Samsung AM AN4PKH Series User manual

Airconditioner
Installationmanual
AM***AN4PKH
• Thank you forpurchasing this Samsung airconditioner.
• Before operating this unit, please read this manual carefullyand retain it forfuture reference.
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGX YWYXTWXTY`GGG㝘䟸GZaZ`a\\

2English
Contents
SafetyInformation 3
SafetyInformation 3
InstallationProcedure 5
Installation Procedure 5
Step1 Checking and preparing accessories 5
Step 2 Choosing the installation location 5
Step 3 Optional: Insulating the bodyof the indoorunit 7
Step 4 Installing the indoorunit 8
Step 5 Purging inert gas fromthe indoorunit 9
Step 6 Cutting and flaringthe pipes 9
Step 7 Connecting the assemblypipes to the refrigerant pipes 10
Step 8 Performing the gas leak test 11
Step 9 Insulating the refrigerant pipes 11
Step10 Installing the drain hose and drain pipe 12
Step11 Performing the drainage test 14
Step12 Connecting the powerand communication cables 15
Step13 Optional: Extending the powercable 18
Step14 Setting the indoorunit addresses and the installation options 20
Appendix 37
Troubleshooting 37
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGY YWYXTWXTY`GGG㝘䟸GZaZ`a\\

3
English
SafetyInformation
WARNING
• Hazards orunsafe practices that mayresult in severe
personal injuryordeath.
CAUTION
• Hazards orunsafe practices that mayresult in minor
personal injuryorpropertydamage.
• Carefully followthe precautions listed belowbecause
theyare essential to guaranteethe safety of the
equipment.
WARNING
• Always disconnect the airconditionerfrom the power
supplybefore servicing it oraccessing its internal
components.
• Verifythat installation and testing operations are
performed byqualified personnel.
• Verifythat the airconditioneris not installed in an
easilyaccessible area.
Generalinformation
WARNING
• Carefully read the content of this manual before installing
the airconditionerand store the manual in a safe place in
orderto be ableto use it as reference afterinstallation.
• Formaximum safety, installers should always carefullyread
the followingwarnings.
• Store the operation and installation manual in a safe
location and rememberto hand it overto the newownerif
the airconditioneris sold ortransferred.
• This manual explains howto install an indoorunitwith a
split systemwith two SAMSUNG units. The use of other
types of unitswith different control systems maydamage
the units and invalidate thewarranty. The manufacturer
shall not be responsible fordamages arising from the use of
non compliant units.
• The manufacturershall not be responsible fordamage
originating from unauthorized changes orthe improper
connection of electric and requirements set forth in the
“Operating limits” table, included in the manual, shall
immediatelyinvalidate the warranty.
• The airconditionershould be used onlyforthe applications
forwhich it has been designed: the indoorunit is not
suitable to be installed in areas used forlaundry.
• Do not use the units if damaged. If problems occur, switch
the unit off and disconnect it from the powersupply.
• In orderto prevent electric shocks, fires orinjuries, always
stop the unit, disablethe protection switch and contact
SAMSUNG’s technical support if the unit produces smoke, if
the powercable is hot ordamaged orif the unit isvery noisy.
• Always rememberto inspect the unit, electric connections,
refrigerant tubes and protections regularly. These
operations should be performed byqualified personnel only.
• The unit contains moving parts,which should always be
kept out of the reach of children.
• Do not attemptto repair, move, alterorreinstall the unit. If
performed byunauthorized personnel, these operations may
cause electric shocks orfires.
• Do not place containerswith liquids orotherobjects on the
unit.
• All the materials usedforthe manufacture and packaging of
the airconditionerare recyclable.
• The packing material and exhaust batteries of the remote
controller(optional) must be disposed of in accordancewith
current laws.
• The airconditionercontains a refrigerant that has to be
disposed of as specialwaste.At the end of its life cycle, the
airconditionermust be disposed of in authorised centres
orreturned to the retailerso that it can be disposed of
correctly and safely.
Installingtheunit
WARNING
IMPORTANT:Wheninstallingthe unit,alwaysremember
toconnectfirsttherefrigeranttubes,thenthe electrical
lines.
• Always disassemble the electric lines before the refrigerant
tubes.
• Upon receipt, inspectthe product toverify that it has not
been damaged during transport. If the product appears
damaged, DO NOTINSTALL it and immediatelyreport
the damage tothe carrierorretailer(if the installerorthe
authorized technician has collected the material from the
retailer.)
SafetyInformation
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGZ YWYXTWXTY`GGG㝘䟸GZaZ`a\\

