Samsung AR24CSDADWKNCV User manual

AIR CONDITIONER CONTENTS
SPLIT-TYPE AIR CONDITIONER
OUTDOOR UNI T
MODEL CODE
INDOOR UNIT
1. Precautions
2. Product Specications
3. Alignment and Adjustments
4. Disassembly and Reassembly
5. ASSY CONTROL
6. Wiring Diagram
7. PCB Diagram
8. Operating Instructions
9. Troubleshooting
10.Block Diagram
11. Reference Sheet
AR07CSDAFWKNCV
AR09CSDABWKNCV
AR12CSDABWKNCV
AR15CSDAFWKNCV
AR15CSDABWKNCV
AR18CSDABWKNCV
AR24CSDABWKNCV
AR07CSFCMWKNCV
AR09CSFCMWKNCV
AR12CSFCMWKNCV
AR15CSFCMWKNCV
AR18CSFCMWKNCV
AR24CSFCMWKNCV
AR24CSDADWKNCV
AR09CSDABWKXCV
AR12CSDABWKXCV
AR15CSDABWKXCV
AR18CSDABWKXCV
AR24CSDABWKXCV
AR09CSFCMWKXCV
AR12CSFCMWKXCV
AR15CSFCMWKXCV
AR18CSFCMWKXCV
AR24CSFCMWKXCV
AR09CSDACWKXCV
AR12CSDACWKXCV
AR15CSDACWKXCV
AR18CSDACWKXCV
AR24CSDACWKXCV
AR18CSDADWKXCV
AR18CSDAEWKXCV
AR24CSDAEWKXCV
AR15CSFCMWKXCV
AR18CSFCMWKXCV
AR09CSDABWKXCV
AR12CSDABWKXCV
AR09CSFCMWKXCV
AR12CSFCMWKXCV
AR09CSDACWKXCV
AR12CSDACWKXCV
AR07CSFCMWKNCV
AR09CSFCMWKNCV
AR12CSFCMWKNCV
AR15CSFCMWKNCV
AR18CSFCMWKNCV
AR24CSFCMWKNCV
AR15CSDABWKXCV
AR18CSDABWKXCV
AR24CSFCMWKXCV
AR15CSDACWKXCV
AR18CSDACWKXCV
AR07CSDAFWKNCV
AR09CSDABWKNCV
AR12CSDABWKNCV
AR15CSDAFWKNCV
AR15CSDABWKNCV
AR18CSDABWKNCV
AR24CSDABWKNCV
AR24CSDADWKNCV
AR24CSDABWKXCV
AR24CSDACWKXCV
AR18CSDADWKXCV
AR18CSDAEWKXCV
AR24CSDAEWKXCV

2
Contents
1. Precautions 4
1-1 Installing the air conditioner 4
1-2 Power supply and circuit breaker 4
1-3 During operation 4
1-4 Disposing of the unit 5
1-4 Others 5
2. Product Specications 6
2-1 The Feature of Product 6
2-2 Product Specifications 7
2-3 The comparative specifications of product 9
2-4 Accessory and option specifications 13
3. Alignment and Adjustments 14
3-1 Test mode 14
3-2 Display Error and Check Method 15
3-3 Setting Option Setup Method 17
4. Disassembly and Reassembly 22
4-1 Indoor Unit 23
4-2 Outdoor Unit 33
5. ASSY CONTROL 51
5-1 ASSY KIT INDOOR CODE DB92-05191G, J 51
5-2 ASSY KIT INDOOR CODE DB92-05201F 52
5-3 ASSY KIT OUTDOOR CODE DB92-05037H,J 53
5-4 ASSY KIT OUTDOOR CODE DB92-05037K 54
6. Wiring Diagram 55
6-1 Indoor unit 55
6-2 Outdoor unit 56
7. PCB Diagram 58
7-1 Indoor Main PCB CODE DB92-05043J 58
7-2 Outdoor Main PCB CODE DB92-04837U, V 59
7-3 Outdoor PCB Inverter CODE DB92-04838Q, R 61
7-4 DISPLAY PCB 63
7-5 Wire connecting the indoor unit terminal blocks 64

