Samsung AC TN4PKG Series User manual

Air conditioner
User manual
AC***TN4PKG
•Thank you for purchasing this Samsung air conditioner.
•Before operating this unit, please read this user manual carefully and retain it for future
reference.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 1 2019-07-25 오후 3:06:38

2English
Safety Information 3
Safety Information 3
At a Glance 10
Indoor Unit Overview 10
Operation Features 11
Operating temperature and humidity
Cleaning and Maintenance 12
Cleaning and Maintaining 12
Cleaning the indoor unit exterior • Disassembling the air filter •
Cleaning the air filter • Reassembling the air filter • Periodical maintenance •
Troubleshooting • Technical specifications
Contents
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product and its electronic accessories should not be mixed with other commercial wastes for disposal.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 2 2019-07-25 오후 3:06:38

3English
Safety Information
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the extensive
features and functions of your new appliance.
Because the following operating instructions cover various models, the
characteristics of your air conditioner may differ slightly from those
described in this manual. If you have any questions, call your nearest
contact centre or find help and information online at www.samsung.com.
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut-off the power supply.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Use the power line with the power specifications of the product or
higher and use the power line for this appliance only. In addition, do not
use an extension line.
• Extending the power line may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric shock or fire.
• If the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualified
technician or service company.
• Failing to do so may result in electric shock, fire, explosion, problems with
the product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
Safety Information
Safety Information
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 3 2019-07-25 오후 3:06:38

4English
Safety InformationSafety Information
Safety Information
Fix the outdoor unit firmly so that the electric part of the outdoor unit
is not exposed.
• Failing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inflammable material. Do
not install this appliance in a humid, oily or dusty location, in a location
exposed to direct sunlight and water (rain drops). Do not install this
appliance in a location where gas may leak.
• This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external
wall where it could fall.
• If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance
to a gas pipe, plastic water pipe, or telephone line.
• Failure to do so may result in electric shock, fire, an explosion, or other
problems with the product.
• Never plug the power cord into a socket that is not grounded correctly
and make sure that it is in accordance with local and national codes.
CAUTION
Install your appliance on a level and hard floor that can support its weight.
• Failing to do so may result in abnormal vibrations, noise, or problems
with the product.
Install the drain hose properly so that water is drained correctly.
• Failing to do so may result in water overflowing and property damage.
Avoid adding drain to waste pipes as odours may arise in the future.
The product shall be stored in a room with no ignition sources
(e.g. open flames, gas appliance, electric heater, etc.).
• Note that the refrigerant has no odour.
When installing the outdoor unit, make sure to connect the drain hose
so that draining is performed correctly.
• The water generated during the heating operation in the outdoor unit
may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death
or property damage.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 4 2019-07-25 오후 3:06:39

5English
Safety Information
Do not install the product in a place where thermo-hygrostat is needed
(such as server room, machinery room, computer room, etc.)
• Those places do not provide guaranteed operation condition of the
product therefore performance can be poor in these places.
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service centre.
Do not pull or excessively bend the power line. Do not twist or tie the
power line. Do not hook the power line over a metal object, place a
heavy object on the power line, insert the power line between objects,
or push the power line into the space behind the appliance.
• This may result in electric shock or fire.
CAUTION
When not using the air conditioner for a long period of time or during a
thunder/lightning storm, cut the power at the circuit breaker.
• Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, unplug
the power plug immediately and contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
In case of a malfunction, immediately stop operation of the air
conditioner and disconnect the entire power system. Then consult the
authorized service personnel.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate
immediately without touching the power line. Do not touch the
appliance or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 5 2019-07-25 오후 3:06:39