4
SafetyInformation
English
SafetyInformation
• Aftercompleting the installation, always carryout a
functional test and provide the instructions on howto
operatethe airconditionerto the user.
• Do not use the airconditionerin environmentswith
hazardous substances orclose to equipment that release
freeflames to avoid the occurrence of fires, explosions or
injuries.
• Ourunits should be installed in compliancewith the spaces
shown in the installation manual,to ensure accessibility
from both sides and allowrepairs ormaintenance
operations to be carried out. The unit’s components should
be accessible and easyto disassemble without endangering
people and objects.
Forthis reason,when provisions of the installation manual
are not compliedwith, the cost required to access and repair
the units (in SAFETY CONDITIONS, as set out in prevailing
regulations)with harnesses, ladders, scaffolding orany
otherelevation systemwill NOTbe considered part of the
warrantyand will be charged tothe end customer.
Powersupplyline,fuseorcircuit
breaker
WARNING
• Always make sure that the powersupplyis compliant with
current safetystandards. Always install the airconditionerin
compliancewith current local safetystandards.
• Always verify that a suitable grounding connection is
available.
• Verifythat the voltage and frequency of the powersupply
complywith the specifications and that the installed power
is sufficient to ensure the operation of anyotherdomestic
appliance connected tothe same electric lines.
• Alwaysverifythat the cut-off and protection switches are
suitablydimensioned.
• Verifythat the airconditioneris connected tothe power
supplyin accordance with the instructions provided in the
wiring diagram included in the manual.
• Alwaysverifythat electric connections (cable entry, section
of leads, protections…) are compliant withthe electric
specifications andwith the instructions provided in the
wiring scheme.Alwaysverifythat all connections comply
with the standards applicable tothe installation of air
conditioners.
• Devices disconnected from the powersupply should be
completely disconnected in the condition of overvoltage
category.
• Be sure notto perform powercable modification, extension
wiring, and multiplewire connection.
– It maycause electric shock orfire due to poorconnection,
poorinsulation, orcurrent limit override.
– When extensionwiring is required due to powerline
damage, referto Step13 Optional: Extendingthepower
cable in the installation manual.
CAUTION
Makesurethatyou earththe cables.
• Do not connect the earthwire to the gas pipe,waterpipe,
lighting rod ortelephonewire. If earthing is not complete,
electric shock orfire mayoccur.
Installthe circuitbreaker.
• If the circuit breakeris not installed, electric shock orfire
mayoccur.
Makesurethat thecondensedwaterdrippingfromthe
drainhose runsoutproperlyand safely.
Install thepowercableand communicationcable of
the indoorand outdoorunit at least1m awayfromthe
electricappliance.
Install theindoorunit awayfromlighting apparatus
usingthe ballast.
• If you use the wireless remote control, reception errormay
occurdue to the ballast of the lighting apparatus.
SafetyInformation
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGG[ YWYXTWXTY`GGG㝘䟸GZaZ`a\\

5
English
InstallationProcedure
InstallationProcedure
Step1 Checkingandpreparing
accessories
The following accessories are supplied with the indoor
unit. The type and quantitymay differ, depending on the
specifications.
Patternsheet(1) Drainhose(1)
Insulationpipe
(Liquidside1,gasside1) Insulationdrainhose(1)
Installationmanual(1) Usermanual (1)
Cable-tie(6) Clamp (1)
Dimensiongauge(1)
Step2 Choosingtheinstallation
location
Installationlocationrequirements
• There must be no obstacles nearthe airinlet and
outlet.
• Install the indoorunit on a ceilingthat can support its
weight.
• Maintain sufficient clearance around the indoorunit.
• Before installing the indoorunit, be sure to check
whetherthe chosen location iswell-drained.
• The indoorunit must be installed such that it is beyond
public access and is not touchable byusers.
• Rigidwallwithoutvibration.
• Where it is not exposed to direct sunshine.
• Wherethe airfiltercan be removed and cleaned easily.
Do notinstallthe airconditionerin following
places.
• Placewhere there is mineral oil orarsenic acid. Resin
parts flame and the accessories may drop orwater
mayleak. The capacityof the heat exchangermay
reduce orthe airconditionermaybe out of order.
• The placewhere corrosive gas such as sulphuric acid
gas generatesfrom thevent pipe orairoutlet.
• The copperpipe orconnection pipe maycorrode and
refrigerant may leak.
• The placewhere there is a machine that generates
electromagneticwaves. The airconditionermay not
operate normally due to control system.
• The placewhere there is a dangerof existing
combustible gas, carbonfibre orflammable dust.
• The placewhere thinnerorgasoline is handled. Gas
mayleak and it maycause fire.
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGG\ YWYXTWXTY`GGG㝘䟸GZaZ`a\]

6
InstallationProcedure
English
InstallationProcedure
(Unit: mm)
950
840
240
55 60
330 237
302
950
890~910 (Celling opening)
The sub duct hole is not applicable totheWind-Free models.
890~910 (Celling opening)
735 (Space of suspension bolts)
735 (Space of suspension bolts)
55
41
71
133
186
C
370
185
92
120
A
166
B
351
101
Model AM028AN4PKH* AM036AN4PKH* AM045AN4PKH* AM056AN4PKH* AM071AN4PKH* AM090AN4PKH* AM112AN4PKH* AM128AN4PKH* AM140AN4PKH*
Chassis Small Medium Large
Amm 215 238 238
Bmm 105 127 127
Cmm 196 222 222
Net
dimension
(W×D×H) mm 840X840X204 840X840X204 840X840X 204 840 X 840X204 840X840X204 840X840X246 840X840X288
Netweight kg 15.0 15.0 15.0 16.5 16.5 18.0 18.0 21.5 21.5
Liquidpipe
connection mm 6.35 6.35 6.35 6.35 9.52 9.52 9.52 9.52 9.52
Gaspipe
connection mm 12.7 12.7 12.7 12.7 15.88 15.88 15.88 15.88 15.88
Drainhose
connection mm outerdiameter: 32, innerdiameter: 26.5
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGG] YWYXTWXTY`GGG㝘䟸GZaZ`a\]