2 3
Contents
8. Operating Instructions 65
8-1 Name of Each Part 65
8-2 Wireless Remote Control-Buttons and Display 66
9. Troubleshootin 68
9-1 Items to be checked First 68
9-2 Communication Error 69
9-2-1 Communication Error 69
9-2-2 Indoor temperature sensor Error 70
9-2-3 Indoor fan motor speed detecting error (BLDC fan) 71
9-2-4 Outdoor temperature sensor error 72
9-2-5 Outdoor Cond temperature sensor error 73
9-2-6 Outdoor Discharge temperature sensor error 74
9-2-7 Operation condition secession error 75
9-2-8 EEPROM error/OTP error 76
9-2-9 Outdoor Fan motor error 77
9-2-10 Compressor starting error 78
9-2-11 Compressorwire missing error/rotation error 79
9-2-12 Current sensor error/Input current sensor error 80
9-2-13 O.C(Over Current) error 81
9-2-14 No power outdoor (Initial Diagnosis) (Not displayed) 83
9-2-15 When the Up/Down, Left/Right, Grill louver motor does not operate 84
9-2-16 When the remote control is not receiving 85
9-2-17 Smart Install error 86
9-2-18 Outdoor OLP over temperature error (One way Inverter Only) 87
9-2-19 EEV or VALVE CLOSE error (C422) 88
10. Block Diagram 89
10-1 Indoor unit 89
10-2 Outdoor unit 90
11. Reference Sheet 93
11-1 Low Refrigerant Pressure Distribution 93
11-2 Pressure & Capacity mark 93
11-3 Q & A for Non-trouble 94
11-4 Cleaning /Filter Change 97
11-5 Installation 100
11-6 Installation Diagram of Indoor Unit and Outdoor Unit 101
11-7 Reference sheet 103

4
1-1 Installing the air conditioner
• Uses should not install the air conditioner by themselves. Ask the dealer or authorized company to install
the air conditioner except window-type air conditioner in U.S.A and Canada.
• If you don't install the air conditioner properly, it may cause a fire, a water leakage or an electric shock.
• You must install the air conditioner according to the national wiring regulations and safety regulations.
• Install the indoor unit higher than 2.5m from the floor to avoid the injury caused by the operation of the fan.
(except the window-type air conditioner)
• The manufacturer is not responsible for any accidents or injury caused by an incorrect installation.
• When installing the built-in type air conditioner, keep all electric cables such as the power cable and the
connection cord in pipes, ducts, or cable channels to protect them from the danger of impact or any other
incidents.
1-2 Powersupply and circuit breaker
• If the power cord of the air conditioner is damaged, it must be replaced by the manufacturer or a qualified
person in order to avoid a hazard.
• The air conditioner must be plugged into an independent circuit if applicable or connect the power cable to
the auxiliary circuit breaker. An all pole disconnection form the power supply must be incorporated in the
fixed wiring with a contact opening of>3mm.
• Do not extend an electric cord to the air conditioner.
• The air conditioner must be plugged in after you complete the installation.
1-3 During operation
• Do not repair the air conditioner at your discretion. It is recommended to contact a service center directly.
• Never spill any kind of liquid on the air conditioner. If this happens, turn off the air conditioner and contact
an authorized service center.
• Do not insert anything between the airflow blades to prevent damage of the inner fan and consequent
injury. Keep children away from the air conditioner.
• Do not place any obstacles in front of the air conditioner.
• Do not spray any kind of liquid into the indoor unit. If this happens, turn off the air conditioner and contact
a service center.
• Make sure that the air conditioner is well ventilated at all times. Do not place a cloth or other materials over
it.
• Remove the batteries if you don't use the remote control for a long time. (If applicable)
• Use the remote control within 7 meters from the indoor unit. (If applicable)
1. Precautions

5
1-4 Disposing of the unit
• Before the throwing out the air conditioner, remove the batteries from the remote control.
• When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant
may blow out and cause air pollution. When it contacts with your skin, it can cause skin injury.
• The package of the air conditioner should be recycled or disposed of properly for environmental reasons.
1-5 Others
• Never store or load the air conditioner upside down or sideways to prevent the damage to the compressor.
• Young children or infirm persons should be always supervised when they use the air conditioner.
• Max current is measured according to IEC standard for safety.
• Current is measured according to ISO standard for energy efficiency.

