Samsung GT-I5700 User manual

GSM TELEPHONE
GT-i5700
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts list
6. MAIN Electrical Parts List
7. Block Diagrams
8. PCB Diagrams
9. Chart of Troubleshooting
10. Reference data
11. Disassembly and Assembly
Instructions
GSM TELEPHONE CONTENTS

This Service Manual is aproperty of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
Samsung Electronics Co.,Ltd.
2009. 10. Rev.1.0
ⓒ
Country Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast &Africa mea.samsungportal.com
GSPN (Global Service Partner Network)

SAMSUNG Proprietary-Contents may change without notice
1. Safety Precautions
1-1
This Document can not be used without Samsung's authorization
1-1. Repair Precaution
―Repair in Shield Box, during detailed tuning. Take specially care of tuning or test, because
specipicty of cellular phone is sensitive for surrounding interference(RF noise).
―Be careful to use akind of magnetic object or tool, because performance of parts is damaged by
the influence of magnetic force.
―Surely use astandard screwdriver when you disassemble this product, otherwise screw will be
worn away.
―Use athicken twisted wire when you measure level.
Athicken twisted wire has low resistance, therefore error of measurement is few.
―Repair after separate Test Pack and Set because for short danger (for example an overcurrent
and furious flames of parts etc) when you repair board in condition of connecting Test Pack and
tuning on.
―Take specially care of soldering, because Land of PCB is small and weak in heat.
―Surely tune on/off while using AC power plug, because arepair of battery charger is dangerous
when tuning ON/OFF PBA and Connector after disassembling charger.
―Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

SAMSUNG Proprietary-Contents may change without notice
Safety Precautions
1-2
This Document can not be used without Samsung's authorization
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
―Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity prevention
string on wrist.
―Use earthed soldering steel when you connect or disconnect ESD.
―Use soldering removing tool to break static electricity. ,otherwise ESD will be damaged by static
electricity.
―Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum plate to have conductive power,they are prevented from static electricity.
―You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or acircuit board.

SAMSUNG Proprietary-Contents may change without notice
2. Specification
This Document can not be used without Samsung's authorization
2-1
GSM850 EGSM 900 DCS1800 PCS1900 W-CDMA
900
W-CDMA
2100
Freq.
Band[MHz]
Uplink/Downl
ink
824~849
869~894
880~915
925~960
1710~1785
1805~1880
1850~1910
1930~1990
882~913
927~958
1920~1980
2110~2170
ARFCN
range 128~251 0~124 &
975~1023 512~885 512~810 UL:2712~2863
DL:2937~3088
UL:9612~9888
DL:10562~
10838
Tx/Rx
spacing 45MHz 45MHz 95MHz 80MHz 45MHz 130MHz
Mod. Bit
rate/
Bit Period
270.833kb
ps
3.692us
270.833kb
ps
3.692us
270.833kb
ps
3.692us
270.833kb
ps
3.692us
3.84Mcps 3.84Mcps
Time Slot
Period/Frame
Period
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
576.9us
4.615ms
Frame
length:10ms
Slot length:
0.667ms
Frame
length:10ms
Slot length:
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSK
HQPSK
QPSK
HQPSK
MS Power 33dBm
~5dBm
33dBm
~5dBm
30dBm
~0dBm
30dBm
~0dBm
24dBm~
-50dBm
24dBm~
-50dBm
Power Class
4
(max
+33dBm)
4
(max
+33dBm)
1
(max
+33dBm)
1
(max
+33dBm)
3
(max +24dBm)
3
(max +24dBm)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm
TDMA Mux 8 8 8 8
Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km
2-1. GSM General Specification

SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification
2-2
TX Power
control level
GSM850
GSM900
5 33±2 dBm
6 31±2 dBm
7 29±2 dBm
8 27±2 dBm
9 25±2 dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control level DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
2-2. GSM TX power class
TX Power
control level PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

SAMSUNG Proprietary-Contents may change without notice
3. Operation Instruction and Installation
3-1
This Document can not be used without Samsung's authorization
Main Function
-Slim Bar Design 3G MITS
-3.0Megapixel Camera
-3.2"WHVGA 262K Color TFT Screen
-External Memory microSD (T-Flash)
-Video Recording &Messaging
-Music Player(MP3/AAC/AAC+)
-A-GPS Support
-Bluetooth Wireless Technology V2.0+EDR
-Multimedia Message Service (MMS) /SMS /E-mail
-Voice recorder
-Speaker Phone
-Java MIDP 2.0/ WAP2.0
-GSM/GPRS Class 10
-Quad-band(850/900/1800/1900MHz)
-WCDMA Dual(900/2100MHz)

