Samsung AC052BN4PKG User manual

Air conditioner
User manual
AC***BN4PKG
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this user manual carefully and retain it for future
reference.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGX YWYYTW[TY`GGG㝘䟸GYaX^aZY

2English
Contents
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories
(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of
their working life. To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact eitherthe retailerwhere they purchased this product, or their local
government office, for details of where and how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract.
This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
For information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g.
REACH, visit: www.samsung.com/uk/aboutsamsung/sustainability/environment/our-commitment/data/
Safety Information 3
Safety Information 3
At a Glance 13
Indoor Unit Overview 13
Operation Features 14
Operating temperature and humidity 14
Cleaning and Maintenance 15
Cleaning and Maintaining 15
Cleaning the indoor unit exterior • Cleaning the outdoor unit heat exchanger 15
Disassembling the air filter 16
Cleaning the air filter • Reassembling the air filter 17
Resetting the air filter 18
Periodical maintenance 19
Troubleshooting 20
Technical specifications 24
Information about refrigerant 24
Important information: regulation regarding the refrigerant used 24
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGY YWYYTW[TY`GGG㝘䟸GYaX^aZY

3
English
Safety Information
Before using your new air conditioner, please read this manual
thoroughly to ensure that you know how to safely and efficiently
operate the extensive features and functions of your new appliance.
Because the following operating instructions cover various models,
the characteristics of your air conditioner may differ slightly from
those described in this manual. If you have any questions, call your
nearest contact centre or find help and information online at www.
samsung.com.
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut-off the power supply.
Do NOT disassemble.
Safety Information
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGZ YWYYTW[TY`GGG㝘䟸GYaX^aZZ

4
Safety Information
English
Safety Information
FOR INSTALLATION
Use the power line with the power specifications of the product
or higher and use the power line for this appliance only.
In addition, do not use an extension line.
• Extending the power line may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric
shock or fire.
• If the voltage/frequency/rated current condition is different, it
may cause fire.
The installation of this appliance must be performed by a
qualified technician or service company.
• Failing to do so may result in electric shock, fire, explosion,
problems with the product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
Fix the outdoor unit firmly so that the electric part of the outdoor
unit is not exposed.
• Failing to do so may result in electric shock or fire.
Do not install this appliance near a heater or open flame, as it
contains inflammable materials and substances. Do not install
this appliance in a humid, oily or dusty location, in a location
exposed to direct sunlight and water (rain drops). Do not install
this appliance in a location where gas may leak.
• This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high
external wall where it could fall.
• If the outdoor unit falls, it may result in injury, death or
property damage.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGG[ YWYYTW[TY`GGG㝘䟸GYaX^aZZ

5
English
Safety Information
This appliance must be properly grounded. Do not ground the
appliance to a gas pipe, plastic water pipe, ortelephone line.
• Failure to do so may result in electric shock, fire, an explosion,
or other problems with the product.
• Never plug the power cord into a socket that is not grounded correctly
and make sure that it is in accordance with local and national codes.
CAUTION
Install your appliance on a level and hard floor that can support
its weight.
• Failing to do so may result in abnormal vibrations, noise, or
problems with the product.
Install the drain hose properly so that water is drained correctly.
• Failing to do so may result in water overflowing and property
damage. Avoid adding drain to waste pipes as odours may
arise in the future.
The product shall be stored in a room with no ignition sources
(e.g. open flames, gas appliance, electric heater, etc.).
• Note that the refrigerant has no odour.
When using the outdoor unit for heating, make sure not to
connect a drain hose, a drain plug and a drain cap so that
draining is performed more rapidlywith less risk of freezing.
• The water generated during the heating operation in the
outdoor unit may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in
injury, death or property damage.
Do not install the product in a place where thermo-hygrostat is
needed (such as server room, machinery room, computer room, etc.)
• Those places do not provide guaranteed operation condition of
the product therefore performance can be poor in these places.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGG\ YWYYTW[TY`GGG㝘䟸GYaX^aZZ

6
Safety Information
English
Safety Information
FOR POWER SUPPLY
When the circuit breaker is damaged, contact your nearest
service centre.
Do not pull or excessively bend the power line. Do not twist or tie
the power line. Do not hook the power line over a metal object,
place a heavy object on the power line, insert the power line
between objects, or push the power line into the space behind
the appliance.
• This may result in electric shock or fire.
CAUTION
When not using the air conditioner for a long period of time or
during a thunder/lightning storm, cut the power at the circuit
breaker.
• Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service
centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or
smoke, cut-off the power supply immediately and contact the
nearest service center.
• Failing to do so may result in electric shock or fire.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGG] YWYYTW[TY`GGG㝘䟸GYaX^aZZ

