Samsung AX90A7080WD User manual

Air Purier
User manual
AX90A7080WD
ꞏ Thank you for purchasing this Samsung air purier.
ꞏ Before operating this unit, please read this user manual carefully and retain it for future reference.
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 1DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 1 2021-06-03 오전 9:24:292021-06-03 오전 9:24:29

2English
Safety Information 3
Safety Information 3
Package Content 9
Accessories / Product specications 9
At a Glance 10
General 10
Display and buttons 11
Removing the lters 12
Assembling the lters 13
Operation Features 16
Turning the power on/off / Controlling the fan speed 16
Sleep mode / Timed on/off function / Display lighting 17
Turning the Wi-Fi feature on/off / Clearing the lter replacement reminder / Lock function 18
Checking the air quality 19
Cleaning and Maintenance 21
Cleaning the air purier exterior 21
Cleaning and drying the lters 22
SmartThings app 23
SmartThings app 23
Appendix 28
Before Requesting Service 28
Contents
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of
their working life. To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government ofce, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 2DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 2 2021-06-03 오전 9:24:292021-06-03 오전 9:24:29

3
English
Safety Information
These safety precautions are for owner’s safety and preventions of property
damage.
Therefore, please read this manual thoroughly before using your product.
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Only connect to a socket that can provide the rated power supply. Do not use the
socket with other products. Do not extend the power cord.
• Using a multi-socket with other products or extending the power cord may cause
electric shock or fire.
• Using a voltage converter may cause electric shock or fire.
• Failing to meet the exact voltage, frequency and/or rated current may cause electric
shock or fire.
Do not install the air purier near a heat source and inammable objects, or in
areas that are highly humid or dusty. Avoid exposure to oil, gas, direct sunlight and
water.
• Follow instructions to avoid electric shock or fire.
Safety Information
Safety Information
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 3DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 3 2021-06-03 오전 9:24:292021-06-03 오전 9:24:29

4English
Safety Information
Safety Information
CAUTION
When installing the product, make sure that the power plug can be easily removed
when needed.
• Follow instructions to avoid electric shock or fire due to electrical leakage.
Install the product on a solid at ground.
• Follow instructions to avoid excessive vibration, noise and operational issues thereof.
Keep a safe distance from surrounding objects.
• Clear space from each side: at least 60 cm and the front: at least 25 cm
• The space is necessary to ensure efficient air intake and proper purification.
• Make sure that the inlet and outlet are not covered.
Make sure that the power cord is not pressed underthe product.
• Follow instructions to avoid electric shock or fire.
FOR POWER SUPPLY
WARNING
Use a dry cloth to wipe the power plug and the contact area to keep them free
from dust, water and other undesirable substances.
• Follow instructions to avoid electric shock or fire.
Check the position of the powerplug when you connect it to a socket.
• Having the cord hanging from above the plug may damage the wires inside, which can
lead to electric shock or fire.
Please contact yourlocal Samsung Service Centre if the power plug or cord is
damaged.
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a hazard.
Make sure that the power plug is securely tted in the socket. Do not use it when
the plug or cord is damaged.
• Follow instructions to avoid electric shock or fire.
When you disconnect the power cord, pull it by the plug. Do not pull the cord itself.
• Follow instructions to avoid electric shock or fire.
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 4DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 4 2021-06-03 오전 9:24:292021-06-03 오전 9:24:29

5
English
Safety Information
Do not fold, pull out, twist or tie the power cord. Do not hang it over a metal object
or place a heavy object on it. Do not put the cord between objects or behind the air
purier.
• Follow instructions to avoid electric shock or fire.
CAUTION
Remove the power plug of your air purier when it is not used for a period of time
and during a thunderstorm.
• Follow instructions to avoid electric shock or fire.
Product installation must be handled by ofcial Samsung service personnel or
a certied local technician to avoid power cord or plug damage, which can be
dangerous.
Disconnect the air purier from the power source before cleaning or repairing.
FOR USING
WARNING
If the product is exposed to water, immediately disconnect it from the power
source and contact your local Samsung Service Centre.
• Follow instructions to avoid electric shock or fire.
If you notice a noise, burning smell or smoke from the product, immediately stop
using it and contact your local Samsung Service Centre.
• Follow instructions to avoid electric shock or fire.
In the event of a gas leak in proximity of the air purier, do not touch it or attempt
to unplug it. Immediately ventilate the room and contact your provider or a
certied technician for advice.
• Do not turn the ventilation fan on.
• A spark can cause an explosion or fire.
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 5DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 5 2021-06-03 오전 9:24:292021-06-03 오전 9:24:29

