Samsung Galaxy Tab GT-P1000 Building instructions

GSM TELEPHONE
GT-P1000
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Disassembly and Assembly
Instructions
8. Chart of Troubleshooting
9. Reference data
Notice :
All functionality, features, specifications and other
product information provided in this document inclu
ding, but not limited to, the benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice or obligation. Samsung reserves the right to
make changes to this document and the product
described herein, at anytime, without obligation on
Samsung to provide notification of such change.
GSM TELEPHONE CONTENTS

This Service Manual is aproperty of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
Samsung Electronics Co.,Ltd.
2010. 09. Rev.1.0
ⓒ
Country Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast &Africa mea.samsungportal.com
GSPN (Global Service Partner Network)

2. Specification
2-1
2-1. GSM General Specification
GSM850 EGSM 900 DCS1800 PCS1900 WCDMA
2100
WCDMA
1900
WCDMA
900
Freq.
Band[MHz]
Uplink/
Downlink
824~849
869~894
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
1922~1977
2112~2167
1852~1907
1932~1987
880~915
925~960
ARFCN
range 128~251 0~124 &
975~1023 512~885 512~810
UL:9612~9888
DL:10562~108
38
UL:9262~9538
DL:9662~9938
UL:2712~2863
DL:2937 ~
3088
Tx/Rx
spacing 45MHz 45MHz 95MHz 80MHz 190MHz 80MHz 45MHz
Mod. Bit
rate/
Bit Period
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us
270.833kbps
3.692us 3.84Mcps 3.84Mcps 3.84Mcps
Time Slot
Period/
Frame
Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSKHQPSK QPSKHQPSK QPSKHQPSK
MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dB
m
30dBm~0dB
m
24dBm~
-50dBm
24dBm~
-50dBm
24dBm~
-50dBm
Power
Class 5pcl ~ 19pcl 5pcl ~19
pcl 0pcl ~15 pcl 0pcl ~15 pcl 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm -106.7dBm
TDMA Mux 8 8 8 8 888
Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km 2Km

Specification
2-2
2-2. GSM Tx Power Class
TX Power
control
level
GSM850
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
EGSM900
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control
level
PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

SAMSUNG Proprietary-Contents may change without notice
3. Operation Instruction and Installation
3-1
This Document can not be used without Samsung's authorization
Main Function
•Android OS: Froyo
•HSDPA 7.2Mbps /HSUPA 5.76Mbps
•3
MP AF with LED Flash
•7.0"
WSVGA TFT Full Touch (C-Type)
•A-GPS /BT v3.0 /USB v2.0 /WiFi (802.11 a/b/g/n)
•Recording 480p (D1, 720*480) / Full HD Playback 1080p, DLNA
•Sensors: Accelation, Magnetic, Gyro, Light
•Additional :
-Application store /Voice &Motion UI
-SMS/MMS/Email/Push Email (Exchange ActiveSync)/
Video Messaging Email
-Multi-touch, Multi-task manager

SAMSUNG Proprietary-Contents may change without notice
6. Level 1Repair
6-1
This Document can not be used without Samsung's authorization
6-1. S/W Download
6-1-1. Pre-requisite for S/W Downloading
Downloader Program (Odin3 v1.31.exe)
GT-P1000 Mobile Phone
JIG BOX (GH99-36900A)
RF Test Cable (GH39-00985A)
JIG Cable (GH39-09211A)
Adapter (GH99-38251A)
Data Link Cable
Binary files
Settings
Data Link Cable

SAMSUNG Proprietary-Contents may change without notice
Level 1Repair
6-2
This Document can not be used without Samsung's authorization
6-1-2. S/W Downloader Program
Load the binary download program by executing the
"Odin3 v1.31.exe" Run this file.
1.Option Selection
-Check Re-Partition, Auto Reboot and F. Reset Time, then select PIT File

SAMSUNG Proprietary-Contents may change without notice
Level 1Repair
6-3
This Document can not be used without Samsung's authorization
2.Enter Device into Download Mode
-Enter the device into Download Mode by pressing down on Volume Down button
and Power On button at the same time.
3.Connect the Device to PC via Data Cable.
Make sure ID:COM box highlighted yellow that the device is connected to the PC.
Volume Down Button
Power On Button