6
2-1 The Feature of Product
uFast cooling
If you want the strong and cool air, just select Fast function! It will get you the strongest air!
uWindFree Cooling
UsetheWindFreeCoolingfunctiontoenjoyamildbreezecomingthroughneholes
intheWindFreepanelinsteadofaircomingdirectlythroughtheairowblades.
uEco
Use the Single User function when you’re along at home. Aside from energy savings from the
inverter technology, the Single User Mode will further minimize your energy consumption and
reduce your electricity bill by adjusting the maximum operating capacity of the compressor.
uEasy Filter
Thereisnogrilletoremovebeforeseparatingthelterfromtheairconditioner!Therefore,lter
canbecleanedeasilyandmorefrequently.Constantltercleaningwillpreventdustfromenter-
ingtheproductoraccumulatingonthelter.
ugood’sleep function
good’sleep function will allow you to have deep, good night’sleep by adjusting the temperature,
fanspeedandairowdirection.
uSmart Install
When the installation is done, your product will examine itself through trial operation to check if
it was installed properly.
uEasy Installation
It’s so easy to install! You can easily hang the product on the wall and connect the pipes
and wires by opening the cover on the bottom of the product. Now you won’t have to tilt
the product to connect the pipe and the wires!
2. Product Specications

7
2-2 Product specication
Model AR09CSDABWKNCV AR12CSDABWKNCV AR15CSDABWKNCV AR18CSDABWKNCV
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool Btu/h 9000 12000 15000 18000
T3 Cool Btu/h ----
Heat Btu/h 11000 12000 15000 20000
Power Input
T1 Cool W 580 890 1070 1385
T3 Cool W - - - -
Heat W 730 830 980 1570
Current
T1 Cool A 2.8 4.2 56.2
T3 Cool A - - - -
Heat - 3.4 3.8 4.5 7
Efciency
EER Btu/hW 15.50 13.50 14.00 13.00
-- - - -
COP W/W 15.05 14.45 15.30 12.75
Dehumidifying l/hr. 2.5 2.5 2.5 2.5
Platform IDU - QF2 QF2 QF3 QF3
ODU - N-SI N-SI P-520 P-520
Evap
Main -
Φ7,(2R*10S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S, 1by2
Φ7,(2R*10S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S, 1by2
Φ7,(2R*10S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic, 4by4
Φ7,(2R*10S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic, 4by4
Sub -
Φ7,(2R*6S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S : (S2-3)
Φ7,(2R*6S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S : (S2-3)
Φ7,(2R*6S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic : (S3-6)
Φ7,(2R*6S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic : (S3-6)
Cond Main -
Φ7W,2R*24S*850/825mm,
Corrugate1.5, N.G.S,
4by4by2
Φ7W,2R*24S*850/825mm,
Corrugate1.5, N.G.S,
4by4by2
Φ7W,2R*36S*906.8mm,
Corrugate1.5, N.G.S,
5by5by1
Φ7W,2R*36S*906.8mm,
Corrugate1.5, N.G.S,
5by5by1
Sub -----
Comp Model - KTN130D42UFR KTN130D42UFR KTN150D42UFR UG8TH8265FEW
OLP - ----
Motor In Code - DB31-00636A DB31-00636A DB31-00637A DB31-00637A
Name - - - - -
Motor Out Code - DB31-00642C DB31-00642C DB31-00579A DB31-00579A
Name - - - - -
Expansion Φ*L -Φ1.4 Φ1.4 Φ1.65 Φ1.65
Refrigerant type - R410A R410A R410A R410A
charge g 1150 g 1150 g 1600 g 1800 g
SVC Valve Liquid /
Gas -Φ6.35/Φ9.52 Φ6.35/Φ9.52 Φ6.35/Φ12.7 Φ6.35/Φ12.7
Tube Dis. /
Suc. -Φ9.52/Φ12.7 Φ9.52/Φ12.7 Φ9.52/Φ12.7 Φ9.52/Φ15.88
Drain hose D*L mm 20*550 20*550 20*550 20*550
4-WAY V/V -----
Power Supply V/Hz/Φ 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Climate Class - T1 T1 T1 T1
Noise IDU UT,T dB 41dB↓ 43dB↓ 46dB↓ 48dB↓
ODU dB 51dB↓ 53dB↓ 57dB↓ 57dB↓
Net Size
(W*D*H)
IDU mm 889*299*215 889*299*215 1055*299*215 1055*299*215
ODU 790*548*285 790*548*285 880*798*310 880*798*310
Weight IDU kg 10.1 10.1 11.5 11.5
ODU 32.4 32.4 49.0 55.6
Operation
range
Cooling IDU 61~90˚F 61~90˚F 61~90˚F 61~90˚F
ODU 14 ~ 115 °F 14 ~ 115 °F 14 ~ 115 °F 14 ~ 115 °F
Heating IDU 81˚Forless 81˚Forless 81˚Forless 81˚Forless
ODU -5.1 ~ 75 °F -5.1 ~ 75 °F -5.1 ~ 75 °F -5.1 ~ 75 °F

