Samsung AVXCSH022EE User manual

Refer to the service manual in the GSPN(see the rear cover) for the more information.
AIR CONDITIONER CONTENTS
SYSTEM AIR CONDITIONER
INDOOR UNIT
AVXCSH022/028/036EE
ND022/028/0361HXEA/XSE
AVXC2H056/071EE
AVXC4H045/056/071/090/112/128/140EE
AVXC4H045/056/071/090/112/128/140EG
ND045/056/071/090/112/128/1404HXEA/XSE
AVXCMH028/036/056/060EE
AVXDSH022/028/036/045/056/071/090/112/128/140EE
ND022/028/036/045/056/071/090/112/128/140LHXEA
ND022/028/036/045/056/071/090/112/128/140LHXEA/XSE
AVXDUH056/071/090/112/128/140EE
ND056/071/090/112/128/140SHXEA/XSE
ND140HHXEA
AVXDUH210/280EG
ND200/220/280HHXEA
ND200/220/280HHXEA/XSE
ND220/280HHXEASTK
AVXTFH056/071EE
ND056/071CHXEA/XSE
AVXTJH028/036/056EE
ND028/036/056JHXEA/XSE
AVXWBH028/036/056/071EE
ND028/036/056/071BHXEA/XSE
AVXWNH022/028/036/056/071EE
ND022/028/036/056/071NHXEA/XSE
ND022/028/036/045/056/071QHXEA
AVXWVH022/028/036/056/071EE
ND022/028/036/056/071VHXEA/XSE
ND0561/0711HXEH
ND022/028/036/045/056/071QHXEB
ND022/028/036/045/056/071QHXEBSTK
OUTDOOR UNIT
RD080/100/120/140/160/180/200HHXGA
RD080/100/120/140/160/180/200HRXGA
RD080/100/120/140/160/180/200HHXGB
RD080/100/120/140/160/180/200HRXGB
RD080/100/120/140/160/180/200 HHXGASTK
RD080/100/120/140/160/180/200 HHXGASTK
RD080/100/120/140/160/180/200HHXGBXSE
1. Precautions
2. Product Specifications
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded Views and Parts List
6. PCB Diagram and Parts List
7. Wiring Diagram
8. Schematic Diagram
9. Reference Sheet
$9;&6+B$BFRLQGG 

Section 0
Samsung Electronics 1
Contents
1. Precautions
........................................................................................................................................
1-1
1-1 Precautions for the Service
............................................................................................................
1-1
1-2 Precautions for the Static Electricity and PL
...............................................................................
1-1
1-3 Precautions for the Safety
..............................................................................................................
1-1
1-4 Precautions for Handling Refrigerant for Air Conditioner
.......................................................
1-2
1-5 Precautions for Welding the Air Conditioner Pipe
.....................................................................
1-2
1-6 Precautions for Additional Supplement of Air Conditioner Refrigerant
...............................
1-2
1-7 Other Precautions
............................................................................................................................
1-2
2. Product Specifications
...............................................................................................................
2-1
2-1 The Feature of Product
...................................................................................................................
2-1
2-1-1 Feature
.....................................................................................................................................
2-1
2-1-2 Changes in comparison to basic model
...........................................................................
2-6
2-2 Product Specifacations
...................................................................................................................
2-10
2-2-1 Indoor Unit
..............................................................................................................................
2-10
2-2-2 Outdoor Unit
..........................................................................................................................
2-31
2-3 Accessory and Option Specifications
...........................................................................................
2-35
2-3-1 Accessories
..............................................................................................................................
2-35
3. Disassembly and Reassembly
...............................................................................................
3-1
3-1 Indoor Unit
.........................................................................................................................................
3-2
3-2 Outdoor Unit
.....................................................................................................................................
3-23
3-3 MCU
.....................................................................................................................................................
3-41
3-4 EEV KIT
................................................................................................................................................
3-42
4. Troubleshooting
..............................................................................................................................
4-1
4-1 Check-up Window Description
.....................................................................................................
4-1
4-2 Troubleshooting
...............................................................................................................................
4-2
4-2-1 Setting Option Setup Method
............................................................................................
4-2
4-2-2 What to check before diagnosis
.........................................................................................
4-18
4-3 Diagnosis Checklist
..........................................................................................................................
4-32
4-3-1 Number Display Method
.....................................................................................................
4-32
4-4 Auto Inspect Mode
...........................................................................................................................
4-33
4-4-1 Outline
.....................................................................................................................................
4-33
4-4-2 Auto Inspect Mode Steps
.....................................................................................................
4-35
4-4-3 Preliminary Inspection
..........................................................................................................
4-36
4-4-4 Troubleshooting for inspected items
.................................................................................
4-37
4-4-5 Error Code
...............................................................................................................................
4-50
4-5 Responses According to Condition
...............................................................................................
4-57
4-5-1 Outdoor Unit Operation Flow
.............................................................................................
4-57
$9;&6+B$BaLQGG 

