Samsung GT-E2550L User manual

Printed in Korea
Code No.:GH68-29179A
English (LTN). 08/2010. Rev. 1.0
Some of the contents in this manual may differ from your phone
depending on the software of the phone or your service provider.
www.samsungmobile.com
E2550L_UM_LTN.indb 2 2010-08-16 오전 10:08:50

GT-E2550L
user manual
E2550L_UM_LTN.indb 3 2010-08-16 오전 10:08:51

2
Using this manual
This user manual has been specially designed to
guide you through the functions and features of
your mobile phone. To get started quickly, refer to
"Introducing your mobile phone," "Assembling and
preparing your mobile phone," and "Using basic
functions."
Instructional icons
Note: notes, usage tips, or additional
information
→
Followed by: the order of options or menus
you must select to perform a step; for example:
In Menu mode, select Messages → Create
message (represents Messages, followed by
Create message)
[ ] Square brackets: phone keys; for example:
[] (represents the Power/End key)
< >
Angled brackets: softkeys that control different
functions at each screen; for example: <OK>
(represents the OK softkey)
►Refer to: pages with related information; for
example: ► p. 12 (represents "see page 12")
E2550L_UM_LTN.indb 2 2010-08-16 오전 10:08:51

3
Copyright information
Rights to all technologies and products that
comprise this phone are the property of their
respective owners:
Bluetooth•
®
is a registered trademark of the
Bluetooth SIG, Inc. worldwide.
Java™ is a trademark of Sun Microsystems,•
Inc.
E2550L_UM_LTN.indb 3 2010-08-16 오전 10:08:51

4
Contents
Introducing your mobile phone...............................6
Phone layout ...............................................................6
Icons............................................................................8
Assembling and preparing your mobile phone.....9
Install the SIM card and battery ..................................9
Charge the battery ....................................................10
Insert a memory card (optional)................................ 11
Using basic functions.............................................12
Turn your phone on or off..........................................12
Access menus...........................................................12
Customise your phone..............................................13
Use basic call functions ............................................14
Send and view messages.........................................15
Enter text...................................................................16
Add and nd contacts ...............................................17
Use basic camera functions......................................18
Listen to music ..........................................................20
Browse the web.........................................................22
Using advanced functions.....................................23
Use advanced call functions .....................................23
Use advanced phonebook functions ........................26
Use advanced messaging functions.........................27
Use advanced camera functions ..............................27
Use advanced music functions.................................30
E2550L_UM_LTN.indb 4 2010-08-16 오전 10:08:51

5
Using tools and applications.................................33
Use the Bluetooth wireless feature...........................33
Activate and send an SOS message........................35
Activate the mobile tracker........................................36
Make fake calls .........................................................37
Record and play voice memos .................................37
Use Java-powered games and applications.............38
Create a world clock .................................................38
Set and use alarms ...................................................39
Use the calculator .....................................................40
Convert currencies or measurements ......................40
Set a countdown timer ..............................................40
Use the stopwatch ....................................................41
Create a text memo ..................................................41
Manage your calendar ..............................................41
Troubleshooting......................................................43
Safety and usage information ...............................49
E2550L_UM_LTN.indb 5 2010-08-16 오전 10:08:51

6
Introducing your
mobile phone
In this section, learn about your mobile phone’s
layout, keys, and icons.
Phone layout
3
8
7
1
2
4
6
5
E2550L_UM_LTN.indb 6 2010-08-16 오전 10:08:51

7
1
4-way navigation key
In ldle mode, access user-
dened menus; Make a fake
call (down); In Menu mode,
scroll through menu options
Depending on your service
provider, pre-dened menus
may differ
► " Make fake calls"
2
Dial key
Make or answer a call; In Idle
mode, retrieve recently dialled,
missed, or received numbers;
Send an SOS message
► " Activate and send an SOS
message"
3
Voice mail service key
In ldle mode, access voice
mails (press and hold)
4
Softkeys
Perform actions indicated at
the bottom of the display
5
Power/End key
Turn the phone on or off
(press and hold); End a call;
In Menu mode, cancel input
and return to Idle mode
6
Conrm key
In Idle mode, access Menu
mode; Launch the web
browser (press and hold);
In Menu mode, select the
highlighted menu option or
conrm an input
Depending on your service
provider or region, the key may
perform differently
7
Alphanumeric keys
8
Silent prole key
In ldle mode, activate or
deactivate the silent prole
(press and hold)
E2550L_UM_LTN.indb 7 2010-08-16 오전 10:08:51