7
English
InstallationProcedure
Spacingrequirements
2500 mm ormore
Obstruction
1500 mm ormore
17 mm
20 mm
A
(Unit: mm)
Model
AM028AN4PKH
AM036AN4PKH
AM045AN4PKH
AM056AN4PKH
AM071AN4PKH
AM090AN4PKH
AM112AN4PKH AM128AN4PKH AM140AN4PKH
A251 293 335
CC
C
C
(Unit: mm)
C:1500 mm ormore
CAUTION
• The indoorunit must be installed accordingto the
specified distances in orderto permit accessibility
from each side, to guarantee correct operationfssss,
maintenance, and repairof the unit. The components
of the indoorunit must be reachable and removable
undersafe conditions forpeople and the unit.
• Do not holdthe dischargewhile carrying the indoor
unit to avoid the possibility of breakage.
• You must hold the hangerplate on the cornerand
carrythe indoorunit.
Step3 Optional:Insulatingthebody
oftheindoorunit
Ifyouinstall acassettetype indooruniton theceilingwhen
temperature isover27°C andhumidityis over80%,you
mustapplyan extra10 mmthick polyethyleneinsulation ora
similartypeof insulationtothe bodyoftheindoorunit.
Cut away the partwhere pipes are pulled outforthe
insulatingwork.
D
A
E
B
C
Insulate the end ofthe pipe and some curved area by
using separate insulator.
NOTE
• A: Reference forthe outercircumference of the unit
(When insulating the bodyof the indoorunit, use Aas
the reference forits outercircumference.)
(Unit: mm)
Indoorunit A B C D E
4wayCassette <S>
(840x204x840)
AM028AN4PKH
910X151 940X151 610X151 650X151 870X870
AM036AN4PKH
AM045AN4PKH
AM056AN4PKH
AM071AN4PKH
4wayCassette <M>
(840x246x840) AM090AN4PKH
910X193 940X193 610X193 650X193 870X870
AM112AN4PKH
4wayCassette <L>
(840x288x840) AM128AN4PKH
910X235 940X235 610X235 650X235 870X870
AM140AN4PKH
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGG^ YWYXTWXTY`GGG㝘䟸GZaZ`a\_

8
InstallationProcedure
English
InstallationProcedure
Step4 Installingtheindoorunit
When deciding on the location of the airconditionerthe
following restrictions must be taken into account.
1 Place the pattern sheet onthe ceiling at the spot
whereyouwant to install the indoorunit.
NOTE
• Since the diagram is made of paper, it mayshrink
orstretch slightlydue to temperature orhumidity.
Forthis reason, before drilling the holes, be sure
to maintain the correct dimensions between the
markings.
2 Insert bolt anchors, use existing ceiling supports or
construct a suitable support as shown in figure.
Concrete
Suspension bolt (M8) - field supply
Hole in anchor
Hole in plug Insert
3 Install the suspension bolts, depending on the ceiling
type.
Ceiling support
CAUTION
• Make sure that the ceiling is strong enough to support
theweight of the indoorunit. Before hanging the unit,
test the strength of each attached suspension bolt.
• If the length ofthe suspension bolt is more than1.5 m,
you are required to preventvibration.
4 Screweight pairs of nuts and washers to the
suspension bolts, making space forhanging the indoor
unit.
CAUTION
• You must install all of the suspension rods.
• It is important to leave sufficient space in thefalse
ceiling to allow access formaintenance orrepairs to
the drainage pipe connection,the refrigerant pipe
connection, orto remove the unit if necessary.
5 Hang the indoorunit to the suspension bolts between
two nuts. Cut a pad stopperand place it on the
suspension bolts to hold thewasher. Remove the
stopperand screwthe nuts to fix the unit.
2
2
1
6 Check the level of the indoorunit byusing a leveler.
• Atilt of the indoorunit maycause malfunction of a
built-in float switch andwaterleaks.
Level
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGG_ YWYXTWXTY`GGG㝘䟸GZaZ`a\`

