Samsung AVMKH020EA0 User manual

CONTENTSAIR CONDITIONER
11. Precautions
12. Numbering system of model
13. Product Specification
14. Installation
15. Disassembly and Reassembly
16. Refrigerating Cycle Diagram
17. Set up the Model Option
18. Troubleshooting
19. Exploded Views and Parts List
10. Wiring Diagram
11. Schematic Diagram
SERVICE
Manual
SYSTEM AIR CONDITIONER
(DVM Series)

Precautions
1
11. Cut off the power.
● Make sure to cut off the power before repair. If not, you may be damaged by an electric shock.
12. Do not install an outdoor unit on the apartment outside wall(or equivalent) for safety.
● Installing an outdoor unit on the apartment outside wall(or equivalent) is prohibited for the safety purpose. Service will not
be available for the outdoor unit where our servicemen can not access and the cost of moving the outdoor unit to the
service area will be borne by the customer.
● If requested by the customer, you shall discourage him to install an outdoor unit on the apartment outside wall(or
equivalent).
13. Keep the drain hose outlet free.
● Otherwise, air flow will get slow, which may hinder cooling capacity.
● Also, dew may be laden on the service valve.
14. Use of Certified Parts
● Use certified parts only. (An electric contact part, if broken down, shall not be repaired but replaced with a new one.
Remodeling shall be prohibited. In no case, the customer shall repair the product on his own because this is dangerous
enough to bring about breakdown or fire.)
15. Ban on Middle Connection of Power Cord
● Do not cut the power cord in the middle to be connected to other power cord nor use a middle socket between two power
cords. This is dangerous enough to bring about breakdown or fire.
16. Check Insulation
● After assembly, be sure to check insulation resistance.
(Use an insulation ohmmeter to measure the insulation resistance between the power cord and the earthing wire. Do not
supply power until it reads 30MΩ.)
17. Be sure to keep the symmetry of the product.
● Otherwise, you may hear vibration noise.
18. Caution for Children
● Do not keep children off the product while it is in repair. Otherwise, they might be endangered.
19. Be sure to put the indoor or outdoor unit free of corrosive gases such as sulfuric water,
ammonium, and sulfuric gas.
● Otherwise, copper tubes or soldered parts could be corroded causing refrigerant leak.
10. Arrangement of surroundings
● After repair finishes, clean the air conditioner and its surroundings and inform the customer of what it is like.
- 1 -
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 1

- 2 -
Model
AVM
!
K
@
H
#
020
$
E
%
A
^
00 0 0
@@@@@@@@e?
@@@@@@@@e?
@@h?
@@h?
@@h?
@@h?
@@h?
@@h?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
?@@
?@@
?@@
?@@
?@@
?@@
?@@@@@@@@
?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
@@g
@@g
@@g
@@g
@@g
@@g
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
&
2-1. Indoor unit and outdoor unit
2-1-1. Indoor unit
- 2 -
! Semi-finished product
Variable capacity free AVM
joint multi(DVM)
@ Classification of product
1-Way K
4-Way C
2-Way G
Exposed N
Low silhouette D
High pressure H
Low pressure L
Built-in B
Wall-mounted type W
Ceiling type F
Floor standing type (PAC) P
# Mode
Cooling only (C/O) C
Heat pump (H/P) H
H/P+Heater E
C/O+Heater G
C/O+Hot water heater N
% Power supply
220V, 60Hz B
208~230V, 60Hz C
220~240V, 50HZ E
^ Refrigerant
R22/R407C A
R410A C
& Version
-0
~1
~2
Cassette
type
Duct
type
$ Capacity (x1/10kW, 3 digits)
Btu/h Watt
50Hz 60Hz
7K 2,000W 2,000W
9K 2,600W 3,200W
12K 3,500W 4,000W
18K 5,200W 5,200W
20K 6,000W 6,000W
24K 7,000W 7,200W
28K 8,200W 8,300W
36K 10,500W 10,500W
44K 12,800W 12,800W
48K 14,000W 14,000W
Numbering system of model
2
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 2

- 3 -- 3 -
Model
RVM
!
H
@
060
#
C
$
B
%
M
^
00 0 0
@@@@@@@@e?
@@@@@@@@e?
@@h?
@@h?
@@h?
@@h?
@@h?
@@h?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
?@@
?@@
?@@
?@@
?@@
?@@
?@@@@@@@@
?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@
@@g
@@g
@@g
@@g
@@g
@@g
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
&
2-1-2. Outdoor unit
! Semi-finished product
Variable capacity free RVM
joint multi(DVM, DVM HR)
Fixed capacity fixed RFP
joint multi (DPM)
Module Multi RMA
Module Multi RMB
@ Mode
Cooling only (C/O) C
Heat pump (H/P) H
Heat recovery(DVM HR) R
# Capacity (x 1/10 HP, 3 digits)
& Version
^ Combination of indoor unit
1-Way K
2-Way G
4-Way C
Exposed N
Low silhouette D
High pressure H
Low pressure L
Built-in B
Wall-mounted type W
Ceiling type F
Floor standing type (PAC) P
Free M
$ Power supply
208~230V, 60Hz C
220V, 60Hz B
220~240V, 50Hz E
208~230V, 60Hz, 3ø F
380~415V, 50Hz, 3ø G
380V, 60Hz, 3ø H
460V, 60Hz, 3ø J
Cassette
type
Duct
type
% Refrigerant / Discharge direction
Refrigerant Discharge Classification
direction
R22 Upward A
Onward B
R470C Upward C
Onward D
R410A Upward E
Onward F
Numbering system of model
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 3

