Samsung SGH-X630 User manual

SGH-X630
User’s Guide

Drive safely at all times
Do not use a hand-held phone while driving.
Park the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and
dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external
radio frequency energy. Follow any regulations
or rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or
illegal.

1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any
area and always switch off your phone
whenever it is forbidden to use it, or when it
may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it
dry.
Sensible use
Use only in the normal position (held to the
ear). Avoid unnecessary contact with the
antenna when the phone is switched on.
Emergency call
Key in the emergency number for your
present location, then press .
Keep your phone away from small
children
Keep the phone and all its parts, including
accessories, out of the reach of small
children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data
cables. Use of any unauthorised accessories
could damage you or your phone and may
be dangerous.
Qualified service
Only qualified service personnel may repair
your phone.
For more detailed safety information, see
"Health and safety information" on page 79.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged
listening to a headset can damage
your hearing.

2
About this Guide
This User’s Guide provides you with
condensed information about how to use
your phone. To quickly learn the basics for
your phone, please refer to “Get started”
and “Step outside the phone.”
In this guide, the following instruction icons
appear:
Indicates that you need to pay careful
attention to the subsequent
information regarding safety or phone
features.

Indicates that you can get more
information on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the
specified option and then select it.
[ ]
Indicates a key on the phone. For
example,
[]
< >
Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Menu >
• Camera and camcorder
Use the camera module
on your phone to take a
photo or record a video.
Special features of your phone
• Music player
Play music files using
your phone as a music
player.
•Bluetooth
Transfer media files and
personal data and
connect to other devices
using free, wireless
Bluetooth technology.
•FMradio
Listen to your favourite
radio stations anytime,
anywhere.

3
Special features of your phone
•Webbrowser
Access the wireless web
to get up-to-the-minute
information and a wide
variety of media content.
• Get personal with
photo caller ID
See who’s calling you
when their very own
photo displays.
• Name card
Create name cards with
your number and profile.
Whenever introducing
yourself to others, use
this convenient electronic
name card.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and
audio.
•Java
Enjoy Java ™ -based
embedded games and
download new games.
•Calendar
Keep track of your daily,
weekly, and monthly
schedule.
• Voice recorder
Record memos or
sounds.
•Alarm
Use your phone as an
alarm clock to wake you
up in the morning or
notify you of an
impending event.

4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Keys, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ...................... 7
Power on or off......................................... 8
Keys and display ...................................... 9
Access menu functions ............................ 11
Customise your phone............................. 12
Make/Answer calls .................................. 14
Step outside the phone 14
Begin with your camera, the music player, the FM
radio, and other special features
Use the camera ...................................... 14
Play music ............................................. 15
Listen to the FM radio.............................. 16
Browse the web ...................................... 17
Use Phonebook ....................................... 18
Send messages....................................... 19
View messages ....................................... 20
Use Bluetooth ......................................... 20
Enter text 22
AB, T9, Number, and Symbol modes
Call functions 24
Advanced calling features
Menu functions 28
All menu options listed
Solve problems 77
Help and personal needs
Health and safety information 79
Index 87

5
1 Call log  p. 28
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call cost
*
 p. 28
 p. 29
 p. 29
 p. 29
 p. 29
 p. 29
 p. 30
2 Phonebook  p. 30
1 Contact list
2 Add new contact
3 Group
4 Speed dial
5 My namecard
6 Own number
7 Management
8 Service number
*
 p. 30
 p. 31
 p. 32
 p. 32
 p. 33
 p. 33
 p. 33
 p. 34
3 Applications  p. 34
1 Music player
2 FM Radio
3 Voice recorder
4 Java world
5 World clock
 p. 34
 p. 36
 p. 37
 p. 38
 p. 39
3 Applications (continued)
6 Alarm
7 Calculator
8 Convertor
9 Timer
0 Stopwatch
* SIM AT
*
 p. 40
 p. 40
 p. 41
 p. 41
 p. 42
 p. 42
4 Browser  p. 42
1 Home
2 Bookmarks
3 http://
4 WAP profile
5 Clear cache
 p. 42
 p. 43
 p. 44
 p. 44
 p. 44
5 Messaging  p. 44
1 Create message
2 My messages
3 Templates
4 Delete all
5 Settings
6 Memory status
 p. 44
 p. 47
 p. 50
 p. 51
 p. 51
 p. 54
6 File manager  p. 54
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory status
 p. 54
 p. 55
 p. 56
 p. 56
 p. 57
 p. 57
7 Calendar  p. 57
8 Camera  p. 61
9 Settings  p. 65
1 Time and date
2 Phone settings
3 Display settings
4 Sound settings
5 Network services
6 Bluetooth
7 Security
8 Connection settings
9 Reset settings
 p. 65
 p. 66
 p. 67
 p. 68
 p. 69
 p. 72
 p. 74
 p. 75
 p. 77
* Shows only if supported by your SIM
card.
Overview of menu functions
To access Menu mode, press < Menu > in Idle mode.