9
English
InstallationProcedure
7 Adjust the unitto the appropriate position, taking into
account the installation area forthe front panel.
• Place the pattern sheet onthe indoorunit.
• Adjust the space between the ceiling and the
indoorunit by using a dimension gauge.
• Fix the indoorunit securelyafteradjusting the level
of the unit byusing a leveller.
• Removethe pattern sheet, connect the other
cables. and installthe front panel.
20 mm
Indoorunit Ceiling
17 mm
Gauge of dimensions
Step5 Purginginertgasfromthe
indoorunit
The indoorunit comes with nitrogen gas (inert gas)
charged atthe factory. Therefore, all inert gas must be
purged before connecting the assembly piping.
Unscrewthe pinchpipeattheend ofeach refrigerant pipe.
Insulator Liquid side
Gas side
NOTE
• To prevent dirt orforeign objects from getting into the
pipes during installation, do not remove the pinch pipe
completely untilyou are readyto connect the piping.
Step6 Cuttingandflaringthepipes
1 Make sure that you have the required tools available:
pipe cutter, reamer, flaring tool, and pipe holder.
2 Ifyou wishto shorten the pipes, cut themwith a pipe
cutter, ensuring that the cut edge remains at a 90°
angle to the side of the pipe. Referto the illustrations
belowforexamples of edges cut correctly and
incorrectly.
Pipe cutter
Pipe
90°
Oblique Rough Burr
3 To prevent anygas from leaking out, remove all burrs
at the cut edge of the pipe, using a reamer.
4 Slide a flare nut on to the pipe and modifythe flare.
D
D
A
Flare
Pipe
90° ±2°
45° ±2°
R 0.4 to 0.8 mm
LFlare
OuterDiameter(D) Depth (A) Flaredimension(L)
Ø6.35 mm 1.3 mm 8.7 to 9.1 mm
Ø9.52 mm 1.8 mm 12.8 to13.2 mm
Ø12.70 mm 2.0 mm 16.2 to16.6 mm
Ø15.88 mm 2.2 mm 19.3 to19.7 mm
Ø19.05 mm 2.2 mm 23.6 to 24.0 mm
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGG` YWYXTWXTY`GGG㝘䟸GZaZ`a\`

10
InstallationProcedure
English
InstallationProcedure
5 Check that the flaring is correct, referring to the
illustrations belowforexamples of incorrectflaring.
Correct Inclined Damaged
Surface Cracked Uneven Thickness
Step7 Connectingtheassembly
pipestotherefrigerantpipes
Therearetworefrigerant pipesof different diameters:
• A smallerone forthe liquid refrigerant.
• A largerone forthe gas refrigerant. The inside of
copperpipe must be clean and has no dust.
1 Removethe pinch pipe on the pipes and connect the
assemblypipes to each pipe, tightening the nuts, first
manuallyand thenwith a torquewrench, a spanner
applying the following torque.
2
3
3
1
Torque
wrench
Flare nut
Union
Spanner
OuterDiameter(mm) Torque(N•m)
Ø6.35 14 to18
Ø9.52 34 to 42
Ø12.70 49to 61
Ø15.88 68 to 82
Ø19.05 100to120
(1 N•m=10 kgf•cm)
NOTE
• If the pipes must be shortened, see Step6 Cutting
andflaring thepipes on page 9.
2 Be sureto use an insulatorthick enough to coverthe
refrigerant tube to protect the condensate wateron
the outside of the pipe falling onto thefloorand to
improve the efficiencyof the unit.
3 Cut off anyexcessfoam insulation.
4 Make sure that there are no cracks orwaves on the
bent area.
5 Itwould be necessaryto double the insulation thickness
(10 mm ormore) to prevent condensation even on the
insulatorwhen if the installed area iswarm and humid.
6 Do not use joints orextensions forthe pipes
connecting the indoorand outdoorunits.
CAUTION
• Connect the indoorand outdoorunits using pipeswith
flared connections (not supplied). Forthe lines, use
insulated, unwelded, degreased and deoxidized copper
pipe (Cu DHP type to ISO1337 orUNI EN12735-1),
ϑЇϩɇɵʪ˙ͱθͱΧʪθɇϩ˝ΧθʪϑϑЇθʪϑͱ˙ɇϩʪɇϑϩߥࢋߣđťɇɇʒ
˙ͱθɇɵЇθϑϩΧθʪϑϑЇθʪͱ˙ɇϩʪɇϑϩߣߡࢋߨđťɇࢋAͱΧΧʪθΧΧʪ˙ͱθ
hydro-sanitaryapplications is completelyunsuitable.
• Forsizing and limits (height difference, line length,
max. bends, refrigerant charge, etc.) seethe outdoor
unit installation manual.
• Allrefrigerantconnectionmustbeaccessible,inorderto
permiteitherunit maintenanceorremovingitcompletely.
• If the pipes require brazing, make sure that oxygen
free nitrogen (OFN) isflowing throughthe system.
• Nitrogen blowing pressure range is 0.02to 0.05 MPa.
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGXW YWYXTWXTY`GGG㝘䟸GZaZ`a\`