2-2. Indoor unit Version
2-2-1. 1-Way cassette type (K)
2-2-2. 2-Way cassette type (G)
2-2-3. 4-Way cassette type (C)
- 4 -
Numbering system of model
2
Version Modification
Indoor unit model
Heat Pump Cooling only
AVMKH020E(C)A0
AVMKH026EA0 AVMKH032CA0
AVMKH035EA0 AVMKH040CA0
AVMKC020E(C)A0
AVMKC026EA0 AVMKC032CA0
AVMKC035EA0 AVMKC040CA0
-0
AVMKH020E(C)A1
AVMKH026EA1 AVMKH032CA1
AVMKH035EA1 AVMKH040CA1
AVMKC020E(C)A1
AVMKC026EA1 AVMKC032CA1
AVMKC035EA1 AVMKC040CA1
- Built in electric expansion valve1
AVMKH020E(C)A3
AVMKH026EA3 AVMKH032CA3
AVMKH035EA3 AVMKH040CA3
AVMKC020E(C)A3
AVMKC026EA3 AVMKC032CA3
ACMKC035EA3 AVMKC040CA3
- Auto address setting for indoor unit
- Applicable non-polarity
communication
3
AVMKH020E(C)A4
AVMKH026EA4 AVMKH032CA4
AVMKH035EA4 AVMKH040CA4
AVMKC020E(C)A4
AVMKC026EA4 AVMKC032CA4
ACMKC035EA4 AVMKC040CA4
- DVM HR indoor4
Version Modification
Indoor unit model
Heat Pump Cooling only
AVMGH052E(C)A3 AVMGH070EA3
AVMGH072CA3
AVMGC052E(C)A3 AVMGC070EA3
AVMGC072CA3
- Auto address setting for indoor unit
- Applicable non-polarity
communication
3
AVMGH052E(C)A4 AVMGH070EA4
AVMGH072CA4
AVMGC052E(C)A4 AVMGC070EA4
AVMGC072CA4 - DVM HR indoor4
Version Modification
Indoor unit model
Heat Pump Cooling only
AVMCH052E(C)A0 AVMCH070EA0
AVMCH105E(C)A0
AVMCC052E(C)A0 AVMCC070EA0
AVMCC105E(C)A0 -
- Auto address setting for Indoor unit
- Applicable non-polarity
communication
0
1
3
AVMCH052E(C)A1 AVMCH070EA1
AVMCH105E(C)A1 AVMCH140E(C)A1
AVMCC052E(C)A1 AVMCC070EA1
AVMCC105E(C)A1 AVMCC140E(C)A1
AVMCH052E(C)A3 AVMCH070EA3
AVMCH105E(C)A3 AVMCH140E(C)A3
AVMCC052E(C)A3 AVMCC070EA3
AVMCC105E(C)A3 AVMCC140E(C)A3
- DVM HR indoor4AVMCH052E(C)A4 AVMCH070EA4
AVMCH105E(C)A4 AVMCH140E(C)A4
AVMCC052E(C)A4 AVMCC070EA4
AVMCC105E(C)A4 AVMCC140E(C)A4
- New Design indoor
- Modify the specification of
drain hose
- Additional capacity of indoor unit
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 4

2-2. ???
2-2-4. Duct type (Silhouette : D)
2-2-5. Duct type (High pressure : H)
2-2-6. Duct type (Low pressure : L)
- 5 -
Numbering system of model
Version Modification
Indoor unit model
Heat Pump Cooling only
AVMDH052E(C)A0 AVMDH070EA0
AVMDH072CA0
AVMDC052E(C)A0 AVMDC070EA0
AVMDC072CA0 -
- Auto address setting for indoor unit
- Applicable non-polarity
communication
0
3AVMDH052E(C)A3 AVMDH070EA3
AVMDH072CA3
AVMDC052E(C)A3 AVMDC070EA3
AVMDC072CA3
- DVM HR indoor4AVMDH052E(C)A4 AVMDH070EA4
AVMDH072CA4
AVMDC052E(C)A4 AVMC070EA4
AVMDC072CA4
Version Modification
Indoor unit model
Heat Pump Cooling only
AVMHH105E(C)A0 AVMHH128E(C)A0 AVMHC105E(C)A0 AVMHC128E(C)A0 -
- Auto address setting for indoor unit
- Applicable non-polarity
communication
0
3AVMHH105E(C)A3 AVMHH128E(C)A3
AVMHH140E(C)A3
AVMHC105E(C)A3 AVMHC128E(C)A3
AVMHC140E(C)A3
- DVM HR indoor4AVMHH105E(C)A4 AVMHH128E(C)A4
AVMHH140E(C)A4
AVMHC105E(C)A4 AVMHC128E(C)A4
AVMHC140E(C)A4
Version Modification
Indoor unit model
Heat Pump Cooling only
- Auto address setting for indoor unit
- Applicable non-polarity
communication
3AVMLH105E(C)A3 AVMLH128E(C)A3
AVMLH140E(C)A3
AVMLC105E(C)A3 AVMLC128E(C)A3
AVMLC140E(C)A3
- DVM HR indoor4AVMLH105E(C)A4 AVMLH128E(C)A4
AVMLH140E(C)A4
AVMLC105E(C)A4 AVMLC128E(C)A4
AVMLC140E(C)A4
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 5