Section 0
2Samsung Electronics
Contents
4-5-2 Indoor Unit ROOM sensor Error (Open/Short)
................................................................
4-61
4-5-3 Indoor unit EVAP IN sensor Error (Open/Short)
...............................................................
4-62
4-5-4 Indoor EVAP OUT sensor Error (Open/Short)
..................................................................
4-63
4-5-5 Indoor heat exchanger's EVAP IN sensor dislocation error
..........................................
4-64
4-5-6 Indoor Heat Exchanger's EVA OUT sensor dislocation error (Open/Short)
...............
4-65
4-5-7 Simultaneous Indoor heat exchanger's EVA IN, OUT sensor dislocation error (Open/Short)
......
4-66
4-5-8 Operational error of indoor Unit's Clean Fan (Open/Short)
.........................................
4-67
4-5-9 Breakdown of EEV (2nd)
......................................................................................................
4-68
4-5-10 Problem with EEV closure (2nd)
......................................................................................
4-69
4-5-11 : Detection of Floating Switch of Indoor Unit's Drain Pump
........................
4-70
4-5-12 The operational error of Indoor Unit's Fan Motor
........................................................
4-71
4-5-13
Mixed operation Error (Only applicable to Heat Pump Model/Not to HR model )
............
4-72
4-5-14 EEPROM error
......................................................................................................................
4-73
4-5-15 Option error of the Remote Controller for an Indoor Unit
.........................................
4-74
4-5-16 Error due to confused use of Fahrenheit and Celsius
.................................................
4-74
4-5-17 Simultaneous opening of Cooling/heating MCU SOL Valves 1st/2nd
.....................
4-75
4-5-18
Error due to incorrect Indoor Unit Power/Communication Cable Connection
...........
4-76
4-5-19 SPI Feedback Error
.............................................................................................................
4-77
4-5-20 Outdoor Unit Pipe Inspection Error
.................................................................................
4-78
4-5-21 Communication Error between Indoor and Outdoor Units during Tracking
.........
4-79
4-5-22 Communication Error between Indoor and Outdoor Units after Tracking
.............
4-81
4-5-23 Communication error between main and sub Micom of outdoor unit or
between outdoor units
.....................................................................................................
4-82
4-5-24 Communication Error between MCU and Outdoor Unit
...........................................
4-83
4-5-25 Communication Error between MAIN/HUB PBA
..........................................................
4-84
4-5-26
Communication Error between MCU and Outdoor Unit after Tracking is Completed
......
4-85
4-5-27 MCU branch part setup error – inconsecutive connection with the use of
2 branch parts
....................................................................................................................
4-86
4-5-28
MCU branch part setup error – Repeated setup for the same address over 3 times
........
4-87
4-5-29 MCU branch part setup error – non-installed address setup
....................................
4-88
4-5-30 Setup Error for MCU Branch part – Setup Error for MCU Quantity Used
................
4-89
4-5-31 MCU branch part setup error – Overlapping Indoor unit Address setup
...............
4-90
4-5-32
MCU branch part setup error – Set as being used without connection to an Indoor unit
........
4-91
4-5-33
MCU branch part setup error – Connect an Indoor unit to a branch part not being used
.......
4-92
4-5-34 MCU branch part setup error – Connect more Indoor units than what is actually
set up in MCU
.....................................................................................................................
4-93
4-5-35 Outdoor Temperature Sensor Error
................................................................................
4-94
4-5-36 Outdoor Temperature dislocation error
.........................................................................
4-95
4-5-37 COND OUT Temperature Sensor Error (OPEN/SHORT)
...............................................
4-96
4-5-38 Outdoor COND OUT sensor breakaway error
...............................................................
4-97
4-5-39 Digital Compressor Discharge Temperature Sensor Error (OPEN/SHORT)
.............
4-98
4-5-40
Constant Rate Compressor Discharge Temperature Sensor Error (OPEN/SHORT)
............
4-99
4-5-41 Compressor Discharge Temperature Sensor Breakaway Error
..................................
4-100
4-5-42 :
Dislocation error of Compressor SUMP Temperature (oil temperature) Sensor
....
4-101
$9;&6+B$BaLQGG 