SAMSUNG Proprietary-Contents may change without notice
4. Array course control
4-1
This Document can not be used without Samsung's authorization
4-1. Software Adjustments
Test Jig (GH99-36900A)
RF Test Cable (GH39-00985A) Adapter (GH99-38251A)
Test Cable (GH39-01339A)

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-2
This Document can not be used without Samsung's authorization
4-2. Software Downloading
4-2-1. Downloading Binary Files
•I5700XXII5_CL76223_Bootloader.tar
•i5700XXII5_Phone_RC3.tar
•I5700XXII5_CLP76423_CLK76376_PDA.tar
•I5700XXII4-CSC-CL71843-OPEN.tar
•Odin Multi Downloader v4.03.exe
4-2-2. Pre-requsite for Downloading
•Downloader Program :(
Odin Multi Downloader v4.03.exe)
•Binary files
•GT-I5700 Mobile Phone
•USB cable
•USB drivers for I5700 which is already installed

SAMSUNG Proprietary-Contents may change without notice
Array course control
4-3
This Document can not be used without Samsung's authorization
4-2-3. S/W Downloader Program
1) Load the binary download program by executing
the "Odin Multi Downloader v4.03.exe"
2) Select the binary filesthat you want to download
-Press the "OPS"button and select "spica.ops"
-Press the "BOOT"button and select "I5700XXII5_CL76223_Bootloader.tar"
-Press the "PHONE"button and select "i5700XXII5_Phone_RC3.tar"
-Press the "PDA"button and select "I5700XXII5_CLP76423_CLK76376_PDA.tar"
-Press the "CSC"button and select "I5700XXII4-CSC-CL71843-OPEN.tar"
3) Make aI5700 device to download mode with 'volume down +camera +power key'
3) Connect USB cable
4) Confirm that correct port is recognized by Multi Downloader.
5) Press 'Start' button to download binary files.

SAMSUNG Proprietary-Contents may change without notice
5. Exploded View and Parts List
5-1
This Document can not be used without Samsung's authorization
5-1. Cellular phone Exploded View
QMI03
QSH03
QSH02
QSP01
QME03
QFR01
QLC01
QLB01
QAR01
QCA01
QMP01
QSH01
QCR08
QRE01
QCR101
QBC00
QKP01
QMI04
QME01
QCK01
QCK02
QVO01
QRF06

- This Document can not be used without Samsung's authorization -
5-2. Cellular phone Parts list : GT-I5700HKATEB
Design LOC Description SEC CODE
QAR01 MODULE-RCV_MOT FPCB ASSY(GT_I5700) GH59-08293A
QBC00 ASSY COVER-BATT GH98-15383B
QCA01 ASSY CAMERA-3M MODULE(GT_I5700) GH96-04122A
QCK01 PMO KEY-CAMERA GH72-56488B
QCK02 PMO KEY-HOLD GH72-56491B
QCR08 SCREW-MACHINE 6001-001456
QCR101 SCREW-MACHINE 6001-002005
QFR01 ASSY CASE-FRONT GH98-14962B
QKP01 ASSY KEYPAD-(EU/BLACK) GH98-14965B
QLB01 ASSY BRACKET-LCD BRK GH98-14961A
QLC01 ASSY LCD-3.2 TFT (GT_I5700) GH96-04103A
QME01 KEY FPCB-KEY FPCB ASSY (I5700) GH59-08248A
QME03 TOUCH/PANEL-GT-I5700 TSP ,BLK GH59-08256B
QMI03 RMO RUBBER-MIC A GH73-13463A
QMI04 ASSY RUBBER-MIC B GH98-15597A
QMP01 A/S ASSY-PBA MAIN GT-I5700 SVC GH82-04221A
QRE01 ASSY CASE-REAR GH98-14963B
QRF06 PMO COVER-USB GH72-56492B
QSH01 ASSY COVER-SHIELD CAN GH98-14964A
QSH02 ASSY COVER-SHIELD GH98-15165A
QSH03 ICT COVER-SHILED BRACKET GH70-05865A
QSP01 MODULE-INTENNA SPK MODULE (GT_I5700) GH59-08295A
QVO01 PMO KEY-VOLUME GH72-56489B

