Floor Standing Unit
AM✴✴✴JNFDCH✴
AM✴✴✴JNGDCH✴
Air Conditioner
user manual
This manual is made with 100% recycled paper.
EN ES FR
imagine the possibilities
Thank you for purchasing this Samsung product.
DB68-05450A-00
k}tGmGzjz]piW\[\WhTWWluUGGGZ YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

2
Features of your new air conditioner
Cool Summer Oer
On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool
comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest. This
summer, beat the heat with your own air conditioner.
Cost Ecient System
Your new air conditioner not only provides maximum cooling power in the summer, but can also be an efficient
heating method in the winter with the advanced“Heat pump” system. This technology is up to 300% more efficient
than electrical heating, so you can further reduce its running cost. Now, meet year-round needs with one air
conditioner.
Flexible installation
Duct type air conditioner is designed to be slimmer and offers different solutions for any shape room allowing for
specific air flow requirements. Also, the air intake can be set up on either the bottom or rear of the unit, so there is
more flexibility in installation.
k}tGmGzjz]piW\[\WhTWWluUGGGY YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

3
ENGLISH
Contents
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Viewing your air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Using your air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning and maintaining the air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
k}tGmGzjz]piW\[\WhTWWluUGGGZ YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

4
Safety precautions
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the extensive
features and functions of your new appliance.
Because the following operating instructions cover various models,
the characteristics of your air conditioner may differ slightly from those
described in this manual. If you have any questions, call your nearest
contact center or find help and information online at www.samsung.com.
Important safety symbols and precautions:
WARNING Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION Hazards or unsafe practices that may result in minor
personal injury or property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric
shock.
Unplug the power plug from the wall socket.
Do NOT disassemble.
FOR INSTALLATION WARNING
Use the power line with the power specications of the product or
higher and use the power line for this appliance only. In addition, do
not use an extension line.
XExtending the power line may result in electric shock or fire.
XDo not use an electric transformer. It may result in electric shock or fire.
XIf the voltage/frequency/rated current condition is different, it may
cause fire.
k}tGmGzjz]piW\[\WhTWWluUGGG[ YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

5
ENGLISH
FOR INSTALLATION WARNING
The installation of this appliance must be performed by a qualied
technician or service company.
XFailing to do so may result in electric shock, fire, explosion, problems
with the product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
XFailing to do so may result in electric shock or fire.
Fix the outdoor unit rmly so that the electric part of the outdoor
unit is not exposed.
XFailing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inammable material.
Do not install this appliance in a humid, oily or dusty location, in a
location exposed to direct sunlight and water (rain drops). Do not
install this appliance in a location where gas may leak.
XThis may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high
external wall where it could fall.
XIf the outdoor unit falls, it may result in injury, death or property
damage.
This appliance must be properly grounded. Do not ground the
appliance to a gas pipe, plastic water pipe, or telephone line.
XFailure to do so may result in electric shock, fire, an explosion, or other
problems with the product.
XNever plug the power cord into a socket that is not grounded correctly
and make sure that it is in accordance with local and national codes.
k}tGmGzjz]piW\[\WhTWWluUGGG\ YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

6
Safety precautions
FOR INSTALLATION CAUTION
Install your appliance on a level and hard oor that can support its
weight.
XFailing to do so may result in abnormal vibrations, noise, or problems
with the product.
Install the draining hose properly so that water is drained correctly.
XFailing to do so may result in water overflowing and property damage.
When installing the outdoor unit, make sure to connect the draining
hose so that draining is performed correctly.
XThe water generated during the heating operation by the outdoor unit
may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death
or property damage.
FOR POWER SUPPLY WARNING
When the circuit breaker is damaged, contact your nearest service
center.
Do not pull or excessively bend the power line. Do not twist or tie
the power line. Do not hook the power line over a metal object,
place a heavy object on the power line, insert the power line
between objects, or push the power line into the space behind the
appliance.
XThis may result in electric shock or fire.
FOR POWER SUPPLY CAUTION
When not using the air conditioner for a long period of time or
during a thunder/lightning storm, cut the power at the circuit
breaker.
XFailing to do so may result in electric shock or fire.
k}tGmGzjz]piW\[\WhTWWluUGGG] YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

7
ENGLISH
FOR USING WARNING
If the appliance is ooded, please contact your nearest service
center.
XFailing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or
smoke, unplug the power plug immediately and contact your
nearest service center.
XFailing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.),
ventilate immediately without touching the power line.
Do not touch the appliance or power line.
XDo not use a ventilating fan.
XA spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service
center.
XFailing to do so may result in problems with the product, water leakage,
electric shock, or fire.
XA delivery service for the product is not provided. If you reinstall the
product in another location, additional construction expenses and an
installation fee will be charged.
XEspecially, when you wish to install the product in an unusual location
such as in an industrial area or near the seaside where it is exposed to
the salt in the air, please contact your nearest service center.
Do not touch the circuit breaker with wet hands.
XThis may result in electric shock.
Do not strike or pull the air conditioner with excessive force.
XThis may result in fire, injury, or problems with the product.
Do not place an object near the outdoor unit that allows children to
climb onto the machine.
XThis may result in children seriously injuring themselves.
k}tGmGzjz]piW\[\WhTWWluUGGG^ YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

8
Safety precautions
FOR USING WARNING
Do not turn the air conditioner o with the circuit breaker while it is
operating.
XTurning the air conditioner off and then on again with the circuit
breaker may cause a spark and result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials
well out of the reach of children, as packaging materials can be
dangerous to children.
XIf a child places a bag over its head, it may result in suffocation.
Do not insert your ngers or foreign substances into the outlet
when the air conditioner is operating or the front panel is closing.
XTake special care that children do not injure themselves by inserting
their fingers into the product.
Do not touch the front panel with your hands or ngers during the
heating operation.
XThis may result in electric shock or burns.
Do not insert your ngers or foreign substances into the air inlet/
outlet of the air conditioner.
XTake special care that children do not injure themselves by inserting
their fingers into the product.
Do not use this air conditioner for long periods of time in badly
ventilated locations or near inrm people.
XSince this may be dangerous due to a lack of oxygen, open a window at
least once an hour.
If any foreign substance such as water has entered the appliance,
cut the power by unplugging the power plug and turning the circuit
breaker o and then contact your nearest service center.
XFailing to do so may result in electric shock or fire.
k}tGmGzjz]piW\[\WhTWWluUGGG_ YWX\TW\TW_GGG㝘㤸GXWa\\aZ`

9
ENGLISH
FOR USING WARNING
Do not attempt to repair, disassemble, or modify the appliance
yourself.
XDo not use any fuse (such as cooper, steel wire, etc.)other than the
standard fuse.
XFailing to do so may result in electric shock, fire, problems with the
product, or injury.
FOR USING CAUTION
Do not place objects or devices under the indoor unit.
XWater dripping from the indoor unit may result in fire or property
damage.
Check that the installation frame of the outdoor unit is not broken at
least once a year.
XFailing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and
current is measured according to ISO standard for energy eciency.
Do not stand on top of the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal
objects, etc.) on the appliance.
XThis may result in electric shock, fire, problems with the product, or
injury.
Do not operate the appliance with wet hands.
XThis may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of
the appliance.
XAs well as being harmful to humans, it may also result in electric shock,
fire or problems with the product.
Do not drink the water from the air conditioner.
XThe water may be harmful to humans.
k}tGmGzjz]piW\[\WhTWWluUGGG` YWX\TW\TW_GGG㝘㤸GXWa\\aZ`