6
Unpack
Make sure you have each item
You can obtain various
accessories from your local
Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with
your phone and the
accessories available at
your Samsung dealer may
vary, depending on your
country or service
provider.
Your phone
Keys, features, and locations
Special
function keys
Earpiece
Display
Power on/
off/ Menu
exit key
Microphone
Correct key
Left soft
key
Volume keys
Dial key
Alphanumeric
keys
Right soft
key
Web access/
Confirm key
Navigation
keys (Up/
Down/Left/
Right)
Headset
jack
Camera
key
Camera
lens
Mirror

7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network,
you receive a plug-in SIM (Subscriber
Identity Module) card loaded with your
subscription details, such as your PIN, and
available optional services.
Install and charge the phone
Remove the
battery cover.
If the phone is
already on, first
turn it off by
pressing and
holding [ ].
Insert the SIM
card.
Make sure that the
gold-coloured
contacts on the
card are face
down.
Install the
battery.
Reattach the
cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall
outlet.

Get started
8
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the
phone automatically turns off. Recharge
your battery.
Power on or off
Keypad lock
You can lock the keypad to prevent
accidental key presses from affecting phone
operations.
In Idle mode, press and hold [ ] and then
press < Yes >. To unlock the keypad, press
the left soft key and then [ ].
You can also set the phone to lock the
keypad automatically.  p. 66
When the phone is completely charged
(the battery icon becomes still), unplug
the adapter from the power outlet.
Remove the adapter from the phone.
Switch on
Do not turn
on the phone
when mobile
phone use is
prohibited.
1. Press and hold [ ].
2. If necessary, enter the
PIN and press < OK >.
Switch off
Press and hold [ ].

Get started
9
Keys and display
Keys
Perform the function indicated on
the bottom line of the display.
In Idle mode, access your favourite
menus directly.
 p. 66
In Menu mode, scroll through menu
options.
In Idle mode, launch the web
browser.
In Menu mode, select the
highlighted menu option or confirm
input.
Make or answer a call.
In Idle mode, retrieve numbers
recently dialled, missed, or
received.
Delete characters from the display
or an item in an application.
End a call.
Press and hold to switch the phone
on or off.
In Menu mode, cancel input and
return the phone to Idle mode.
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold
[1] to
access your voicemail server. Press
and hold [
0 ] to enter an
international call prefix.
Enter special characters.
In Idle mode, press and hold [ ] to
activate or deactivate Silent mode.
Press and hold [ ] to lock the
keypad or enter a pause between
numbers.
Adjust the phone volume.
In Idle mode, adjust the key tone
volume.
In Idle mode, press and hold to turn
on the camera.
In Camera mode, take a photo or
record a video.

Get started
10
Display
Layout
Icons
*
Received signal strength
FM radio on
Call in progress
Out of your service area;
you cannot make or receive
calls
Keypad Lock mode is active
GPRS network
Roaming network
Call diverting feature active
Text and graphics
display messages,
instructions, and
information you
enter.
Soft key function
indicators
show the current
functions assigned
to the soft keys.
Menu Contacts
I
cons
display various
icons.
Home Zone, if registered for
the appropriate service
Office Zone, if registered for
the appropriate service
Bluetooth active
Connected to Bluetooth
hands-free car kit or
headset
Call ringer set to vibration
Silent mode (Vibration)
Silent mode (Mute)
Mute mode, during a call
New message
New voicemail
Alarm set
Battery power level
* Depending on your country or service provider,
the icons shown on the display may vary.

Get started
11
Access menu functions
Use the
soft keys
The roles of the soft keys
vary depending on the
function you are using. The
bottom line of the display
indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Select Back
Select an
option
1. Press a desired soft key.
2. Press the Navigation
keys to move to the next
or previous option.
3. Press < Select > or [ ]
to confirm the function
displayed or option
highlighted.
4. To exit, choose either of
the following methods.
•Press< Back > to
move up one level.
• Press [ ] to return
to Idle mode.
Use
shortcuts
Press the number key
corresponding to the option
you want.

Get started
12
Customise your phone
1. In Idle mode, press
< Menu > and select
Settings → Phone
settings → Language .
2. Select a language.
1. In Idle mode, press
< Menu > and select
Settings → Sound
settings → Incoming
call → Ringtone .
2. Select a ringtone
category.
3. Select a ringtone.
4. Press < Save >.
Display
language
Call ringtone
You can set wallpaper for the
idle screen.
1. In Idle mode, press
< Menu > and select
Settings → Display
settings → Wallpaper
→ Wallpaper image .
2. Select an image or a
video clip category.
3. Select an image or a
video clip.
4. Press < Select >.
5. Press < Save >.
You can change the colour
for the display components,
such as title bars and
highlight bars.
1. In Idle mode, press
< Menu > and select
Settings → Display
settings → Skin .
2. Select a colour pattern.
Idle mode
wallpaper
Menu mode
skin colour