SAMSUNG Proprietary-Contents may change without notice
6. MAIN Electrical Parts List
6-1
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
D400 0401-001144 SUD492H
ZD401 0403-001547 TDZ5.6
ZD605 0404-001089 RB551V-30
D300 0404-001172 RB520S-30
D500,D501,D502,D503 0406-001293 ESD9B3.3ST5G
D505,D506,D507,D700 0406-001293 ESD9B3.3ST5G
D701,D702,D703,D704 0406-001293 ESD9B3.3ST5G
ZD400,ZD600,ZD603 0406-001293 ESD9B3.3ST5G
ZD700,ZD701,ZD702 0406-001293 ESD9B3.3ST5G
ZD601,ZD602,ZD703 0406-001329 ESD9L5.0ST5G
ZD704,ZD705 0406-001329 ESD9L5.0ST5G
Q600 0504-001138 DTA114EM
TR300,TR400 0505-002088 2SK3541
U301 0801-003016 NC7SV08L6X
U200 0801-003022 NC7SV04L6X
U304 0801-003200 NC7SZ00L6X
U300 0801-003265 74AUP1G74GM
U801 0801-003271 74AUP2G08GM
UCP800 0902-002440 SC36410A8N-A040
U400 1001-001394 NLAS5123MNR2G
U600 1001-001461 NLAST9431
U601 1001-001580 FSA9480UCX
U604 1003-002047 ISA1000
U302,U800,U803 1003-002185 NLSV1T34AMX1TCG
F201 1201-002581 ALM-1412
U500 1201-002864 MAX9877AERP-T
PAM101 1201-002889 SKY77186
PAM103 1201-002890 SKY77189
PAM100 1201-002961 TQM7M5012H
U503 1202-001088 NCS2220AMUT1G
U607 1203-003643 XC6401FF20DR
U402 1203-003924 XC61CN3202NR
U602 1203-004571 RP150K002A-TR
U501 1203-004806 RP100K281D-TR
U405 1203-004819 RP103K281D-TR

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-2
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
U606 1203-004845 TPS61161DRVR
U609 1203-005076 XC6401EE27DR
U401 1203-005434 MAX8674EWN+
U404 1203-005667 MAX8698EWO-T
U403 1203-005783 MAX8845YETC
U100 1205-003297 RTR6285
U303 1205-003467 AAT4285IJS-3-T1
U502 1205-003488 AK4671EG-L
UCP300 1205-003726 MSM6246
U700 1205-003903 AT42QT5480-CU-S1
U701 1209-001817 BMA023
U702 1209-001872 AK8973B
TH800 1404-001221 NCP15WB473J04RC
R521 2007-000169 TSR16GJ514V
R201 2007-003006 TSR16GJ160V
R400 2007-003014 TSR16GJ244V
R321,R823,R824,R830 2007-007107 RC1005F1003CS
R831 2007-007107 RC1005F1003CS
R419 2007-007309 MCR01MZP5F1202
R503 2007-007313 RK73H1ETP6801F
R420 2007-007316 RK73H1ETP3301F
R417 2007-007318 MCR01MZP5F1001
R406 2007-007480 RK73H1ETP1303F
R315 2007-007529 RK73H1ETP9102F
R403 2007-007698 RK73H1ETP5101F
R502 2007-007741 M5534204B10E0R
R623 2007-007798 RC1005F0100CS
R622 2007-007875 RK73H1ETP1603F
R801 2007-007942 RC-1005F105CS
R605 2007-007943 RK73H1ETP5603F
R200,R202,R305,R308 2007-008045 ERJ1GEJ101C
R329,R404,R519,R602 2007-008045 ERJ1GEJ101C
R603,R806 2007-008045 ERJ1GEJ101C
R102,R103 2007-008047 RK73B1HTTB181J
R307 2007-008049 MCR006YZPJ202