8
2-2 Product specication
Model AR24CSDABWKNCV AR09CSFCMWKNCV AR12CSFCMWKNCV AR15CSFCMWKNCV
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool Btu/h 21000 9000 12000 15000
T3 Cool Btu/h ----
Heat Btu/h 25000 11000 12000 15000
Power Input
T1 Cool W 1680 692 995 1250
T3 Cool W - - - -
Heat W 2000 865 998 1110
Current
T1 Cool A 7.6 3.1 4.8 5.6
T3 Cool A - - - -
Heat - 94.2 4.6 5.2
Efciency
EER Btu/hW 12.50 13 12 12
-- - - -
COP W/W 12.50 12.70 12.50 13.50
Dehumidifying l/hr. 2.5 2.5 2.5 2.5
Platform IDU - QF3 QF1 QF1 QF3
ODU - UB1 N-SI N-SI Q-480
Evap
Main -
Φ7,(2R*10S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic, 4by4
Φ7,2R*9(10)S*591mm,H1.3,
N.G.S, 1by2
Φ7,2R*9(10)S*591mm,H1.3,
N.G.S, 1by2
Φ7,2R*10S*825.5mm,H1.3,
N.G.S, 4by4
Sub -
Φ7,(2R*6S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic : (S3-7)
Φ7,2R*5(6)S*591mm,H1.3,
N.G.S : (S1-5)
Φ7,2R*5(6)S*591mm,H1.3,
N.G.S : (S1-5)
Φ7,2R*5(6)S*826mm,H1.3,
N.G.S : (S3-3)
Cond Main - Φ7W,2R*46S*950mm,Cor-
rugate1.5, N.G.S, 8by8
Φ7W,2R*24S*850/825mm,
Corrugate1.5, N.G.S,
4by4by2
Φ7W,2R*24S*850/825mm,
Corrugate1.5, N.G.S,
4by4by2
Φ7W,2R*28S*906.8mm,
Corrugate1.5, N.G.S,
4by4by1
Sub -----
Comp Model - UG8TH8265FJW KTN130D42UFR KTN130D42UFR UG9TK3150FE4
OLP - ----
Motor In Code - DB31-00637A DB31-00694A DB31-00694A DB31-00636A
Name - - - - -
Motor Out Code - DB31-00579A DB31-00642C DB31-00642C DB31-00642C
Name - - - - -
Expansion Φ*L -Φ1.65 Φ1.4 Φ1.4 Φ1.65
Refrigerant type - R410A R410A R410A R410A
charge g 2500 g 1000 g 1000 g 1300 g
SVC Valve Liquid /
Gas -Φ6.35/Φ15.88 Φ6.35/Φ9.52 Φ6.35/Φ9.52 Φ6.35/Φ12.7
Tube Dis. /
Suc. -Φ9.52/Φ15.88 Φ9.52/Φ12.7 Φ9.52/Φ12.7 Φ9.52/Φ12.7
Drain hose D*L mm 20*550 20*550 20*550 20*550
4-WAY V/V -----
Power Supply V/Hz/Φ 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Climate Class - T1 T1 T1 T1
Noise IDU UT,T dB 51dB↓ 41dB↓ 43dB↓ 46dB↓
ODU dB 60dB↓ 51dB↓ 53dB↓ 57dB↓
Net Size
(W*D*H)
IDU mm 1055*299*215 820*299*215 820*299*215 1055*299*215
ODU 940*998*330 790*548*285 790*548*285 880*638*310
Weight IDU kg 12.5 8.9 8.9 11.5
ODU 68.2 32.4 32.4 38.1
Operation
range
Cooling IDU 61~90˚F 61~90˚F 61~90˚F 61~90˚F
ODU 14 ~ 115 °F -0.4 ~ 115 °F -0.4 ~ 115 °F -0.4 ~ 115 °F
Heating IDU 81˚Forless 81˚Forless 81˚Forless 81˚Forless
ODU -5.1 ~ 75 °F -13 ~ 75 °F -13 ~ 75 °F -13 ~ 75 °F