2-2-7. Duct type (Built-in : B)
2-2-8. Wall mounted type (W)
- 6 -
Numbering system of model
2
Version Modification
Indoor unit model
Heat Pump Cooling only
-
- Auto address setting for indoor unit
- Applicable non-polarity
communication
0
3
AVMBH020E(C)A0 AVMBH026EA0
AVMBH032CA0 AVMBH035EA0
AVMBH040CA0 AVMBH052E(C)A0
AVMBH070EA0 AVMBH072CA0
AVMBC020E(C)A0 AVMBC026EA0
AVMBC032CA0 AVMBC035EA0
AVMBC040CA0 AVMBC052E(C)A0
AVMBC070EA0 AVMBC072CA0
AVMBH020E(C)A3 AVMBH026EA3
AVMBH032CA3 AVMBH035EA3
AVMBH040CA3 AVMBH052E(C)A3
AVMBH070EA3 AVMBH072CA3
AVMBC020E(C)A3 AVMBC026EA3
AVMBC032CA3 AVMBC035EA3
AVMBC040CA3 AVMBC052E(C)A3
AVMBC070EA3 AVMBC072CA3
- DVM HR indoor4
AVMBH020E(C)A4 AVMBH026EA4
AVMBH032CA4 AVMBH035EA4
AVMBH040CA4 AVMBH052E(C)A4
AVMBH070EA4 AVMBH072CA4
AVMBC020E(C)A4 AVMBC026EA4
AVMBC032CA4 AVMBC035EA4
AVMBC040CA4 AVMBC052E(C)A4
AVMBC070EA4 AVMBC072CA4
Version Modification
Indoor unit model
Heat Pump Cooling only
-
- C&C grille design indoor unit
0
1
AVMWH020E(C)A0 AVMWH026EA0
AVMWH032CA0 AVMWH035EA0
AVMWH040CA0 AVMWH052E(C)A0
AVMWH070EA0 AVMWH072CA0
AVMWC020E(C)A0 AVMWC026EA0
AVMWC032CA0 AVMWC035EA0
AVMWC040CA0 AVMWC052E(C)A0
AVMWC070EA0 AVMWC072CA0
AVMWH020E(C)A1 AVMWH026EA1
AVMWH032CA1 AVMWH035EA1
AVMWH040CA1 AVMWH052E(C)A1
AVMWH070EA1 AVMWH072CA1
AVMWC020E(C)A1 AVMWC026EA1
AVMWC032CA1 AVMWC035EA1
AVMWC040CA1 AVMWC052E(C)A1
AVMWC070EA1 AVMWC072CA1
- Auto address setting for indoor unit
- Applicable non-polarity
communication
3
AVMWH020E(C)A3 AVMWH026EA3
AVMWH032CA3 AVMWH035EA3
AVMWH040CA3 AVMWH052E(C)A3
AVMWH070EA3 AVMWH072CA3
AVMWC020E(C)A3 AVMWC026EA3
AVMWC032CA3 AVMWC035EA3
AVMWC040CA3 AVMWC052E(C)A3
AVMWC070EA3 AVMWC072CA3
- DVM HR indoor4
AVMWH020E(C)A4 AVMWH026EA4
AVMWH032CA4 AVMWH035EA4
AVMWH040CA4 AVMWH052E(C)A4
AVMWH070EA4 AVMWH072CA4
AVMWC020E(C)A4 AVMWC026EA4
AVMWC032CA4 AVMWC035EA4
AVMWC040CA4 AVMWC052E(C)A4
AVMWC070EA4 AVMWC072CA4
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 6

2-2-9. Floor standing type (P)
2-2-10. Ceiling type (F)
2-3. Outdoor unit version
- 7 -
Numbering system of model
Version Modification
Indoor unit model
Heat Pump Cooling only
-0
AVMPH060E(C)A0 AVMPH070EA0
AVMPH072CA0 AVMPH082EA0
AVMPH083CA0
AVMPC060E(C)A0 AVMPC070EA0
AVMPC072CA0 AVMPC082EA0
AVMPC083CA0
- Auto address setting for indoor unit
- Applicable non-polarity
communication
3
AVMPH060E(C)A3 AVMPH070EA3
AVMPH072CA03 AVMPH082EA3
AVMPH083CA3
AVMPC060E(C)A3 AVMPC070EA3
AVMPC072CA3 AVMPC082EA3
AVMPC083CA3
- DVM HR indoor4
AVMPH060E(C)A4 AVMPH070EA4
AVMPH072CA4 AVMPH082EA4
AVMPH083CA4
AVMPC060E(C)A4 AVMPC070EA4
AVMPC072CA4 AVMPC082EA4
AVMPC083CA4
Version Modification
Indoor unit model
Heat Pump Cooling only
-0 AVMFH052E(C)A0 AVMFH070EA0
AVMFH072CA0
AVMFC052E(C)A0 AVMFC070EA0
AVMFC072CA0
- Auto address setting for indoor unit
- Applicable non-polarity
communication
3AVMFH052E(C)A3 AVMFH070EA3
AVMFH072CA3
AVMFC052E(C)A3 AVMFC070EA3
AVMFC072CA3
- DVM HR indoor4AVMFH052E(C)A4 AVMFH070EA4
AVMFH072CA4
AVMFC052E(C)A4 AVMFC070EA4
AVMFC072CA4
Version Modification
Indoor unit model
Heat Pump Cooling only
- Auto address setting for indoor unit
- Applicable non-polarity
communication
3RVMH060GDM3 RVMH100GCM3
- Special anti-corrosion treatment
outdoor unit
5RVMH100FAM5 RVMH080FAM5 RVMC075CBM5 RVMC050CBM5
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 7