Contents
4-5-43 : Suction Temperature Sensor Breakaway Error
...............................................
4-102
4-5-44 SUMP Temperature Sensor Error (OPEN/SHORT)
.........................................................
4-103
4-5-45 High Pressure Sensor Error (OPEN/SHORT)
...................................................................
4-104
4-5-46 Low-Pressure Sensor Error (OPEN/SHORT)
....................................................................
4-105
4-5-47 Oil balance temperature sensor error (OPEN/SHORT)
................................................
4-106
4-5-48 Suction temperature sensor error (OPEN/SHORT)
......................................................
4-107
4-5-49 Double-pipe temperature sensor error (OPEN/SHORT)
.............................................
4-108
4-5-50 Main Cooling Sol Valve Open Error
.................................................................................
4-109
4-5-51 EVI IN Temperature Sensor Error (OPEN/SHORT)
.........................................................
4-110
4-5-52 EVI OUT Temperature Sensor Error (OPEN/SHORT)
.....................................................
4-111
4-5-53 Suction-2 Temperature Sensor Error (OPEN/SHORT)
..................................................
4-112
4-5-54 : COMP. DOWN Due to High Pressure Protection Control
.............................
4-113
4-5-55 : COMP. DOWN Due to Low Pressure Protection
.............................................
4-114
4-5-56 Sump Sensor Error Due to Protection Control
.............................................................
4-115
4-5-57 : COMP.DOWN Due to Compressor Discharge Temperature Sensor
...........
4-116
4-5-58 3-phase Power Reversed Phase and No-phase Inspection
........................................
4-117
4-5-59 : COMP. DOWN Due to Compressor Control
....................................................
4-118
4-5-60 : Oil Valve (oil balance valve) 1 Self-diagnosis
(Open/Close error, Breakaway or Fault of Sensor)
........................................................
4-119
4-5-61 EVI EEV Open Error
.............................................................................................................
4-120
4-5-62 Refrigerant Leakage Error
.................................................................................................
4-121
4-5-63 , : Prohibition of the operation of Compressor due to
OoutdoorTemperature
......................................................................................................
4-122
4-5-64
High Pressure Standard Not Met before Air Conditioning (Inability to Re-operate)
.........
4-123
4-5-65 CCH Malfunction and Sump Sensor Miswiring Error
..................................................
4-124
4-5-66 Momentary Blackout Error
...............................................................................................
4-125
4-5-67 Error by High Temperature in an Outdoor Fan Motor
.................................................
4-125
4-5-68 Outdoor Unit Fan Motor RPM Error
................................................................................
4-126
4-5-69 Over-Voltage Error of an Outdoor Fan Motor
...............................................................
4-128
4-5-70 Counter-Rotation Error of an Outdoor Fan motor
.......................................................
4-128
4-5-71 : Compressor Excess Current Error
.....................................................................
4-129
4-5-72 : Compressor Low-current Error
.........................................................................
4-130
4-5-73 Liquid Compression Prevention Control
.......................................................................
4-131
4-5-74 Breakdown of an EEV(1st)
.................................................................................................
4-132
4-5-75 Breakdown of an EEV closure (1st)
..................................................................................
4-133
4-5-76 Electronic expansion valve closing malfunction (2nd stage)
.....................................
4-134
4-5-77 Electronic expansion valve opening malfunction (2nd stage)
...................................
4-135
5. Exploded Views and Parts List
.............................................................................................
5-1
5-1 Indoor Unit
.........................................................................................................................................
5-1
5-1-1 Slim1 way cassette type
.......................................................................................................
5-1
5-1-2 2 way cassette type
...............................................................................................................
5-9
5-1-3 4 way cassette type
................................................................................................................
5-13
$9;&6+B$BaLQGG 

Contents
5-1-4 Mini 4 way cassette type
.......................................................................................................
5-23
5-1-5 Duct type(Slim I)
.....................................................................................................................
5-27
5-1-6 Duct type(Slim II)
....................................................................................................................
5-29
5-1-7 Duct type(Slim III)
...................................................................................................................
5-31
5-1-8 Duct type(MSP)
.......................................................................................................................
5-33
5-1-9 Duct type(HSP)
........................................................................................................................
5-41
5-1-10 Duct type(SUPER)
.................................................................................................................
5-43
5-1-11 Big Duct
.................................................................................................................................
5-47
5-1-12 Ceiling type
..........................................................................................................................
5-49
5-1-13 Console type
.........................................................................................................................
5-53
5-1-14 Wall-mounted type(Montblanc)
........................................................................................
5-55
5-1-15 Wall-mounted type(Neo Forte without EEV)
..................................................................
5-59
5-1-16 Wall-mounted type(Neo Forte with EEV)
........................................................................
5-63
5-1-17 Wall-mounted type(Vivace)
................................................................................................
5-67
5-2 Outdoor Unit
......................................................................................................................................
5-71
5-2-1 RD080HHXGA/RD100HHXGA/RD120HHXGA
...................................................................
5-71
5-2-2 RD080/100/120HHXGB, RD080/100/120HHXGASTK
......................................................
5-75
5-2-3 RD140HHXGA
..........................................................................................................................
5-79
5-2-4 RD140HHXGB, RD140HHXGASTK
........................................................................................
5-83
5-2-5 RD160HHXGA/RD180HHXGA/RD200HHXGA
...................................................................
5-87
5-2-6 RD160/180/RD200HHXGB, RD160/180/200HHXGASTK
.................................................
5-91
5-2-7 RD080/100/120HRXGA
..........................................................................................................
5-95
5-2-8 RD080/100/120HRXGB, RD080/100/120HRXGASTK
........................................................
5-99
5-2-9 RD140HRXGA
..........................................................................................................................
5-103
5-2-10 RD140HRXGB, RD140HRXGASTK
......................................................................................
5-107
5-2-11 RD160/180/200HRXGA
.......................................................................................................
5-111
5-2-12 RD160/180/200HRXGB, RD160/180/200HRXGASTK
.....................................................
5-115
5-2-13 MCU-4EAE3/6EAE3
..............................................................................................................
5-119
6. PCB Diagram and Parts List
.....................................................................................................
6-1
6-1 Indoor Unit
........................................................................................................................................
6-1
6-1-1 Slim 1 way cassette type
.....................................................................................................
6-1
6-1-2 2 way cassette type
..............................................................................................................
6-5
6-1-3 4 way cassette type
..............................................................................................................
6-7
6-1-4 Mini 4 way cassette type
.....................................................................................................
6-8
6-1-5 Duct type(Slim)
......................................................................................................................
6-9
6-1-6 Duct type(MSP)
......................................................................................................................
6-13
6-1-7 Duct type(HSP)
.......................................................................................................................
6-15
6-1-8 Duct type(SUPER)
..................................................................................................................
6-17
6-1-9 Duct type(BIG)
.......................................................................................................................
6-19
6-1-10 Celing type
...........................................................................................................................
6-23
6-1-11 Console
..................................................................................................................................
6-24
$9;&6+B$BaLQGG 