SAMSUNG Proprietary-Contents may change without notice
Level 1Repair
6-4
This Document can not be used without Samsung's authorization
4.Start Downloading PIT file by clicking Start Button. Then wait for "Pass" to be
appear on the screen.
5.Click on Reset button, then unselect Re-Partition box. Then select PDA, PHONE
and CSC Files.
Start Button

SAMSUNG Proprietary-Contents may change without notice
Level 1Repair
6-5
This Document can not be used without Samsung's authorization
7. Remove the battery, then enter Device into Download Mode again as in step #3.
then connect to the PC.
8. Start Downloading PDA, PHONE and CSC files by clicking Start Button. Then
wait for "Pass" to be appear on the screen.
9.Once the device boots up, confirm the downloaded version name and etc. :
*#1234#
Full Reset :
*2767*3855#

SAMSUNG Proprietary-Contents may change without notice
9. Reference Abbreviate
This Document can not be used without Samsung's authorization
9-1
Reference Abbreviate
―AAC:Advanced Audio Coding.
―AVC :Advanced Video Coding.
―BER :Bit Error Rate
―BPSK:Binary Phase Shift Keying
―CA :Conditional Access
―CDM :Code Division Multiplexing
―C/I :Carrier to Interference
―DMB :Digital Multimedia Broadcasting
―EN :European Standard
―ES :Elementary Stream
―ETSI:European Telecommunications Standards Institute
―MPEG:Moving Picture Experts Group
―PN :Pseudo-random Noise
―PS :Pilot Symbol
―QPSK:Quadrature Phase Shift Keying
―RS :Reed-Solomon
―SI :Service Information
―TDM :Time Division Multiplexing
―TS :Transport Stream

SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
―Repair in Shield Box, during detailed tuning. Take specially care of tuning or test, because
specipicty of cellular phone is sensitive for surrounding interference(RF noise).
―Be careful to use akind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
―Surely use astandard screwdriver when you disassemble this product, otherwise screw will be
worn away.
―Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
―Repair after separate Test Pack and Set because for short danger (for example an overcurrent
and furious flames of parts etc) when you repair board in condition of connecting Test Pack and
tuning on.
―Take specially care of soldering, because Land of PCB is small and weak in heat.
―Surely tune on/off while using AC power plug, because arepair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
―Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
―Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity prevention
string on wrist.
―Use earthed soldering steel when you connect or disconnect ESD.
―Use soldering removing tool to break static electricity. ,otherwise ESD will be damaged by static
electricity.
―Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
―You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or acircuit board.

SAMSUNG Proprietary-Contents may change without notice
4. Exploded View and Parts List
4-1
This Document can not be used without Samsung's authorization
4-1. Cellular phone Exploded View
QLC01
QRE01
QCA02
QAN02
QBA01
QAN03
QMO01
QVK01
QSC01
QCR103
QSP01
QSP02
QCR03
QCA01
QMP01
QCR47
QME16
QVO01
QJK03
QCK01
QJK07
QCR03
QSD01
QRF07