2-4. Accessories (options)
- 8 -
Numbering system of model
2
Classification Model Standard for model name Examples
MXD : Distributor kit
! : EEV Capacity (Double figures)
•14(For 2.0kW~4.0kW Capa Indoor)
•18(For 5.2kW~8.5kW Capa Indoor)
@ : Number of !Capa EEV
# : EEV Capacity (Double figures)
•14(For 2.0kW~4.0kW Capa Indoor)
•18(For 5.2kW~8.5kW Capa Indoor)
$ : Version
MXD-!K@#$
EEV Kit
(Distributor kit) :
Set 2 or
3 EEV
●MXD-14K300A
(3EA of 14
Capa EEV)
●MXD-14K218A
(2EA of 14
Capa EEV,
1EA of 18
Capa EEV)
MDF : Outdoor discharge duct
! : Hole size (ø, cm, Double figures)
@ : Version
MDF-!@
Discharge Duct ●MDF-45A
MCU : Mode change unit kit
! : Indoor unit connection
•4:4 indoor unit can be connected
•6:6 indoor unit can be connected
@ : Indoor power supply type
# : Refrigerant type
$ : Language
% : EEV existence
•E(EEV existence)
•blank(EEV nonexistence)
^ : Version
MCU-!@#$
MCU-%^
MCU Kit
(Mode change
unit kit) :
4, 6 Indoor unit
connection
●MCU-4ECEV0
-MCU for indoor
4 connection,
220~240V/50Hz
power supply,
English,
EEV existence
●MCU-4ECE0
MXJ : Refnet joint
Y : One packing for gas and liquid side
! : Inlet pipe diameter for gas side
(mm, Double figures)
@ : Inlet pipe diameter for liquid side
(mm, Double figures)
# : Version
MXJ-Y!@#
Refnet Joint ●MXJ-Y3112A
(MXJ-3112A: gas side +
MXJ-1206A : liquid side)
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 8

- 9 -
Numbering system of model
Classification Model Standard for model name Examples
MXJ : Refnet header
H : One packing for gas and liquid side
! : Inlet pipe diameter for gas side
(mm, Double figures)
@ : Inlet pipe diameter for liquid side
(mm, Double figures)
# : Version
MXJ-H!@#
Refnet Header ●MXJ-H3112A
MDP : Drain pump for separate sales
! : Lift(mm, Three figures)
@ : Inlet pipe diameter for liquid side
(mm, Double figures)
# : Version
MDP-!@#
Drain Pump ●MDP-075SA
! : G(Grille applicable, Front panel)
@ : Applicable indoor unit
•K : 1-Way cassette
•G : 2-Way cassette
•C : 4-Way cassette
•B : Built in duct
# : Function Classification
•H: Cooling only & Heat pump
•N: Not used wireless remote controller
$ : Size(Mark the longer part between the
width and length, cm, three figures)
% : Color(G: Gray, I: Ivory)
^ : Language [E: English only
^ : Language [C: Chinese
^ : Language [A: Arabic
^ : Language [M: 8 Languages
^ : Language [U: 3 Languages(˚F & Inch)]
& : Version
M!@#$%^&
Front Panel ●MGKH118IE0
- Overseas
- For 1W/C
- Heat Pump
- 8 Languages
MR : Wireless Remote controller
! : Design of Wireless Remote Controller
(A~compact)
@ : Function Classification
(C: For Cooling only, H: Heat pump)
#, $ : Version
MR-!@#$
Wireless Remote
Control
●MR-AC10
(Wireless
remote controller
for cooling only)
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 9

- 10 -
Numbering system of model
2
Classification Model Standard for model name Examples
MRW : Remote Control Receiver Kit Wire
! : Length(m, Double figures)
@ : Version
MRW-!@
Remote Control
Receiver wire
●MRW-10A
MWR : Wired Remote Control
! : Remote Control Design (A ~ Present)
@ : Function Classification
(C: For cooling only, H: Heat Pump )
#, $ : Version
% : Language [None: 9 Languages
% : Language [C: Chinese
% : Language [U: 3 Languages(˚F & Inch)]
MWR-!@#$%
Wired Remote
Control
●MWR-AH01
●MRK-A00MRK : Remote Control Receiver Kit
! : Receiver Kit design (A ~ present)
@ : Function Classification
(C: For cooling only, H: Heat Pump )
# : Version
MRK-!@#
Remote Control
Receiver Kit
(For Duct)
MCM : Controller
! : Function
•A: Controller
•B: Measuring instrument
•C: Others
@ : LCD Classification
(1:LCD 2: Non LCD)
#, $: Version
% : Language [None: 9 Languages
% : Language [C: Chinese
% : Language [U: 3 Languages(˚F & Inch)]
MCM-!@#$%
Controller ●MCM-A200
(Centralized Controller)
●MCM-A100
(Function Controller)
●MCM-B100
(Integrate power
distributor)
●MWC-083D0
(For 8300W of
Low silhouette)
MWC : Water Coil
!, @, # : Applicable Indoor unit Capacity
(x 10kW)
$ : Applicable products
(H : High pressure Duct, D: Small duct
B : Built-in Duct)
% : Version
MWC-!@#$%
Water Coil –
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 10

