Samsung GT-B6520 User manual

GSM TELEPHONE
GT-B6520
GSM TELEPHONE CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Level 2Repair
8. Level 3Repair
9. Reference data
Notice
All functionality, features, specifications and o
ther product information provided in this docu
ment including, but not limited to, the benefit
s, design, pricing, components, performance,
availability, and capabiliti-es of the product
are subject to change without notice or oblig
ation. Samsung reserves the right to make
changes to this document and the product
described herein, at anytime, without
obligation on Samsung to provide notification
of such change.

SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
―Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test, because the specification of cellular phone is sensitive for
surrounding interference(RF noise).
―Be careful to use akind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
―Surely use astandard screwdriver when you disassemble this product, otherwise screw will be
worn away.
―Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
―Repair after separate Test Pack and Set because for short danger (for example an overcurrent
and furious flames of parts etc) when you repair board in condition of connecting Test Pack and
tuning on.
―Take specially care of soldering, because Land of PCB is small and weak in heat.
―Surely tune on/off while using AC power plug, because arepair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
―Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
―Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity prevention
string on wrist.
―Use earthed soldering steel when you connect or disconnect ESD.
―Use soldering removing tool to break static electricity. Otherwise ESD will be damaged by static
electricity.
―Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
―You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or acircuit board.

SAMSUNG Proprietary-Contents may change without notice
2. Specification
This Document can not be used without Samsung's authorization
2-1
2-1. GSM General Specification
GSM 850 EGSM 900 DCS1800 PCS1900 W-CDMA
900 W-CDMA 2100
Freq. Band[MHz]
Uplink/Downlink 824~849 869~894 880~915 925~960 1710~1785 1805~1880 1850~1910 1930~1990 882~913 927~958 1920~1980 2110~2170
ARFCN range 128~25 0~124 &
975~1023 512~885 512~810 UL:2712~2863 DL:2937~3088
UL:9612~9888
DL:10562~
10838
Tx/Rx spacing 45MHz 45MHz 95MHz 80MHz 45MHz 130MHz
Mod. Bit rate/
Bit Period 270.833kbps
3.692us 270.833kbps 3.692us 270.833kbps 3.692us 270.833kbps 3.692us 3.84Mcps 3.84Mcps
Time Slot
Period/Frame
Period
576.9us
4.615ms 576.9us 4.615ms 576.9us 4.615ms 576.9us 4.615ms
Frame length:
10ms
Slot length :
0.667ms
Frame length:
10ms
Slot length :
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSK
HQPSK QPSK HQPSK
MS Power 33dBm
~5dBm 33dBm ~5dBm 30dBm ~0dBm 30dBm ~0dBm 24dBm~- 50dBm 24dBm ~ - 50dBm
Power Class 4 (max
+33dBm)
4
(max
+33dBm)
1
(max
+30dBm)
1
(max
+30dBm)
3
(max +24dBm) 3 (max +24dBm)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm
TDMAMux8888
Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km

SAMSUNG Proprietary-Contents may change without notice
Specification
2-2
This Document can not be used without Samsung's authorization
TX Power
control level GSM850
GSM900
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3 dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control level DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control level PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