Section 0
Samsung Electronics 5
Contents
6-1-12 Wall-mounted type(Montblanc)
.......................................................................................
6-27
6-1-13 Wall-mounted type(Neo Forte without EEV)
.................................................................
6-31
6-1-14 Wall-mounted type(Neo Forte with EEV)
.......................................................................
6-35
6-1-15 Wall-mounted type(Vivace)
...............................................................................................
6-39
6-2 Outdoor Unit
.....................................................................................................................................
6-43
6-2-1 ASS'Y PCB MAIN (RD✳✳✳HHXGA, RD✳✳✳HRXGA Series)
..........................................
6-43
6-2-2 ASS'Y PCB MAIN (RD✳✳✳HHXGB, RD✳✳✳HRXGB Series)
...........................................
6-45
6-2-3 ASS'Y PCB MAIN HUB
............................................................................................................
6-47
6-2-4 ASS'Y BLDC EMI DRIVER (RD✳✳✳HHXGA, RD✳✳✳HRXGA Series)
.............................
6-51
6-2-5 ASS'Y BLDC EMI DRIVER (RD✳✳✳HHXGB, RD✳✳✳HRXGB Series)
..............................
6-53
6-2-6 ASS'Y PCB SUB SENSOR CT UP
............................................................................................
6-55
6-2-7 ASS'Y PCB SUB SENSOR CT LOW
........................................................................................
6-57
6-2-8 MCU
..........................................................................................................................................
6-58
6-3 Parts List
.............................................................................................................................................
6-59
6-3-1 ASS'Y PCB MAIN
.....................................................................................................................
6-59
6-3-2 ASS'Y PCB MAIN HUB : DB93-11209A/B
............................................................................
6-65
6-3-3 ASS'Y PCB SUB DRIVER
.........................................................................................................
6-77
6-3-4 ASS'Y PCB SUB SENSOR CT UP : DB93-11518A
................................................................
6-86
6-3-5 ASS'Y PCB SUB SENSOR CT LOW : DB93-11519A
............................................................
6-89
6-3-6 ASS'Y PCB MAIN MCU : DB93-04661G
...............................................................................
6-90
7. Wiring Diagram
...............................................................................................................................
7-1
7-1 Indoor
.................................................................................................................................................
7-1
7-1-1 Slim 1way cassette type
......................................................................................................
7-1
7-1-2 2way cassette type
...............................................................................................................
7-3
7-1-3 4way cassette type
...............................................................................................................
7-4
7-1-4 Mini 4way cassette type
......................................................................................................
7-5
7-1-5 DUCT type(Slim I, II)
.............................................................................................................
7-6
7-1-6 DUCT type(Slim III)
...............................................................................................................
7-7
7-1-7 DUCT type(MSP)
...................................................................................................................
7-8
7-1-8 DUCT type(HSP)
....................................................................................................................
7-9
7-1-9 DUCT type(SUPER)
...............................................................................................................
7-10
7-1-10 DUCT type(BIG)
....................................................................................................................
7-11
7-1-11 Ceiling
...................................................................................................................................
7-12
7-1-12 Console
.................................................................................................................................
7-13
7-1-13 Wall Mounted type(Montblanc)
......................................................................................
7-14
7-1-14 Wall Mounted type(Neo Forte without EEV)
................................................................
7-15
7-1-15 Wall Mounted type(Neo Forte with EEV)
.......................................................................
7-16
7-1-16 Wall Mounted type(Vivace)
..............................................................................................
7-17
7-1-17 Distributor kit
.......................................................................................................................
7-18
7-2 Outdoor Unit
.....................................................................................................................................
7-19
7-2-1 Outdoor
...................................................................................................................................
7-19
7-2-2 MCU
..........................................................................................................................................
7-21
$9;&6+B$BaLQGG 