11
English
InstallationProcedure
Step8 Performingthegasleaktest
To identify potential gas leaks on the indoorunit, inspect
the connection area of each refrigerant pipe using a leak
detectorforR-410A.
Before recreating thevacuum and recirculating the
refrigerant gas, pressurize thewhole systemwith
nitrogen (using a cylinderwith a pressure reducer) at a
pressure above 0.2 MPa, less than 4 MPa (gauge) in order
to immediately detect leaks on the refrigerant fittings.
Madevacuum for15 minutes and pressurizing system
with nitrogen.
Insulator Liquid side
Gas side
Step9 Insulatingtherefrigerantpipes
Onceyou have checked that there are no leaks in the
system, you can insulate the piping and hose.
1 To avoidcondensation problems, placeAcrylonitrile
ButadienRubberseparatelyaroundeach refrigerantpipe.
No gap
NBR
NOTE
• Always make the seam of pipes face upwards.
CAUTION
• The insulation has to be produced in full compliance
wirh European regulation EEC / EU 2037 / 2000
requiringthe use of sheaths insulation without using
CFC and HCFC gasesforhealth and the environment.
2 Wind insulating tape around the pipes and drain hose
avoiding compressing the insulation too much.
Insulation coverpipe
Indoorunit
Insulation pipe
Be sure to overlap the insulation.
CAUTION
• Be sure towrap insulation tightlywithout any gaps.
3 Finishwrapping insulating tape aroundthe rest of the
pipes leading to the outdoorunit.
4 The pipes and electrical cables connecting the indoor
unitwith the outdoorunit must be fixed tothe wall
with suitable ducts.
CAUTION
• Must fit tightlyagainst bodywithout anygap.
• Make surethat all refrigerant connection must be
accessible foreasymaintenance and detachment.
• Install the insulation not to getwiderand use the
adhesives on the connection part of it to prevent
moisturefrom entering.
• Wind the refrigerant pipe with insulation tape if it is
exposed to outside sunlight.
• Install therefrigerantpipe respecting thatthe insulation
doesnotgetthinneronthe bentpartorhangerofpipe.
• Add the additional insulation if the insulation plate gets
thinner.
Additional insulation
Refrigerant pipe
insulation
Hanger
a
a x 3
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGXX YWYXTWXTY`GGG㝘䟸GZa[WaWW

12
InstallationProcedure
English
InstallationProcedure
5 Selectthe insulation of the refrigerant pipe.
• Insulate the gas side and liquid side pipe, noting
the insulation thickness that must differaccording
to the pipe size.
• Standard: Less than an indoortemperature
of 30°C,with humidityat 85%. If installing in
a high humidityenvironment, use one grade
thickerinsulatorby referring to the table below.
If installing in an unfavourable environment, use
thickerone.
• The heat-resistance temperature of the insulator
must be morethan120°C.
Pipe Pipesize
(mm)
InsulationType(Heating/
Cooling)
Remarks
Standard
[30°C,
85%]
High
humidity
[30°C,over
85%]
EPDM,NBR
Liquid
pipe
Ø6.35 to
Ø9.52 9t 
Internal
temperature
is higherthan
120°C
Ø12.7 to
Ø50.80 13t 
Gas
pipe
Ø6.35 13t 19t
Ø9.52 to
Ø25.40 19t 25t
Ø28.58 to
Ø44.45 32t
Ø50.80 25t 38t
• When installing insulation in the places and
conditions below, use the same insulation that is
used forhigh humidity conditions.
<Geologicalcondition>
High humiditylocations such as shorelines, hot springs, lake
orriversides, and ridges (when part of the building is covered
byearth and sand)
<Operationpurpose condition>
Restaurant ceiling, sauna, swimming pool etc.
<Buildingconstructioncondition>
Ceilings frequently exposed to moisture and cooling are
not covered. Forexample, pipes installed at a corridorof a
dormitoryand studio ornear an exit that opens and closes
frequently.
Places (where the pipes are installed) that are highly humid
due to a lack ofventilation.
• Refrigerant pipe before EEVkit and MCU orwithout
EEVkit and MCU
– You can contact the gas side and liquid side
pipes but the pipes should not be pressed.
– When contacting the gas side and liquid side
pipe, use1 grade thickerinsulator.
• Refrigerant pipe afterEEVkit and MCU
– Install the gas side and liquid side pipes, leave
10mm of space.
– When contacting the gas side and liquid side
pipe, use1 grade thickerinsulator.
Step10 Installingthedrainhoseand
drainpipe
1 Push the supplied drain hose as faras possible over
the drain socket.
2 Tighten the metal clamp as shown in the picture.
3 Wrapthe supplied large sealing pad overthe metal
clamp and drain hose to insulate and fix itwith clamps.
4 Insulate the complete drain piping inside the building
(field supply).
If the drain hose cannot be sufficientlyset on a slope,
fit the hosewith drain raising piping (field supply).
5 Push the drain hose upto insulation when connecting
the drain hose to drain socket.
Metal clamp Drain socket
Drain hose
Be sure to bondthe drain
hose and the main pipe.
Drain pipe
Large seailng pad
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGXY YWYXTWXTY`GGG㝘䟸GZa[WaWW

13
English
InstallationProcedure
PVC TubeJoint+
VP25 (OD: 32 mm, ID: 25 mm)Drain hose
Drain pipe
CAUTION
Check that the indoorunit is levelwith the ceiling by
using the leveller.
• Install airventilation to drain condensation smoothly.
Airventilation
Ceiling
• If it is necessaryto increase the height ofthe drain pipe,
install the drain pipe straight within 300 mm from the
drain hose port. If it is raised higherthan 550 mm, there
maybewaterleaks.
Drain hose
Ceiling
20 mm ormore
1/100 ormore
Band joint
300 mm
orless 300 to
550 mm
• Do not give the hose an upward gradient beyond the
connection port. Thiswill cause waterto flow backwards
when the unit is stopped, resulting in waterleaks.
Undergradient
Ceiling
• Do not applyforce tothe piping on the unit sidewhen
connecting the drain hose. The hose should not be
allowed to hang loose from its connection tothe unit.
Fasten the hose to awall, frame orothersupport as
close to the unit as possible.
Support pieces
1 to1.5 m
1/100 ormore
Ceiling
• Install horizontally.
Be horizontal
Indoorunit
Flexible hose
• Max. allowable axis gap.
Max. 20 mm
Indoorunit
• Max. allowable bending angle.
Indoorunit đɇуࢋߤߡઑ
NOTE
• If a concentrated drain pipe is installed, referto the
figure below.
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGXZ YWYXTWXTY`GGG㝘䟸GZa[WaWW