6English
Safety Information
Safety Information
Do not pull out the power plug while operating the air purier.
• This may cause a spark when reconnecting the plug, which can lead to an explosion or
fire.
Please contact yourlocal Samsung Service Centre when you require repair service.
• Follow instructions to avoid electric shock or fire.
Do not handle the power plug with wet hands.
• Follow instructions to avoid electric shock or fire.
Do not use force on the air purier or pull the unit away.
• Follow instructions to avoid fire, malfunction or injury.
Store the plastic package away from children or discard it according to the law.
• Follow instructions to protect children from a risk of suffocation.
Do not insert your nger or other objects into the air inlet or outlet.
• Take special care to protect children from injury.
Do not place an object near the air purier as children may use them to climb
onto the product.
• Follow instructions to avoid injury from a tip-over or fall.
If the power plug area has contacted water, completely dry it before using the air
purier again.
• Follow instructions to avoid electric shock or fire.
Do not insert a metal object and similar items inside the air purier.
• Follow instructions to avoid electric shock or injury.
Do not place a heavy object on the air purier.
• Follow instructions to avoid malfunction or noise.
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 6DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 6 2021-06-03 오전 9:24:292021-06-03 오전 9:24:29

7
English
Safety Information
If any of the electric components inside the air purier has contacted liquid or
water, disconnect the product from the power source and contact your local
Samsung Service Centre.
• Follow instructions to avoid electric shock or fire.
Do NOT attempt to repair or modify the product.
• Use only the standard rated fuse.
• Follow instructions to avoid electric shock, fire, malfunction or injury.
CAUTION
Keep your air purier at least 2 meters away from a TV or other audio/visual media.
• They can be affected by video or audio noise.
Operate the air purier with no obstacles in the vicinity.
• At least 60 cm from both sides of the product, at least 25 cm from the product inlet,
and at least 100 cm from the product outlet
• The product is designed to intake, purify, and discharge polluted air. If there is any
obstacle in the vicinity, the purification capacity may decrease.
Do not step on the product or place other objects on it (laundry, candles, burning
cigarettes, plates, medicine, metal items, air fresheners, etc.).
• Follow instructions to avoid electric shock, fire, malfunction or injury.
Do not tilt or ip the air purier while the power plug is connected to the socket.
• Follow instructions to avoid malfunction or fire.
Do not use bug repellent or other spray products on the air purier.
• They can be harmful and may cause electric shock, fire or malfunction.
Do not submerge the air purier.
• Follow instructions to avoid malfunction.
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 7DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 7 2021-06-03 오전 9:24:292021-06-03 오전 9:24:29

8English
Safety Information
Safety Information
Do not handle the product with wet hands.
• Follow instructions to avoid electric shock.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be supervised
to ensure that they do not playwith the appliance.
FOR CLEANING
WARNING
Do not apply water, benzene, thinner, alcohol, acetone or similar substances
directly on the product.
• Follow instructions to avoid product discolouration or deformation, electric shock or
fire.
Disconnect the product from the power source when cleaning. Wait for the fan to
completely stop before cleaning.
• Follow instructions to avoid electric shock or fire.
CAUTION
Be sure to disconnect the power plug from the socket before cleaning the product.
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 8DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 8 2021-06-03 오전 9:24:302021-06-03 오전 9:24:30

9
English
Package Content
Package Content
Accessories
2-in-1 lter 2 EA
(Deodorization Filter+ Dust
Collecting Filter)
Pre-lter 2 EA User manual 1 EA
Product specications
The product dimensions are based on the maximum dimensions. They may vary depending on the
measurement position.
The product design and specications are subject to change without prior notice for quality
improvement.
Model name Dimensions
(width × height × depth) Area coverage
AX90A7080WD 360 mm x 1054 mm x 284 mm 90 m² ¹⁾
¹⁾ The area coverage value is in accordance with the Korea Air Cleaning Association (KACA) standard.
Package Content
DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 9DB68-11214A-00_IB_ACR AX7500A_SP_EN_.indd 9 2021-06-03 오전 9:24:302021-06-03 오전 9:24:30

10 English
At a Glance
General
10
11
05
01
02
06
07
09
08
03
12
04
At a Glance
01 Air outlet (top)
02 Display and buttons
03 Display lighting
04 Filter holder
05 Air inlet / Front panel
06 Laser PM sensor
07 Gas sensor
08 Dongle mount
• This model is provided with integrated
Wi-Fi connectivity and does not require
an external dongle to use this function.
09 Handle (rear side)
10 Air outlet (side)
11 2-in-1 lter(Deodorization Filter+Dust
Collecting Filter)
12 Pre-lter