Section 0
6Samsung Electronics
Contents
8. Schematic Diagram
......................................................................................................................
8-1
8-1 Indoor Unit
........................................................................................................................................
8-1
8-1-1 Slim 1 way cassette type
......................................................................................................
8-1
8-1-2 2 way cassette type
..............................................................................................................
8-4
8-1-3 4 way cassette type
..............................................................................................................
8-5
8-1-4 Mini 4 way cassette type
.....................................................................................................
8-6
8-1-5 Duct type(Slim, MSP, HSP)
....................................................................................................
8-7
8-1-6 Duct type(SUPER)
..................................................................................................................
8-8
8-1-7 DUCT type(BIG)
......................................................................................................................
8-9
8-1-8 Ceiling type
.............................................................................................................................
8-11
8-1-9 Console type
..........................................................................................................................
8-12
8-1-10 Wall-mounted type(Montblanc)
......................................................................................
8-15
8-1-11 Wall-mounted type(Neo Forte without EEV/Vivace)
....................................................
8-16
8-1-12 Wall-mounted type(Neo Forte with EEV)
.......................................................................
8-17
8-2 Outdoor Unit
.....................................................................................................................................
8-18
8-2-1 ASS'Y PCB MAIN
.....................................................................................................................
8-18
8-2-2 ASS'Y PCB MAIN HUB
............................................................................................................
8-19
8-2-3 ASS'Y PCB SUB DRIVER
.........................................................................................................
8-20
8-2-4 ASS'Y PCB SUB SENSOR CT UP
............................................................................................
8-22
8-2-5 ASS'Y PCB SUB SENSOR CT LOW
........................................................................................
8-23
9. Reference Sheet
..............................................................................................................................
9-1
9-1 Index for Model Name
....................................................................................................................
9-1
9-1-1 Indoor Unit
..............................................................................................................................
9-1
9-1-2 Outdoor Unit
..........................................................................................................................
9-3
9-2 Refrigerant Circuit Diagram
...........................................................................................................
9-5
9-2-1 Cycle Operation Mode
..........................................................................................................
9-5
9-3 Pump-down Method
......................................................................................................................
9-18
9-3-1 Precautions for Pump-down
...............................................................................................
9-18
9-3-2 For Single Installation of Outdoor Unit (Only One Outdoor Unit Installed)
...............
9-18
9-3-3 When Two or More Outdoor Units are Installed
..............................................................
9-18
9-4 How to Put Refrigerant in Refrigerant Container
......................................................................
9-19
9-4-1 How to put refrigerant in container before pump-down
..............................................
9-19
$9;&6+B$BaLQGG 

Samsung Electronics 1-1
1. Precautions
1-1 Precautions for the Service
OUse the correct parts when changing the electric parts.
– Please check the labels and notices for the model name, proper voltage, and proper current for the electric parts.
OFully repair the connection for the types of harness when repairing the product after breakdown.
– A faulty connection can cause irregular noise and problems.
OWhen disassembling or assembling, make sure that the product is laid down on a work cloth.
– Doing so will prevent scratching to the exterior of the rear side of the product.
OCompletely remove dust or foreign substances on the housing, connection, and inspection parts when performing repairs.
– This can prevent fire hazards for tracking, short, etc.
OPlease tighten the service valve of the outdoor unit and the valve cap of the charging valve as securely as possible by using
a monkey spanner.
OCheck whether the parts are properly and securely assembled after performing repairs.
– These parts should be in the same condition as before the repair.
1-2 Precautions for the Static Electricity and PL
OPlease carefully handle the PCB power terminal during repair and measurement when it is turned on since it is vulnerable
to static electricity.
– Please wear insulation gloves before performing PCB repair and measurement.
OCheck if the place of installation is at least 2m away from electronic appliances such as TV, video players, and stereos.
– This can cause irregular noise or degrade the picture quality.
OPlease make sure the customer does not directly repair the product.
– Arbitrary dismantling may result in electric shock or fire.
1-3 Precautions for the Safety
ODo not pull or touch the power plug or the subsidiary power switch with wet hands.
– This may result in electric shock or fire.
OIf the power line or the power plug is damaged, then it must be changed since this is a hazard.
ODo not bend the wire too much or position it so that it can be damaged by a heavy object on top.
– This may result in electric shock or fire.
OThe use of multiple electric outlets should be prohibited.
– This may result in electric shock or fire.
OGround the connection if it is necessary.
– The connection must be grounded if there is any risk of electrical short due to water or moisture.
OUnplug the power or turn off the subsidiary power switch when changing or repairing electrical parts.
– Doing so will prevent electric shock.
OExplain to workers that the battery for the remote control needs to be separated for storage purposes when the product
will not be used for a long time.
– This can cause a problem for the remote control since battery fluid may trickle out.
$9;&6+B$BaLQGG 