14
InstallationProcedure
English
InstallationProcedure
• If 3 ormore units are installed, installthe main airvent
at the front of the farthest indoorunit fromthe main
drain pipe.
• To preventwaterfromflowing backto indoorunits,install
anindividualairvent atthe topof eachindoorunit.
– The airvents should be Tor7 shaped to prevent
dust orforeign substances from entering.
– You may not need to install airvent if the horizontal
drain pipe is in properslope.
Step11 Performingthedrainagetest
1 Do a leaktest at the connection part of the flexible
hose and the drian pipe:
a Connect a general hose to the connection part of
the flexible hose of the indoorunit, and pourin
somewater.
Waterleakage
check part
Flexible hose
Hose
b Afterpouring some water, reassemblethe rubber
cap on the connection part of a flexible hose of
the indoorunit and firmlytighten itwith a band to
prevent leakage.
c Check the leak test at the part where the adhesive
forthe flexible hose and the drian pipe is used.
CAUTION
• The leak test must be performedforat least 24
hours.
2 Check the condensed waterdrainage:
a Pourabout 2 liters ofwaterinto the indoorunit
drain pan as shown inthe picture.
b When the electric cable connection is completed
• Turn on the indoorunit and outdoorunit.
• Operate inthe Cool mode.
CAUTION
• Onlyin the Cool mode,you can check the correct
operation of the drain pump.
When the electric cable connection has not been
completed
• Removethe control box coverof the indoorunit.
• Connectthe powersupplyto the Land N terminals.
• Reassemble the control box coverand turn on the
indoorunit.
Hanger 1~1.5m
Individual
airvent
Main drainpipe
Main airvent
200 mm ormore
300 to 550 mm
Centralized horizontal drainpipe
(more than1/100 slope)
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGX[ YWYXTWXTY`GGG㝘䟸GZa[WaWW

15
English
InstallationProcedure
CAUTION
• When the float switch is not detected due to
insufficientwateron the drain pan, the drain
pumpwill not work.
• If the powersupplyis directlyconnected to the L
and N terminals, communication errormessage
might appear.
• Aftercompleting the drainage check, turn the unit
off and disconnect the powersupply.
• Reassemble the control box cover.
c Checkwhetherthe drain pumpworks correctly.
d Checkwhetherthe drainage is performing
correctlyat the end of the drain pipe.
e Check forleakage at the drain pipe and drain pipe
connection part.
f When leakage occurs, checkwhetherthe indoor
unit is level and check the drain hose connection
part, drainpipe connection part and drain pump
connection.
g When the drainage check is completed and
the condensedwaterremains on the drain pan,
remove thewater.
Step12 Connectingthepowerand
communicationcables
Powerand communication cableconnection
• Before wiringwork,you must turn off all powersource.
• Connectthe powerand communication cable among
the unitswithin maximum length to set thevoltage
drop under10%.
• The auxiliary circuit breaker(ELCB, MCCB, ELB) should
be considered more capacityif many indoorunits are
connected from one breaker.
• Connect F3, F4(forcommunication) to the
communication cable of the wired remote control.
• Tighten the electricwireswith a propertoolwithin the
torque limit to connect and fix them firmly, and then
organize thewires to prevent outside pressure being
exerted on the covers and otherparts. Failure to do so
mayresult in overheating, electric shock, and fire.
Tighteningtorque(N•m)
M3.5 0.8 ~1.2
M4 1.2 ~1.8
(1 N•m =10 kgf•cm)
• To protect the product fromwaterand possible shock,
you should keep the powerand the communication
cables ofthe indoorand outdoorunits in the iron pipe.
• Connectthe powercableto the auxiliary circuit
breaker(ELCB, MCCB, ELB).
• Keep distances of 50mm ormore between powercable
and communication cables.
• Powersupplycords of parts of appliances foroutdoor
use shall not be lighterthan polychloroprene sheathed
flexible cord. (Code designation IEC:60245 IEC 57 /
CENELEC: H05RN-F orIEC:60245 IEC 66 / CENELEC:
H07RN-F)
• Screws on terminal block must not be unscrewed with
the torque less than12 kgf•cm.
• When installing the indoorunit in a computerroom,
use the double shielded (tape aluminum / polyester
braid + copper) cable of FROHH2R type.
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGX\ YWYXTWXTY`GGG㝘䟸GZa[WaWW