6English
Safety InformationSafety Information
Safety Information
To reinstall the air conditioner, please contact your nearest service centre.
• Failing to do so may result in problems with the product, water leakage,
electric shock, or fire.
• A delivery service for the product is not provided. If you reinstall the
product in another location, additional construction expenses and an
installation fee will be charged.
• Especially, when you wish to install the product in an unusual location
such as in an industrial area or near the seaside where it is exposed to
salt in the air, please contact your nearest service centre.
Do not touch the circuit breaker with wet hands.
• This may result in electric shock.
Do not turn the air conditioner off with the circuit breaker while it is operating.
• Turning the air conditioner off and then on again with the circuit breaker
may cause a spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well
out of the reach of children, as packaging materials can be dangerous to
children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the front panel with your hands or fingers during the
heating operation.
• This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the outlet when
the air conditioner is operating or the front panel is closing.
• Take special care that children do not injure themselves by inserting their
fingers into the product.
Do not insert your fingers or foreign substances into the air inlet/outlet
of the air conditioner.
• Take special care that children do not injure themselves by inserting their
fingers into the product.
Do not strike or pull the air conditioner with excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to
climb onto the machine.
• This may result in children seriously injuring themselves.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 6 2019-07-25 오후 3:06:39

7English
Safety Information
Do not use this air conditioner for long periods of time in badly
ventilated locations or near infirm people.
• Since this may be dangerous due to a lack of oxygen, open a window at
least once an hour.
Do not use means to accelerate the defrost operation or to clean, other
than those recommended by Samsung.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
If any foreign substance such as water has entered the appliance, cut
the power by unplugging the power plug and turning the circuit breaker
off and then contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use any fuse (such as copper, steel wire, etc.)other than the
standard fuse.
• Failing to do so may result in electric shock, fire, problems with the
product, or injury.
CAUTION
Do not place objects or devices under the indoor unit.
• Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at
least once a year.
• Failing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and
current is measured according to ISO standard for energy efficiency.
When the air conditioner does not operate properly for cooling or
heating, there is a possibility of refrigerant leakage. If any leakage, stop
operation, ventilate the room, and consult your dealer immediately for
recharging refrigerant.
The refrigerant is not harmful. However, if it comes in contact with fire,
it may generate harmful gases and there is risk of fire.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 7 2019-07-25 오후 3:06:40

8English
Safety InformationSafety Information
Safety Information
During transportation of the indoor unit, the pipe lines shall be covered
with brackets for protection. Do not move the product with holding the
pipe lines.
• It may cause gas leakage.
Do not install the product in a ship or a vehicle (such as a campervan).
• Salt, vibration or other environmental factor may cause the product
malfunction, electric shock or fire.
Do not stand on top of the appliance or place objects (such as laundry,
lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.)
on the appliance.
• This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
• As well as being harmful to humans, it may also result in electric shock,
fire or problems with the product.
Do not drink the water from the air conditioner.
• The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not
disassemble the remote controller.
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not cut or burn the refrigerant container or pipings.
Do not point the air direction to the fireplace or heater.
Do not use this air conditioner to preserve precision equipment, food,
animals, plants or cosmetics, or for any other unusual purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the air flow from
the air conditioner for long periods of time.
• This may result in harm to humans, animals or plants.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 8 2019-07-25 오후 3:06:40

9English
Safety Information
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
For use in Europe: This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not
use benzene, thinner, alcohol or acetone to clean the appliance.
• This may result in discoloration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, unplug the air conditioner
from the wall socket and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Take care when cleaning the surface of the heat exchanger of the
outdoor unit since it has sharp edges.
• To avoid cutting your fingers, wear thick cotton gloves when cleaning it.
• This should be done by a qualified technician please contact your installer
or service centre.
Do not clean the inside of the air conditioner by yourself.
• For cleaning inside the appliance, contact your nearest service centre.
• When cleaning the internal filter, refer to the descriptions in the ‘Cleaning
and Maintaining’ section.
• Failure to do may result in damage, electric shock or fire.
• Make sure to prevent any injury from sharp edges of the surface when
handling the heat exchanger.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 9 2019-07-25 오후 3:06:40