2-2. GSM Tx Power Class

SAMSUNG Proprietary-Contents may change without notice
3. Operation Instruction and Installation
3-1
This Document can not be used without Samsung's authorization
Main Function
－HSDPA /UMTS, EDGE, GPRS
－BT 2.0 + EDR
－Camera: 2.0 Mega Pixel, CMOS
CIF CAMERA(Video Call)
－LCD :2.4"
LQVGA TFT-LCD
－Size : 116.5x61.8x11.5 mm
－GPRS/EDGE :class 10
－Battery: 1500mAH
－Band: GSM 900/1800/1900, FDDⅠ/Ⅷ
－BB: Qualcomm MSM7225
－RF: Qualcomm RTR6285
－WLAN 802.11 b/g
－A-GPS
－FM RADIO
－Video Sharing /Streaming
－USB 2.0
－MMS /SMS

SAMSUNG Proprietary-Contents may change without notice
4. Exploded View and Parts List
4-1
This Document can not be used without Samsung's authorization
4-1. Cellular phone Exploded View

SAMSUNG Proprietary-Contents may change without notice
Exploded View and Parts List
4-2
This Document can not be used without Samsung's authorization
Design LOC Discription SEC CODE
QCR03 SCREW-MACHINE 6001-001811
QCR49 SCREW-MACHINE 6001-001823
QCR101 SCREW-MACHINE 6001-002005
QAN02 INTENNA-GTB6520 MAIN GH42-02531A
QSM01 KEY FPCB-SIM ASSY GH59-09370A
QSP01 MODULE-SPK+RCV+MOT GH59-09396A
QCA01 CAMERA MODULE-GT-B6520 GH59-09505A
QVK01 KEY FPCB-VOL KEY GH59-09683A
QME01 ASSY MODULE-TF KEY PBA+LCD BRACKET(GTB65 GH96-04892A
QMP01 A/S ASSY-PBA MAIN (COMM) GH82-05107A
QLC01 ASSY LCD-2.4" TFT GT-B6520 GH96-04551A
QCA02 ASSY CAMERA-CIF MODULE(GT-B6520) GH96-04577A
QKP01 ASSY KEYPAD-(BLACK/OPEN) GH98-16968A
QBC00 ASSY CASE-BATT COVER GH98-17868A
QFR01 ASSY CASE-FRONT GH98-16965A
QMW01 ASSY COVER-MAIN WINDOW GH98-17562A
QRE01 ASSY CASE-REAR GH98-16964A
QRF06 PMO COVER-USB GH72-59495A
QSD01 PMO COVER-SD GH72-59496A
QVO01 PMO KEY-VOLUME GH72-59497A
QCK01 PMO KEY-CAMERA GH72-59498A
4-2. Cellular phone Parts list

SAMSUNG Proprietary-Contents may change without notice
5. MAIN Electrical Parts List
5-1
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
0403-001741 ZD400 DIODE-ZENER
0406-001231 ZD401 DIODE-TVS
0406-001231 ZD402 DIODE-TVS
0406-001231 ZD403 DIODE-TVS
0406-001231 ZD502 DIODE-TVS
0406-001231 ZD503 DIODE-TVS
0406-001231 ZD505 DIODE-TVS
0406-001231 ZD507 DIODE-TVS
0406-001231 ZD508 DIODE-TVS
0406-001231 ZD510 DIODE-TVS
0406-001231 ZD511 DIODE-TVS
0406-001231 ZD512 DIODE-TVS
0406-001231 ZD600 DIODE-TVS
0406-001231 ZD602 DIODE-TVS
0406-001231 ZD603 DIODE-TVS
0406-001231 ZD606 DIODE-TVS
0406-001390 ZD513 DIODE-TVS
0406-001413 D601 DIODE-TVS
0406-001413 D602 DIODE-TVS
0406-001413 D603 DIODE-TVS
0406-001413 D604 DIODE-TVS
0406-001413 D605 DIODE-TVS
0406-001413 D606 DIODE-TVS
0406-001413 D607 DIODE-TVS
0406-001413 D608 DIODE-TVS
0406-001413 ZD501 DIODE-TVS
0406-001413 ZD504 DIODE-TVS
0406-001413 ZD509 DIODE-TVS
0407-001002 D400 DIODE-ARRAY
0407-001002 D500 DIODE-ARRAY
0504-001138 TR500 TR-DIGITAL
0505-001325 TR600 FET-SILICON
0505-002341 TR400 FET-SILICON
0801-003200 U302 IC-CMOS LOGIC
0801-003265 U301 IC-CMOS LOGIC
1001-001488 U402 IC-ANALOG SWITCH
1001-001607 U205 IC-RF SWITCH
1001-001645 U500 IC-ANALOG MULTIPLEX
1108-000348 UME300 IC-MCP
1201-002971 U202 IC-RF AMP
1201-003057 PAM101 IC-POWER AMP
1201-003060 PAM102 IC-POWER AMP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-2
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
1201-003112 PAM100 IC-POWER AMP
1202-001068 U502 IC-VOLTAGE COMP.
1203-003924 U400 IC-VOL. DETECTOR
1203-004776 U501 IC-POSI.FIXED REG.