1-2 Samsung Electronics
1-4 Precautions for Handling Refrigerant for Air Conditioner
Environmental Cautions: Air pollution due to gas release
OSafety Cautions
If liquid gas is released, then body parts that come into contact with it may experience frostbite/blister/numbness.
If a large amount of gas is released, then suffocation may occur due to lack of oxygen. If the released gas is heated, then noxious
gas may be produced by combustion.
OContainer Handling Cautions
Do not subject container to physical shock or overheating. (Flowage is possible while moving within the regulated pressure.)
1-5 Precautions for Welding the Air Conditioner Pipe
ODangerous or flammable objects around the pipe must be removed before the welding.
OIf the refrigerant is kept inside the product or the pipe, then remove the refrigerant prior to welding.
If the welding is carried out while the refrigerant is kept inside, the welding cannot be properly performed. This will also produce
noxious gas that is a health hazard. This leakage will also explode with the refrigerant and oil due to an increase in the refrigerant
pressure, posing a danger to workers.
OPlease remove the oxide produced inside the pipe during the welding with nitrogen gas.
Using another gas may cause harm to the product or others.
1-6 Precautions for Additional Supplement of Air Conditioner Refrigerant
OPrecisely calculate the refrigerant by using a scale and S-net, and proceed with the test operation.
Excessive supplement can cause harm to the product since it can cause an inflow of the liquid refrigerant into the compressor.
ODo not heat the refrigerant container for a forced injection.
This may cause harm to the product or others since the refrigerant container may burst.
ODo not operate the product after removing the product safety pressure switch and sensor.
If the product is blocked inside, then this may cause harm to the product or others due to the excess pressure increase of the
refrigerant gas.
1-7 Other Precautions
OThere should be no leakage of the pipes after installation. When withdrawing the refrigerant, the compressor should be
stopped before removing the connecting pipe.
If the compressor is operating while the refrigerant pipe is not correctly connected and the service valve is opened, then
air and other substances can enter the pipe. The interior of the refrigerant cycle may then build up excessive high pressure
resulting in explosion and damage.
$9;&6+B$BaLQGG 

Samsung Electronics 2-1
2. Product Specifications
2-1 The Feature of Product
2-1-1 Feature
Q World-class COP/World-class low-temp heating ability
World-class
World-class standard COP
Double compression hyper
compression
Strong low-temp heating
Core technology
New concept plate-type inter-cooler
Highly efficient G Fin
Linear capacity control
Installation nature
Maximum capacity – 80HP
Longest pipe – 220m
Maximum elevation – 110m
Reduced installation floor area
Cooling Heating
● Achieves world-class efficiency
Full line-up average COP 3.98
● Over 90% stable operation at low-temp
operating condition if -10°C
90% n55%
-10°C Low-temp
Outside Air
QStronger DVM PLUS 4
Achieves world-class efficiency with hyper compressor that applies double compression technology
3.72
4.48
3.49
4.01
X Enterprise New Product
DVM PLUS4
<Single unit average>
$9;&6+B$BaLQGG 

Product Specifications
2-2 Samsung Electronics
Feature (cont.)
● Vapor injection of highly efficien double
compression technology
●
20% increase in refrigerant circulation with
injection volume control
● Comfortable air conditioning and heating with
excellent energy efficiency
QHyper Compressor
QNew Concept Plate-type Inter-cooler
Medium-pressure refrigerant inlet
Low-pressure refrigerant outlet
Medium-pressure refrigerant outlet
High-pressure refrigerant outlet
Increased cooling effect due to
plate-type inter-cooler
● New Concept PHE Inter-cooler
(Plate Heat Exchanger)
Air Conditioning
Efficiency
12%
Heating
Efficiency
19%
$9;&6+B$BaLQGG 

Product Specifications
Samsung Electronics 2-3
Feature (cont.)
QHighly Efficient G-Fin/Wide Width Fin
QLinear Capacity Control
● New highly efficient fin heat exchanger is applied.
- Excellent frosting-delay effect
- Heat exchange amountn
Φ8 Fin Φ7 Wide Width Fin New Φ7 Wide Width Fin
Heat Exchange
Amount
15%
New Φ8 G-Fin
Heat Exchange
Amount
10%
● 10~100% Linear capacity control
efficiency with variable scroll compression
operation for PWM control
Linear capacity variable for every field
(10~100%)
step 1
Increase in refrigerant circulation with
vapor injection
step 2
Low-pressure
refrigerant outlet
Low-pressure
refrigerant outlet
Compressor operating rate
Interior load
Capacity variable
operation
$9;&6+B$BaLQGG 

Product Specifications
2-4 Samsung Electronics
Feature (cont.)
QWorld’s Largest Single Chassis Capacity of 20HP
QLong Pipe – 220m, Elevation – 110m, Total Pipe Length – 1km
● Possible to connect a maximum
of 80HP
- Maximum of 30% decrease in
installation area
Longest Pipe Length 220m
Elevation between Indoor and
Outdoor Units 110m
Elevation between Indoor Units 15m
Total Pipe Length 1000m
Longest Pipe Length after First
Air Conditioning 90m
$9;&6+B$BaLQGG 

Product Specifications
Samsung Electronics 2-5
Feature (cont.)
QSmallest Footprint Area
● 26% reduction compared to existing 2-module
compounded model
Outdoor Unit Floor Area
1.34 m²
0.99 m² 26%
$9;&6+B$BaLQGG 