7
English
Safety Information
In case of a malfunction, immediately stop operation of the
air conditioner and disconnect the entire power system. Then
consult the authorized service personnel.
In the event of a gas leak (such as propane gas, LP gas, etc.),
ventilate immediately without touching the power line. Do not
touch the appliance or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest
service centre.
• Failing to do so may result in problems with the product,
water leakage, electric shock, or fire.
• A delivery service for the product is not provided. If
you reinstall the product in another location, additional
construction expenses and an installation fee will be charged.
• Especially, when you wish to install the product in an unusual
location such as in an industrial area or near the seaside
where it is exposed to salt in the air, please contact your
nearest service centre.
Do not touch the circuit breakerwith wet hands.
• This may result in electric shock.
Do not turn the air conditioner off with the circuit breaker while
it is operating.
• Turning the air conditioner off and then on again with the
circuit breaker may cause a spark and result in electric shock
or fire.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGG^ YWYYTW[TY`GGG㝘䟸GYaX^aZZ

8
Safety Information
English
Safety Information
After unpacking the air conditioner, keep all packaging materials
well out of the reach of children, as packaging materials can be
dangerous to children.
• If a child places a bag over its head, it may result in
suffocation.
Do not touch the front panel with your hands or fingers during
the heating operation.
• This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the outlet
when the air conditioner is operating or the front panel is closing.
• Take special care that children do not injure themselves by
inserting their fingers into the product.
Do not insert your fingers or foreign substances into the air inlet/
outlet of the air conditioner.
• Take special care that children do not injure themselves by
inserting their fingers into the product.
Do not strike or pull the air conditionerwith excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object nearthe outdoor unit that allows children
to climb onto the machine.
• This may result in children seriously injuring themselves.
Do not use this air conditioner for long periods of time in badly
ventilated locations or near infirm people.
• Since this may be dangerous due to a lack of oxygen, open a
window at least once an hour.
Do not use means to accelerate the defrost operation or to clean,
other than those recommended by Samsung.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGG_ YWYYTW[TY`GGG㝘䟸GYaX^aZZ

9
English
Safety Information
If any foreign substance such as water has entered the appliance,
cut-off the power supply and contact the nearest service center.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance
yourself.
• Do not use any fuse (such as copper, steel wire, etc.)other than
the standard fuse.
• Failing to do so may result in electric shock, fire, problems
with the product, or injury.
CAUTION
Do not place objects or devices under the indoor unit.
• Water dripping from the indoor unit may result in fire or
property damage.
Check that the installation frame of the outdoor unit is not
broken at least once a year.
• Failing to do so may result in injury, death or property
damage.
Max current is measured according to IEC standard for safety
and current is measured according to ISO standard for energy
efficiency.
When the air conditioner does not operate properly for cooling
or heating, there is a possibility of refrigerant leakage. If any
leakage, stop operation, ventilate the room, and consult your
dealer immediately for recharging refrigerant.
The refrigerant is not harmful. However, if it comes in contact
with fire, it may generate harmful gases and there is risk of fire.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGG` YWYYTW[TY`GGG㝘䟸GYaX^aZZ

10
Safety Information
English
Safety Information
During transportation of the indoor unit, the pipe lines shall be
covered with brackets for protection. Do not move the product
with holding the pipe lines.
• It may cause gas leakage.
Do not install the product in a ship or a vehicle (such as a
campervan).
• Salt, vibration or other environmental factor may cause the
product malfunction, electric shock or fire.
Do not stand on top of the appliance or place objects (such as
laundry, lighted candles, lighted cigarettes, dishes, chemicals,
metal objects, etc.) on the appliance.
• This may result in electric shock, fire, problems with the
product, or injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the
surface of the appliance.
• As well as being harmful to humans, it may also result in
electric shock, fire or problems with the product.
Do not drink the water from the air conditioner.
• The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not
disassemble the remote controller.
Do not touch the pipes connected with the product.
• This may result in burns or injury.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGXW YWYYTW[TY`GGG㝘䟸GYaX^aZZ