10 English
Indoor Unit Overview
At a Glance
Indoor Unit Overview
At a Glance
01 Display
Operation status Indication on the
display
Power on Ice blue (blinking)
In operation Ice blue
Stopped Off
Timed on/off
function Blue
Requires filter
cleaning Yellow green
Defrost function Ice blue (blinking once
every 10 seconds)
Wide
Mid
Spot
Swing
NOTE
• For the AR-KH00E wireless remote control,
the air flow direction indications appear on
its display, too.
• By using the AR-KH00E wireless remote
control, you can turn on or turn off the air
flow direction indications that appear on
the indoor unit display.
• For the MR-EH00 wireless remote control,
which is designed generally for any indoor
units, the air flow direction is not shown
on the remote control display. Control the
air flow direction with checking it on the
indoor unit display.
02 Remote control sensor (behind the front
grille)
03 Air outlet
04 Front grille /
Air filter (behind the front grille)
NOTE
• For information on how to operate the
product, see the user manual for the
remote control.
• The actual appearances of the indoor units
and their displays may differ slightly from
the images depicted above.
• By using the AR-KH00E wireless remote
control, which is designed specifically
for the 360 cassette indoor units, you
can operate them more conveniently.
In addition, because you can check the
operation status of each indoor unit on
the remote control, you can use the indoor
units more effectively.
02
03
01
04
Circular panel
Square panel
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 10 2019-07-25 오후 3:06:41

11English
At a Glance
Operating temperature and humidity
Mode Outdoor temperature Indoor temperature Indoor humidity
Cool mode -15°C to 50°C 18°C to 32°C 80% or less
Heat mode -20°C to 24°C 30°C or less -
Dry mode -15°C to 50°C 18°C to 32°C 80% or less
CAUTION
• If you use the air conditioner at a relative humidity above 80%, it may cause a formation of
condensation and a leakage of water on the floor.
• The rated heating capacity is based on an outdoor temperature of 7°C. If the outdoor
temperature goes down below 0°C, heating efficiencies may decrease depending on the
temperature conditions.
• If the indoor unit is out of the operating temperature and humidity range, the safery device
may operate and the air conditioner may stops.
Operation Features
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 11 2019-07-25 오후 3:06:41

12 English
Cleaning and Maintaining
Cleaning and Maintenance
Cleaning and Maintaining
Cleaning and Maintenance
Cleaning the indoor unit exterior
Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe off dirt from
odd-shaped areas by using a soft brush.
CAUTION
• Do not use alkaline detergent, sulphuric acid, hydrochloric acid, or organic solvents (such as
thinner, kerosene, and acetone) to clean the surfaces.
• Do not put any stickers on it as this can damage the surface of the indoor unit.
Disassembling the air filter
CAUTION
• For cleaning and maintenance, be sure to turn off the circuit breaker.
NOTE
• When the next filter-cleaning time arrives (after 1000 hours of operation), the indoor unit
display appears in yellow green.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 12 2019-07-25 오후 3:06:42

13English
Cleaning and Maintenance
Cleaning the air filter
NOTE
• Clean the air filter once every two weeks.
• Spray water or use a vacuum cleaner to remove dust.
• After removing dust, dry the air filter completely.
– Avoid direct sunlight. Failure to do so may deform the air filter.
Reassembling the air filter
After cleaning and reassembling the air filter, reset the filter-cleaning reminder as follows:
• AR-KH00E remote control: > Select Filter Reset.
• MR-EH00 remote control: Hold down the Filter Reset button for two seconds.
NOTE
• If you try to assemble the air filter upside down, it will not be assembled because it cannot
be clamped by the internal structure.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 13 2019-07-25 오후 3:06:43