Product Specifications
2-6 Samsung Electronics
2-1-2 Changes in comparison to basic model
Changed
part
Changed
model
Changed Item
and feature Basic After changed
FAN
RD140HHXG✳
RD160HHXG✳
RD180HHXG✳
RD200HHXG✳
RD140HRXG✳
RD160HRXG✳
RD180HRXG✳
RD200HRXG✳
Φ 575mm applied
- 1 Fan o2 Fans
- Airflow is secured.
HEAT
EXCHANGER
RD80HHXG✳
RD100HHXG✳
RD120HHXG✳
RD140HHXG✳
RD160HHXG✳
RD180HHXG✳
RD200HHXG✳
RD80HRXG✳
RD100HRXG✳
RD120HRXG✳
RD140HRXG✳
RD160HRXG✳
RD180HRXG✳
RD200HRXG✳
Heat exchanger
fin shape has been
improved to better fit
the chassis structure.
oImproves heat
exchanger efficiency
and overall optimiza-
tion
New G-Fin
Highly efficient new G-Fin increased
heat transfer performance, reinforced
corrosion resistance, and increased
operating duration in frost condition
Ø7, 2 rows, 60 columns, FP1.5
Ø7, 2 rows, 60 columns, FP1.5
Ø8, 2 rows, 60 columns, FP1.8
Ø7, 3 rows, 60 columns, FP1.7
Ø8, 3 rows, 60 columns, FP1.8
Changed
part
Changed Item
and feature Basic After changed
CABINET
Front Cabinet
- Wire cover has been removed
- Cover valve shape has been
changed
- Detachable front cabinet
operational effectiveness has been
improved.
WINDOW
DISPLAY
PBA monitoring window has been
added
- Installation/service ability has been
improved.
MOTOR
New motor is applied.
- 1 Fan o2 Fans
- RESIN MOTOR
$9;&6+B$BaLQGG 

Product Specifications
Samsung Electronics 2-7
Changes in comparison to basic model (cont.)
Changed
part
Changed Item
and feature Basic After changed
Control
Box
Structure
- Allows for easy servicing.
- Wire standardization inside the
product has been improved.
Detachable Power Box Structure
- The main control box cover does
not need to be separated for
connecting wires (improved
reliability).
Installation method for relay
station has changed.
- Installed inside power box
Changed
part
Changed Item
and feature Basic After changed
Main PBA
Main PBA has changed.
- Separation between load-use and
control-use
-
Optional resistance for each model
has been removed (Standardization)
- Downloading options are required
to change PBA.
Hub PBA
New Hub PBA
- Separation between load-use and
control use
- Load/sensor wire standardization
has been improved.
BLDC PBA Unification of two controllers
Unification of EMI Board
$9;&6+B$BaLQGG 

Product Specifications
2-8 Samsung Electronics
Changes in comparison to basic model (cont.)
Changed
part
Changed Item
and feature Basic After changed
CT PBA
Assembly/service abilities has been
strengthened.
- Interchangeable CT sensor
Changed
part
Changed
model
Changed Item
and feature Basic After changed
ASS'Y PIPE
RD080HHXG✳
RD100HHXG✳
RD120HHXG✳
RD140HHXG✳
RD160HHXG✳
RD180HHXG✳
RD200HHXG✳
RD080HRXG✳
RD100HRXG✳
RD120HRXG✳
RD140HRXG✳
RD160HRXG✳
RD180HRXG✳
RD200HRXG✳
Pipe Optimization
oReduced pressure
loss
oImproved efficiency
Service ability
improvement
oWorking space
is secured by
positioning all pipes
hidden by C-BOX to
the side.
$9;&6+B$BaLQGG 

Product Specifications
Samsung Electronics 2-9
Q Position of changing parts
C-BOX
COVER TOP
FAN
PBA
ASS'Y PIPE
HEAT
EXCHANGER
CONTROL IN
FRONT CABI
COVER VALVE
$9;&6+B$BaLQGG 