9
2-2 Product specication
Model AR18CSFCMWKNCV AR24CSFCMWKNCV AR09CSDACWKNCV AR12CSDACWKNCV
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool Btu/h 18000 22000 9000 12000
T3 Cool Btu/h ----
Heat Btu/h 21000 24000 11000 12000
Power Input
T1 Cool W 1635 2100 580 890
T3 Cool W - - - -
Heat W 1850 2290 730 830
Current
T1 Cool A 7.4 9.8 2.8 4.2
T3 Cool A - - - -
Heat - 8.2 10.5 3.4 3.8
Efciency
EER Btu/hW 11 10.50 15.50 13.50
-- - - -
COP W/W 11.35 10.50 15.05 14.45
Dehumidifying l/hr. 2.5 2.5 2.5 2.5
Platform IDU - QF3 QF3 QF2 QF2
ODU - Q-480 P-520 N-SI N-SI
Evap
Main - Φ7,2R*10S*825.5mm,H1.3,
N.G.S, 4by4
Φ7,2R*10S*825.5mm,H1.3,
Hydrophilic, 4by4
Φ7,(2R*10S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S, 1by2
Φ7,(2R*10S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S, 1by2
Sub -Φ7,2R*5(6)S*826mm,H1.3,
N.G.S : (S3-3)
Φ7,2R*5(6)S*825.5mm,
H1.3, Hydrophilic : (S3-4)
Φ7,(2R*6S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S : (S2-3)
Φ7,(2R*6S+1R*4S
)*660mm,(H1.3+H1.3),
N.G.S : (S2-3)
Cond Main -
Φ7W,2R*28S*906.8mm,
Corrugate1.5, N.G.S,
4by4by1
Φ7W,2R*36S*906.8mm,
Corrugate1.5, N.G.S,
5by5by1
Φ7W,2R*24S*850/825mm,
Corrugate1.5, N.G.S,
4by4by2
Φ7W,2R*24S*850/825mm,
Corrugate1.5, N.G.S,
4by4by2
Sub -----
Comp Model - UG9TK3150FE4 UG8TH8265FEW KTN130D42UFR KTN130D42UFR
OLP - ----
Motor In Code - DB31-00636A DB31-00636A DB31-00636A DB31-00636A
Name - - - - -
Motor Out Code - DB31-00642C DB31-00579A DB31-00642C DB31-00642C
Name - - - - -
Expansion Φ*L -Φ1.65 Φ1.65 Φ1.4 Φ1.4
Refrigerant type - R410A R410A R410A R410A
charge g 1300 g 1800 g 1150 g 1150 g
SVC Valve Liquid /
Gas -Φ6.35/Φ12.7 Φ6.35/Φ15.88 Φ6.35/Φ9.52 Φ6.35/Φ9.52
Tube Dis. /
Suc. -Φ9.52/Φ12.7 Φ9.52/Φ15.88 Φ9.52/Φ12.7 Φ9.52/Φ12.7
Drain hose D*L mm 20*550 20*550 20*550 20*550
4-WAY V/V -----
Power Supply V/Hz/Φ 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Climate Class - T1 T1 T1 T1
Noise IDU UT,T dB 48dB↓ 51dB↓ 41dB↓ 43dB↓
ODU dB 57dB↓ 60dB↓ 51dB↓ 53dB↓
Net Size
(W*D*H)
IDU mm 1055*299*215 1055*299*215 889*299*215 889*299*215
ODU 880*638*310 880*798*310 790*548*285 790*548*285
Weight IDU kg 11.5 11.5 10.1 10.1
ODU 38.1 55.6 32.4 32.4
Operation
range
Cooling IDU 61~90˚F 61~90˚F 61~90˚F 61~90˚F
ODU -0.4 ~ 115 °F -0.4 ~ 115 °F -0.4 ~ 115 °F -0.4 ~ 115 °F
Heating IDU 81˚Forless 81˚Forless 81˚Forless 81˚Forless
ODU -13 ~ 75 °F -13 ~ 75 °F -13 ~ 75 °F -13 ~ 75 °F