8
Icons
Icons shown on the display may vary depending
on your region or service provider.
Icon Denition
Signal strength
Call in progress
Call diverting activated
SOS message feature activated
GPRS network connected
Roaming (outside of normal service area)
Connecting to secured web page
FM radio on
Bluetooth activated
Alarm activated
Memory card inserted
New text message (SMS)
New multimedia message (MMS)
New voice mail message
Normal prole activated
Silent prole activated
Battery power level
E2550L_UM_LTN.indb 8 2010-08-16 오전 10:08:51

9
Assembling and
preparing your mobile
phone
Get started by assembling and setting up your
mobile phone for its first use.
Install the SIM card and battery
Remove the back cover and insert the SIM1.
card.
Back cover SIM card
Insert the battery and replace the back cover.2.
Battery
E2550L_UM_LTN.indb 9 2010-08-16 오전 10:08:51

10
Charge the battery
Plug the small end of the supplied travel1.
adapter into the multifunction jack.
Plug the large end of the travel adapter into a2.
power outlet.
When charging is finished, unplug the travel3.
adapter.
Do not remove the battery from the phone before
unplugging the travel adapter rst. Otherwise, the
phone may be damaged.
E2550L_UM_LTN.indb 10 2010-08-16 오전 10:08:51

11
Insert a memory card (optional)
Your phone accepts microSD™ or microSDHC™
memory cards up to 8 GB (depending on memory
card manufacturer and type).
Formatting the memory card on a PC may cause•
incompatibility with your phone. Format the
memory card only on the phone.
Frequent writing and erasing of data will shorten•
the lifespan of memory cards.
Remove the back cover.1.
Insert a memory card with the gold-coloured2.
contacts facing down.
Replace the back cover.3.
E2550L_UM_LTN.indb 11 2010-08-16 오전 10:08:51

12
Using basic functions
Learn how to perform basic operations and use the
main features of your mobile phone.
Turn your phone on or off
To turn your phone on,
Press and hold [1. ].
Enter your PIN and press <2. OK> (if necessary).
To turn your phone off, repeat step 1 above.
Access menus
To access your phone's menus,
In Idle mode, press <1. Menu> to access Menu
mode.
You may need to press the Conrm key to access
Menu mode depending on your region or service
provider.
Use the Navigation key to scroll to a menu or2.
option.
Press <3. Select>, <Save>, or the Confirm key to
confirm the highlighted option.
Press <4. Back> to move up one level; Press
[] to return to Idle mode.
E2550L_UM_LTN.indb 12 2010-08-16 오전 10:08:51

13
When you access a menu requiring the PIN2,•
you must enter the PIN2 supplied with the SIM
card. For details, contact your service provider.
Samsung is not responsible for any loss of•
passwords or private information or other
damages caused by illegal software.
Customise your phone
To set the sound prole
To switch to sound profile,
In Menu mode, select1. Settings → Profiles.
Select a profile you want.2.
To edit a sound profile,
In Menu mode, select1. Settings → Profiles.
Scroll to a user profile and press <2. Options>
→ Edit.
Customise the sound settings as desired.3.
To set menu shortcuts
In Menu mode, select1. Settings → Phone →
Shortcuts.
Select a key to use as a shortcut.2.
Select a menu to assign to the shortcut key.3.
E2550L_UM_LTN.indb 13 2010-08-16 오전 10:08:51