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-3
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
R412,R413,R501,R807 2007-008052 ERJ1GENJ472X
R813,R814,R815,R816 2007-008052 ERJ1GENJ472X
R832,R833,R834,R835 2007-008052 ERJ1GENJ472X
R845,R846 2007-008052 ERJ1GENJ472X
R203,R213,R312,R327 2007-008055 ERJ1GENJ104X
R407,R415,R416,R418 2007-008055 ERJ1GENJ104X
R423,R517,R714,R723 2007-008055 ERJ1GENJ104X
R800,R840,R847,R849 2007-008055 ERJ1GENJ104X
R108,R109,R110,R111 2007-008419 ERJ1GEJ102C
R117,R322,R323,R325 2007-008419 ERJ1GEJ102C
R511,R624,R701,R702 2007-008419 ERJ1GEJ102C
R704,R705,R706,R707 2007-008419 ERJ1GEJ102C
R808,R809,R810,R811 2007-008419 ERJ1GEJ102C
R309,R328 2007-008420 RMC-1/20-330JPA
R204,R300,R303,R304 2007-008516 ERJ1GEJ103C
R306,R409,R421,R422 2007-008516 ERJ1GEJ103C
R604,R716,R718,R720 2007-008516 ERJ1GEJ103C
R841,R842,R848 2007-008516 ERJ1GEJ103C
R115,R512,R513 2007-008531 MCR006MZPJ0100
R505 2007-008544 ERJ1GEJ681C
R105,R106 2007-008579 RMC1/20221JPA
R212 2007-008581 RK73B1HTTB271J
R211 2007-008587 ERJ1GEJ561C
R100 2007-008588 MCR006YZPJ222
R326 2007-008766 ERJ2RKF6041X
R114 2007-008774 ERJ1GEJ2R2C
R715,R837,R838 2007-008798 MCR006YZPJ153
R618 2007-008806 RC0603J510CS
R316,R509,R510,R708 2007-009084 MCR006YZPJ105
R709,R710,R711,R712 2007-009084 MCR006YZPJ105
R713 2007-009084 MCR006YZPJ105
R514,R516 2007-009111 RC0603J220CS
R104,R107,R112,R119 2007-009115 RC0603J240CS
R310 2007-009115 RC0603J240CS
R408,R411 2007-009155 MCR006YZPJ474

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-4
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
R425,R817 2007-009157 MCR006YZPF1003
R405 2007-009158 MCR006MZPF1503
R206,R207,R208,R209 2007-009171 MCR006YZPJ513
R210,R611,R700,R802 2007-009171 MCR006YZPJ513
R803,R804,R805 2007-009171 MCR006YZPJ513
R101 2007-009201 MCR006YZPJ300
R518 2007-009233 MCR006YZPJ514
R410 2007-009361 MCR006YZPJ304
R507 2007-009402 RC0603F152CS
R113 2007-009410 RC0603F123CS
R703 2007-009793 MCR006YZPF3002
R414 2007-009838 RK73H1HTTC1203F
R401 2007-009954 MCR006YZPF6802
R839 2007-009964 MCR01MZP5F44R2
R836 2007-010030 MCR01MZP5F6491
C400,C425 2203-000233 GRP1555C1H101J
C823,ZD402 2203-000254 GRP155R71C103K
C415 2203-000359 GRP1555C1H151JD01E
C822,C824 2203-000386 GRP1555C1H150J
C206,C209,C212 2203-000438 GRP155R71H102K
C225 2203-000696 GRP1555C1H2R0C
C609 2203-000725 GRP155R71H392KA01E
C204 2203-000812 GRP1555C1H330J
C103 2203-000854 GRP1555C1H390J
C540,C544 2203-001072 GRP1555C1H560JD01E
C101 2203-002677 CL05CR75BBNC
C829 2203-005138 04025C182KAT2A
C528 2203-005483 GRP155R61A683KA01E
C100,C104,C120,C121 2203-005682 GRP0335C1E330JD01E
C122,C126,C151,C152 2203-005682 GRP0335C1E330JD01E
C176,C183,C186,C205 2203-005682 GRP0335C1E330JD01E
C208,C302,C714,C716 2203-005682 GRP0335C1E330JD01E
C723 2203-005682 GRP0335C1E330JD01E
C125 2203-005683 GRP0335C1E8R0DD01E
C181,C189 2203-005717 GRP0335C1E270JD01E