- 11 -
Numbering system of model
Classification Model Standard for model name Examples
●MIM-B00 :
Centralized
controller
interface module
(up to 10HP
outdoor unit)
●MIM-B04 :
Centralized
controller
interface module
(up to 34HP
outdoor unit)
●MIM-B01A :
PLC interface
Module
●MIM-B02 :
Key-Tag
interface module
●MIM-B04 :
UART interface
module
●MIM-B06 :
Integrate power
distributor
interface module
for PC metering
●MIM-B07 :
Longwork
interface module
●MIM-B08 :
Peak power
control interface
module
MIM : Interface Module
! : Applicable part
•A: Indoor unit
•B: Outdoor unit
•C: Others
@, # : Version
$ : Language
(None: 9 Languages, C: Chinese)
MIM-!@#$
Transmitter
(Interface Module)
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 11

- 12 -
Numbering system of model
2
2-5. Combination
2-5-1. Outdoor unit
■Cooling only
Power supplyDesign Model
60Hz 208~230V, 1øRVMC050CBM0
Capacity(HP)
5
Refrigerant
R22
50Hz
60Hz
50Hz
60Hz
380~415V, 3ø
380~415V, 3ø
208~230V, 3ø
RVMC060GAM0
RVMC060GAM1
RVMC070FAM0(5)
6
6
7
R22
R22
R22
380~415V, 3ø
208~230V, 3ø
RVMC100GAM0
RVMC100FAM0
10
10
R22
R22
•The system enables the connection of indoor units with a total capacity of between 50 to 120% of that of
the corresponding outdoor unit but where this capacity ratio exceeds 100% then the actual capacity of each
indoor unit will fall a little short of its individual rated capacity when all the units are operated simultaneously.
(Except for the Middle East models)
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 12

- 13 -
2-5. Combination
2-5-1. Outdoor unit
■Heat pump
■Heat recovery
Numbering system of model
Power supplyDesign Model
50Hz
60Hz
380~415V, 3ø
380~415V, 3ø
208~230V, 1ø
RVMH060GBM0
RVMH060GDM0(3)
RVMH050CBM0
Capacity(HP)
6
6
5
Refrigerant
R22
R407C
R22
50Hz
60Hz
380~415V, 3ø
380~415V, 3ø
208~230V, 3ø
RVMH100GAM0
RVMH100GCM0(3)
RVMH100FAM0(5)
10
10
10
R22
R407C
R22
380V, 3ø
380V, 3ø
380V, 3ø
380V, 3ø
380V, 3ø
380V, 3ø
380V, 3ø
380V, 3ø
380V, 3ø
RMAH140GAM✳
RMAH160GAM✳
RMAH180GAM✳
RMAH200GAM✳
RMAH220GAM✳
RMAH240GAM✳
RMAH260GAM✳
RMAH280GAM✳
RMAH300GAM✳
14
16
18
20
24
26
28
30
32
R22
R22
R22
R22
R22
R22
R22
R22
R22
Power supplyDesign Model
50Hz 380~415V, 3øRVMR100GCM0
Capacity(HP)
10
Refrigerant
R407C
•The system enables the connection of indoor units within 100%.
•The maximum number of connectable indoor unit should be computed on the basis of the minimum capacity
of indoor unit within 100%.
(But, the minimum capacity of RMAH✳✳✳ is 0.7HP.)
* Separate installation of
RMBH100GAM✳
*Note
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 13

2-5-2. Indoor unit
Numbering system of model
2
Design Power
supply
2.0kW
(7,000Btu/h)
2.6kW
(9,000Btu/h)
3.2kW
(11,000Btu/h)
3.5kW
(12,000Btu/h)
4.0kW
(13,500Btu/h)
5.2kW
(18,000Btu/h)
6.0kW
(20,000Btu/h)
AVMKC020EA✳
AVMKH020EA✳
AVMKC020CA✳
AVMKH020CA✳
-
-
-
-
-
-
-
-
-
-
-
-
AVMBC020EA✳
AVMBH020EA✳
AVMBC020CA✳
AVMBH020CA✳
-
-
-
-
AVMWC020EA✳
AVMWH020EA✳
AVMWC020CA✳
AVMWH020CA✳
-
-
-
-
-
-
-
-
Cool/
Heat
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
AVMKC026EA✳
AVMKH026EA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMBC026EA✳
AVMBH026EA✳
-
-
-
-
-
-
AVMWC026EA✳
AVMWH026EA✳
-
-
-
-
-
-
-
-
-
-
-
-
AVMKC032CA✳
AVMKH032CA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMBC032CA✳
AVMBH032CA✳
-
-
-
-
-
-
AVMWC032CA✳
AVMWH032CA✳
-
-
-
-
-
-
-
-
AVMKC035EA✳
AVMKH035EA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMBC035EA✳
AVMBH035EA✳
-
-
-
-
-
-
AVMWC035EA✳
AVMWH035EA✳
-
-
-
-
-
-
-
-
-
-
-
-
AVMKC040CA✳
AVMKH040CA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMBC040CA✳
AVMBH040CA✳
-
-
-
-
-
-
AVMWC040CA✳
AVMWH040CA✳
-
-
-
-
-
-
-
-
-
-
-
-
AVMGC052EA✳
AVMGH052EA✳
AVMGC052CA✳
AVMGH052CA✳
AVMCC052EA✳
AVMCH052EA✳
AVMCC052CA✳
AVMCH052CA✳
AVMDC052EA✳
AVMDH052EA✳
AVMDC052CA✳
AVMDH052CA✳
AVMBC052EA✳
AVMBH052EA✳
AVMBC052CA✳
AVMBH052CA✳
-
-
-
-
AVMWC052EA✳
AVMWH052EA✳
AVMWC052CA✳
AVMWH052CA✳
-
-
-
-
AVMFC052EA✳
AVMFH052EA✳
AVMFC052CA✳
AVMFH052CA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMPC060EA✳
AVMPH060EA✳
AVMPC060CA✳
AVMPH060CA✳
-
-
-
-
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
1-Way cassette type
2-Way cassette type
4-Way cassette type
Duct type(Low silhouette)
Duct type (Built-in)
Duct type
(High pressure,Low pressure)
Wall-mounted type
Floor standing type
Ceiling type
✳ The design and capacity of indoor unit are subject to change without notice.
- 14 -
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 14

