Samsung Infuse i997 Assembly instructions

Samsung Infuse i997
Screen Repair Guide
Touch Screen & LCD Screen Repair

For more instructional repair guides for other makes or models, view our full catalog of Repair Guides!
This is the Samsung Infuse i997 take apart repair guide. Following this guide will help you take apart the Samsung Infuse
i997 fairly easily in a step by step manner giving you a chance to replace faulty parts. Once you have replaced the parts
you want, the guide can be used in reverse to put everything back together again.
This guide will help you to install the following Samsung Infuse i997 parts:
•Samsung Infuse i997 LCD + Touch Screen Digitizer Replacement
•And Other Samsung Infuse i997 Parts
Tools Required:
•Safe Open Pry Tool
•Small Phillips Screwdriver
•Adhesive Strips
•Heat Gun / Hair Dryer
Samsung Infuse i997 take apart/repair guide:
•To get in started, make sure that the device is off and remove the back battery cover. Also remove the battery, the
memory card, and the sim card.
•Now, we have six (6) small Phillips screws to remove as shown in Figure 1.
Figure 1
•With the screws released, turn the phone over and use a safe open pry tool between the screen assembly and
back housing.
•Use a safe open pry tool as shown on Figure 2 to release the clips and remove the back housing.

Figure 2
•We have two (2) small Phillips screws that need to be removed - located in orange in Figure 3. Use a safe open
pry tool to release the four (4) pop connectors (red) on the motherboard.
Figure 3
•You can now ease off the motherboard carefully, being sure not to rip any cables.
•Now, use a heat gun or hair dryer to warm the adhesive holding the screen assembly to the front housing. Use
medium heat on the front of the screen, consistently moving around the screen edges. This should take no longer
than 1 minute.
•Use a safe open pry tool to release the screen assembly from the housing. Reheat if the adhesive is still strong.
•Remove the screen from the housing and replace.
Your Samsung Infuse is now disassembled and ready for replacement of part(s). Reverse the
instructions above to reassemble your Infuse.