1203-006291 U401 IC-POWER SUPERVISOR
1203-006346 U405 IC-RESET
1203-006370 U601 IC-DC/DC CONVERTER
1205-003297 U100 IC-TRANSCEIVER
1205-003883 U203 IC-BLUETOOTH
1205-004047 UCP300 IC-MODEM
1205-004076 U201 IC-WIFI
1404-001221 TH300 THERMISTOR-NTC
2007-000137 R319 R-CHIP
2007-000138 R100 R-CHIP
2007-000138 R321 R-CHIP
2007-000138 R335 R-CHIP
2007-000138 R415 R-CHIP
2007-000138 R500 R-CHIP
2007-000138 R515 R-CHIP
2007-000140 R330 R-CHIP
2007-000140 R331 R-CHIP
2007-000140 R332 R-CHIP
2007-000140 R333 R-CHIP
2007-000140 R518 R-CHIP
2007-000140 R606 R-CHIP
2007-000141 R108 R-CHIP
2007-000141 R303 R-CHIP
2007-000141 R304 R-CHIP
2007-000141 R309 R-CHIP
2007-000141 R310 R-CHIP
2007-000143 R311 R-CHIP
2007-000143 R312 R-CHIP
2007-000144 R400 R-CHIP
2007-000148 R305 R-CHIP
2007-000148 R430 R-CHIP
2007-000148 R502 R-CHIP
2007-000149 R112 R-CHIP
2007-000149 R423 R-CHIP
2007-000153 R603 R-CHIP
2007-000157 R207 R-CHIP
2007-000157 R208 R-CHIP
2007-000157 R417 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-3
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2007-000157 R418 R-CHIP
2007-000157 R419 R-CHIP
2007-000157 R420 R-CHIP
2007-000157 R421 R-CHIP
2007-000157 R422 R-CHIP
2007-000157 R435 R-CHIP
2007-000162 R301 R-CHIP
2007-000162 R306 R-CHIP
2007-000162 R308 R-CHIP
2007-000162 R313 R-CHIP
2007-000162 R314 R-CHIP
2007-000162 R322 R-CHIP
2007-000162 R325 R-CHIP
2007-000162 R413 R-CHIP
2007-000162 R434 R-CHIP
2007-000162 R512 R-CHIP
2007-000162 R605 R-CHIP
2007-000165 R404 R-CHIP
2007-000165 R516 R-CHIP
2007-000165 R602 R-CHIP
2007-000168 R504 R-CHIP
2007-000168 R604 R-CHIP
2007-000170 R513 R-CHIP
2007-000172 R334 R-CHIP
2007-000172 R600 R-CHIP
2007-000172 R601 R-CHIP
2007-000172 R607 R-CHIP
2007-000174 R113 R-CHIP
2007-000242 R506 R-CHIP
2007-000242 R508 R-CHIP
2007-000242 R509 R-CHIP
2007-001119 R505 R-CHIP
2007-001119 R507 R-CHIP
2007-001119 R511 R-CHIP
2007-001217 R121 R-CHIP
2007-001217 R122 R-CHIP
2007-001292 R324 R-CHIP
2007-001292 R407 R-CHIP
2007-001292 R408 R-CHIP
2007-001298 R101 R-CHIP
2007-001298 R104 R-CHIP
2007-001298 R403 R-CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-4
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2007-001305 R115 R-CHIP
2007-001313 R205 R-CHIP
2007-001313 R210 R-CHIP
2007-001333 R517 R-CHIP
2007-003015 R436 R-CHIP
2007-007014 R302 R-CHIP
2007-007107 R409 R-CHIP
2007-007156 R318 R-CHIP
2007-007468 R411 R-CHIP
2007-007480 R410 R-CHIP
2007-007573 R405 R-CHIP
2007-008046 R116 R-CHIP
2007-008046 R119 R-CHIP
2007-008046 R120 R-CHIP
2007-008055 R510 R-CHIP
2007-008419 R107 R-CHIP
2007-008419 R109 R-CHIP
2007-008419 R110 R-CHIP
2007-008419 R111 R-CHIP
2007-008419 R117 R-CHIP
