use a Host OTG adapter.
You can connect headphones to the 1/8” (3.5mm) Headphone
output to monitor the wireless signal.
Connecting to a smartphone