2-10 Samsung Electronics
2-2 Product Specifacations
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model AVXCSH022E6
ND0221H6
AVXCSH028E6
ND0281H6
AVXCSH036E6
ND0361H6
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR HP / HR
Performance Capacity
Cooling*2) kW 2.2 2.8 3.6
Btu/h 7,500 9,500 12,200
Heating*3) kW 2.5 3.2 4.0
Btu/h 8,500 10,900 13,600
Condensate (with High fan speed) Liters/h 1.12 1.44 1.6
Power Input W 40*5) 45*5) 50*5)
Running Current A 0.20*5) 0.23*5) 0.25*5)
Sound Level Sound Pressure (High/Low)*4) dB(A) 30 / 25 30 / 25 32 / 27
Fan
Type - Crossflow fan Crossflow fan Crossflow fan
Motor
Model - SFN-220-20-4B-1 SFN-220-20-4B-1 SFN-220-20-4B-1
Type - Feedback SSR Feedback SSR Feedback SSR
Output W *5) *5) *5)
Airflow Rate Cooling (High) m3/min 5.36*5) 6.04*5) 7.45*5)
Heating (High) m3/min 7.57*5) 8.64*5) 9.73*5)
Refrigerant Type - R410A R410A R410A
Control Method - EEV EEV EEV
Temperature Control - Micom & Thermistors Micom & Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 6.35 6.35
Gas (Flare) ø, mm 12.7 12.7 12.7
Drain (Quick Lock) ø, mm VP20 (OD 25, ID 20) VP20 (OD 25, ID 20) VP20 (OD 25, ID 20)
Weight Net Weight kg 10.5 10.5 10.5
Shipping Weight kg 13.5 13.5 13.5
Dimensions Net Dimensions (W x H x D) mm 970x135x410 970x135x410 970x135x410
Shipping Dimensions (W x H x D) mm 1,164x212x478 1,164x212x478 1,164x212x478
Panel Size
Model - PSSMA PSSMA PSSMA
Net Weight kg 3.0 3.0 3.0
Shipping Weight kg 5.0 5.0 5.0
Net Dimensions (W x H x D) mm 1,180x25x460 1,180x25x460 1,180x25x460
Shipping Dimensions (W x H x D) mm 1,259x144x539 1,259x144x539 1,259x144x539
Functions
Auto Restart - O O O
Auto Swing - O O O
Group/Individual Control - O O O
External Contact Control - O O O
Trouble Shooting by LED - O O O
Standard
Accessories
Installation Manual - O O O
Operation Manual - X X X
Pattern Sheet for Installation - O O O
Flexible Drain Hose - O O O
Filter / Safety Grille - Filter (Washable) Filter (Washable) Filter (Washable)
Drain Pump (Pumping speed, lift) ℓ/h,mm 24, 750 24, 750 24, 750
Optional
Accessories
Wireless Remote Controller - MR-BH01 MR-BH01 MR-BH01
Wired Remote
Controller
Simplified - MWR-SH00 MWR-SH00 MWR-SH00
Standard - MWR-TH01 MWR-TH01 MWR-TH01
Premium - MWR-WS00 MWR-WS00 MWR-WS00
External Contact Interface Module - MIM-B14 MIM-B14 MIM-B14
2-2-1 Indoor Unit
QSlim 1way cassette type
$9;&6+B$BaLQGG 

Product Specifications
Samsung Electronics 2-11
*1) Mode
- HP : Heat Pump, HR : Heat Recovery
*2) Nominal cooling capacities are based on;
- Indoor temperature : 27˚C DB, 19˚C WB
- Outdoor temperature : 35˚C DB, 24˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*3) Nominal heating capacities are based on;
- Indoor temperature : 20˚C DB, 15˚C WB
- Outdoor temperature : 7˚C DB, 6˚C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
*4) Sound pressure was acquired in a dead room. Thus actual noise level may be different depending on the installation conditions.
*5) Specifications may be subject to change without prior notice for product improvement.
Model ND0561HXE✳ND0711HXE✳
Power Supply ø/V/Hz 1/220~240/50 1/220~240/50
Mode*1) HP / HR HP / HR
Performance Capacity
Cooling*2) kW 5.6 7.1
Btu/h 19,100 24,200
Heating*3) kW 6.3 8
Btu/h 21,400 27,200
Condensate (with High fan speed) Liters/h 2.87 3.19
Power Input W 55 80
Running Current A 0.28 0.40
Sound Level Sound Pressure (High/Low)*4) dB(A) 46/42 47/44
Fan
Type - Crossflow fan Crossflow fan
Motor
Model - SIC-55CVL-F158-3 SIC-55CVL-F158-3
Type - BLDC BLDC
Output W 54 54
Airflow Rate Cooling (High) m3/min 15.0 16.5
Heating (High) m3/min
Refrigerant Type - R410A R410A
Control Method - EEV EEV
Temperature Control - Micom &Thermistors Micom & Thermistors
Safety Devices - Fuse Fuse
Piping
Connections
Liquid (Flare) ø, mm 6.35 9.52
Gas (Flare) ø, mm 12.7 15.88
Drain (Quick Lock) ø, mm VP25 (OD 32, ID 25) VP25 (OD 32, ID 25)
Weight Net Weight kg 14.5 14.5
Shipping Weight kg 18.5 18.5
Dimensions Net Dimensions (W x H x D) mm 1,200x138x450 1,200x138x450
Shipping Dimensions (W x H x D) mm 1,435x214x525 1.435x214x525
Panel Size
Model - PC1BUSEA PC1BUSEA
Net Weight kg 4.5 4.5
Shipping Weight kg 7.0 7.0
Net Dimensions (W x H x D) mm 1,420x23x500 1,420x23x500
Shipping Dimensions (W x H x D) mm 1,483x144x573 1,483x144x573
Functions
Auto Restart - O O
Auto Swing - O O
Group/Individual Control - O(option) O(option)
External Contact Control - O O
Trouble Shooting by LED - O O
Standard
Accessories
Installation Manual - O O
Operation Manual - X X
Pattern Sheet for Installation - O O
Flexible Drain Hose - O O
Filter / Safety Grille - O O
Drain Pump (Pumping speed, lift) ℓ/h,mm O O
Optional
Accessories
Wireless Remote Controller - MR-DH00 MR-DH00
Wired Remote
Controller
Simplified - MWR-TH01 MWR-TH01
Standard -
Premium -
External Contact Interface Module -
Indoor Unit(cont.)
QSlim 1way cassette type(cont.)