11
English
Safety Information
Do not cut or burn the refrigerant container or pipings.
Do not point the air direction to the fireplace or heater.
Do not use this air conditioner to preserve precision equipment,
food, animals, plants or cosmetics, or for any other unusual
purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the air flow
from the air conditioner for long periods of time.
• This may result in harm to humans, animals or plants.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
For use in Europe: This appliance can be used by children aged
from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGXX YWYYTW[TY`GGG㝘䟸GYaX^aZZ

12
Safety Information
English
Safety Information
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it.
Do not use benzene, thinner, alcohol or acetone to clean the
appliance.
• This may result in discoloration, deformation, damage, electric
shock or fire.
Before cleaning or performing maintenance, cut-off the power
supply and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Take care when cleaning the surface of the heat exchanger of the
outdoor unit since it has sharp edges.
• To avoid cutting your fingers, wear thick cotton gloves when
cleaning it.
• This should be done by a qualified technician please contact
your installer or service centre.
Do not clean the inside of the air conditioner by yourself.
• For cleaning inside the appliance, contact your nearest service
centre.
• When cleaning the internal filter, refer to the descriptions in
the ‘Cleaning and Maintaining’ section.
• Failure to do may result in damage, electric shock or fire.
• Make sure to prevent any injury from sharp edges of the
surface when handling the heat exchanger.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGXY YWYYTW[TY`GGG㝘䟸GYaX^aZZ

13
English
At a Glance
02
04
03
01
01 Display
02 Air flow blade/Air outlet (inside) /
Wind-Free panel
(You can use the Wind-Free Cooling function
when the Cool, Dry, or Fan mode is running.)
(Refer to the remote control manual for
product operation)
Indication Function
On/Off operation indicator
Removing frost indicator
Timer indicator
Filter cleaning indicator
Remote control sensor
03 Air intake
04 Air filter (under the grille)
Indoor Unit Overview
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGXZ YWYYTW[TY`GGG㝘䟸GYaX^aZ[

14
Operation Features
English
At a Glance
Operating temperature and humidity
Mode Outdoor temperature Indoor temperature Indoor humidity
Cool mode ࣛߤߢঙϩͱߧߤঙ 18°C to 32°C 80% or less
Heat mode ࣛߤߧঙϩͱߤߦঙ 30°C or less -
Dry mode ࣛߤߢঙϩͱߧߤঙ 18°C to 32°C 80% or less
CAUTION
• If you use the air conditioner at a relative humidity above 80%, it may cause a formation of condensation
and a leakage of water on the floor.
• The rated heating capacity is based on an outdoor temperature of 7°C. If the outdoor temperature goes
down below 0°C, heating efficiencies may decrease depending on the temperature conditions.
• If the indoor unit is out of the operating temperature and humidity range, the safery device may operate
and the air conditioner may stops.
• If the indoor unit is installed in an IT room (for example, computer room), a separate back-up system
must be installed, and the reliability of our product cannot be guaranteed at temperatures outside the
operating temperature range.
Operation Features
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGX[ YWYYTW[TY`GGG㝘䟸GYaX^aZ[

15
English
Cleaning and Maintenance
Cleaning the indoor unit exterior
Wipe the surface of the unit with a slightly wet
or dry cloth when needed. Wipe off dirt of odd-
shaped areas by using a soft brush.
CAUTION
• Do not use alkaline detergent, sulphuric acid,
hydrochloric acid, or organic solvents (such as
thinner, kerosene, and acetone) to clean the
surfaces.
• Do not attach any stickers on the surfaces
because this may cause damage.
• When you clean the heat exchanger on the
indoor unit, you need to disassemble the
indoor unit. Therefore, you must contact the
local service center for help.
Cleaning the outdoor unit heat exchanger
Spray water to clean the dust.
NOTE
• When you clean and inspect the heat
exchanger on the outdoor unit, contact the
local service center for help.
CAUTION
• Make sure to prevent any injury from sharp
edges of the surface when handling the heat
exchanger.
Cleaning and Maintaining
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGX\ YWYYTW[TY`GGG㝘䟸GYaX^aZ[

16
Cleaning and Maintaining
English
Cleaning and Maintenance
Disassembling the air filter
CAUTION
• Before cleaning the indoor unit, be sure to turn off the auxiliary power switch.
• Be sure to hold the grille with a hand to prevent dropping from the opening of the front grille.
Push down the hooks at each side of the front
grille to open the grille.
NOTE
• The hooks are located on both sides of the
front grill with the Samsung logo.
Pull out the air filter from the indoor unit.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGX] YWYYTW[TY`GGG㝘䟸GYaX^aZ[