10
2-2 Product specication
Model AR15CSDACWKNCV AR18CSDACWKNCV AR24CSDACWKNCV AR24CSDADWKNCV
Rating Mode Unit Wall-mounted Wall-mounted Wall-mounted Wall-mounted
Capacity
T1 Cool Btu/h 15000 18000 21000 21000
T3 Cool Btu/h - - - -
Heat Btu/h 15000 20000 25000 24500
Power Input
T1 Cool W 1070 1385 1680 1680
T3 Cool W - - - -
Heat W 980 1570 2000 1950
Current
T1 Cool A 5 6.2 7. 6 7.6
T3 Cool A - - - -
Heat - 4.5 7 9 9
Efciency
EER Btu/hW 14.00 13.00 12.50 12.50
- - - - -
COP W/W 15.30 12.75 12.50 12.55
Dehumidifying l/hr. 2.5 2.5 2.5 2.5
Platform IDU - QF3 QF3 QF3 QF3
ODU - P-520 P-520 UB1 UB1
Evap
Main -
Φ7,(2R*10S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic, 4by4
Φ7,(2R*10S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic, 4by4
Φ7,(2R*10S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic, 4by4
Φ7,(2R*10S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic, 4by4
Sub -
Φ7,(2R*6S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic : (S3-6)
Φ7,(2R*6S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic : (S3-6)
Φ7,(2R*6S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic : (S3-7)
Φ7,(2R*6S+1R*4S
)*825.5mm,(H1.3+H1.3),
Hydrophilic : (S3-7)
Cond Main -
Φ7W,2R*36S*906.8mm,
Corrugate1.5, N.G.S,
5by5by1
Φ7W,2R*36S*906.8mm,
Corrugate1.5, N.G.S,
5by5by1
Φ7W,2R*46S*950mm,
Corrugate1.5, N.G.S, 8by8
Φ7W,2R*46S*950mm,
Corrugate1.5, N.G.S, 8by8
Sub -----
Comp Model - KTN150D42UFR UG8TH8265FEW UG8TH8265FJW UG8TH8265FJW
OLP - - - - -
Motor In Code - DB31-00637A DB31-00637A DB31-00637A DB31-00637A
Name - - - - -
Motor Out Code - DB31-00579A DB31-00579A DB31-00579A DB31-00579A
Name - - - - -
Expansion Φ*L -Φ1.65 Φ1.65 Φ1.65 Φ1.65
Refrigerant type - R410A R410A R410A R410A
charge g 1600 g 1800 g 2500 g 2500 g
SVC Valve Liquid /
Gas -Φ6.35/Φ12.7 Φ6.35/Φ12.7 Φ6.35/Φ15.88 Φ6.35/Φ15.88
Tube Dis. /
Suc. -Φ9.52/Φ12.7 Φ9.52/Φ15.88 Φ9.52/Φ15.88 Φ9.52/Φ15.88
Drain hose D*L mm 20*550 20*550 20*550 20*550
4-WAY V/V -----
Power Supply V/Hz/Φ 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Climate Class - T1 T1 T1 T1
Noise IDU UT,T dB 46dB↓ 48dB↓ 51dB↓ 51dB↓
ODU dB 57dB↓ 57dB↓ 60dB↓ 60dB↓
Net Size
(W*D*H)
IDU mm 1055*299*215 1055*299*215 1055*299*215 1055*345*215
ODU 880*798*310 880*798*310 940*998*330 880*798*310
Weight IDU kg 11.5 11.5 12.5 13.3
ODU 49.0 55.6 68.2 55.6
Operation
range
Cooling IDU 61~90˚F 61~90˚F 61~90˚F 61~90˚F
ODU -0.4 ~ 115 °F -0.4 ~ 115 °F -0.4 ~ 115 °F -0.4 ~ 115 °F
Heating IDU 81˚Forless 81˚Forless 81˚Forless 81˚Forless
ODU -13 ~ 75 °F -13 ~ 75 °F -13 ~ 75 °F -13 ~ 75 °F