2007-008766 R317 R-CHIP
2007-008812 R406 R-CHIP
2007-009766 R114 R-CHIP
2007-009766 R118 R-CHIP
2007-009794 R201 R-CHIP
2203-000233 C463 C-CER,CHIP
2203-000254 C101 C-CER,CHIP
2203-000254 C137 C-CER,CHIP
2203-000254 C173 C-CER,CHIP
2203-000254 C233 C-CER,CHIP
2203-000278 C334 C-CER,CHIP
2203-000330 C213 C-CER,CHIP
2203-000330 C226 C-CER,CHIP
2203-000330 C445 C-CER,CHIP
2203-000330 C446 C-CER,CHIP
2203-000330 C447 C-CER,CHIP
2203-000330 C448 C-CER,CHIP
2203-000330 C449 C-CER,CHIP
2203-000438 C106 C-CER,CHIP
2203-000438 C109 C-CER,CHIP
2203-000438 C113 C-CER,CHIP
2203-000438 C128 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-5
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2203-000438 C152 C-CER,CHIP
2203-000438 C327 C-CER,CHIP
2203-000438 C510 C-CER,CHIP
2203-000466 C102 C-CER,CHIP
2203-000489 C332 C-CER,CHIP
2203-000550 C427 C-CER,CHIP
2203-000550 C428 C-CER,CHIP
2203-000585 C423 C-CER,CHIP
2203-000585 C520 C-CER,CHIP
2203-000585 C521 C-CER,CHIP
2203-000627 C160 C-CER,CHIP
2203-000627 C174 C-CER,CHIP
2203-000627 C175 C-CER,CHIP
2203-000696 C256 C-CER,CHIP
2203-000812 C100 C-CER,CHIP
2203-000812 C131 C-CER,CHIP
2203-000812 C139 C-CER,CHIP
2203-000812 C142 C-CER,CHIP
2203-000812 C143 C-CER,CHIP
2203-000812 C155 C-CER,CHIP
2203-000812 C163 C-CER,CHIP
2203-000812 C171 C-CER,CHIP
2203-000812 C179 C-CER,CHIP
2203-000812 C184 C-CER,CHIP
2203-000812 C188 C-CER,CHIP
2203-000812 C214 C-CER,CHIP
2203-000812 C215 C-CER,CHIP
2203-000812 C231 C-CER,CHIP
2203-000812 C235 C-CER,CHIP
2203-000812 C240 C-CER,CHIP
2203-000812 C241 C-CER,CHIP
2203-000812 C258 C-CER,CHIP
2203-000812 C442 C-CER,CHIP
2203-000812 C506 C-CER,CHIP
2203-000812 C507 C-CER,CHIP
2203-000812 C509 C-CER,CHIP
2203-000812 C512 C-CER,CHIP
2203-000812 C513 C-CER,CHIP
2203-000812 C516 C-CER,CHIP
2203-000854 C230 C-CER,CHIP
2203-000995 C108 C-CER,CHIP
2203-000995 C121 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-6
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2203-000995 C330 C-CER,CHIP
2203-000995 C424 C-CER,CHIP
2203-001153 C144 C-CER,CHIP
2203-001153 C151 C-CER,CHIP
2203-001405 C405 C-CER,CHIP
2203-001405 C406 C-CER,CHIP
2203-001437 C130 C-CER,CHIP
2203-002443 C514 C-CER,CHIP
2203-002443 C517 C-CER,CHIP
2203-002443 C522 C-CER,CHIP
2203-002677 C239 C-CER,CHIP
2203-002709 C505 C-CER,CHIP
2203-002709 C511 C-CER,CHIP
2203-003054 C508 C-CER,CHIP
2203-003054 C602 C-CER,CHIP
2203-003054 C611 C-CER,CHIP
2203-005052 C114 C-CER,CHIP
2203-005052 C153 C-CER,CHIP
2203-005052 C158 C-CER,CHIP
2203-005053 C119 C-CER,CHIP
2203-005053 C120 C-CER,CHIP
2203-005053 C154 C-CER,CHIP
2203-005057 C127 C-CER,CHIP
2203-005234 C169 C-CER,CHIP