SAMSUNG Proprietary-Contents may change without notice
5. MAIN Electrical Parts List
5-1
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
ANT100,ANT101,ANT104 3712-001348 CONNECTOR-TERMINAL
ANT108,ANT202,ANT203 3712-001348 CONNECTOR-TERMINAL
ANT206 3712-001361 CONNECTOR-TERMINAL
BTC700 3711-007494 CONNECTOR-HEADER
C100,C114,C160,C170 2203-005736 C-CER,CHIP
C102,C308,C309,C343 2203-006399 C-CER,CHIP
C103,C226,C254,C307 2203-007210 C-CER,CHIP
C104,C105,C106,C107 2203-006194 C-CER,CHIP
C108,C109,C110,C111 2203-006194 C-CER,CHIP
C112,C130,C134,C135 2203-006194 C-CER,CHIP
C115 2203-006318 C-CER,CHIP
C116,C125,C127 2203-005732 C-CER,CHIP
C117,C138,C188,C189 2203-005682 C-CER,CHIP
C121 2203-005731 C-CER,CHIP
C123,C129,C227,C228 2203-006423 C-CER,CHIP
C124 2203-005727 C-CER,CHIP
C126,C142,C143,C146 2203-005726 C-CER,CHIP
C128 2203-005552 C-CER,CHIP
C132,C234 2203-005729 C-CER,CHIP
C133,C181,C304,C321 2203-006562 C-CER,CHIP
C136,C215,C219,C220 2203-006839 C-CER,CHIP
C137,C513,C767,C768 2203-007133 C-CER,CHIP
C139,C704,C814,C849 2203-007270 C-CER,CHIP
C140,C720,C721,C831 2203-006208 C-CER,CHIP
C141,C403,C404,C421 2203-000627 C-CER,CHIP
C144 2203-006123 C-CER,CHIP
C147,C289,C297 2203-006187 C-CER,CHIP
C148,C150 2203-005726 C-CER,CHIP
C149,C153,C158,C300 2203-007271 C-CER,CHIP
C151 2203-006620 C-CER,CHIP
C152,C214 2203-006979 C-CER,CHIP
C154,C231,C235,C239 2203-006305 C-CER,CHIP
C155 2203-006693 C-CER,CHIP
C156,C161 2203-006194 C-CER,CHIP
C159,C221,C238,C247 2203-005683 C-CER,CHIP
C165 2203-005234 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-2
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
C167,C212 2203-005725 C-CER,CHIP
C185,C301,C303,C313 2203-006048 C-CER,CHIP
C186,C312,C763 2203-000254 C-CER,CHIP
C187,C296 2203-000233 C-CER,CHIP
C190,C283 2203-005682 C-CER,CHIP
C200,C201,C203,C204 2203-006872 C-CER,CHIP
C205,C213,C318,C319 2203-006872 C-CER,CHIP
C206 2203-006410 C-CER,CHIP
C216 2203-007474 C-CER,CHIP
C217,C218,C224,C225 2203-007317 C-CER,CHIP
C222,C299,C302 2203-007449 C-CER,CHIP
C223,C278,C279,C298 2203-006839 C-CER,CHIP
C229,C244 2203-006423 C-CER,CHIP
C240,C242,C243,C246 2203-006305 C-CER,CHIP
C248,C250,C514,C517 2203-007393 C-CER,CHIP
C249 2203-006994 C-CER,CHIP
C252,C253,C259,C260 2203-006305 C-CER,CHIP
C257,C286 2203-005683 C-CER,CHIP
C268 2203-006968 C-CER,CHIP
C272 2203-006439 C-CER,CHIP
C273,C288,C290 2203-006305 C-CER,CHIP
C274 2203-005736 C-CER,CHIP
C277 2203-005792 C-CER,CHIP
C281,C284,C292 2203-007369 C-CER,CHIP
C291 2203-006400 C-CER,CHIP
C305,C454,C456 2203-006839 C-CER,CHIP
C306,C310,C311,C322 2203-006190 C-CER,CHIP
C314,C316,C719 2203-006890 C-CER,CHIP
C315,C323,C324,C329 2203-006048 C-CER,CHIP
C317,C320,C715,C739 2203-006681 C-CER,CHIP
C325,C331,C336,C341 2203-006260 C-CER,CHIP
C326,C327 2203-000812 C-CER,CHIP
C328,C348,C349,C350 2203-000812 C-CER,CHIP
C330,C337,C771 2203-007230 C-CER,CHIP
C332,C333,C701 2203-007240 C-CER,CHIP
C334,C335,C408,C418 2203-006048 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-3
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
C338,C339,C412,C460 2203-000386 C-CER,CHIP
C340,C426,C427,C433 2203-007317 C-CER,CHIP
C342,C437,C438,C439 2203-006872 C-CER,CHIP
C345,C346,C347,C407 2203-006562 C-CER,CHIP
C406,C413,C445,C448 2203-000425 C-CER,CHIP
C409,C417,C446,C447 2203-001153 C-CER,CHIP
C411,C425,C429,C457 2203-006562 C-CER,CHIP
C422 2203-000627 C-CER,CHIP
C428,C430,C431,C432 2203-006048 C-CER,CHIP
C434,C435,C502,C600 2203-006048 C-CER,CHIP
C440,C441,C443,C444 2203-007317 C-CER,CHIP
C449,C453,C462,C835 2203-000425 C-CER,CHIP
C450,C451,C463 2203-001153 C-CER,CHIP
C458,C465,C466,C507 2203-006562 C-CER,CHIP
C461 2203-000386 C-CER,CHIP
C467,C528,C605,C608 2203-007317 C-CER,CHIP
C500,C773,C791,C792 2203-007279 C-CER,CHIP
C503,C762 2203-006841 C-CER,CHIP
C504 2203-006978 C-CER,CHIP
C506,C532 2203-006844 C-CER,CHIP
C509,C510,C511,C512 2203-006562 C-CER,CHIP
C518,C519,C522,C524 2203-007393 C-CER,CHIP
C525,C527,C811 2203-007393 C-CER,CHIP
C526,C779 2203-006190 C-CER,CHIP
C529,C531,C533,C603 2203-006562 C-CER,CHIP
C530,C820,C821,C853 2203-007271 C-CER,CHIP
C601,C602,C604,C606 2203-006048 C-CER,CHIP
C607,C610,C611,C613 2203-006562 C-CER,CHIP
C609,C612,C615,C617 2203-006048 C-CER,CHIP
C614,C619,C703,C716 2203-006562 C-CER,CHIP
C616,C852 2203-007317 C-CER,CHIP
C618,C623,C625,C626 2203-006048 C-CER,CHIP
C620 2203-005138 C-CER,CHIP
C621,C622 2203-006133 C-CER,CHIP
C627,C806,C809,C818 2203-002709 C-CER,CHIP
C628 2203-000489 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-4
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
C700 2203-006348 C-CER,CHIP
C702 2203-006399 C-CER,CHIP
C705,C706,C708,C709 2203-006824 C-CER,CHIP
C710,C711,C712,C777 2203-006824 C-CER,CHIP
C717,C723,C724,C727 2203-006562 C-CER,CHIP
C718,C740 2203-000550 C-CER,CHIP
C725,C726,C730,C732 2203-006872 C-CER,CHIP
C728,C729,C731,C733 2203-006562 C-CER,CHIP
C734,C737,C754,C765 2203-006562 C-CER,CHIP
C735,C736,C738,C794 2203-006872 C-CER,CHIP
C753 2203-000725 C-CER,CHIP
C764,C803,C805,C834 2203-006048 C-CER,CHIP
C775,C776 2203-007425 C-CER,CHIP
C780 2203-006824 C-CER,CHIP
C782 2203-007133 C-CER,CHIP
C789,C807,C808,C810 2203-000254 C-CER,CHIP
C793 2203-007279 C-CER,CHIP
C800,C804,C812,C813 2203-006562 C-CER,CHIP
C817 2203-006562 C-CER,CHIP
C819,C822,C823 2203-002709 C-CER,CHIP
C824,C825,C826,C827 2203-006872 C-CER,CHIP
C828,C829,C830,C833 2203-006872 C-CER,CHIP
C832,C783 2203-006208 C-CER,CHIP
C836,C837 2203-006872 C-CER,CHIP
C838,C839,C848 2203-006048 C-CER,CHIP
C840,C841 2230-005057 C-CER,CHIP
C842 2203-003054 C-CER,CHIP
C850 2203-006257 C-CER,CHIP
C851 2203-000254 C-CER,CHIP
C854 2203-007269 C-CER,CHIP
CD300 3709-001575 CONNECTOR-CARD EDGE
D100,D101,D600 0404-001250 DIODE-SCHOTTKY
D301,D302,D303,D400 0406-001239 DIODE-TVS
D401,D402,D403,D404 0406-001375 DIODE-TVS
D500,D900 0407-001002 0407-001002
D501,D502,D804,ZD501 0406-001239 0407-001002