14 English
Cleaning and Maintaining
Cleaning and Maintenance
Periodical maintenance
Unit Maintenance item Interval Requires qualified
technicians
Indoor
unit
Clean the air filter. At least once a month
Clean the condensate drain pan. Once a year Required
Clean up the heat exchange. Once a year Required
Clean the condensate drain pipe. Once every 4 months Required
Replace the remote control
batteries. At least once a year
Outdoor
unit
Clean the heat exchanger on the
outside of the unit. Once every 4 months Required
Clean the heat exchanger on the
inside of the unit. Once a year Required
Clean the electric components with
jets of air. Once a year Required
Verify that all the electric
components are firmly tightened. Once a year Required
Clean the fan. Once a year Required
Verify that the fan assemblies are
firmly tightened. Once a year Required
Clean the condensate drain pan. Once a year Required
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 14 2019-07-25 오후 3:06:43

15English
Cleaning and Maintenance
Troubleshooting
Refer to the following chart if the air conditioner operates abnormally. This may save time and
unnecessary expense.
Problem Solutionz
The air conditioner
does not operate
at all.
• Check if the power plug is properly connected.
• Check whether the auxiliary power switch (MCCB, ELB) is turned on.
• If the auxiliary power switch (MCCB, ELB) is turned off, the air
conditioner does not work although you press the (Power)
button.
• When you clean the air conditioner or do not use it for an extended
period of time, turn off the auxiliary power switch (MCCB, ELB).
• After the air conditioner is not used for an extended period of time,
be sure to turn on the auxiliary power switch (MCCB, ELB) 6 hours
before starting operation.
NOTE
• The auxiliary power switch (MCCB, ELB) is sold separately.
• Make sure that auxiliary power switch (MCCB, ELB) is installed
in the distribution box inside the building.
• If the air conditioner is turned off by the Timed off function, turn on
the air conditioner again by pressing the (Power) button.
The temperature
does not change.
• Check whether the Fan mode is running. In the Fan mode, the air
conditioner controls the set temperature automatically, and you
cannot change the set temperature.
Warm air does not
come out of the air
conditioner.
• Check whether the outdoor unit is designed for cooling only. In
this case, warm air does not come out although you select the Heat
mode.
• Check whether the remote control is designed only for cooling only.
Use a remote control that supports both cooling and heating.
The fan speed does
not change.
• Check whether the Auto or Dry mode is running. In these modes, the
air conditioner controls the fan speed automatically, and you cannot
change the fan speed.
The wireless
remote control
does not operate.
• Check whether the batteries are discharged. Replace the batteries
with new ones.
• Make sure that nothing is blocking the remote control sensor.
• Check whether any strong lighting sources are near the air
conditioner. Strong light which comes from fluorescent bulbs or
neon signs may interfere with the remote control.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 15 2019-07-25 오후 3:06:43

16 English
Cleaning and Maintaining
Cleaning and Maintenance
Problem Solutionz
The wired remote
control does not
operate.
• Check whether the indicator is displayed at the bottom right
of the remote control display. In this case, turn off both the air
conditioner and the auxiliary power switch, and then contact a
service centre.
The air conditioner
is not turned on or
off immediately
with the wired
remote control.
• Check whether the wired remote control is set for group control. In
this case, the air conditioners connected to the wired remote control
are turned on or off sequentially. This operation takes up to 32
seconds.
The Timed on/off
function does not
operate.
• Check whether you pressed the (SET) button on the remote
control after setting the on/off time. Set the on/off time.
The indoor unit
display blinks
continuously.
• Turn on the air conditioner again by pressing the (Power)
button.
• Turn off and then turn on the auxiliary power switch, and then turn
on the conditioner.
• If the indoor unit display is still blinking, contact a service centre.
I want to get
cooler air.
• Operate the air conditioner with a electric fan to save energy and
enhance the cooling efficiency.
The air is not cool
or warm enough.
• In the Cool mode, cool air does not come out if the set temperature
is higher than the current temperature.
– MR-EH00 remote control: Press the Temperature button
repeatedly until the set temperature (minimum: 18°C) is set to
lower than the current temperature.
– AR-KH00E remote control: Press the Temperature button on the
remote control. Then rotate the Wheel until the set temperature
(minimum: 18°C) is set to lower than the current temperature.
• In the Heat mode, warm air does not come out if the set temperature
is lower than the current temperature.
– MR-EH00 remote control: Press the Temperature button
repeatedly until the set temperature (maximum: 30°C) is set to
higher than the current temperature.
– AR-KH00E remote control: Press the Temperature button on the
remote control. Then rotate the Wheel until the set temperature
(maximum: 30°C) is set to higher than the current temperature.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 16 2019-07-25 오후 3:06:43