14
Use basic call functions
To make a call
In Idle mode, enter an area code and a phone1.
number.
Press [2. ] to dial the number.
To end the call, press [3. ].
To answer a call
When a call comes in, press [1. ].
To end the call, press [2. ].
To adjust the volume of voice during a call
While a call is in progress, press the Navigation
key up or down to adjust the volume.
To use the speakerphone feature
During a call, press the Confirm key to activate1.
the speaker.
To switch back to the earpiece, press the2.
Confirm key again.
In noisy environments, you may have difculty
hearing the calls while using the speakerphone
feature. For better audio performance, use the
normal phone mode.
E2550L_UM_LTN.indb 14 2010-08-16 오전 10:08:51

15
To use the headset
By plugging the supplied headset into the
multifunction jack, you can make and answer calls:
To redial the last call, press and hold the•
headset button.
To answer a call, press the headset button.•
To end a call, press and hold the headset•
button.
Send and view messages
To send a text or multimedia message
In Menu mode, select1. Messages → Create
message.
Enter a recipient number and scroll down.2.
Enter your message text. ► p. 3. 16
For sending as a text message, skip to step 5.
For attaching multimedia, continue with step 4.
Press <4. Options>→ Add multimedia and add
an item.
Press the Confirm key to send the message.5.
To view text or multimedia messages
In Menu mode, select1. Messages → Inbox.
Select a text or multimedia message.2.
E2550L_UM_LTN.indb 15 2010-08-16 오전 10:08:51

16
Enter text
You can enter text by pressing keys on the keypad.
Available text input modes may vary depending
on your region.
To change the text input mode
Press and hold [• ] to switch between T9 and
ABC modes.
Press [• ] to change case or switch to Number
mode.
Press [• ] to switch to Symbol mode.
Press and hold [• ] to select an input mode or
change the input language.
T9 mode
Press appropriate alphanumeric keys to enter1.
an entire word.
When the word displays correctly, press [2. 0]
to insert a space. If the correct word does not
display, press the Navigation key up or down to
select an alternate word.
ABC mode
Press an appropriate alphanumeric key until the
character you want appears on the display.
E2550L_UM_LTN.indb 16 2010-08-16 오전 10:08:51

17
Number mode
Press an appropriate alphanumeric key to enter a
number.
Symbol mode
Press an appropriate alphanumeric key to enter
a symbol.
To move the cursor, press the Navigation key.•
To delete characters one by one, press <• Clear>.
To quickly delete characters, press and hold
<Clear>.
To insert a space between characters, press [• 0].
To enter punctuation marks, press [• 1].
Add and nd contacts
The memory location to save new contacts may
be preset depending on your service provider.
To change the memory location, in Menu mode,
select Contacts → Management → Save new
contacts to → a memory location.
To add a new contact
In Idle mode, enter a phone number and press1.
<Options> → Create contact.
Select a memory location (if necessary).2.
E2550L_UM_LTN.indb 17 2010-08-16 오전 10:08:51

18
Select a number type (if necessary).3.
Enter contact information.4.
Press the Confirm key to add the contact to5.
memory.
To nd a contact
In Menu mode, select1. Contacts → Contact
list.
Enter the first few letters of the name you want2.
to find.
Select the contact’s name from the contact list.3.
Use basic camera functions
To capture photos
In Menu mode, select1. Camera to turn on the
camera.
Aim the lens at the subject and make any2.
adjustments.
Press the Confirm key to take a photo. The3.
photo is saved automatically.
Press <4. Back> to take another photo (step 2).
E2550L_UM_LTN.indb 18 2010-08-16 오전 10:08:51

19
To view photos
In Menu mode, select My files → Images → a
photo file.
To capture videos
In Menu mode, select1. Camera to turn on the
camera.
Press <2. Options> → Camcorder to switch to
Recording mode.
Aim the lens at the subject and make any3.
adjustments.
Press the Confirm key to start recording.4.
Press the Confirm key or <5. Stop> to stop
recording. The video is saved automatically.
To view videos
In Menu mode, select My files → Videos → a
video file.
E2550L_UM_LTN.indb 19 2010-08-16 오전 10:08:51