16
InstallationProcedure
English
InstallationProcedure
OutdoorUnit
220~240V~
ELB
MCCB
IndoorUnit1 IndoorUnit 2 IndoorUnit 3
IndoorUnit 4 IndoorUnit 5 IndoorUnit 6
EEVkit
Wired Remote
Control
࢘kø9ࡠkϑϑʪϩɇÃϑϩɇɇϩͱ
࢘Aʪ˝ࡡиɇࣗͱЇϩʪʒʒͱͱθЇϩࢋ
Selectingthecrimpingterminallug
1 Selectthe crimping terminal lug based on the norminal dimension of the powercable.
2 Coverthe connection part of the powercable and crimping terminal lug to insulate it.
B
2
R
d2
B
F
L
E
Silversolder
d1
D
t
Norminal
dimensions
forcable
(mm²)
Norminal
dimensions
forscrew
(mm)
BDd1EFLd2t
Standard
dimension
(mm) Allowance
(mm) Standard
dimension
(mm) Allowance
(mm) Standard
dimension
(mm) Allowance
(mm) Min. Min. Max. Standard
dimension
(mm) Allowance
(mm) Min.
1.5 46.6 ± 0.2 3.4 +0.3
-0.2 1.7 ± 0.2 4.1 6 16 4.3 +0.2
00.7
48
2.5 46.6 ± 0.2 4.2 +0.3
-0.2 2.3 ±0.2 6 6 17.5 4.3 +0.2
00.8
48.5
449.5±0.25.6
+0.3
-0.2 3.4 ± 0.2 6 5 20 4.3 +0.2
00.9
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGX] YWYXTWXTY`GGG㝘䟸GZa[WaWX

17
English
InstallationProcedure
Specificationsoftheterminalblocks
(Unit: mm)
AC power: M4 screw
11
13
18
7.5 9.0
13.8
Communication: M3.5 screw
Powersupply
(singlephase) MCCB ELB
Min :198V
Max : 242V XA XA, 30 mA
0.1 s
Powercable Earth cable Communication
cable
2.5 mm² ormore 2.5 mm² 0.75to1.5 mm²
Decide the powercable specification and maximum
length byformula 2.
1 Decide the capacityof ELB and MCCB bybelow
formula.
Ɵ˵ʪʀɇΧɇʀϩцͱ˙kø9ࡡđAA9ǹࣄࣅߢࢋߣߦǹߢࢋߢǹן
NOTE
• X : The capacityof ELB, MCCB
• ןࡠƊЇͱ˙θɇϩ˝ʀЇθθʪϩϑͱ˙ʪɇʀ˵ʒͱͱθЇϩࢋ
Ratedcurrents
Model Ratingcurrent(A)
AM028AN4PKH* 0.25
AM036AN4PKH* 0.27
AM045AN4PKH* 0.30
AM056AN4PKH* 0.32
AM071AN4PKH* 0.35
AM090AN4PKH* 0.45
AM112AN4PKH* 0.60
AM128AN4PKH* 0.75
AM140AN4PKH* 0.85
2 Decide the powercable specification and maximum
lengthwithin10% voltage drop among indoorunits.
nCoef×35.6×Lk ×ik) <10%of inputvoltage[V]
࣍ 1000×Ak
k=1
NOTE
• Coef:1.55
• Lk: Distance among each indoorunit[m], Ak: Power
cable specification[mm
2
]
• ik: Running current of each unit[A]
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGX^ YWYXTWXTY`GGG㝘䟸GZa[WaWX

18
InstallationProcedure
English
InstallationProcedure
Exampleof Installation
Total powercable length L=100(m), Initial pull-in current =10[A], Running current of each units =1[A], Total10 indoor
unitswere installed
MCCB+ELB 10 [A] 9 [A] 1 [A]
100[m]10[m] 20[m]0[m]
Indoorunit10
Indoorunit1 Indoorunit 2
or
ELCB
• Applyfollowing equation.
nCoef×35.6×Lk×ik
࣍ ) < 10% of inputvoltage[V]
k=1 1000×Ak
• Calculation
– Installing with1 sort wire.
2.5[mm2]
-2.2 [V]
220 [V]
-(2.2+2.0+1.8+1.5+1.3+1.1+0.9+0.7+0.4+0.2)=-11.2 [V]
-2.2[V]
2.5[mm2] ······· 2.5 [mm2] ······· Within198V
to 242V
208.8 [V] :
Applicable
– Installing with 2 different sortwire.
4.0 [mm2]4.0[mm
2]
-1.2 [V]-1.2 [V]
220 [V]
-(1.4+1.2+1.8+1.5+1.3+1.1+0.9+0.7+0.4+0.2)=-10.5 [V]
······· 2.5 [mm2] ······· Within198V
to 242V
209.5[V]:
Applicable
CAUTION
• Select the powercable in accordance with relevant local
and national.
• Wire size must complywith local and national code.
• You should connect the powercable into the power
cableterminal and fasten it with a clamp.
• The unbalanced powermust be maintainedwithin10%
of supplyrating among whole indoorunits.
• If the poweris unbalanced greatly, it mayshorten
the life of the condenser. If the unbalanced poweris
exceeded over10% of supplyrating, the indoorunit is
protected, stopped andthe errormode indicates
• Connect the powercable to the auxiliarycircuit breaker.
An all pole disconnectionfrom the powersupplymust
ɵʪʀͱθΧͱθɇϩʪʒϩ˵ʪ˙уʪʒиθ˝࣍ߤ࣎ࢋ
• You must keep the cable in a protection tube.
• Maximum length of powercables are decidedwithin
10% of powerdrop. If it exceeds,you must consider
anotherpowersupplying method.
• The circuit breaker(MCCB, ELB) should be considered
more capacityif many indoorunits are connected from
one breaker.
• Use round pressure terminal forconnections to the
powerterminal block.
• Forwiring, use the designated powercable and
connect it firmly, then secure to prevent outside
pressure being exerted on theterminal board.
• Use an appropriate screwdriverfortighteningthe
terminal screws.A screwdriverwith a small headwill
strip the head and make propertightening impossible.
• Over-tightening the terminal screws may break them.
Step13 Optional:Extendingthe
powercable
1 Prepare the following tools.
Tools Spec Shape
Crimping pliers MH-14
Connection sleeve
(mm) 20xØ6.5 (HxOD)
Insulationtape Width19
mm
Contraction tube
(mm) 70xØ8.0 (LxOD)
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGX_ YWYXTWXTY`GGG㝘䟸GZa[WaWX