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-5
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
C141,C148,C157,C158 2203-005725 GRP0335C1E220JD01E
C164,C165,C166,C167 2203-005725 GRP0335C1E220JD01E
C168,C173,C199,U807 2203-005725 GRP0335C1E220JD01E
C531,C542,C546,C548 2203-005726 GRM0335C1E560J
C530,C541,C547,C549 2203-005729 CL03C150JAGC
C109,C710,C711 2203-005731 GRM0335C1E180J
C131,C135 2203-005732 GRP0335C1E680JD01E
C129,C130,C139,C146 2203-005736 GRP0335C1E101JD01E
C147,C170,C174,C187 2203-005736 GRP0335C1E101JD01E
C190,C196,C197 2203-005736 GRP0335C1E101JD01E
C114 2203-005777 CL03C010CA3GNNC
C194 2203-005779 CL03C090DA3GNNC
C192,C198 2203-005792 CL03C1R5CA3GNNC
C118,C172,C179,C227 2203-005806 GRP033R71C102KD01E
C308,C313,C315 2203-005806 GRP033R71C102KD01E
C115,C116 2203-006187 GRM0335C1E3R9B
C171,C193,C207,C211 2203-006194 GRP033R70J103KA01E
C330,C331,C332,C410 2203-006194 GRP033R70J103KA01E
C411,C517,C704,C705 2203-006194 GRP033R70J103KA01E
C706,C707,C708,C709 2203-006194 GRP033R70J103KA01E
C803,U808 2203-006194 GRP033R70J103KA01E
C604,C605 2203-006257 GRM155R60J474KE19E
C533 2203-006305 CM03CG100J25AH
C613 2203-006348 CV105X5R105K25AT
C614 2203-006377 GRM21BR61E475KA12L
C509 2203-006379 GRP033R70J472KA01
C216,C221,C305,C306 2203-006399 GRM155R60J105KE19D
C312,C314,C316,C321 2203-006399 GRM155R60J105KE19D
C322,C323,C325,C327 2203-006399 GRM155R60J105KE19D
C328,C335,C340,C408 2203-006399 GRM155R60J105KE19D
C409,C422,C423,C424 2203-006399 GRM155R60J105KE19D
C436,C437,C438,C439 2203-006399 GRM155R60J105KE19D
C441,C442,C443,C602 2203-006399 GRM155R60J105KE19D
C606,C610,C611,C615 2203-006399 GRM155R60J105KE19D
C616,C617,C618,C713 2203-006399 GRM155R60J105KE19D

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-6
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
C802 2203-006399 GRM155R60J105KE19D
C127 2203-006410 CL03C1R8CA3GNNC
C105,C140,C142,C159 2203-006423 GRM33X5R104K6.3
C169,C175,C191,C200 2203-006423 GRM33X5R104K6.3
C201,C202,C222,C223 2203-006423 GRM33X5R104K6.3
C228,C301,C304,C309 2203-006423 GRM33X5R104K6.3
C310,C311,C317,C318 2203-006423 GRM33X5R104K6.3
C319,C320,C324,C326 2203-006423 GRM33X5R104K6.3
C329,C333,C334,C336 2203-006423 GRM33X5R104K6.3
C338,C403,C417,C418 2203-006423 GRM33X5R104K6.3
C504,C505,C512,C600 2203-006423 GRM33X5R104K6.3
C700,C701,C702,C703 2203-006423 GRM33X5R104K6.3
C717,C718,C719,C720 2203-006423 GRM33X5R104K6.3
C800,C801,C804,C806 2203-006423 GRM33X5R104K6.3
C807,C808,C809,C810 2203-006423 GRM33X5R104K6.3
C811,C812,C813,C814 2203-006423 GRM33X5R104K6.3
C815,C816,C817,C818 2203-006423 GRM33X5R104K6.3
C819,C820,C821,C826 2203-006423 GRM33X5R104K6.3
C827,C828,U806 2203-006423 GRM33X5R104K6.3
C303 2203-006462 GRM033R60J333K
C337 2203-006556 GRM0335C1E470JD01D
C502,C507,C516,C518 2203-006562 CV05X5R105K10AH
C521 2203-006562 CV05X5R105K10AH
C108 2203-006611 GRM0335C1E2R7CD01D
C825 2203-006626 GRM155R61A334KE15D
C612 2203-006636 GRM188R71E224KA88D
C117,C178 2203-006642 GRM033R71E331KA01D
C508,C513 2203-006648 GRM033R60J223KE01D
C300 2203-006668 GRM033R61A222K
C111,C112 2203-006674 CL03C3R3BA3GNN
C435,C607 2203-006681 GRM155F51E104ZA01D
C220,C406,C427,C428 2203-006824 CV105X5R475K10AT
C429 2203-006824 CV105X5R475K10AT
C210,C414,C506,C529 2203-006839 CL03A104KP3NNNC
C532,C534,C830 2203-006839 CL03A104KP3NNNC