- 15 -
✳ The design and capacity of indoor unit are subject to change without notice.
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Cooling only
Heat pump
Design
7.0kW
(24,000Btu/h)
7.2kW
(24,000Btu/h)
8.2kW
(28,000Btu/h)
8.3kW
(28,000Btu/h)
10.5kW
(36,000Btu/h)
12.8kW
(44,000Btu/h)
14.0kW
(48,000Btu/h)
-
-
-
-
AVMGC070EA✳
AVMGH070EA✳
-
-
AVMCC070EA✳
AVMCH070EA✳
-
-
AVMDC070EA✳
AVMDH070EA✳
-
-
AVMBC070EA✳
AVMBH070EA✳
-
-
-
-
-
-
AVMWC070EA✳
AVMWH070EA✳
-
-
AVMPC070EA✳
AVMPH070EA✳
-
-
AVMFC070EA✳
AVMFH070EA✳
-
-
-
-
-
-
-
-
AVMGC072CA✳
AVMGH072CA✳
-
-
AVMCC072CA✳
AVMCH072CA✳
-
-
AVMDC072CA✳
AVMDH072CA✳
-
-
AVMBC072CA✳
AVMBH072CA✳
-
-
-
-
-
-
AVMWC072CA✳
AVMWH072CA✳
-
-
AVMPC072CA✳
AVMPH072CA✳
-
-
AVMFC072CA✳
AVMFH072CA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMPC082EA✳
AVMPH082EA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMPC083CA✳
AVMPH083CA✳
-
-
-
-
-
-
-
-
-
-
-
-
AVMCC105EA✳
AVMCH105EA✳
AVMCC105CA✳
AVMCH105CA✳
-
-
-
-
-
-
-
-
AVMH(L)C105EA✳
AVMH(L)H105EA✳
AVMH(L)C105CA✳
AVMH(L)H105CA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMCC128EA✳
AVMCH128EA✳
AVMCC128CA✳
AVMCH128CA✳
-
-
-
-
-
-
-
-
AVMH(L)C128EA✳
AVMH(L)H128EA✳
AVMH(L)C128CA✳
AVMH(L)H128CA✳
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
AVMCC140EA✳
AVMCH140EA✳
AVMCC140CA✳
AVMCH140CA✳
-
-
-
-
-
-
-
-
AVMH(L)C140EA✳
AVMH(L)H140EA✳
AVMH(L)C140CA✳
AVMH(L)H128CA✳
-
-
-
-
-
-
-
-
-
-
-
-
1-Way cassette type
2-Way cassette type
4-Way cassette type
Duct type(Low silhouette)
Duct type (Built-in)
Duct type
(High pressure,Low pressure)
Wall-mounted type
Floor standing type
Ceiling type
Power
supply
Cool/
Heat
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
50Hz
60Hz
Numbering system of model
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 15