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-5
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
D800,D801,D802,D803 0406-001375 0407-001002
F100 2904-001939 FILTER-SAW
F201 2910-000108 DUPLEXER-SAW
F204 2909-001330 FILTER-LC
F500 2901-001634 FILTER-EMI/ESD
F800,F801,F802 2901-001525 FILTER-EMI/ESD
HDC400,HDC401,HDC500 3711-006615 HEADER-BOARD TO BOARD
HDC800 3711-006865 HEADER-BOARD TO BOARD
HDC801,HDC802 3711-006882 HEADER-BOARD TO BOARD
HDC803 3711-007245 HEADER-BOARD TO BOARD
IFC500 3710-003319 SOCKET-BOARD TO CABLE
L102,L117 2703-002918 INDUCTOR-SMD
L105 2703-002870 INDUCTOR-SMD
L107,L115 2703-002793 INDUCTOR-SMD
L108 2703-002953 INDUCTOR-SMD
L111 2703-002775 INDUCTOR-SMD
L114 2703-002900 INDUCTOR-SMD
L116 2703-001949 INDUCTOR-SMD
L121 2703-002313 INDUCTOR-SMD
R124 3301-001912 INDUCTOR-SMD
L204 3301-001659 INDUCTOR-SMD
L205,L206,L207,L208 3301-001895 INDUCTOR-SMD
L209 3301-001895 INDUCTOR-SMD
L212,L221,L222,L223 2703-002958 INDUCTOR-SMD
L213,L302,L303 2703-003869 INDUCTOR-SMD
L219 2703-002842 INDUCTOR-SMD
L220,L403,L404,L405 3301-001885 INDUCTOR-SMD
L300,L301 3301-001120 INDUCTOR-SMD
L304,L804,L806 3301-001956 INDUCTOR-SMD
L400,L401,L407,L409 3301-001756 INDUCTOR-SMD
L408 3301-001885 INDUCTOR-SMD
L410,L411,L412,L413 3301-001812 INDUCTOR-SMD
L504,L801 2703-003502 INDUCTOR-SMD
L701,L702,L703 2703-003913 INDUCTOR-SMD
L7042703-003907 INDUCTOR-SMD
L705,L706 2703-001868 INDUCTOR-SMD

