Samsung SGH-V200 User manual

SGH-V200
WAP Browser
User’s Manual
ELECTRONICS
* Some of the contents in this manual may differ from your phone,
depending on the software installed or your service provider.
Printed in Korea
Code No.: GH68-04827A
English. 01/2004. Rev. 1.0
World Wide Web
http://www.samsungmobile.com

2
What is WAP?
WAP (Wireless Application Protocol) is the
gateway to a new world of mobile data. It
provides a universal standard, enabling you
to access web-based interactive information
services and applications directly from your
mobile phone.
3
Contents
About the WAP Browser............................ 4
Setting Up the WAP Browser..................... 5
Accessing the WAP Browser ...................... 5
Configuring the WAP Browser .................... 7
Getting Started ......................................... 10
Starting the WAP Browser......................... 10
Exiting the WAP Browser .......................... 10
Using the WAP Browser ............................ 11
Using the Soft Keys.................................. 11
Navigating the WAP Browser ..................... 11
Entering Text, Numbers or Symbols ........... 12
Using the WAP Browser Menus ................. 13
Using and Selecting Menu Options ............. 13
Reload ................................................... 13
Home..................................................... 13
Go to URL............................................... 14
Show URL............................................... 14
Edit Home .............................................. 15
Inbox..................................................... 15

4
About the
WAP Browser
Your phone comes equipped with a WAP (Wireless
Application Protocol) browser, making it possible for
you to access the Wireless Web.
The WAP Browser allows you to:
• access up-to-the-minute information via your
phone
• view specially designed text versions of popular
Internet sites including Yahoo!
®
, CNN Mobile
SM
and the Weather Channel
®
Browsing the Wireless Web using your phone is
unlike using your computer, in that site providers
have:
• selected only the critical aspects of their site for
wireless phone users
• removed most graphics
Each time you start the WAP Browser, the phone
connects to the Wireless Web and the service
indicator icon ( ) appears on the display to inform
you that you are:
• are connected to the Wireless Web
•will be billed accordingly (rates vary according to
your service option)
The WAP Browser ends the network connection
after a certain period of inactivity and automatically
reconnects as necessary. For this reason, you may
find that you are billed for several network
connections within a single session. This is normal
and is designed to minimize your bill.
5
Setting Up the
WAP Browser
Accessing the WAP Browser
To enter the WAP Browser menu to access the
WAP browser:
1. When the idle screen is displayed, press the
Menu soft key to enter menu mode.
2. Press the or key until the
Funbox menu
option is displayed, and then press the
Select
soft key. You can also press the key directly.
Service Provider
05:17
Sat 02 Oct
Menu Name
9
Network Services
Select
T ext Messages

Setting Up the WAP Browser
6
3. Press the or key one or more times to
highlight
WAP Browser , then press the Select
soft key. You can also press the key directly.
4. Press the or key one or more times to
highlight the required option and then press the
Select soft key.
Option Description
Home
Connects the phone to the
network and loads the homepage
of the Wireless Web service
provider.
Favorite Allows you to store the URL
addresses of your favourite Web
sites. You can access this menu
directly by pressing and holding
the key while using the WAP
Browser.
9.2
Funbox
Games
WAP Browser
Downloads
9.2.1
WAP Browser
Home
Favorite
http://
Select
Settings
Clear Cache
Push message
Select
Setting Up the WAP Browser
7
Configuring the WAP Browser
To configure the WAP Browser:
1. In the WAP Browser menu, highlight
Settings
using the and keys, and then press the
Favorite
(continued)
To store a URL address, select an
empty location and enter the
address.
Three submenus are available:
•
Goto URL : quickly accesses
you to the site.
•
Edit : edits the selected
address.
•
Erase : deletes the selected
address.
http://
Settings
Allows you to manually enter the
URL address of the website that
you want to access.
Allows you to manually enter the
URL address of the Web site that
you wish to access
Clear
Cache
Clears the information stored in
the cache (the phone’s
temporary memory used to store
the most recently accessed Web
pages).
Push
Message
Allows you to set whether or not
you will receive Web messages
from the server, and read or
delete the messages received.
Option Description