19
English
InstallationProcedure
2 As shown in thefigure, peel off the shieldsfrom the
rubberand wire of the powercable.
• Peel off 20 mm of cable shields fromthe pre-
installed tube.
Powercable (Unit: mm)
20 20 20
60
120
180
180
120
60
20 20 20
Pre-installed
tube forthe
powercable
CAUTION
• Forinformation about the powercable specifications
forindoorand outdoorunits, referto the installation
manual.
• Afterpeeling off cable wires from the pre-installed
tube, insert a contractiontube.
3 Insert both sides of corewire ofthe powercable into
the connection sleeve.
• Method1: Push the core wire into the sleevefrom
both sides.
• Method2: Twist thewire cores togetherand push it
into the sleeve.
Method1
Connection sleeve Connection sleeve
Method2
CAUTION
• If cablewires are connectedwithout using connecting
sleeves, theircontact area becomes reduced, or
corrosion develops on the outersurfaces ofthe wires
(copperwires) overa long time. This maycause an
increase of resistance (reduction of passing current)
and consequentlymay result in a fire.
4 Using a crimping tool, compress the two points and
flip it overand compress anothertwo points in the
same location.
• The compression dimension should be 8.0.
Compression
dimension
• Aftercompressing it, pull both sides of thewireto
make sure it is firmlypressed.
Method1 Method2
5 mm
Compress it 4 times. Compress it 4 times.
5 mm
5 Apply heat to the contraction tube to contract it.
Method1Contractiontube Contractiontube Method2
6 Wrap itwith the insulation tape twice ormore and
position your contraction tube in the middle of the
insulation tape.
Method1 Method2
40 mm
Insulationtape Insulation tape
35 mm
7 Aftertube contractionwork is completed,wrap itwith
the insulation tape to finish.
Three ormore layers of insulation are required.
Method1 IInsulationtape IInsulation tape Method2
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGX` YWYXTWXTY`GGG㝘䟸GZa[WaWX

20
InstallationProcedure
English
InstallationProcedure
CAUTION
• Make sure that the connection parts are not exposed
to outside.
• Be sure to use insulation tape and a contraction tube
made of approved reinforced insulating materials
that havethe same level ofwithstand voltage with
the powercable. (Complywith the local regulations on
extensions.)
WARNING
• In case of extending the electricwire, please DO NOT
use a round-shaped Pressing socket.
– Incompletewire connections can cause electric
shock ora fire.
Step14 Settingtheindoorunit
addressesandtheinstallationoptions
You cannot set both of the indoorunit addresses and the
installation options in a batch: set both of them respectively.
Commonstepsforsettingtheaddressesand options
LowTemp button
High Temp button Mode button
Low Fan button
High Fan button
Settingthe
optionvalues
Enteringthe
modeforsetting
theoptions
NOTE
• The remote control displayand buttons mayvary
depending on the model.
1 Enterthe mode forsetting the options:
a Remove the batteries from the remote control,
and then insert them again.
b While holding down the (High Temp) and
(LowTemp) buttons simultaneously, insert the
batteries intothe remote control.
c Make sure that you are enteredto the mode for
setting the options:
2 Set the option values.
CAUTION
• The total numberof available options are 24: SEG1 to SEG24.
• BecauseSEG1,SEG7,SEG13,and SEG19arethe pageoptions
usedbythe previousremotecontrolmodels,themodes to
setvaluesfortheseoptions areskipped automatically.
• Seta 2-digitvalueforeachoptionpairin thefollowingorder:
ƊkߣɇʒƊkߤƊkߥɇʒƊkߦƊkߧɇʒƊkߩ
ƊkߪɇʒƊkߢߡƊkߢߢɇʒƊkߢߣƊkߢߥɇʒƊkߢߦ
ƊkߢߧɇʒƊkߢߨƊkߢߩɇʒƊkߣߡƊkߣߢɇʒƊkߣߣ
SEG23and SEG24
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6
0XXXXX
SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
1XXXXX
SEG13 SEG14 SEG15 SEG16 SEG17 SEG18
2XXXXX
SEG19 SEG20 SEG21 SEG22 SEG23 SEG24
3XXXXX
On (SEG1to SEG12) Off (SEG13toSEG24)
ki]_TW``]^hTWWptk}tGolG~GmG[l|luUGGGYW YWYXTWXTY`GGG㝘䟸GZa[WaWY