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-7
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
C434,C522,C523,C524 2203-006841 CV05X5R105K16AH
C525,C526,C527,C608 2203-006841 CV05X5R105K16AH
L102,L103 2203-006846 ECJZEC1E2R0B
C217,C219,C307,C419 2203-006872 GRM155R60J225ME15D
C420,C421,C440,C444 2203-006872 GRM155R60J225ME15D
C503,C511 2203-006872 GRM155R60J225ME15D
U809 2203-006979 CL03B103KP3NNNC
C182,C402,C416,C426 2203-007165 CL05A475KQ5NRNC
C430,C431,C432 2203-007165 CL05A475KQ5NRNC
C510,C514,C515 2203-007210 CV03X5R224K06AH
TA500 2203-007230 CL21A476MQYNNNE
C405,C407,C412,C413 2203-007271 CL05A225KP5NSNC
C433,C445 2203-007271 CL05A225KP5NSNC
C107,C119,C180,C224 2203-007279 CV105X5R106M10AT
C404,C500,C501,C601 2203-007279 CV105X5R106M10AT
C603 2203-007279 CV105X5R106M10AT
C218,C520,C805 2203-007317 CV05X5R475M06AH
C215 2203-007393 CL05A475KP5NRNC
TA300 2404-001339 TEESVJ1A475M8R
TA400 2404-001506 TCTP1A476M8R-D
L100 2703-001178 LL1005-FH3N3S
L201 2703-001748 LL1005-FH5N6S
L204 2703-002774 VLF3010AT-3R3MR87
L205 2703-002782 VLF3010AT-4R7MR70
L108,L122 2703-002793 LQP03TN5N6J00D
C106,C185,L104,L107 2703-002795 LQP03TN22NG00D
L123 2703-002795 LQP03TN22NG00D
L112,L113 2703-002842 LLV0603-F2N2S
L602 2703-002856 LPF3015T-220M
L200 2703-002858 HK0603-4N7S-T
L121,L125 2703-002901 LLV0603-F15NJ
C177,L119 2703-002917 LQP03TN2N2B04D
L111,L120 2703-002918 LQP03TN3N3B00D
L124 2703-002919 LQP03TN12NJ04D
L105 2703-002960 MLG0603S82NJT

SAMSUNG Proprietary-Contents may change without notice
Main Electrical Parts List
6-8
This Document can not be used without Samsung's authorization
Design LOC SEC CODE Description
L101 2703-002961 MLG0603SR10JT
L109 2703-003003 LQP03TN1N5B04D
L600,L60 2703-003205 LQG15HS82NJ02
C110 2703-003239 LQP03TN18NG00D
L400 2703-003258 APIS05G4R7MT
L401,L402,L403,L404 2703-003260 CIG21W2R2MNE
L405 2703-003260 CIG21W2R2MNE
L110 2703-003335 LQP03TN5N1H00D
OSC800 2801-004543 DSX321G(12MHZ,10PPM)
OSC700 2801-004568 CX3225SB16000D0KHQZZ
OSC400 2804-001700 SG-3040LC(32.768KHZ)
OSC801 2804-001704 SG-8002CESC(48MHZ,50PPM)
OSC201 2804-001762 KC2520B26.0000C1WE00
OSC500 2804-001796 CSC3M192000EEVRS00
OSC200 2809-001345 KT3225P19200ACW28ZN0
F701,F702,F703 2901-001361 ICVE31056E250R101FR
F700 2901-001413 ICVE10184E070R101FR
F704,F705,F706 2901-001434 ICVE10184E150R500FR
U505 2901-001522 EMIF02-MIC03M6
U608 2901-001552 EMIF06-MSD01C2
F104 2904-001756 SAFEB2G14FA0F00
F200 2904-001759 FAR-F6KA-1G5754-L4AAHZ
F103 2904-001785 FAR-F5KA-897M50-D4DCHZ
F101 2904-001789 FAR-F6KA-1G9500-D4DGHZ
DUF102 2910-000065 SAYFP897MCA0B00
DUF100 2910-000070 SAYFP1G95AA0B00
F100 2911-000136 LMSP43QLA003
MIC500 3003-001136 SPU0410HR5H
L202,L502 3301-001756 BLM15HG102SN1D
L500,L501,L504,L505 3301-001885 BLM15HD182SN1D
TAC700,TAC701,TAC702 3404-001303 LS12K2-T
TAC703 3404-001303 LS12K2-T
RFS100 3705-001503 KMS-560
SIM700 3709-001540 SCGC1B0102
CD600 3709-001575 SCHA4B0301