2203-005281 C136 C-CER,CHIP
2203-005344 C620 C-CER,CHIP
2203-005382 C210 C-CER,CHIP
2203-005382 C218 C-CER,CHIP
2203-005395 C244 C-CER,CHIP
2203-005446 C104 C-CER,CHIP
2203-005446 C164 C-CER,CHIP
2203-005446 C181 C-CER,CHIP
2203-005682 C107 C-CER,CHIP
2203-005682 C146 C-CER,CHIP
2203-005682 C147 C-CER,CHIP
2203-005682 C150 C-CER,CHIP
2203-005682 C156 C-CER,CHIP
2203-005682 C176 C-CER,CHIP
2203-005682 C177 C-CER,CHIP
2203-005682 C178 C-CER,CHIP
2203-005682 C191 C-CER,CHIP
2203-005682 C192 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-7
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2203-005682 C195 C-CER,CHIP
2203-005682 C197 C-CER,CHIP
2203-005717 C243 C-CER,CHIP
2203-005725 C183 C-CER,CHIP
2203-005725 C254 C-CER,CHIP
2203-005777 C165 C-CER,CHIP
2203-005777 C180 C-CER,CHIP
2203-005792 C187 C-CER,CHIP
2203-005792 C189 C-CER,CHIP
2203-005806 C167 C-CER,CHIP
2203-005806 C208 C-CER,CHIP
2203-006047 C326 C-CER,CHIP
2203-006048 C110 C-CER,CHIP
2203-006048 C159 C-CER,CHIP
2203-006048 C166 C-CER,CHIP
2203-006048 C185 C-CER,CHIP
2203-006048 C232 C-CER,CHIP
2203-006048 C250 C-CER,CHIP
2203-006048 C300 C-CER,CHIP
2203-006048 C301 C-CER,CHIP
2203-006048 C305 C-CER,CHIP
2203-006048 C306 C-CER,CHIP
2203-006048 C308 C-CER,CHIP
2203-006048 C311 C-CER,CHIP
2203-006048 C312 C-CER,CHIP
2203-006048 C313 C-CER,CHIP
2203-006048 C314 C-CER,CHIP
2203-006048 C316 C-CER,CHIP
2203-006048 C322 C-CER,CHIP
2203-006048 C323 C-CER,CHIP
2203-006048 C328 C-CER,CHIP
2203-006048 C331 C-CER,CHIP
2203-006048 C335 C-CER,CHIP
2203-006048 C420 C-CER,CHIP
2203-006048 C433 C-CER,CHIP
2203-006048 C434 C-CER,CHIP
2203-006048 C435 C-CER,CHIP
2203-006048 C436 C-CER,CHIP
2203-006048 C443 C-CER,CHIP
2203-006121 C253 C-CER,CHIP
2203-006190 C524 C-CER,CHIP
2203-006194 C138 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-8
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2203-006194 C161 C-CER,CHIP
2203-006194 C186 C-CER,CHIP
2203-006399 C302 C-CER,CHIP
2203-006399 C304 C-CER,CHIP
2203-006399 C307 C-CER,CHIP
2203-006399 C315 C-CER,CHIP
2203-006399 C319 C-CER,CHIP
2203-006399 C333 C-CER,CHIP
2203-006399 C407 C-CER,CHIP
2203-006399 C408 C-CER,CHIP
2203-006399 C413 C-CER,CHIP
2203-006399 C415 C-CER,CHIP
2203-006399 C419 C-CER,CHIP
2203-006399 C425 C-CER,CHIP
2203-006399 C437 C-CER,CHIP
2203-006399 C438 C-CER,CHIP
2203-006399 C439 C-CER,CHIP
2203-006399 C452 C-CER,CHIP
2203-006399 C453 C-CER,CHIP
2203-006399 C454 C-CER,CHIP
2203-006399 C458 C-CER,CHIP
2203-006399 C459 C-CER,CHIP
2203-006399 C461 C-CER,CHIP
2203-006399 C462 C-CER,CHIP
2203-006399 C464 C-CER,CHIP
2203-006399 C600 C-CER,CHIP
2203-006399 C601 C-CER,CHIP
2203-006423 C105 C-CER,CHIP