Setting Up the WAP Browser
8
Select soft key. You can also press the key
directly.
2. Select a proxy server and enter the parameters
required. Contact your service provider for
details.
The remaining options depend on the
Bearer
setting, as indicated below.
When the bearer is set to Data
Parameter Description
Profile
Name
Name that you wish to assign
to the HTTP proxy server.
Homepage
URL
Address of your startup
homepage. When the default
homepage displays, you can
delete it using the key and
enter your own choice.
Security Data transmission mode.
Choose
Secure to protect your
data against unauthorised
access; otherwise, choose
Non-Secure .
IP Address WAP gateway address required
to connect to the Internet.
Bearer Bearer to be used for each type
of network address accessed:
GPRS or Data .
Parameter Description
Login
Name
PPP server login ID.
Password PPP server password.
Dial-up
Number
PPP server phone number.
Setting Up the WAP Browser
9
When the bearer is set to GPRS
Note
: The WAP Browser settings may vary,
depending on the service provider. Contact
your service provider for more information.
3. After selecting each of these settings, a dialogue
box displays; you can either enter the
information required or choose between given
options. When you are satisfied with your input,
press the
OK soft key.
4. When you have finished configuring the WAP
Browser, press the key or the right soft
key.
Data Call
Type
Data call type: Analogue or
ISDN .
Parameter Description
User Name
User ID required to connect to
the GPRS network.
Password Password required to connect to
the GPRS network.
APN Access point name used for the
address of the GPRS network
gateway.
Parameter Description

10
Getting Started
Starting the WAP Browser
To start the WAP Browser when the idle screen
displays, press the key or press the
Menu soft
key, followed by the , and keys.
A connection is established with your service
provider and the corresponding homepage displays.
The content of the WAP Browser startup homepage
depends on your Wireless Web service provider. To
scroll through the screen, use the and keys.
Note : To access the startup homepage from any
other screen in the WAP Browser, use the
Home option. For more information on the
WAP Browser menus, refer to page 13.
Exiting the WAP Browser
To exit the browser at any time, simply press
the key or press and hold the key.
11
Using the
WAP Browser
Using the Soft Keys
A bar containing browser commands is located at
the bottom of the WAP Browser display. The soft
keys below the bar are used to execute these
commands. The two keys are called soft keys
because their function changes depending on the
WAP Browser application in use.
Navigating the WAP Browser
To Then
scroll through and
select browser
items
press the or key
until the symbol points to
the required item, and then
press the
OK soft key to
confirm the selection.
select a numbered
item
press the corresponding
numeric key.
return to the
previous page
press the
Back soft key or
the key.
return to the
startup homepage
select the
Home menu
option; for more information
on this option, refer to
page 13.

Using the WAP Browser
12
Entering Text, Numbers or Symbols
When you are prompted to enter text, the current
text entry mode is indicated on the screen. The
following modes are available:
Note: To enter symbols, press the key until the
required symbol displays.
Mode Description
Allows you to enter letters in the
alphabet. Press the corresponding
key until the required letter
displays.
Allows you to enter numbers.
To Then
change
modes
press the key one or more
times.
enter a
space
press the key.
edit text • set the cursor to the right of
the character(s) to be
corrected.
• press the key as required.
• enter the correct character(s).
13
Using the WAP
Browser Menus
Using and Selecting Menu Options
Various menu options are available when you are
using the WAP Browser to navigate the Wireless
Web.
To access a menu option:
1. Press and hold down the key.
A menu displays.
2. Highlight the required menu option by pressing
the and keys.
3. Select the option by pressing the
Select soft
key.
4. If necessary, select the secondary option using
the and keys, and press the
Select soft
key to confirm.
Note : The menus may vary, depending on your
version of the WAP Browser.
Reload
This option reloads the current page.
Home
This option takes you back at any time to the
homepage of the Wireless Web service provider.

Using the WAP Browser Menus
14
Go to URL
This option allows you to manually enter the URL
address of the required Web page.
After entering an address, press the
OK soft key to
go there directly.
Show URL
This feature displays the URL address of the site to
which you are currently connected. It also enables
you to declare the current site as the startup
homepage.
To Press the
declare the current
page as your startup
homepage
Option soft key, select
the
Save to Home
option and press
Select .
set a bookmark for
the current page
Option soft key, select
the
Save to Bookmark
option and press
Select .
cancel your setting
Back soft key.
Using the WAP Browser Menus
15
Edit Home
With this feature, you can change the startup
homepage manually.
To change the homepage, enter the required URL
and press the
OK soft key.
For more information on entering text, numbers or
symbols, refer to page 12.
Inbox
This menu allows you to read messages received
from the web server.