- 16 -
3-1. Indoor unit
3-1-1. 1-Way cassette type
■50Hz
- 16 -
Model
Power supply
Remark
Performance
Power
Piping connections
Set size
Panel size
Function /
Option
Cooling ✳ 1)
Heating ✳2)
Model
Type
Output
Air flow rate
(High/Low)
-
-
Liquid(Flare)
Gas(Flare)
Drain
Capacity
Sound level
Fan motor
Running current
Power input
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Auto restart
Auto change over
Centralized controller (On/Off)
Group/Individual control for R/C
Troubleshooting by L.E.D
Auto swing (Up/Down)
Max. installation ceiling height
Drain pump
AVMKC020EA✳AVMKC026EA✳AVMKC035EA✳AVMKH020EA✳AVMKH026EA✳AVMKH035EA✳
1, 220~240, 50
7,000 9,000 12,000 7,000 9,000 12,000
2.0 2.6 3.5 2.0 2.6 3.5
- - - 7,500 10,000 13,000
- - - 2.2 2.9 3.8
32/29 36/32 38/35 32/29 36/32 38/35
PFS040WTVE PFS040WTVE PFS040WTVE PFS040WTVE PFS040WTVE PFS040WTVE
Cross fan Cross fan Cross fan Cross fan Cross fan Cross fan
13 14 16 13 14 16
5.8 7.0 7.5 5.8/6.0 7.0/7.5 7.5/8.0
0.18 0.20 0.23 0.18 0.20 0.23
35 40 45 35 40 45
EEV(Electronic Expansion Valve) EEV(Electronic Expansion Valve)
6.35 6.35 6.35 6.35 6.35 6.35
12.7 12.7 12.7 12.7 12.7 12.7
15 15 15 15 15 15
18 18 18 18 18 18
970x180x390 970x180x390 970x180x390 970x180x390 970x180x390 970x180x390
1,168x302x467 1,168x302x467 1,168x302x467 1,168x302x467 1,168x302x467 1,168x302x467
3.5 3.5 3.5 3.5 3.5 3.5
6.2 6.2 6.2 6.2 6.2 6.2
1,180x35x460 1,180x35x460 1,180x35x460 1,180x35x460 1,180x35x460 1,180x35x460
1,259x144x539 1,259x144x539 1,259x144x539 1,259x144x539 1,259x144x539 1,259x144x539
Yes Yes Yes Yes Yes Yes
No No No No No No
Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
195 195 195 195 195 195
Yes Yes Yes Yes Yes Yes
Cooling only
Refrigerant control
VP 20, external diameter 26, internal diameter 20 VP 20, external diameter 26, internal diameter 20
Heat pump
Btu/h
kW
Btu/h
kW
dB
-
-
W
m3/min
A
W
mm
mm
mm
kg
kg
mm
mm
kg
kg
mm
mm
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
mm
Yes/No
ø, V, Hz
✳ 1) Nominal cooling capacities are based on:
✳ 1) - indoor temperature : 27˚C DB, 19˚C WB, outdoor temperature : 35˚C DB, Equivalent refrigerant piping : 10m(horizontal)
✳ 2) Nominal heating capacities are based on:
✳ 1) - indoor temperature : 20˚C DB, outdoor temperature : 7˚C DB, 6˚C WB Equivalent refrigerant piping : 10m(horizontal)
Product Specification
3
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 16

- 17 -
1-Way cassette type (cont.)
■60Hz
- 17 -
✳ 1) Nominal cooling capacities are based on:
✳ 1) - indoor temperature : 27˚C DB, 19˚C WB, outdoor temperature : 35˚C DB, Equivalent refrigerant piping : 10m(horizontal)
✳ 2) Nominal heating capacities are based on:
✳ 1) - indoor temperature : 20˚C DB, outdoor temperature : 7˚C DB, 6˚C WB Equivalent refrigerant piping : 10m(horizontal)
Product Specification
Model
Power supply
Remark
Performance
Power
Piping connections
Set size
Panel size
Function /
Option
Cooling ✳ 1)
Heating ✳2)
Model
Type
Output
Air flow rate
(High/Low)
-
-
Liquid(Flare)
Gas(Flare)
Drain
Capacity
Sound level
Fan motor
Running current
Power input
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Auto restart
Auto change over
Centralized controller (On/Off)
Group/Individual control for R/C
Troubleshooting by L.E.D
Auto swing (Up/Down)
Max. installation ceiling height
Drain pump
AVMKC020CA✳AVMKC032CA✳AVMKC035CA✳AVMKH020CA✳AVMKH032CA✳AVMKH035CA✳
1, 208~230, 60
7,000 11,000 13,500 7,000 11,000 13,500
2.0 3.2 4.0 2.0 3.2 4.0
- - - 7,500 12,000 14,500
- - - 2.2 3.5 4.3
32/29 36/32 38/35 32/29 36/32 38/35
PFS040WTVE PFS040WTVE PFS040WTVE PFS040WTVE PFS040WTVE PFS040WTVE
Cross fan Cross fan Cross fan Cross fan Cross fan Cross fan
13 14 16 13 14 16
5.8 7.5 8.0 5.8/6.0 7.5/8.0 8.0/8.5
0.18 0.20 0.23 0.18 0.20 0.23
35 40 45 35 40 45
EEV(Electronic Expansion Valve) EEV(Electronic Expansion Valve)
6.35 6.35 6.35 6.35 6.35 6.35
12.7 12.7 12.7 12.7 12.7 12.7
15 15 15 15 15 15
18 18 18 18 18 18
970x180x390 970x180x390 970x180x390 970x180x390 970x180x390 970x180x390
1,168x302x467 1,168x302x467 1,168x302x467 1,168x302x467 1,168x302x467 1,168x302x467
3.5 3.5 3.5 3.5 3.5 3.5
6.2 6.2 6.2 6.2 6.2 6.2
1,180x35x460 1,180x35x460 1,180x35x460 1,180x35x460 1,180x35x460 1,180x35x460
1,259x144x539 1,259x144x539 1,259x144x539 1,259x144x539 1,259x144x539 1,259x144x539
Yes Yes Yes Yes Yes Yes
No No No No No No
Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes Yes Yes Yes Yes Yes
Yes Yes Yes Yes Yes Yes
195 195 195 195 195 195
Yes Yes Yes Yes Yes Yes
Cooling only
Refrigerant control
VP 20, external diameter 26, internal diameter 20 VP 20, external diameter 26, internal diameter 20
Heat pump
Btu/h
kW
Btu/h
kW
dB
-
-
W
m3/min
A
W
mm
mm
mm
kg
kg
mm
mm
kg
kg
mm
mm
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
mm
Yes/No
ø, V, Hz
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 17