2203-006423 C148 C-CER,CHIP
2203-006423 C149 C-CER,CHIP
2203-006423 C182 C-CER,CHIP
2203-006423 C190 C-CER,CHIP
2203-006423 C193 C-CER,CHIP
2203-006423 C196 C-CER,CHIP
2203-006423 C200 C-CER,CHIP
2203-006423 C203 C-CER,CHIP
2203-006423 C205 C-CER,CHIP
2203-006423 C206 C-CER,CHIP
2203-006423 C209 C-CER,CHIP
2203-006423 C221 C-CER,CHIP
2203-006423 C262 C-CER,CHIP
2203-006562 C426 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-9
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2203-006839 C247 C-CER,CHIP
2203-006839 C248 C-CER,CHIP
2203-006839 C303 C-CER,CHIP
2203-006839 C320 C-CER,CHIP
2203-006839 C321 C-CER,CHIP
2203-006839 C329 C-CER,CHIP
2203-006872 C234 C-CER,CHIP
2203-006872 C236 C-CER,CHIP
2203-006872 C237 C-CER,CHIP
2203-006872 C245 C-CER,CHIP
2203-006872 C246 C-CER,CHIP
2203-006872 C615 C-CER,CHIP
2203-006872 C616 C-CER,CHIP
2203-006978 C618 C-CER,CHIP
2203-007194 C261 C-CER,CHIP
2203-007271 C202 C-CER,CHIP
2203-007271 C217 C-CER,CHIP
2203-007271 C255 C-CER,CHIP
2203-007271 C409 C-CER,CHIP
2203-007271 C410 C-CER,CHIP
2203-007271 C417 C-CER,CHIP
2203-007271 C421 C-CER,CHIP
2203-007271 C422 C-CER,CHIP
2203-007271 C460 C-CER,CHIP
2203-007271 C500 C-CER,CHIP
2203-007271 C501 C-CER,CHIP
2203-007271 C619 C-CER,CHIP
2203-007279 C103 C-CER,CHIP
2203-007279 C129 C-CER,CHIP
2203-007279 C157 C-CER,CHIP
2203-007279 C400 C-CER,CHIP
2203-007279 C401 C-CER,CHIP
2203-007279 C402 C-CER,CHIP
2203-007279 C403 C-CER,CHIP
2203-007279 C465 C-CER,CHIP
2203-007279 C518 C-CER,CHIP
2203-007279 C523 C-CER,CHIP
2203-007317 C112 C-CER,CHIP
2203-007317 C194 C-CER,CHIP
2203-007317 C412 C-CER,CHIP
2203-007317 C416 C-CER,CHIP
2203-007317 C429 C-CER,CHIP

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-10
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2203-007317 C430 C-CER,CHIP
2203-007317 C431 C-CER,CHIP
2203-007317 C432 C-CER,CHIP
2203-007385 C309 C-CER,CHIP
2203-007385 C310 C-CER,CHIP
2203-007391 C238 C-CER,CHIP
2203-007403 C212 C-CER,CHIP
2203-007425 C519 C-CER,CHIP
2203-007449 C318 C-CER,CHIP
2409-001172 BAT400 C-EDL
2703-001708 L150 INDUCTOR-SMD
2703-001708 L151 INDUCTOR-SMD
2703-001726 L106 INDUCTOR-SMD
2703-001726 L108 INDUCTOR-SMD
2703-001726 L111 INDUCTOR-SMD
2703-001726 L112 INDUCTOR-SMD
2703-001729 L128 INDUCTOR-SMD
2703-001733 L129 INDUCTOR-SMD
2703-001734 L210 INDUCTOR-SMD
2703-001737 L101 INDUCTOR-SMD
2703-001737 L203 INDUCTOR-SMD
2703-001747 L114 INDUCTOR-SMD
2703-001747 L130 INDUCTOR-SMD
2703-001748 L148 INDUCTOR-SMD
2703-001786 L147 INDUCTOR-SMD
2703-001786 L201 INDUCTOR-SMD
2703-001938 L501 INDUCTOR-SMD
2703-001938 L504 INDUCTOR-SMD
2703-002155 L103 INDUCTOR-SMD
2703-002155 L109 INDUCTOR-SMD