Get started
13
You can set the Navigation
keys to function as shortcuts
to access your favourite
menus.
1. In Idle mode, press
< Menu > and select
Settings → Phone
settings → Shortcuts .
2. Select a key.
3. Select a menu to be
assigned to the key.
You can switch the phone to
Silent mode to avoid
disturbing other people.
Press and hold [ ] in Idle
mode.
Menu
shortcuts
Silent mode
You can protect the phone
against unauthorised use
with a phone password. The
phone will require the
password on power-up.
1. In Idle mode, press
< Menu > and select
Settings → Security →
Change password .
2. Enter the default
password, 00000000 ,
and press < OK >.
3. Enter a new 4- to 8-digit
password and press
< OK >.
4. Enter the new password
again and press < OK >.
5. Select Phone lock .
6. Select Enable .
7. Enter the password and
press < OK >.
Phone lock

14
Make/Answer calls
Step outside the phone
Begin with your camera, the music player, the
FM radio, and other special features
Use the camera
1. In Idle mode, enter an
area code and phone
number.
2. Press [ ].
3. To end the call, press
[].
1. When the phone rings,
press [ ].
2. To end the call, press
[].
Press [ / ].
Make a call
Answer a call
Adjust the
volume
during a call
1. In Idle mode, press and
hold [ ] to turn on the
camera.
2. Aim the lens at the
subject and make any
desired adjustments.
3. Press [ ] or [ ] to take
a photo. The photo is
saved automatically.
4. Press < Preview > to
take another photo.
1. In Idle mode, press
< Menu > and select File
manager → Images →
Photos .
2. Select the photo you
want.
Take a photo
View a photo

Step outside the phone
15
Play music
1. In Idle mode, press and
hold [ ] to turn on the
camera.
2. Press [ 1 ] to switch to
Record mode.
3. Press [ ] or [ ] to start
recording.
4. Press [ ], < >, or
[ ] to stop recording.
The video is saved
automatically.
5. Press < Preview > to
record another video.
1. In Idle mode, press
< Menu > and select File
manager → Videos →
Video clips .
2. Select the video you
want.
Record a
video
Play a video
Use these methods:
• Download from the
wireless web  p. 42
• Download from a
computer using the
optional Samsung PC
Studio  Samsung PC
Studio User’s Guide
• Receive via an active
Bluetooth connection
 p. 72
1. In Idle mode, press
< Menu > and select
Applications → Music
player .
2. Press < Options > and
select Add to playlist →
Add all or Add files .
Copy music
files to the
phone
Create a
play list

16
Listen to the FM radio
3. For Add files , press [ ]
to select the files you
want and press
< Select >.
4. Press < Back > to return
to the music player
screen.
1. From the music player
screen, press [ ].
2. During playback, use the
following keys:
• : pa u se s or r esu mes
playback.
• Left: returns to the
previous file.
• Right: skips to the
next file.
• Up: opens the play
list.
• / : adjusts the
volume.
• Down: stops
playback.
Create a
play list
(continued)
Play music
files
1. Plug the connector of the
supplied headset into the
jack on the right side of
the phone.
2. In Idle mode, press
< Menu > and select
Applications → FM
Radio .
3. Press [ ].
4. Press [Left] or [Right] to
find available radio
stations.
5. To turn off the radio,
press [ ] or disconnect
the headset from the
phone.
Listen to the
radio

Step outside the phone
17
Browse the web
Using a built-in web browser, you can easily
access to the wireless web to get a variety of
up-to-date services and information and to
enjoy downloads of web content.
1. From the station list on
the FM Radio screen,
press < Options > and
select Add .
2. Enter the frequency of
the station and press
< Save >.
3. Select a location in which
you want to store the
station.
Store a radio
station
In Idle mode, press [ ].
• To scroll through browser
items, press [Up] or
[Down].
• To select an item, press
[].
• To return to the previous
page, press [ C ].
• To access browser
options, press < Menu >.
Launch the
web browser
Navigate the
web

Step outside the phone
18
Use Phonebook
To the phone’s memory:
1. In Idle mode, enter a
phone number and press
< Options >.
2. Select Save contact →
Phone → a number type.
3. Specify contact
information: First name,
Last name, Mobile,
Home, Office, Fax, Other,
Email, Caller ID,
Ringtone, Group, and
Memo.
4. Press < Save > to save
the contact.
To th e SI M c ar d :
1. In Idle mode, enter a
phone number and press
< Options >.
2. Select Save contact →
SIM .
Add a
contact
3. Enter a name.
4. Press < Save > to save
the contact.
1. In Idle mode, press
< Contacts >.
2. Select a contact.
3. Scroll to a number and
press [ ] to dial, or
press [ ] to edit contact
information.
1. In Idle mode, press
< Menu > and select
Phonebook → My
namecard .
2. Specify your contact
information.
3. Press < Save > to save
the name card.
4. To send the name card,
press < Options > and
select Send via → a
sending method.
Find a
contact
Create and
send a name
card