- 18 -
Product Specification
3
3-1-2. 2-Way cassette type
■50Hz
Model
Power supply
Remark
Performance
Power
Piping connections
Set size
Panel size
Function /
Option
Cooling ✳ 1)
Heating ✳2)
Model
Type
Output
Air flow rate
(High/Low)
-
-
Liquid(Flare)
Gas(Flare)
Drain
Capacity
Sound level
Fan motor
Running current
Power input
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Auto restart
Auto change over
Centralized controller (On/Off)
Group/Individual control for R/C
Troubleshooting by L.E.D
Auto swing (Up/Down)
Max. installation ceiling height
Drain pump
AVMGC052EA✳AVMGC070EA✳AVMGH052EA✳AVMGH070EA✳
1, 220~240, 50
18,000 24,000 18,000 24,000
5.2 7.0 5.2 7.0
- - 19,000 26,000
- - 5.6 7.6
40/36 42/40 40/36 42/40
PFS040AVEB PFS040AVEB PFS040AVEB PFS040AVEB
Cross Fan Cross Fan Cross Fan Cross Fan
14x2ea 14x2ea 14x2ea 14x2ea
14 14 14/16 14/16
0.38 0.40 0.38 0.40
70 75 70 75
9.52 9.52 9.52 9.52
15.88 15.88 15.88 15.88
21 21 21 21
25 25 25 25
890x230x575 890x230x575 890x230x575 890x230x575
1,077x642x299 1,077x642x299 1,077x642x299 1,077x642x299
4444
8888
1,030x25x650 1,030x25x650 1,030x25x650 1,030x25x650
1,103x151x727 1,103x151x727 1,103x151x727 1,103x151x727
Yes Yes Yes Yes
No No No No
Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes Yes Yes Yes
Yes Yes Yes Yes
255 255 255 255
Yes Yes Yes Yes
Cooling only
Refrigerant control
VP 25, external diameter 32, internal diameter 25 VP 25, external diameter 32, internal diameter 25
EEV(Electronic Expansion Valve) EEV(Electronic Expansion Valve)
Heat pump
Btu/h
kW
Btu/h
kW
dB
-
-
W
m3/min
A
W
mm
mm
mm
kg
kg
mm
mm
kg
kg
mm
mm
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
mm
Yes/No
ø, V, Hz
✳ 1) Nominal cooling capacities are based on:
✳ 1) - indoor temperature : 27˚C DB, 19˚C WB, outdoor temperature : 35˚C DB, Equivalent refrigerant piping : 10m(horizontal)
✳ 2) Nominal heating capacities are based on:
✳ 1) - indoor temperature : 20˚C DB, outdoor temperature : 7˚C DB, 6˚C WB Equivalent refrigerant piping : 10m(horizontal)
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 18

- 19 -
Product Specification
2-Way cassette type (cont.)
■60Hz
Model
Power supply
Remark
Performance
Power
Piping connections
Set size
Panel size
Function /
Option
Cooling ✳ 1)
Heating ✳2)
Model
Type
Output
Air flow rate
(High/Low)
-
-
Liquid(Flare)
Gas(Flare)
Drain
Capacity
Sound level
Fan motor
Running current
Power input
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Net weight
Shipping weight
Net dimension (WxHxD)
Shipping dimension (WxHxD)
Auto restart
Auto change over
Centralized controller (On/Off)
Group/Individual control for R/C
Troubleshooting by L.E.D
Auto swing (Up/Down)
Max. installation ceiling height
Drain pump
AVMGC052CA✳AVMGC072CA✳AVMGH052CA✳AVMGH072CA✳
1, 220~240, 50
18,500 24,000 18,500 24,000
5.5 7.2 5.5 7.2
- - 21,500 26,000
- - 6.4 7.6
40/36 42/40 40/36 42/40
PFS040AVEB PFS040AVEB PFS040AVEB PFS040AVEB
Cross Fan Cross Fan Cross Fan Cross Fan
14x2ea 14x2ea 14x2ea 14x2ea
14 14 14/16 14/16
0.38 0.40 0.38 0.40
70 75 70 75
9.52 9.52 9.52 9.52
15.88 15.88 15.88 15.88
21 21 21 21
25 25 25 25
890x230x575 890x230x575 890x230x575 890x230x575
1,077x642x299 1,077x642x299 1,077x642x299 1,077x642x299
4444
8888
1,030x25x650 1,030x25x650 1,030x25x650 1,030x25x650
1,103x151x727 1,103x151x727 1,103x151x727 1,103x151x727
Yes Yes Yes Yes
No No No No
Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes(Option) Yes(Option) Yes(Option) Yes(Option)
Yes Yes Yes Yes
Yes Yes Yes Yes
255 255 255 255
Yes Yes Yes Yes
Cooling only
Refrigerant control
VP 25, external diameter 32, internal diameter 25 VP 25, external diameter 32, internal diameter 25
EEV(Electronic Expansion Valve) EEV(Electronic Expansion Valve)
Heat pump
Btu/h
kW
Btu/h
kW
dB
-
-
W
m3/min
A
W
mm
mm
mm
kg
kg
mm
mm
kg
kg
mm
mm
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
mm
Yes/No
ø, V, Hz
✳ 1) Nominal cooling capacities are based on:
✳ 1) - indoor temperature : 27˚C DB, 19˚C WB, outdoor temperature : 35˚C DB, Equivalent refrigerant piping : 10m(horizontal)
✳ 2) Nominal heating capacities are based on:
✳ 1) - indoor temperature : 20˚C DB, outdoor temperature : 7˚C DB, 6˚C WB Equivalent refrigerant piping : 10m(horizontal)
DB98-17816A(2)_1~3 11/22/04 4:15 PM Page 19