17
English
Cleaning and Maintenance
Cleaning the air filter
Clean the air filter with a vacuum cleaner or soft
brush. If dust is too heavy, then rinse it with
running water and dry it in a ventilated area.
CAUTION
Do not scrub the air filter with a brush or other
cleaning utensil. This may damage the filter.
NOTE
• If the air filter dries in a humid area, it may
produce offensive odours. Clean it again and
dry it in a well-ventilated area.
• The cleaning period may differ depending on
the usage and environmental conditions, so
clean the air filter every week if the indoor unit
is in the dusty area.
• You can request a filter cleaning service. Note
that it is a charged service.
Reassembling the air filter
CAUTION
• If the indoor unit is used without the air filter,
the indoor unit may be damaged due to dust.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGX^ YWYYTW[TY`GGG㝘䟸GYaX^aZ\

18
Cleaning and Maintaining
English
Cleaning and Maintenance
Resetting the air filter
After cleaning and reassembling the air filter,
be sure to reset the filter-cleaning reminder as
follows:
• Indoor unit with the wired remote control:
Press the Filter Reset button.
• Indoor unit with the wireless remote control:
Press the SettingɵЇϩϩͱ<or >࣑Filter
Reset࣒9˝Χθʪϑϑϩ˵ʪSet button.
NOTE
• The filter reset indicator blinks when the air
filter should be cleaned.
• If the angle of the air flow blade is changed
by opening the front grille for installation or
maintenance of the indoor unit, be sure to turn
off and then on the auxiliary switch before
operating the indoor unit again. If not, the
angle of the air flow blade may be changed and
the blades may not be closed after turning off
the indoor unit.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGX_ YWYYTW[TY`GGG㝘䟸GYaX^aZ\

19
English
Cleaning and Maintenance
Periodical maintenance
Unit Maintenance item Interval Requires qualified
technicians
Indoor
unit
Clean the airfilter. At least once a month
Clean the condensate drain pan. Once a year Required
Clean up the heat exchange. Once a year Required
Clean the condensate drain pipe. Once every 4 months Required
Replace the remote control batteries. At least once a year
Outdoor
unit
Clean the heat exchanger on the outside of the unit. Once every 4 months Required
Clean the heat exchanger on the inside of the unit. Once a year Required
Clean the electric components with jets of air. Once a year Required
Verify that all the electric components are firmly
tightened. Once a year Required
Clean the fan. Once a year Required
Verify that the fan assemblies are firmly tightened. Once a year Required
Clean the condensate drain pan. Once a year Required
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGX` YWYYTW[TY`GGG㝘䟸GYaX^aZ\

20
Cleaning and Maintaining
English
Cleaning and Maintenance
Troubleshooting
Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary
expense.
Problem Solution
The air conditioner
does not operate
immediately after it
has been restarted.
• Because of the protective mechanism, the appliance does not start
operating immediately to keep the unit from overloading. The air
conditioner will start in 3 minutes.
The air conditioner
does not operate
at all.
• Check whether the power is turned on, and then operate the air conditioner
again.
• Check whether the auxiliary power switch (MCCB, ELB) is turned on.
• If the auxiliary power switch (MCCB, ELB) is turned off, the air conditioner
does not work although you press the (Power) button.
• When you clean the air conditioner or do not use it for an extended period of
time, turn off the auxiliary power switch (MCCB, ELB).
• After the air conditioner is not used for an extended period of time, be sure
to turn on the auxiliary power switch (MCCB, ELB) 6 hours before starting
operation.
NOTE
• The auxiliary power switch (MCCB, ELB) is sold separately.
• Make sure that auxiliary power switch (MCCB, ELB) is installed in the
distribution box inside the building.
• If the air conditioner is turned off by the Timed off function, turn on the air
conditioner again by pressing the (Power) button.
The temperature
does not change.
• Check whether the Fan mode is running. In the Fan mode, the air conditioner
controls the set temperature automatically, and you cannot change the set
temperature.
Warm air does not
come out of the air
conditioner.
• Check whether the outdoor unit is designed for cooling only. In this case,
warm air does not come out although you select the Heat mode.
• Check whether the remote control is designed only for cooling only. Use a
remote control that supports both cooling and heating.
The fan speed does
not change.
• Check whether the Auto or Dry mode is running. In these modes, the air
conditioner controls the fan speed automatically, and you cannot change
the fan speed.
ki]_TXX]][hTWWpijhjGyZYGwytG~mG[l|luUGGGYW YWYYTW[TY`GGG㝘䟸GYaX^aZ\