11
2-3 The comparative specication of product
Model DEVELOPMENT MODEL
AR09CSDABWKNCV AR12CSDABWKNCV AR15CSDABWKNCV AR18CSDABWKNCV
Design
Indoor Unit
Outdoor Unit
Net Weight Indoor Unit 10.1 10.1 11.5 11.5
Outdoor Unit 32.4 32.4 49.0 55.6
Net Dimension Indoor Unit 889*299*215 889*299*215 1055*299*215 1055*299*215
Outdoor Unit 790*548*285 790*548*285 880*798*310 880*798*310
Noise Indoor Unit 41dB↓ 43dB↓ 46dB↓ 48dB↓
Outdoor Unit 51dB↓ 53dB↓ 57dB↓ 57dB↓
Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER
Indoor Display 88 SEG 88 SEG 88 SEG 88 SEG
Model DEVELOPMENT MODEL
AR24CSDABWKNCV AR09CSFCMWKNCV AR12CSFCMWKNCV AR15CSFCMWKNCV
Design
Indoor Unit
Outdoor Unit
Net Weight Indoor Unit 12.5 8.9 8.9 11.5
Outdoor Unit 68.2 32.4 32.4 38.1
Net Dimension Indoor Unit 1055*299*215 820*299*215 820*299*215 1055*299*215
Outdoor Unit 940*998*330 790*548*285 790*548*285 880*638*310
Noise Indoor Unit 51dB↓ 41dB↓ 43dB↓ 46dB↓
Outdoor Unit 60dB↓ 51dB↓ 53dB↓ 57dB↓
Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER
Indoor Display 88 SEG 88 SEG 88 SEG 88 SEG

12
2-3 The comparative specication of product
Model DEVELOPMENT MODEL
AR18CSFCMWKNCV AR24CSFCMWKNCV AR09CSDACWKNCV AR12CSDACWKNCV
Design
Indoor Unit
Outdoor Unit
Net Weight Indoor Unit 11.5 11.5 10.1 10.1
Outdoor Unit 38.1 55.6 32.4 32.4
Net Dimension Indoor Unit 1055*299*215 1055*299*215 889*299*215 889*299*215
Outdoor Unit 880*638*310 880*798*310 790*548*285 790*548*285
Noise Indoor Unit 48dB↓ 51dB↓ 41dB↓ 43dB↓
Outdoor Unit 57dB↓ 60dB↓ 51dB↓ 53dB↓
Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER
Indoor Display 88 SEG 88 SEG 88 SEG 88 SEG
Model DEVELOPMENT MODEL
AR15CSDACWKNCV AR18CSDACWKNCV AR24CSDACWKNCV AR24CSDADWKNCV
Design
Indoor Unit
Outdoor Unit
Net Weight Indoor Unit 11.5 11.5 12.5 13.3
Outdoor Unit 49.0 55.6 68.2 55.6
Net Dimension Indoor Unit 1055*299*215 1055*299*215 1055*299*215 1055*299*215
Outdoor Unit 880*798*310 880*798*310 940*998*330 940*998*330
Noise Indoor Unit 46dB↓ 48dB↓ 51dB↓ 51dB↓
Outdoor Unit 57dB↓ 57dB↓ 60dB↓ 60dB↓
Air Purifying System EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER EASY CLEAN FILTER
Indoor Display 88 SEG 88 SEG 88 SEG 88 SEG

13
2-4 Accessoryand Option Specifications
Item Descriptions Code No. Q’ty Remark
ASSY HANGER
DB90-11453A
(Q1, Q2)
1
Indoor unit case
DB90-11454A
(Q3)
1
ASSY WIRELESS REMOCON DB96-25318V 1
MANUAL USER DB68-12013A 1
MANUAL INSTALL DB68-12003A 1
Batteries for Remote controller 4301-000121 2
Rubber Leg DB67-01533A 4
Outdoor unit
case
Drain plug
DB67-20011A 1