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-6
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
L800 3301-001901 INDUCTOR-SMD
L802,L803 3301-001729 INDUCTOR-SMD
L805 2703-003412 INDUCTOR-SMD
LED800 0601-002413 LED-FLASH
OSC100 2809-001358 OSCILLATOR-VCTCXO
OSC200 2809-001348 OSCILLATOR-VCTCXO
OSC201 2801-004589 CRYSTAL-SMD
OSC300,OSC700 2801-004909 CRYSTAL-SMD
OSC600 2801-004682 CRYSTAL-SMD
OSC800 2801-004626 CRYSTAL-SMD
PAM100 1201-003034 IC-POWER AMP
PAM101 1201-003033 IC-POWER AMP
PAM102 1201-003032 IC-POWER AMP
PAM103 1201-002801 IC-POWER AMP
Q100,Q500 0504-001113 TR-DIGITAL
R100 2007-008419 R-CHIP
R101,R102,R342 2007-009801 R-CHIP
R103 2007-000155 R-CHIP
R109 2007-007008 R-CHIP
R110 2007-007099 R-CHIP
R115,R118,R119 2007-000758 R-CHIP
R116 2007-000775 R-CHIP
R202 2007-007132 R-CHIP
R203,R204,R205,R206 2007-010202 R-CHIP
R207 2007-010202 R-CHIP
R208 2007-008579 R-CHIP
R212 2007-008531 R-CHIP
R213 2007-008806 R-CHIP
R216 2007-008043 R-CHIP
R217 2007-009111 R-CHIP
R218,R225,R428,R429 2007-008516 R-CHIP
R300,R320,R322,R325 2007-000157 R-CHIP
R306,R334,R360,R540 2007-000148 R-CHIP
R307,R308,R309,R310 2007-007014 R-CHIP
R311,R586,R602,R694 2007-000143 R-CHIP
R314,R332,R595 2007-000167 R-CHIP