17English
Cleaning and Maintenance
Problem Solutionz
The air is not cool
or warm enough.
• Both cooling and heating do not operate in the Fan mode. Select the
Cool, Heat, Auto, or Dry mode.
• Check whether the air filter is blocked with dirt. A dusty filter may
decrease the cooling and heating efficiencies. Clean the air filter
frequently.
• If a cover is on the outdoor unit or any obstacle is present near the
outdoor unit, remove them.
• Install the outdoor unit in a well-ventilated place. Avoiding places
exposed to direct sunlight or close to a heating appliance.
• Place a sunscreen over the outdoor unit to protect it from direct
sunlight.
• If the indoor unit is installed in a place exposed to direct sunlight,
pull the curtains on the windows.
• Close the windows and doors to maximize the cooling and heating
efficiencies.
• If the Cool mode is stopped and then started immediately, cool air
comes out after about 3 minutes to protect the compressor of the
outdoor unit.
• When the Heat mode is started, warm air does not come out
immediately to prevent cool air from coming out at the beginning.
• If the refrigerant pipe is too long, the cooling and heating
efficiencies may be decreased. Avoid exceeding the maximum pipe
length.
The air conditioner
makes strange
noises.
• In certain conditions (especially, when the outdoor temperature is
lower than 20°C), a hissing, rumbling, or splashing sound may be
heard while the refrigerant is circulating through the air conditioner.
This is a normal operation.
• When you press the (Power) button on the remote control, noise
may be heard from the drain pump inside the air conditioner. This
noise is a normal sound.
Unpleasant odours
permeate the
room.
• If the air conditioner is running in a smoky area or if there is a smell
entering from outside, ventilate the room properly.
• If both indoor temperature and indoor humidity are high, operate
the air conditioner in the Clean or Fan mode for 1 to 2 hours.
• If the air conditioner has not been operated for an extended period
of time, clean the indoor unit and then operate the air conditioner
in the Fan mode for 3 to 4 hours to dry the inside of the indoor unit
for removal of unpleasant odours.
• If the air filter blocked with dirt, clean the air filter.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 17 2019-07-25 오후 3:06:43

18 English
Cleaning and Maintaining
Cleaning and Maintenance
Problem Solutionz
Steam is produced
on the indoor unit.
• In winter, if the indoor humidity is high, steam may be produced
around the air outlet while the defrost function is running. This is a
normal operation.
The outdoor unit
fan continues to
operate when the
air conditioner is
turned off.
• When the air conditioner is turned off, the outdoor unit fan may
continue to operate to reduce noise of the refrigerant gas. This is a
normal operation.
Water drops
from the piping
connections of the
outdoor unit.
• Condensation may develop due to the difference in temperature.
This is a normal condition.
Steam is produced
on the outdoor
unit.
• In winter, when the air conditioner runs in the Heat mode, the frost
on the heat exchanger melts and steam may be produced. This is a
normal operation, neither product malfunction nor a fire.
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 18 2019-07-25 오후 3:06:43

19English
Cleaning and Maintenance
Memo
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 19 2019-07-25 오후 3:06:43

COUNTRY CALL OR VISIT US ONLINE AT
AUSTRALIA 1300 362 603 (Other) www.samsung.com/au/support
QUESTIONS OR COMMENTS?
This appliance is filled with R-32. DB68-08493A-00
CAC_R32_호주향 무풍 360 IB_DB68-08493A-00.indb 20 2019-07-25 오후 3:06:44