14
3-1 Test Mode
u
How to Approach Test Mode
You can approach the test mode by pressing the on/off
switch of indoor unit for 5 seconds.
u
Test mode operation option
After installing the air conditioner, check whether each subordinate is normally operated or not by
operating the test mode.
• When an Error occurs, display the Error Mode.
• Operation Mode : Cool mode. operate the cool mode by operating the compressor by force
without the compressor ON/OFF according to the set temperature/indoor temperature. (Do not
follow the antifreeze control)
• Up-down louver : Up-down swing mode
• Indoor Fan : Turbo
Note
• Because the heat mode operate the cool mode by force not related to the set temperature
/ indoor temperature, check whether each subordinate is operated normally or not after
completing installation and must turn off the power of the air conditioner.
3. Alignment and Adjustments

15
3-2 Display Error and Check Method
3-2-1 Indoor Display Error and Check Mathod
ERROR MODE TYPE
DESCRIPTION
7-SEG INDOOR/
OUTDOOR
C101, C102
INDOOR
Communication error
C108 Set address error
C121 Room TH sensor error
C122, C123 INDOOR MID, INDOOR IN EVA-TH sensor error
C140 Dust sensor error
C142 Humidity error
C143 Motion sensor error
C154 Fan error(indoor)
C161 Mixed operation error
C163 Option error
C187 K1lterfeedbackerror
C665 Drain pump error
*Note*
If the set doesn’t work (No power), check the thermal fuse of terminal block OPEN or
SHORT with Multimeter.
*MeasurethethermalfusehousingPIN#1~2:OPEN(disconnection)->defectiveproduct

16
3-2 Display Error and Check Method
3-2-2 Outdoor Display Error and Check Mathod
ERROR MODE DESCRIPTION
7-SEG YEL GRN RED
-Power off /VDD NG
-Power on reset (1sec)
-Normal operation
-Abnormal communication
(Indoor <-> Outdoor)
-
C464 IPM over current (O.C) error
C461 Comp. strating error
C470 EEPROM data error (no data)
C466 DC-Link voltage under / Over error
C484 PFC over load error
C483 Over voltage protection error
C221 OUT-TH (Outdoor temperature) sensor error
C416 DIS-TH (Discharge temperature) Over error
C251 DIS-TH (Discharge temperature) sensor error
C468 Current sensor error
C474 Heatsink sensor error
C485 Input current sensor error
C465 Comp. V_limit/ I_limit error
C500 Heatsinkover temperature error
C231 CON-TH (Cond temperature) sensor error
C203 Time out Comp. (Inv Micom <->Main Micom)
C458 Fan error
C471
EEPROM data error (Main Micom <-> INV Micom)
C467 Comp. wire missing error
C440 Prohibit operation condition error (Heating)
C441 Prohibit operation condition error (Cooling)
C469 DC-Link voltage sensor
C488 AC Input voltage sensor
C462 AC Input I_limit trip error
C554 Gas leak error
C574 Gas shortage error
C422 EEV or valve close error-self diagnosis
-Test operation at Cooling mode
-Test operation at Heating mode
:LAMP ON : LAMP OFF : LAMP BLINK

17
3-3 Setting Option Setup Method
Step 2
Enter the Options Setup mode and select your options asscording to the following procedure.
Ex) Option No. :
Step 1
Enter the Option Setup mode.
1. Tack out the batteries of remote control.
2. Press the temperaturebutton simultaneously and insert the battery again.
3. Make sure the remote control display shown as
Setting option SEG1
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Press the button to set Cool mode.
5
4
3
2
1
MethodDisplay
Setting option SEG2
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG3
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG4
Press the button the display panel to .
Press the button repeatedly to select .
⋯

18
6
7
8
9
10
11
12
13
14
Method Display
Press the button to set Dry mode.
Setting option SEG5
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG6
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG7
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG8
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG9
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG10
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Press the button to set Fan mode.
Press the button to set Heat mode.

19
15
16
17
18
19
20
21
22
23
MethodDisplay
Setting option SEG16
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG15
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG14
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG13
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG11
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG12
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Press the button to set Auto mode.
Press the button to set Cool mode.
Press the button to set Dry mode.

20
24
25
26
27
28
29
Method Display
Press the button to set Fan mode.
Press the button to set Heat mode.
Setting option SEG17
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG18
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG19
Press the button the display panel to .
Press the button repeatedly to select .
⋯
Setting option SEG20
Press the button the display panel to .
Press the button repeatedly to select .
⋯