2703-002155 L113 INDUCTOR-SMD
2703-002170 L153 INDUCTOR-SMD
2703-002176 L138 INDUCTOR-SMD
2703-002198 L146 INDUCTOR-SMD
2703-002203 L105 INDUCTOR-SMD
2703-002203 L115 INDUCTOR-SMD
2703-002204 L152 INDUCTOR-SMD
2703-002205 L216 INDUCTOR-SMD
2703-002207 L200 INDUCTOR-SMD
2703-002208 L132 INDUCTOR-SMD
2703-002208 L154 INDUCTOR-SMD
2703-002267 L116 INDUCTOR-SMD

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-11
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
2703-002281 L142 INDUCTOR-SMD
2703-002281 L143 INDUCTOR-SMD
2703-002313 L217 INDUCTOR-SMD
2703-002313 L218 INDUCTOR-SMD
2703-002314 L204 INDUCTOR-SMD
2703-002314 L219 INDUCTOR-SMD
2703-002365 L119 INDUCTOR-SMD
2703-002368 L144 INDUCTOR-SMD
2703-002368 L145 INDUCTOR-SMD
2703-002369 L126 INDUCTOR-SMD
2703-002369 L149 INDUCTOR-SMD
2703-002557 L503 INDUCTOR-SMD
2703-002793 L134 INDUCTOR-SMD
2703-002793 L136 INDUCTOR-SMD
2703-002794 L140 INDUCTOR-SMD
2703-002842 L137 INDUCTOR-SMD
2703-002858 L139 INDUCTOR-SMD
2703-003485 L600 INDUCTOR-SMD
2703-003686 L400 INDUCTOR-SMD
2703-003686 L401 INDUCTOR-SMD
2703-003686 L402 INDUCTOR-SMD
2703-003686 L403 INDUCTOR-SMD
2801-004821 OSC200 CRYSTAL-SMD
2801-004909 OSC400 CRYSTAL-SMD
2809-001361 TCX100 OSCILLATOR-VCTCXO
2901-001454 F604 FILTER-EMI/ESD
2901-001516 F600 FILTER-EMI/ESD
2901-001516 F601 FILTER-EMI/ESD
2901-001516 F602 FILTER-EMI/ESD
2901-001516 F603 FILTER-EMI/ESD
2901-001516 F605 FILTER-EMI/ESD
2904-001756 F103 FILTER-SAW
2904-001770 F102 FILTER-SAW
2904-001847 F101 FILTER-SAW
2904-001850 F100 FILTER-SAW
2904-001944 F200 FILTER-SAW
2910-000073 DUF102 DUPLEXER-SAW
2910-000099 DUF101 DUPLEXER-SAW
2910-000100 DUF100 DUPLEXER-SAW
2911-000148 RFS101 DUPLEXER-FEM
3301-001756 L104 BEAD-SMD
3301-001756 L502 BEAD-SMD

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
5-12
This Document can not be used without Samsung's authorization
SEC Code Design Location Description
3301-001756 L505 BEAD-SMD
3301-001812 L404 BEAD-SMD
3301-001812 L405 BEAD-SMD
3301-001812 L500 BEAD-SMD
3301-001885 L506 BEAD-SMD
3301-001885 L507 BEAD-SMD
3301-001885 L509 BEAD-SMD
3705-001503 RFS100 CONNECTOR-COAXIAL
3709-001575 CD400 CONNECTOR-CARD EDGE
3710-003306 SOC600 CONNECTOR-SOCKET
3711-005962 HDC600 HEADER-BOARD TO BOARD
3711-006105 HDC601 HEADER-BOARD TO BOARD
3711-006615 SIM400 HEADER-BOARD TO BOARD
3711-006650 HDC500 HEADER-BOARD TO BOARD
3711-006852 HDC602 HEADER-BOARD TO BOARD
3711-006910 BTC400 HEADER-BATTERY
3722-002871 IFC500 JACK-MINI USB
4709-001905 F202 BALUN
4709-001906 F201 BALUN
GH71-08731A ANT200 NPR CONTACT-CAM
GH71-08731A ANT201 NPR CONTACT-CAM
Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list.
